The growing request for more sustainable materials and environmentally friendly nanofabrication methods in the electronics field has recently driven the scientific community in the development of bio-derived materials as an alternative to conventional lithographic resists. In this work, we used chitosan, a biodegradable and biocompatible polysaccharide, as a green direct-write resist material for Atomic Force Microscopy-based nanolithography. Chitosan thin layers were obtained by spin coating and systematically characterized, in terms of thickness and surface roughness, demonstrating nanoscale smoothness and tunable film thickness. Three Pulse–Atomic Force Lithography (P-AFL) approaches, i.e., Constant Pulse, Gradient Pulse, and Raster Pulse AFL methods, were used to pattern nanostructures with constant-depth nanogrooves, variable-depth (2.5D) profile, and three-dimensional nanoholes on chitosan films. The results reveal high pattern fidelity, reproducibility, and tunability of feature dimensions as a function of applied force and scanning direction. Moreover, the RP-AFL technique enabled the fabrication of well-defined 3D nanostructures with depths matching the film thickness, which is a prerequisite for subsequent pattern transfer. This experimental work provided a first proof-of-concept to adopt chitosan as a more sustainable alternative with respect to conventional resists. Moreover, the results highlight P-AFL methods as a versatile and low-impact nanofabrication strategy, contributing to the development of greener micro- and nano-manufacturing technologies. Full article

Hybrid strategies that combine conventional top-down lithography with bottom-up molecular assembly are of interest for a range of applications including nanolithography and sensors. Interest in these strategies stems from the ability to create complex architectures over large areas with molecular-scale control and precision. The molecular-ruler process typifies this approach where the sequential layer-by-layer assembly of mercaptoalkanoic acid molecules and metal ions are combined with conventional top-down lithography to create precise, registered nanogaps. However, the quality of the metal-ligated mercaptoalkanoic acid multilayer is a critical characteristic in generating reproducible and robust nanoscale structures via the molecular-ruler process. Therefore, we explore the assembly of alkanethiolate monolayers, mercaptohexadecanoic acid (MHDA) monolayers, and Cu-ligated MHDA multilayers on Au{111} substrates using atomic force microscopy and in situ dynamic spectroscopic ellipsometry. The chemical film thicknesses in situ dynamic spectroscopic ellipsometry agree with previous ex situ surface analytical methods. Moreover, in situ dynamic spectroscopic ellipsometry provides insight into the assembly process without interrupting the assembly process and potentially altering the characteristics of the resulting chemical film. By following the real-time dynamics of each deposition step, the assembly of the Cu-ligated MHDA multilayers can be optimized to minimize deposition time while having minimal impact to the quality of the chemical film. Full article

Nowadays, mechanical AFM-based nanolithography has emerged as the most promising nanolithography technique, allowing the patterning of nanostructures on polymer layers with a sub-nanometer resolution. In such a stimulating context, we developed the Pulse-AFM method to obtain continuous structures with a controlled depth profile, either constant or variable, on a polymer layer. However, those nanostructures are contoured by polymer pile-ups that limit their integration into high-tech devices. Since pile-up removal is still an open challenge, AFM force–distance curve analysis was performed to characterize the stiffness of bulges, and an effective strategy to easily remove pile-ups while preserving the shape and morphology of nanostructures was then developed. Full article

The increasing use of nanomaterials in high-tech devices has posed an exciting challenge for the scientific community to develop new, easy, high-throughput nanofabrication approaches. Here, we present an easy AFM-based nanofabrication approach based on Static Plowing Lithography, with which we are able to realize patterns of 3D nanostructures on a thin PMMA layer. By coupling a wet etching process with ultrasound exposure, we effectively removed the polymer bulges at the nanostructure’s borders, increasing the quality of the patterned 3D nanostructures, and paving the way for their integration into lab-on-a-chip devices. Full article

This paper proposes two different approaches to studying resistive switching of oxide thin films using scratching probe nanolithography of atomic force microscopy (AFM). These approaches allow us to assess the effects of memristor size and top-contact thickness on resistive switching. For that purpose, we investigated scratching probe nanolithography regimes using the Taguchi method, which is known as a reliable method for improving the reliability of the result. The AFM parameters, including normal load, scratch distance, probe speed, and probe direction, are optimized on the photoresist thin film by the Taguchi method. As a result, the pinholes with diameter ranged from 25.4 ± 2.2 nm to 85.1 ± 6.3 nm, and the groove array with a depth of 40.5 ± 3.7 nm and a roughness at the bottom of less than a few nanometers was formed. Then, based on the Si/TiN/ZnO/photoresist structures, we fabricated and investigated memristors with different spot sizes and TiN top contact thickness. As a result, the HRS/LRS ratio, U_SET, and I_LRS are well controlled for a memristor size from 27 nm to 83 nm and ranged from ~8 to ~128, from 1.4 ± 0.1 V to 1.8 ± 0.2 V, and from (1.7 ± 0.2) × 10⁻¹⁰ A to (4.2 ± 0.6) × 10⁻⁹ A, respectively. Furthermore, the HRS/LRS ratio and U_SET are well controlled at a TiN top contact thickness from 8.3 ± 1.1 nm to 32.4 ± 4.2 nm and ranged from ~22 to ~188 and from 1.15 ± 0.05 V to 1.62 ± 0.06 V, respectively. The results can be used in the engineering and manufacturing of memristive structures for neuromorphic applications of brain-inspired artificial intelligence systems. Full article

Atomic force microscopy (AFM) in conjunction with microfluidic delivery was utilized to produce three-dimensional (3D) lipid structures following a custom design. While AFM is well-known for its spatial precision in imaging and 2D nanolithography, the development of AFM-based nanotechnology into 3D nanoprinting requires overcoming the technical challenges of controlling material delivery and interlayer registry. This work demonstrates the concept of 3D nanoprinting of amphiphilic molecules such as 1-palmitoyl-2-oleoyl-sn-glycero-3-phosphocholine (POPC). Various formulations of POPC solutions were tested to achieve point, line, and layer-by-layer material delivery. The produced structures include nanometer-thick disks, long linear spherical caps, stacking grids, and organizational chiral architectures. The POPC molecules formed stacking bilayers in these constructions, as revealed by high-resolution structural characterizations. The 3D printing reached nanometer spatial precision over a range of 0.5 mm. The outcomes reveal the promising potential of our designed technology and methodology in the production of 3D structures from nanometer to continuum, opening opportunities in biomaterial sciences and engineering, such as in the production of 3D nanodevices, chiral nanosensors, and scaffolds for tissue engineering and regeneration. Full article

In recent years, Atomic Force Microscope (AFM)-based nanolithography techniques have emerged as a very powerful approach for the machining of countless types of nanostructures. However, the conventional AFM-based nanolithography methods suffer from low efficiency, low rate of patterning, and high complexity of execution. In this frame, we first developed an easy and effective nanopatterning technique, termed Pulse-Atomic Force Lithography (P-AFL), with which we were able to pattern 2.5D nanogrooves on a thin polymer layer. Indeed, for the first time, we patterned nanogrooves with either constant or varying depth profiles, with sub-nanometre resolution, high accuracy, and reproducibility. In this paper, we present the results on the investigation of the effects of P-AFL parameters on 2.5D nanostructures’ morphology. We considered three main P-AFL parameters, i.e., the pulse’s amplitude (setpoint), the pulses’ width, and the distance between the following indentations (step), and we patterned arrays of grooves after a precise and well-established variation of the aforementioned parameters. Optimizing the nanolithography process, in terms of patterning time and nanostructures quality, we realized unconventional shape nanostructures with high accuracy and fidelity. Finally, a scanning electron microscope was used to confirm that P-AFL does not induce any damage on AFM tips used to pattern the nanostructures. Full article

In recent decades, great efforts have been made to develop innovative, effective, and accurate nanofabrication techniques stimulated by the growing demand for nanostructures. Nowadays, mechanical tip-based emerged as the most promising nanolithography technique, allowing the pattern of nanostructures with a sub-nanometer resolution, high reproducibility, and accuracy. Unfortunately, these nanostructures result in contoured pile-ups that could limit their use and future integration into high-tech devices. The removal of pile-ups is still an open challenge. In this perspective, two different AFM-based approaches, i.e., Force Modulation Mode imaging and force-distance curve analysis, were used to characterize the structure of pile-ups at the edges of nanogrooves patterned on PMMA substrate by means of Pulse-Atomic Force Lithography. Our experimental results showed that the material in pile-ups was less stiff than the pristine polymer. Based on this evidence, we have developed an effective strategy to easily remove pile-ups, preserving the shape and the morphology of nanostructures. Full article

The widespread use of nanotechnology in different application fields, resulting in the integration of nanostructures in a plethora of devices, has addressed the research toward novel and easy-to-setup nanofabrication techniques to realize nanostructures with high spatial resolution and reproducibility. Owing to countless applications in molecular electronics, data storage, nanoelectromechanical, and systems for the Internet of Things, in recent decades, the scientific community has focused on developing methods suitable for nanopattern polymers. To this purpose, Atomic Force Microscopy-based nanolithographic techniques are effective methods that are relatively less complex and inexpensive than equally resolute and accurate techniques, such as Electron Beam lithography and Focused Ion Beam lithography. In this work, we propose an evolution of nanoindentation, named Pulse-Atomic Force Microscopy, to obtain continuous structures with a controlled depth profile, either constant or variable, on a polymer layer. Due to the modulation of the characteristics of voltage pulses fed to the AFM piezo-scanner and distance between nanoindentations, it was possible to indent sample surface with high spatial control and fabricate highly resolved 2.5D nanogrooves. That is the real strength of the proposed technique, as no other technique can achieve similar results in tailor-made graded nanogrooves without the need for additional manufacturing steps. Full article

Silicon nanowire (SiNW) field-effect transistors (FETs) have been developed as very sensitive and label-free biomolecular sensors. The detection principle operating in a SiNW biosensor is indirect. The biomolecules are detected by measuring the changes in the current through the transistor. Those changes are produced by the electrical field created by the biomolecule. Here, we have combined nanolithography, chemical functionalization, electrical measurements and molecular recognition methods to correlate the current measured by the SiNW transistor with the presence of specific molecular recognition events on the surface of the SiNW. Oxidation scanning probe lithography (o-SPL) was applied to fabricate sub-12 nm SiNW field-effect transistors. The devices were applied to detect very small concentrations of proteins (500 pM). Atomic force microscopy (AFM) single-molecule force spectroscopy (SMFS) experiments allowed the identification of the protein adsorption sites on the surface of the nanowire. We detected specific interactions between the biotin-functionalized AFM tip and individual avidin molecules adsorbed to the SiNW. The measurements confirmed that electrical current changes measured by the device were associated with the deposition of avidin molecules. Full article

The bottom-up design of smart nanodevices largely depends on the accuracy by which each of the inherent nanometric components can be functionally designed with predictive methods. Here, we present a rationally designed, self-assembled nanochip capable of capturing a target protein by means of pre-selected binding sites. The sensing elements comprise computationally evolved peptides, designed to target an arbitrarily selected binding site on the surface of beta-2-Microglobulin (β2m), a globular protein that lacks well-defined pockets. The nanopatterned surface was generated by an atomic force microscopy (AFM)-based, tip force-driven nanolithography technique termed nanografting to construct laterally confined self-assembled nanopatches of single stranded (ss)DNA. These were subsequently associated with an ssDNA–peptide conjugate by means of DNA-directed immobilization, therefore allowing control of the peptide’s spatial orientation. We characterized the sensitivity of such peptide-containing systems against β2m in solution by means of AFM-based differential topographic imaging and surface plasmon resonance (SPR) spectroscopy. Our results show that the confined peptides are capable of specifically capturing β2m from the surface–liquid interface with micromolar affinity, hence providing a viable proof-of-concept for our approach to peptide design. Full article

We introduce a nanopipette/quartz tuning fork (QTF)–atomic force microscope (AFM) for nanolithography and a nanorod/QTF–AFM for nanoscratching with in situ detection of shear dynamics during performance. Capillary-condensed nanoscale water meniscus-mediated and electric field-assisted small-volume liquid ejection and nanolithography in ambient conditions are performed at a low bias voltage (~10 V) via a nanopipette/QTF–AFM. We produce and analyze Au nanoparticle-aggregated nanowire by using nanomeniscus-based particle stacking via a nanopipette/QTF–AFM. In addition, we perform a nanoscratching technique using in situ detection of the mechanical interactions of shear dynamics via a nanorod/QTF–AFM with force sensor capability and high sensitivity. Full article

While thermally reversible polymer network coatings based on the Diels-Alder reaction are widely studied, the mechanisms responsible for the heating-mediated healing of damage is still not well understood. The combination of microscopic evaluation techniques and fundamental insights for the thermoreversible network formation in the bulk and coating shed light on the mechanisms behind the damage healing events. The thermomechanical properties of thermoset and elastomer coatings, crosslinked by the furan-maleimide Diels-Alder cycloaddition reaction, were studied in bulk and compared to the thermal behaviour applied as coatings onto aluminium substrates. The damage sealing of thermoset (T_g = 79 °C) and elastomer (T_g = −49 °C) coatings were studied using nano-lithography and atomic force microscopy (AFM). The sealing event is studied and modelled at multiple temperatures and correlated to the changes in the network structure and corresponding thermomechanical properties. Full article

Solvent vapor annealing of block copolymer (BCP) thin films can produce a range of interesting morphologies, especially when the perpendicular orientation of micro-domains with respect to the substrate plays a role. This, for instance, allows BCP thin films to serve as useful templates for nanolithography and hybrid materials preparation. However, precise control of the arising morphologies is essential, but in most cases difficult to achieve. In this work, we investigated the solvent and thickness effects on the morphology of poly(styrene-b-2 vinyl pyridine) (PS-b-P2VP) thin films with a film thickness range from 0.4 L₀ up to 0.8 L₀. Ordered perpendicular structures were achieved. One of the main merits of our work is that the phase behavior of the ultra-high molecular weight BCP thin films, which hold a 100-nm sized domain distance, can be easily monitored via current available techniques, such as scanning electron microscope (SEM), atomic force microscope (AFM), and transmission electron microscope (TEM). Systematic monitoring of the self-assembly behavior during solvent vapor annealing can thus provide an experimental guideline for the optimization of processing conditions of related BCP films systems. Full article

A new in-process atomic-force microscopy (AFM) based inspection is presented for nanolithography to compensate for any deviation such as instantaneous degradation of the lithography probe tip. Traditional method used the AFM probes for lithography work and retract to inspect the obtained feature but this practice degrades the probe tip shape and hence, affects the measurement quality. This paper suggests a second dedicated lithography probe that is positioned back-to-back to the AFM probe under two synchronized controllers to correct any deviation in the process compared to specifications. This method shows that the quality improvement of the nanomachining, in progress probe tip wear, and better understanding of nanomachining. The system is hosted in a recently developed nanomanipulator for educational and research purposes. Full article
