Search Results (55)

The electromechanical composite transmission technology for tracked vehicles demonstrates excellent performance in energy efficiency, mobility, and ride comfort. However, due to frequent operation under harsh conditions, the components of the electric drive system, such as drive motors, are prone to failures. This paper proposes three fault-tolerant control methods for three typical fault scenarios of the electromechanical composite transmission system (ECTS) to ensure the normal operation of tracked vehicles. Firstly, an ECTS and the electromechanical coupling dynamics model of the tracked vehicle are established. Moreover, a double-layer anti-windup PID control for motors and an instantaneous optimal control strategy for the engine are proposed in the fault-free case. Secondly, an anti-windup PID control law for motors and an engine control strategy considering the state of charge (SOC) and driving demands are developed in the case of single-side drive motor failure. Thirdly, a B4 clutch control strategy during starting and a steering brake control strategy are proposed in the case of electric drive system failure. Finally, in the straight-driving condition of the tracked vehicle, the throttle opening is set as 0.6, and the motor failure is triggered at 15 s during the acceleration process. Numerical simulations verify the fault-tolerant control strategies’ feasibility, using the tracked vehicle’s maximum speed and acceleration at 30 s as indicators for dynamic performance evaluation. The simulation results show that under single-motor fault, its straight-line driving power drops by 33.37%; with electric drive failure, the drop reaches 43.86%. The vehicle can still maintain normal straight-line driving and steering under fault conditions. Full article

This paper presents some of the most significant findings in the design of a hydraulic servomechanism for flight controls, which were primarily achieved by the first author during his activity in an aviation institute. These results are grouped into four main topics. The first one outlines a classical theory, from the 1950s–1970s, of the analysis of nonlinear automatic systems and namely the issue of absolute stability. The uninformed public may be misled by the adjective “absolute”. This is not a “maximalist” solution of stability but rather highlights in the system of equations a nonlinear function that describes, for the case of hydraulic servomechanisms, the flow-control dependence in the distributor spool. This function is odd, and it is therefore located in quadrants 1 and 3. The decision regarding stability is made within the so-called Lurie problem and is materialized by a matrix inequality, called the Lefschetz condition, which must be satisfied by the parameters of the electrohydraulic servomechanism and also by the components of the control feedback vector. Another approach starts from a classical theorem of V. M. Popov, extended in a stochastic framework by T. Morozan and I. Ursu, which ends with the description of the local and global spool valve flow-control characteristics that ensure stability in the large with respect to bounded perturbations for the mechano-hydraulic servomechanism. We add that a conjecture regarding the more pronounced flexibility of mathematical models in relation to mathematical instruments (theories) was used. Furthermore, the second topic concerns, the importance of the impedance characteristic of the mechano-hydraulic servomechanism in preventing flutter of the flight controls is emphasized. Impedance, also called dynamic stiffness, is defined as the ratio, in a dynamic regime, between the output exerted force (at the actuator rod of the servomechanism) and the displacement induced by this force under the assumption of a blocked input. It is demonstrated in the paper that there are two forms of the impedance function: one that favors the appearance of flutter and another that allows for flutter damping. It is interesting to note that these theoretical considerations were established in the institute’s reports some time before their introduction in the Aviation Regulation AvP.970. However, it was precisely the absence of the impedance criterion in the regulation at the appropriate time that ultimately led, by chance or not, to a disaster: the crash of a prototype due to tailplane flutter. A third topic shows how an important problem in the theory of automatic systems of the 1970s–1980s, namely the robust synthesis of the servomechanism, is formulated, applied and solved in the case of an electrohydraulic servomechanism. In general, the solution of a robust servomechanism problem consists of two distinct components: a servo-compensator, in fact an internal model of the exogenous dynamics, and a stabilizing compensator. These components are adapted in the case of an electrohydraulic servomechanism. In addition to the classical case mentioned above, a synthesis problem of an anti-windup (anti-saturation) compensator is formulated and solved. The fourth topic, and the last one presented in detail, is the synthesis of a fuzzy supervised neurocontrol (FSNC) for the position tracking of an electrohydraulic servomechanism, with experimental validation, in the laboratory, of this control law. The neurocontrol module is designed using a single-layered perceptron architecture. Neurocontrol is in principle optimal, but it is not free from saturation. To this end, in order to counteract saturation, a Mamdani-type fuzzy logic was developed, which takes control when neurocontrol has saturated. It returns to neurocontrol when it returns to normal, respectively, when saturation is eliminated. What distinguishes this FSNC law is its simplicity and efficiency and especially the fact that against quite a few opponents in the field, it still works very well on quite complicated physical systems. Finally, a brief section reviews some recent works by the authors, in which current approaches to hydraulic servomechanisms are presented: the backstepping control synthesis technique, input delay treated with Lyapunov–Krasovskii functionals, and critical stability treated with Lyapunov–Malkin theory. Full article

This paper proposes a Distributed Cooperative Algorithm (DCA) that solves the windup problem caused by the saturation of the Distributed Energy Resource (DER) PI-based control unit. If the reference reactive current output by the PI exceeds the maximum reactive power capacity of the DER, the control unit saturates, preventing the optimal voltage regulation at the connection node of the Active Distribution Network (ADN). Instead of relying on a centralized solution, we proposed a cooperative approach in which each DER’s control unit takes part in the DCA. If a control unit saturates, the voltage regulation error is not null, and the algorithm is activated to assign a share of this error to all DERs’ control units according to a weighted average principle. Subsequently, the algorithm determines the control unit’s new value of the voltage setpoint, desaturating the DER and enhancing the voltage profile. The proposed DCA is independent of the design of the control unit, does not require parameter tuning, exchanges only the regulation error at a low sampling rate, handles multiple saturations, and has limited communication requirements. The effectiveness of the proposed DCA is validated through numerical simulations of an ADN composed of two IEEE 13-bus Test Feeders. Full article

As an X–Y table has input saturation constraints or inadequate trajectory planning, the positioning control performance degrades. To overcome this issue, this study proposes an effective anti-integral windup approach based on basic PID control, and then plans a motion trajectory with an S-curve velocity profile to enhance the overall control performance. Finally, the corresponding experiments are conducted to assure the effectiveness of the control framework. The experimental results demonstrate that the proposed control scheme can greatly improve the system positioning precision compared to that without anti-windup when the X–Y table suffers from actuator saturations. Moreover, the corresponding results clearly showcase the superior tracking responses with errors of ±11.23 mm in the X-axis and ±13.63 mm in the Y-axis using the S-curve velocity profile for tracking errors, and ±13.48 mm in the X-axis and ±19.88 mm in the Y-axis applied to the T-curve velocity profile. It is validated and concluded that the proposed control scheme combined with trajectory planning can effectively mitigate integral windup and enhance the positioning precision with the smoother velocity as well as continuous acceleration profiles without vibration. Full article

Given the growing need to enhance the accuracy of exploration robots, this study focuses on designing a teleoperated navigation system for a robot equipped with a continuous-track traction system. The goal was to improve navigation performance by developing mathematical models that describe the robot’s behavior, which were validated through experimental measurements. The system incorporates a digital twin based on ROS (Robot Operating System) to configure the nodes responsible for teleoperated navigation. A PID controller is implemented for each motor, with zero-pole cancellation to achieve first-order dynamics, and anti-windup to prevent integral error accumulation when the reference is not met. Finally, a physical implementation was carried out to validate the functionality of the proposed navigation system. The results demonstrated that the system ensured precise and stable navigation, highlighting the effectiveness of the proposed approach in dynamic environments. This work contributes to advancing robotic navigation in controlled environments and offers potential for improving teleoperation systems in more complex scenarios. Full article

Real-world plants have various nonlinear characteristics such as friction and hysteresis, so nonlinear control is essential for precise control. In addition, actuators of plants have input constraints, which cause the integrator of the controller to windup. So far, anti-windup methods have mainly been for linear controllers, and research on nonlinear controllers has not been sufficient. This paper proposes a back-calculation anti-windup method for nonlinear controllers. By analyzing and extending the back-calculation anti-windup for a Proportional–Integral controller using operator theory, it can be applied to nonlinear controllers. The proposed method is applied to integral sliding mode control and right coprime factorization. In the simulation, we compared the proposed method with and without its application, as well as with conditional integration, and confirmed the effectiveness of the proposed method. In the future, it is necessary to extend the method to be applicable to more complex systems. This study has the potential to contribute to the practical application of nonlinear control. Full article

This study presents the design of an intelligent robust controller for the 3-degree-of-freedom motion of an aerial robot using waterpower. The proposed controller consists of two parts: (1) an anti-windup super-twisting algorithm that provides stability to the system under actuator saturation; and (2) a fully adaptive radial basis function neural network that estimates and compensates for unexpected influences, i.e., system uncertainties, water hose vibration, and external disturbances. The stability of the entire closed-loop system is analyzed using the Lyapunov stability theory. The controller parameters are optimized such that the effect of these unexpected influences on the control system is minimized. This optimization problem is interpreted in the form of an eigenvalue problem, which is solved using the method of centers. Experiments are conducted where a proportional-integral-derivative controller and a conventional sliding mode controller are deployed for comparison. The results demonstrate that the proposed control system outperforms the others, with small tracking errors and strong robustness against unexpected influences. Full article

This paper provides a comprehensive survey on advanced control techniques for Takagi-Sugeno (T-S) fuzzy systems that are subject to input and output performance constraints. The focus is on addressing practical applications, such as actuator saturation and output limits, which are often encountered in industries like aerospace, automotive, and robotics. The paper discusses key control methods such as model predictive control, anti-windup compensators, and Linear Matrix Inequality (LMI)-based control, emphasizing their effectiveness in handling input and output constraints. These techniques ensure system stability, robustness, and performance even under strict physical limitations. The survey also highlights the importance of T-S fuzzy systems, which provide a flexible framework for modeling and controlling nonlinear systems by breaking them down into simpler linear models. Additionally, recent developments in robust and adaptive control strategies are explored, particularly in handling time delays, disturbances, and uncertainties. These methods are crucial for real-time applications where the system must remain stable and safe despite unmeasured states or external disturbances. By reviewing these advanced techniques, the paper aims to identify research gaps and future directions, particularly in scalable solutions and integrating data-driven approaches with T-S fuzzy control frameworks. Full article

The present paper proposes a new Maximum Torque Per Ampere (MTPA) algorithm applied to sensorless speed control for the Synchronous Reluctance Machine (SynRM). The SynRM mathematical model is suitably modified and expressed in the γδ estimated reference frame, which could be applied in sensorless implementations. In the controller–observer scheme, an MTPA controller is coupled with a sliding mode observer (SMO) of first order. The provided equivalent control inputs are directly utilized by a modified EMF observer to estimate the rotor speed and position. Also, the MTPA control, SMO, and modified EMF observer are accordingly expressed in the γδ reference frame. In the duration of the SynRM operation, the developed MTPA algorithm succeeds in adjusting both stator current components in the γ-axis and δ-axis to the maximum torque point, while the SMO converges rapidly, achieving the coincidence between the γδ and dq reference frames. In addition, a simple torque decoupling technique is used to determine the γ-axis and δ-axis reference currents connected with the Anti-Windup Controller (AWC) for stator current control. Despite conventional MTPA methods, the proposed MTPA control strategy is designed to be robust in a wide speed range, exhibiting a high dynamic performance, regardless of the presence of external torque disturbances, reference speed variation, and even current measurement noise. The performance of the overall observer–control system is examined and evaluated using MATLAB/Simulink and considering noisy current feedback. Simulation results demonstrate the robustness and effectiveness of the proposed MTPA-based control method. Full article

Variable-Speed Hydropower Plants (VSHP) are becoming more promising for stabilising power grids with the increasing integration of renewable energy sources. This research focuses on improving fault ride-through capabilities and delivering efficient ancillary services for VSHPs to support the grid by developing a comprehensive control strategy. The control system proposed integrates a machine-side controller, a Frequency Support Controller (FSC), a Virtual Synchronous Machine (VSM), a Vector Current Controller (VCC) for the grid-side converter, a turbine governor for regulating turbine speed, and a DC-link controller. PID with an anti-windup scheme and a Model Predictive Controller (MPC) were employed for the turbine governor. The MPC turbine governor results demonstrate the potential of advanced control methods for enhanced performance of the VSHP. A benchmarking between the MPC and the PID governor was made. The benchmarking results have reported that the MPC can achieve reference tracking improvements up to $99.42\%$. Tests on a diverse set of grid scenarios were conducted, and the graphical results showed significant improvements in mitigating the frequency drops through the effective governor response. The synthetic inertia provision is swift, completing within seconds of a frequency drop. Compared to the fixed-speed approach, the VSHP improves the grid’s overall stability by minimising frequency dipping and achieving steady-state recovery remarkably faster. The fixed-speed approach only begins to recover minutes after the VSHP reaches the settling time. By effectively providing critical ancillary services such as frequency support, synthetic inertia, and smooth fault ride-through capability, the VSHP can become a transformative solution for future power grids, which are estimated to be more reliant on renewable energy sources. Full article

The windup phenomenon occurs and results in performance degradation while the designed positioning controller output makes actuators saturated. This study presents significant and effective anti-windup controllers for performance improvement and comparison of the position tracking. To address real-world industrial scenarios, the trajectory with a T-curve velocity profile is planned to regulate hardware limitations and maintain efficiency throughout the control process. At first, the dynamic model of an inertia load for a servo control system is established using Newton’s law of motion. Then, anti-windup controllers are designed and implemented based on basic PID controllers. The conducted simulations validate its effectiveness and feasibility. Finally, experimental results demonstrate that the proposed algorithms achieve smaller overshoot and faster settling time under input saturations when executing specific paths on the X-Y platform, even though the given control commands change. It is verified that the proposed approaches can, indeed, effectively mitigate the windup phenomenon, leading to improved positioning accuracy in industrial applications. Full article

This work studies the dynamic positioning (DP) control issue of unmanned surface vessels subjected to thruster saturation, error constraints, and lumped disturbances composed of time-varying marine environmental disturbances and model parameter uncertainties. Combining the disturbance-accurate estimation technique and the prescribed performance control strategy, a novel prescribed-time DP control scheme is established to address this challenging problem. In particular, the prescribed-time lumped disturbance observer is designed to accurately estimate external marine disturbances, which guarantees that the estimation error converges to zero within a prescribed time. Subsequently, a prescribed performance control strategy is proposed to guarantee that the positioning errors of DP surface vessels with thruster saturation constraints meet the error constraints requirements within a prescribed time. Furthermore, an anti-windup compensator is presented to mitigate the thruster saturation and improve the robustness of the DP control system. The stability analysis demonstrates that all positioning errors of the closed-loop system can converge to predefined performance constraints within a prescribed time. Finally, the numerical simulation confirms the efficacy and superiority of the proposed PTDP scheme. Full article

This contribution examines the control problem for very large wind energy converters during shutdown operation and analyses the most important control approaches. The control methods make use of the built-in conventional control infrastructure, but control system reconfigurations are undertaken in order to meet the demands of the shutdown control operation. Hence, the torque controller as well as the collective pitch controller (CPC) are redesigned from their regulator functions to reference tracking control systems with constraints. In addition, the CPC is combined with a feedforward controller in order to gain responsiveness. Constraints in magnitude and rate are managed by a modified anti-windup mechanism. Simulations of a 20 MW reference wind turbine verify the performance of the approaches. Full article

Power converters (PCs) are vital elements of critical applications, making their reliable operation crucial. Enhancing PCs’ reliability can be achieved by adding intelligence to the system, enabling it to predict failures and generate early warnings before a failure occurs. In this context, intelligence is integrated into the system through preventive diagnostic algorithms (PDAs) that assess the converter condition. This article introduces a PDA designed to determine the optimal replacement timing for aluminum electrolytic capacitors (AECs) within power converters. AECs, in addition to being a fundamental component of PCs, also represent the most vulnerable element of the PCs’ power section. The aging of AECs is characterized by a decrease in capacitance (C) and an increase in the equivalent series resistance (ESR). Therefore, ESR and C serve as key indicators for assessing the AECs’ health status. One of the most critical functional requirements for designing a PDA is its accuracy, which can be significantly affected by transients. The solution proposed in this paper is resilient to transients, overcoming a common problem in implementing AECs’ PDAs. The proposed algorithm employs discrete wavelet transform (DWT) to extract the converter signal modes. Subsequently, key characteristics of these modes are extracted, enabling the calculation of both ESR and C. Finally, by using the estimated ESR and C values, two fault indicators can be obtained that are resilient to transients. Employing a Kalman filter reduces noise and ensures the indicators’ resilience to transients, making them highly effective for evaluating the AECs’ health status. The proposed PDA was validated through multiple computer simulations conducted in MATLAB/Simulink for a three-phase interleaved boost converter (3ϕIBC), which includes a proportional-integral (PI) controller with anti-windup capability. Full article

This paper investigates an anticipatory activation anti-windup approach based on Linear Active Disturbance Rejection Control (LADRC) to address the influences of accelerated saturation on the actuators in a Miniaturized Inertial Stabilized Platform (MISP) with extreme external disturbance. The proposed method aims to eliminate the high-frequency vibrations on the Line of Sight (LOS) of electro-optical devices during actuator saturation. To achieve this, the Linear Extended State Observer (LESO) is modified by adding saturation feedback to the total disturbance observed state variable, which is operated as an anticipatory activation anti-windup compensator. The stability of the proposed controller is discussed, and the gains are optimized by the Linear Matrix Inequality (LMI) constraints though quadratic programming and an H-infinite performance indicator. Additionally, as the multiple activated scheme for anti-windup, the effectiveness of immediate activation in dealing with accelerated saturation is compared and analyzed. These comparisons and verification are implemented through simulations, where the external disturbance is introduced using recorded attitude data from USV sailing. Finally, experiments are conducted on an MISP for a visual tracking system, demonstrating that the anticipatory activation mothed effectively suppresses high-frequency vibrations on the LOS during instances of accelerated saturation. Full article
