Search Results (54)

This paper presents field investigations of a corrugated steel soil–steel arch structure with a span of 25.7 m and a rise of 9.0 m—currently the largest single-span structure of its kind in Europe. The structure, serving as a wildlife crossing along the DK16 expressway in northeastern Poland, was constructed using deep corrugated steel plates (500 mm× 237 mm) made from S315MC steel, without additional reinforcements such as stiffening ribs or geosynthetics. The study focused on monitoring the structural behavior during the critical backfilling phase. Displacements and strains were recorded using 34 electro-resistant strain gauges and a geodetic laser system at successive backfill levels, with particular attention to the loading stage at the crown. The measured results were compared with predictions based on the Swedish Design Method (SDM). The SDM equations did not accurately predict internal forces during backfilling. At the crown level, bending moments and axial forces were overestimated by approximately 69% and 152%, respectively. At the final backfill level, the SDM underestimated bending moments by 55% and overestimated axial forces by 90%. These findings highlight limitations of current design standards and emphasize the need for revised analytical models and long-term monitoring of large-span soil–steel structures. Full article

The shear tests are conducted on six precast segmental concrete beams (PSCBs) in this paper. A new specimen design scheme is presented to compare the effects of segmental joints on the shear performance of PSCBs. The failure modes, shear strength, structural deflection, stirrup strain, and tendon stress are recorded. The factors of shear span ratio, the position of segmental joints, and hybrid tendon ratio are focused on, and their effects on the shear behaviors are compared. Based on the measured responses, the shear contribution proportions of concrete segments, prestressed tendons, and stirrups are decomposed and quantified. With the observed failure modes, the truss–arch model is employed to clarify the shear mechanism of PSCBs, and simplified equations are further developed for predicting the shear strength. Using the collected test results of 30 specimens, the validity of the proposed equations is verified with a mean ratio of calculated-to-test values of 0.96 and a standard deviation of 0.11. Furthermore, the influence mechanism of shear span ratio, segmental joints, prestressing force, and hybrid tendon ratio on the shear strength is clarified. The increasing shear span ratio decreases the inclined angle of the arch ribs, thereby reducing the shear resistance contribution of the arch action. The open joints reduce the number of stirrups passing through the diagonal cracks, lowering the shear contribution of the truss action. The prestressing force can reduce the inclination of diagonal cracks, improving the contribution of truss action. The external unbonded tendon will decrease the height of the arch rib due to the second-order effects, causing lower shear strength than PSCBs with internal tendons. Full article

During the construction of large-span steel truss arch bridges, challenges such as complex control calculations, frequent adjustments of the cantilever structure, and deviations in the closure state often arise in the process of the assembly and closure of arch ribs. Based on the stress-free state control theory, this paper proposes a precise assembly control method for steel truss arch bridges, which takes the minimization of structural deformation energy and the maintenance of the stress-free dimensions of the closure wedge as the control objectives. By establishing a mathematical relationship between temporary buckle cables and the spatial position of the closure section, as well as adopting the influence matrix method and the quadprog function to determine the optimal parameters of temporary buckle cables (i.e., size, position, and orientation) conforming to actual construction constraints, the automatic approaching of bridge alignment to the target alignment can be achieved. Combined with the practical engineering case of Muping Xiangjiang River Bridge, a numerical calculation study of the precise assembly and closure of steel truss arch bridges was conducted. The calculated results demonstrate that, under the specified construction scheme, the proposed method can determine the optimal combination for temporary buckle cable tension. Considering the actual construction risk and the economic cost, the precise matching of closure joints can be achieved by selectively trimming the size of the closure wedge by a minimal amount. The calculated maximum stress of the structural rods in the construction process is 42% of the allowable value of steel, verifying the feasibility and practicality of the proposed method. The precise assembly method of steel truss arch bridges based on stress-free state control can significantly provide guidance and reference for the design and construction of bridges of this type. Full article

Aiming to address the problem of low efficiency in the traditional manual measurement of the main arch rib components of concrete-filled steel tube (CFST) arch bridges, this study proposes a digital measurement technology based on the integration of geometric parameters and computer-aided design (CAD) models. In this method, first, we perform the high-precision registration of the preprocessed scanned point cloud of the CFST arch rib components with the discretized design point cloud of the standardized CAD model. Then, in view of the fact that the fitting of point cloud geometric parameters is susceptible to the influence of sparse or uneven massive point clouds, these points are treated as outliers for elimination. We propose a method incorporating slicing to solve the interference of outliers and improve the fitting accuracy. Finally, the evaluation of quality, accuracy, and efficiency is carried out based on distance deviation analysis and geometric parameter comparison. The experimental results show that, for the experimental data, the fitting error of this method is reduced by 76.32% compared with the traditional method, which can improve the problems with measurement and fitting seen with the traditional method. At the same time, the measurement efficiency is increased by 5% compared with the traditional manual method. Full article

The multi-station registration of concrete-filled steel tubular (CFST) arch rib segments poses significant challenges due to structural complexity and environmental constraints during terrestrial laser scanning, requiring multi-angle acquisition for comprehensive coverage. This study introduces a cascaded registration framework comprising: (1) a coarse registration method utilizing local geometric features of segmented tubular joints, where equidistant cross-section partitioning extracts inherent circularity constraints from cylindrical segments, and (2) a refined registration stage employing the Coherent Point Drift (CPD) algorithm with k-d tree acceleration for computational efficiency. Experimental results demonstrate that the coarse registration achieves 31 mm RMSE with R²= 0.889, eliminating 88.9% of initial misalignment. The CPD refinement reduces RMSE to 4 mm (87% precision improvement), reaching sub-centimeter accuracy with exceptional congruence (R² = 0.995, residual error = 0.5%). Notably, k-d tree acceleration decreases computational time by 34.2% (13.30 s vs. 20.21 s) compared to conventional CPD. Validated on 2.2 m CFST specimens, this method provides an efficient solution for multi-station point cloud registration of complex steel structures. Full article

During the construction of concrete-filled steel tubular (CFST) arch bridges, hollow steel tube arch ribs are typically erected using the cantilever method with cable hoisting. In this construction stage, the arch ribs exhibit low out-of-plane stiffness and are thus highly susceptible to wind-induced vibrations, which may lead to cable failure or even collapse of the structure. Despite these critical risks, research on the aerodynamic performance of CFST arch ribs with different cross-sectional forms during cantilever construction remains limited. Most existing studies focus on individual bridge cases rather than generalized aerodynamic behavior. To obtain generalized aerodynamic parameters and buffeting response characteristics applicable to cantilevered CFST arch ribs, this study investigates two common cross-sectional configurations: four-tube trussed and horizontal dumbbell trussed sections. Sectional model wind tunnel tests were conducted to determine the aerodynamic force coefficients and aerodynamic admittance functions (AAFs) of these arch ribs. Comparisons with commonly used empirical AAF formulations (e.g., the Sears function) indicate that these simplified models, or assumptions equating aerodynamic forces with quasi-steady values, are inaccurate for the studied cross-sections. Considering the influence of the curved arch axis on buffeting behavior, a buffeting analysis computational program was developed, incorporating the experimentally derived aerodynamic characteristics. The program was validated against classical theoretical results and practical measurements from an actual bridge project. Using this program, a parametric analysis was conducted to evaluate the effects of equivalent AAF formulations, coherence functions, first-order mode shapes, and the number of structural modes on the buffeting response. The results show that the buffeting response of cantilevered hollow steel arch ribs is predominantly governed by the first-order mode, which can be effectively approximated using a bending-type mode shape expression. Full article

The behavior of long-span concrete-filled steel tube (CFST) arch bridges during the pouring stage is complex. The coupling effect of the time-varying hydration heat and the evolution of the elastic modulus is crucial for the linear control of the structure. Most of the existing models focus on static self-weight analysis but generally ignore the above-mentioned dynamic heat–force interaction, resulting in significant prediction deviations. In response to this limitation, this paper proposes an analysis method for the injection stage considering the time-varying heat of hydration and elastic modulus of concrete inside the pipe. Firstly, based on the composite index model of the hydration heat and through the reduction of the participating materials, the heat source function of the hydration heat of the arch rib was obtained, and its accuracy was verified by using two test components. Secondly, the equivalent application method of the hydration heat temperature field of the bar system model was proposed. Combined with the modified time-varying model of the elastic modulus at the initial age, the analysis method for the pouring stage of concrete-filled steel tube arch bridges was established. Finally, the accuracy of the proposed method was verified by analysis and calculation combined with engineering examples and comparison with the measured results. The results show that the time-varying heat of hydration and the time-varying elastic modulus during the concrete pouring stage inside the pipe can lead to residual deflection after the arch rib is poured. The calculated value of the example reaches 154 mm, while the influence of the lateral displacement is relatively small and recoverable. The proposed method improves the calculation accuracy by 44.19% compared with the traditional method, which is of great significance for the actual engineering construction control. Full article

During long-span arch bridge construction, repeated adjustments of large cantilevered segments and nonuniform cable tensions can lead to deviations from the desired arch profile, reducing structural efficiency and increasing labor and material costs. To precisely control the process of cable-stayed buckle construction in long-span arch bridges and achieve an optimal arch formation state, a constrained optimization for the buckle and anchor cable forces under one-time tension is developed in this paper. First, by considering the coupling effect of the cable-stayed buckle system with the buckle tower and arch rib structure, the control equations between the node displacement and cable force after tensioning are derived based on the influence matrix method. Then, taking the cable force size, arch rib closure joint alignment, upstream and downstream side arch rib alignment deviation, tower deviation, and the arch formation alignment displacement after loosening the cable as the constraint conditions, the residual sum of squares between the arch rib alignment and the target alignment during the construction stage is regarded as the optimization objective function, to solve the cable force of the buckle and anchor cables that satisfy the requirements of the expected alignment. Applied to a 310 m asymmetric steel truss arch bridge, the calculation of arch formation alignment is consistent with the ideal arch alignment, with the largest vertical displacement difference below 5 mm; the maximum error between the measured and theoretical cable forces during construction is 4.81%, the maximum difference between the measured and theoretical arch rib alignments after tensioning is 3.4 cm, and the maximum axial deviation of the arch rib is 5 cm. The results showed the following: the proposed optimization method can effectively control fluctuations of arch rib alignment, tower deviation, and cable force during construction to maintain the optimal arch shape and calculate the buckle and anchor cable forces at the same time, avoiding iterative calculations and simplifying the analysis process. Full article

Air ribs are the critical components of tents. Ten air ribs were designed to study the influence of rise–span ratios on load-bearing performance and explore the failure mechanism. According to the maximum stress that appears at the top and bending regions of the rib, the ribs can be divided into an upright region and an arc-like region. So, a segmentation failure competition mechanism was proposed. In order to enhance the bearing performance, the upright region and arc-like region should be designed to fail at the same time. For the rib named 0.333-S, the stress distributes uniformly and the critical load is 2.62 ${\mathrm{kN}/\mathrm{m}}^2$; the upright region and arc-like region fail at the same time. For the rib named 0.5-S/R, the critical load is 1.465 ${\mathrm{kN}/\mathrm{m}}^2$, and it fails at the upright region, resulting in a reduction of 44%. The tent with ribs named 0.333-S shows better resistance performance against wind load, and the end ribs of this tent deform less. Its maximum displacement is 0.112 m, which is reduced by 65.8% compared with that of the original upright arch tent. Full article

In view of the fact that the specification does not specify the calculation model for the temperature gradient of the concrete box-shaped arch rib without wing plates, and there is also a lack of relevant research on the temperature model of this type of arch rib, this paper carries out research on the impact of sunshine temperature on a section of concrete box arch rib without a flange plate based on the 355 m Shuiluohe Bridge. Firstly, a temperature experiment of the arch rib without flange plates was conducted. According to the experimental data, the temperature distribution and changing rules of the arch rib cross-section were analyzed. Then, according to the measured temperature data, a calculation mode of the vertical temperature gradient of the arch rib was proposed and compared with the specification. Finally, in view of the most disadvantageous phases of the arch rib in the construction process, the influence of different gradient modes on the structural mechanical behavior was analyzed by means of a simulation model. The results show that along the span from the springing to L/2, the maximal temperatures of the top plate, web plate and bottom plate gradually increase. The temperature gradient of the box’s top plate is the largest, that of the web plate is the second largest, and that of the bottom plate is the smallest. The vertical temperature difference of the key section of the arch rib gradually increases from the springing to L/2, and the maximal temperature difference of the section at L/2 is 16.3 °C, which is 4.2 °C higher than that of the springing section. The vertical temperature gradient proposed in this paper is a four-fold nonlinear model. Compared with the temperature gradient distribution range specified in the specification, the vertical temperature gradient in this article has a wider distribution range in the cross-section height, and the temperature varies more quickly along the cross-section height. The temperature gradient model proposed has more adverse effects on the mechanical behavior of the structure. The temperature gradient model proposed in this paper not only fills the gap in the specification but also provides suggestions for the design and construction of bridges. Meanwhile, the temperature distribution model of this type of arch rib also lays a theoretical foundation for the further development of corresponding thermal insulation materials for concrete surfaces or new concrete materials. Full article

In order to solve the problems of high production cost and complex control of the inverted arch of an unsupported prestressed concrete composite slab, a flange truss high-ductility concrete composite slab floor is proposed to change the structure and pouring material to meet the requirements of no support during construction. The crack distribution and bending performance of the flange truss high-ductile concrete composite slab floor (CRHDCS) under different structures are clarified through the test and numerical analysis of four different rib plate structure floors. According to the analysis results, the calculation formulas of the cracking moment and short-term stiffness before cracking are modified, and the equivalent short-term stiffness formula of a single web member of the “V” truss to this kind of bottom plate is established. The results show that, unlike the short-term stiffness-change law of typical concrete composite slabs after cracking, the short-term stiffness of the designed bottom plate in this paper includes a short-term increase stage. The numerical simulation results are the same as the experimental ones; the maximum error is 10%. The maximum errors between the modified cracking moment and the short-term stiffness calculation formula are 6% and 8%, respectively. The influence rates of removing flange plate, truss-inverted binding, and adding rib plate on the cracking bending moment of foundation structure are −81.5%, 11.0%, and 22.2% respectively, and the influence rates on short-term stiffness are −87.6%, −1.5%, and 37.5% respectively. Full article

The prevention of non-uniform corrosion in steel bridges remains a global challenge. Addressing this gap, the present study investigates atmospheric corrosion in steel bridges and introduces a non-uniform corrosion rate prediction process based on micro-environments, including the temperature and relative humidity of the air near the steel bridge surface (T_S and RH_S) and the deposition of pollutants on the steel bridge (D_P). Using a CFST arch bridge as a case study, this research examines the causes of non-uniform corrosion and explores effective protective measures. The findings reveal a maximum of 1.48 °C for the T_S and 15.7% for the RHs in different parts of the arch ribs. Significant disparities of the D_P are observed in different parts of the arch ribs. The largest D_P at the upper chord is up to 44.3 mg/m²/day (mdd), and the smallest amount of deposition at the lower chord is close to 0 mdd. Under the influence of the aforementioned factors, significant non-uniform corrosion of the ribs was found, with the fastest corrosion rate being up to 18.5 μm/year and the slowest corrosion rate being close to 0 μm/year. Uneven pollutant deposition is the primary cause of the non-uniform corrosion of the CFST arch bridge. By conducting the regular cleaning of the ribs, non-uniform corrosion could be mitigated. Full article

To address the issue of regional water resource scarcity, water diversion projects have been constructed worldwide. As an essential lifeline project, the prefabricated aqueduct is prevalently utilized in cross-regional water transfer and diversion projects. This paper was based on the prefabricated aqueduct project, which adopted fabricated technologies including the connection technology among the gravity pier, the prefabricated arch ribs, and the prefabricated bent frame columns. The PHC piles, bearing platforms, bent frame columns, arch ribs, and groove bodies were all prefabricated components that were transported to the site for installation. The connections of the prefabricated aqueduct employed to link different components were of such crucial significance that their safety and stability determined whether the overall structure would be compromised. Therefore, the main objective of this paper was to examine the stress and deformation of this prefabricated aqueduct to prevent the occurrence of security risks throughout the entire construction stage. The finite element model was established in Midas Civil, and the entire construction stage was simulated and analyzed. Coupled with on-site monitoring, the stress and deformation of the prefabricated aqueduct were evaluated. The results indicated that the tensile stress, the compressive stress, the vertical displacement, and the lateral displacement of each part of the prefabricated aqueduct met the requirements of the standard, suggesting that the overall structure with the applied connection technology was in a safe and stable state throughout the entire construction stage. Full article

The construction duration of long-span arch bridges is excessively prolonged due to insufficient closing precision and the non-convergence of traditional cable adjustment calculation methods. This study investigates cable force management in long-span concrete-filled steel tubular (CFST) arch bridges during cable-stayed buckle construction, aiming to improve construction safety and precision in arch rib alignment. Using the Pingnan Third Bridge and Tian’e Longtan Bridge as practical examples, the research develops a multi-objective optimization method for cable forces that integrates influence matrices, constrained minimization, and a forward iterative approach. This method offers a robust strategy for tensioning and cable-stayed buckling, enabling real-time monitoring, calculation, and adjustment during the construction of large-span CFST arch bridges. The results reveal that the iterative approach notably enhances calculation efficiency compared to conventional methods. For instance, field measurements at the Pingnan Third Bridge show a minimal arch closure error of only 3 mm. Additionally, the study addresses concerns about excessive stress in exposed steel tubes during concrete casting. By optimizing the sequence of main arch closure and concrete casting, stress in the exposed steel tube is reduced from 373 MPa to 316 MPa, thus meeting specification requirements. In summary, the multi-objective cable force optimization method demonstrates superior efficiency in determining cable tension and controlling rib alignment during cable-stayed buckle construction of long-span CFST arch bridges. Full article

When the arch rib of the mid-bearing through and lower-bearing through arch bridges undergoes out-of-plane deformation, it is usually subject to the resilience force provided by the flexible hanger, which is known as the “non-conservative force effect” of the suspender. In contrast to the static condition, in the dynamic scenario, the time-varying non-conservative force exerted by the flexible suspender becomes more complex due to dynamic changes in external load. Moreover, the difference in fundamental frequency and vibration period between the bridge system and arch rib may influence the stress distribution within the arch rib during ground motion. This paper investigates the impact of time-varying non-conservative forces on the dynamic stability of arch ribs in concrete-filled steel tube (CFST) bridges under seismic loads. Specifically, it examines the influence of different seismic waveforms, frequency disparities between bridge slabs and arch ribs, and suspender stiffness on the non-conservative effect. The results reveal significant disparities in the impact of non-conservative forces exerted by the suspender during seismic events with identical intensity but varying frequency characteristics. The influence of non-conservative forces on the dynamic stability of bridges escalates as deck stiffness increases, while it remains relatively unaffected by changes in suspender stiffness. Full article
