Search Results (15)

Quasi-brittle structures modeled with softening constitutive laws may lose the uniqueness of equilibrium, producing bifurcation and multiple admissible crack evolutions even under symmetric loading. This paper develops a stability test and a constructive multiplicity procedure for finite element cracking analyses formulated as a Parametric Linear Complementarity Problem (PLCP) solved in tableau form. The approach exploits the pivot sequence of a complementary tableau to monitor stability by tracking the positive definiteness of the reduced active-mode Hessian $\widehat{\mathbf{A}}$ through a complement condition, without eigenvalue computations. A direct relationship between loss of positive definiteness and the sign of the incremental load factor $\Delta \dot{\mathsf{\alpha }}$ is established, providing an intrinsic indicator of transition to descending response. When degeneracy occurs, a “void pivot” mechanism is introduced to generate an alternative admissible tableau, enabling a systematic construction of multiple isolated solutions associated with competing crack patterns. The method is demonstrated on a two-notched direct tension specimen with cohesive softening, where symmetric and antisymmetric paths emerge at a critical step. The implementation is compatible with parallelized matrix operations and remains effective in the presence of non-holonomic constraints. Full article

This study employs physical experiments and the RFPA3D numerical method to investigate the fracture evolution of rocks containing a central hole with symmetrically arranged double cracks (seven inclination angles β) under biaxial compression. The results demonstrate that peak stress and strain exhibit nonlinear increases with rising β. Tensile–shear failure dominates at lower angles (β = 0–60°), characterized by secondary crack initiation at defect tips and wing/anti-wing crack development at intermediate angles (β = 45–60°). At higher angles (β = 75–90°), shear failure prevails, governed by crack propagation along hole walls. When β exceeds 45°, enhanced normal stress on crack planes suppresses mode II propagation and secondary crack formation. Elevated lateral pressures (15–20 MPa) significantly alter failure patterns by redirecting the maximum principal stress, causing cracks to align parallel to this orientation and driving anti-wing cracks toward specimen boundaries. Three-dimensional analysis reveals critical differences between internal and surface fracture propagation, highlighting how penetrating cracks around the hole crucially impact stability. This study provides valuable insights into complex fracture mechanisms in defective rock masses, offering practical guidance for stability assessment in underground mining operations where such composite defects commonly occur. Full article

Taking the tunnels crossing active faults in China’s Sichuan–Tibet Railway as the research background, experimental studies were conducted using a custom-developed split model box. The research focused on the cracking characteristics of the surrounding rock surface under the action of strike-slip faults, the progressive failure process of the tunnel model, and the mechanical response of the tunnel lining. In-depth analyses were performed on the tunnel damage mechanism under strike-slip fault action and the mitigation effects of combined anti-dislocation measures. The results indicate the following: Damage to the upper surface of the surrounding rock primarily occurs within the fault fracture zone. The split model box enables the graded transfer of fault displacement within this zone, improving the boundary conditions for the model test. Under a 50 mm fault displacement, the continuous tunnel experiences severe damage, leading to a complete loss of function. The damage is mainly characterized by circumferential shear and is concentrated within the fault fracture zone. The zone 20 cm to 30 cm on both sides of the fault plane is the primary area influenced by tunnel forces. The force distribution on the left and right sidewalls of the lining exhibits an anti-symmetric pattern across the fault plane. The left side wall is extruded by surrounding rock in the moving block, while the right side wall experiences extrusion from the surrounding rock in the fracture zone, and there is a phenomenon of dehollowing and loosening of the surrounding rock on both sides of the fault plane; the combination of anti-dislocation measures significantly enhances the tunnel’s stress state, reducing peak axial strain by 93% compared to a continuous tunnel. Furthermore, the extent and severity of tunnel damage are greatly diminished. The primary cause of lining segment damage is circumferential stress, with the main damage characterized by tensile cracking on both the inner and outer surfaces of the lining along the tunnel’s axial direction. Full article

First, a recently developed eigenfunction expansion technique, based in part on the separation of the thickness variable and partly utilizing a modified Frobenius-type series expansion technique in conjunction with the Eshelby–Stroh formalism, is employed to derive three-dimensional singular stress fields in the vicinity of the front of an interfacial crack weakening an infinite bicrystalline superlattice plate, made of orthorhombic (cubic, hexagonal, and tetragonal serving as special cases) phases of finite thickness and subjected to the far-field extension/bending, in-plane shear/twisting, and anti-plane shear loadings, distributed through the thickness. Crack-face boundary and interface contact conditions as well as those that are prescribed on the top and bottom surfaces of the bicrystalline superlattice plate are exactly satisfied. It also extends a recently developed concept of the lattice crack deflection (LCD) barrier to a superlattice, christened superlattice crack deflection (SCD) energy barrier for studying interfacial crack path instability, which can explain crack deflection from a difficult interface to an easier neighboring cleavage system. Additionally, the relationships of the nature (easy/easy, easy/difficult, or difficult/difficult) interfacial cleavage systems based on the present solutions with the structural chemistry aspects of the component phases (such as orthorhombic, tetragonal, hexagonal, as well as FCC (face-centered cubic) transition metals and perovskites) of the superlattice are also investigated. Finally, results pertaining to the through-thickness variations in mode I/II/III stress intensity factors and energy release rates for symmetric hyperbolic sine-distributed loads and their skew-symmetric counterparts that also satisfy the boundary conditions on the top and bottom surfaces of the bicrystalline superlattice plate under investigation also form an important part of the present investigation. Full article

The early detection of small cracks in large metal structures is a crucial requirement for the implementation of a structural health monitoring (SHM) system with a low transducers density. This work tackles the challenging problem of the early detection of submillimeter notch-type defects with a semielliptical shape and a groove at a constant width of 100 µm and 3 mm depth in a 4.1 mm thick aluminum plate. This defect is investigated with an ultrasonic guided wave (UGW) A₀ mode at 550 kHz to investigate the long range in thick metal plates. The mode selection is obtained by interdigital transducers (IDTs) designed to operate with a 5 mm central wavelength. The novel contribution is the validation of the detection by pulse-echo and pitch and catch with UGW transducers to cover a distance up to 70 cm to reduce the transducers density. The analysis of scattering from this submillimeter defect at different orientations is carried out using simulations with a Finite Element Model (FEM). The detection of the defect is obtained by comparing the scattered signals from the defect with baseline signals of the pristine laminate. Finally, the paper shows that the simulated results are in good agreement with the experimental ones, demonstrating the possible implementation in an SHM system based on the efficient propagation of an antisymmetric mode by IDTs. Full article

The buckling behavior of a functionally graded graphene-platelet-reinforced composite (FG-GPLRC) was traditionally investigated, mostly with respect to its undamaged structures. In this context, the current study investigated the buckling behavior of an FG-GPLRC cylindrical panel with an anti-symmetric central crack by introducing a 2-D extended natural element method (XNEM). The displacement was basically expressed with the first-order shear deformation theory (FSDT) and approximated using Laplace interpolation functions (for the non-singular displacement part) and crack-tip singular functions (for the singular displacement part) without grid refinement around the crack tips. The complex numerical manipulation on the curved shell surface was resolved by geometrically transforming the curved shell surface to a 2-D planar rectangular NEM grid. The painstaking numerical locking was suppressed by adopting the concept of a stabilized MITC3+ shell element. The validity of the developed numerical method was examined through a benchmark test, and the fundamental buckling loads of cracked FG-GPLRC cylindrical panels were investigated in depth by changing the major parameters. The numerical results also included a comparison with the FG-CNTRC. The numerical results indicated that the developed numerical method effectively predicts the buckling loads with reasonable accuracy, and that the fundamental buckling load of cracked FG-GPLRC cylindrical panels are remarkably influenced by the inclination angle and length of the crack as well as the other associated parameters. Full article

The mutual interactions of Lamb waves in nonlinear elastic plates are studied in this article. Many researchers have investigated the interactions of Lamb wave modes at nonlinear higher harmonics. However, little is known about nonlinearity-driven Lamb modulations from two primary modes with different frequencies. In this study, the existence of symmetric or antisymmetric mode due to Lamb wave mutual interactions is firstly theoretically formulated. Then, an approach is proposed to evaluate the intensity of phase velocity matching for selecting primary modes. Finally, the characteristics of the modulated wave generation are investigated and demonstrated. The generation of modulated waves in an aluminum plate and fatigue crack can be detected by mutual interactions of Lamb waves. The main contribution of this work is the proposed mutual interaction theory of Lamb waves in fatigue plates, which can guide fatigue detection in the metal plate. Full article

In view of the near-field seismic action, considering that oblique incidence of seismic waves is more realistic than vertical incidence, the seismic response of the Hong Kong–Zhuhai–Macao immersed tunnel subjected to an obliquely incident SV wave is investigated. Using the finite element method and time-domain wave method, the seismic input is transformed into an equivalent node load with a viscous–spring artificial boundary, and a three-dimensional simulation technology for SV waves of oblique incidence is presented. A half-space numerical example is given to demonstrate the accuracy of the proposed simulation technology. Taking the stress field formed by the self-weight stress and hydrostatic pressure as the initial state of the dynamic response analysis, the static–dynamic coupling numerical simulation of the seismic response of a soil-immersed tunnel system is realized. The results show that the amplification in the vertical and longitudinal response of the tunnel, due to the oblique incidence, reaches maximum when the incident angle is close to the critical angle. Furthermore, the horizontal response and incident angle show the inverse relation and tend to be stable. In addition, the oblique incidence also causes asymmetric shearing in symmetric parts of the tunnel. The root of the shear key easily produces tensile cracks, while the end angle of the shear key is prone to stress concentration and local damage. Thus, the impact of oblique incidence should be considered in the seismic design, and attention should be paid to the optimization of the end angle of the shear key and the configuration of anti-crack reinforcement at the root of shear key to meet the seismic requirements. Full article

The enhancement of the detection of weak signals against a strong noise background is a key problem in local gear fault diagnosis. Because the periodic impact signal generated by local gear damage is often modulated by high-frequency components, fault information is submerged in its envelope signal when demodulating the fault signal. However, the traditional bistable stochastic resonance (BSR) system cannot accurately match the asymmetric characteristics of the envelope signal because of its symmetrical potential well, which weakens the detection performance for weak faults. In order to overcome this problem, a novel method based on underdamped asymmetric periodic potential stochastic resonance (UAPPSR) is proposed to enhance the weak feature extraction of the local gear damage. The main advantage of this method is that it can better match the characteristics of the envelope signal by using the asymmetry of its potential well in the UAPPSR system and it can effectively enhance the extraction effect of periodic impact signals. Furthermore, the proposed method enjoys a good anti-noise capability and robustness and can strengthen weak fault characteristics under different noise levels. Thirdly, by reasonably adjusting the system parameters of the UAPPSR, the effective detection of input signals with different frequencies can be realized. Numerical simulations and experimental tests are performed on a gear with a local root crack, and the vibration signals are analyzed to validate the effectiveness of the proposed method. The comparison results show that the proposed method possesses a better resonance output effect and is more suitable for weak fault feature extraction under a strong noise background. Full article

Carbon fiber-reinforced polymer (CFRP) reinforcement technology has been widely used in the reinforcement of reinforced concrete (RC) beams. At this stage, high prestressed CFRP board reinforcement is often used in actual reinforcement. However, most reinforced bridges are designed for a long time, and the design value of the protective layer is low, and it is impossible to achieve a large prestressed tension. Therefore, this paper proposes the reverse-arch method to paste the CFRP board and apply low prestress to strengthen the symmetrical RC beam. Through the three-point forward loading test, the cracking load, ultimate load, crack width, mid-span deflection, strain and failure mode of a reverse-arch method-pasted CFRP board-reinforced beam, a directly pasted CFRP board-reinforced beam and an unreinforced beam are compared. The results show that the load-bearing capacity and stiffness of the test beam can be improved by pasting CFRP plates with anti-arch method, but the ductility of the test beam is reduced. Compared with the unreinforced beam, the maximum cracking load and ultimate load are increased by 56% and 63% respectively. The reverse-arch method can produce low prestress, improve the stiffness and bearing capacity of members, and has a good prospect of engineering application. Full article

This study investigates and evaluates the technology of using plate waves to detect the locations and sizes of circular holes and cracks in plates. Piezoelectric ceramic discs surface-mounted on both sides of an aluminum alloy plate were used as narrow-frequency plate wave actuators and sensors, and the antisymmetric plate wave signal was analyzed by wavelet transform in the time-frequency domain. The damage location and frequency spectrum characteristics were identified by the wave through time-of-flight difference and signal analysis of the damage scattered wave group. The plate wave signal of the damaged plate included the scattered wave signal and the plate wave signal transmitted directly between the piezoelectric discs. Under ideal conditions, the plate wave signal indicating damage can be obtained by subtracting the plate wave signal in a plate without damage from the plate wave signal scattered from actuators to sensors. This study established an optimization program based on the simplex algorithm to inversely calculate the location of the plate damage. The developed damage location objective function has a unique global minimum value that can ensure the accuracy of the damage location calculation, and good results were obtained in experiments. The spectral characteristics of the scattered plate wave were related to the type, size, wave propagation path, and incident angle of the damage. Numerical analyses of scattered spectra for various damages are needed as references to compare with experimental results in the future. Full article

The scattering phenomena of the fundamental antisymmetric Lamb wave mode with a horizontal notch enabling the partial energy transfer (PET) option is addressed in this paper. The PET functionality for a given waveguide is realized using the material interface. The energy scattering coefficients are identified using two methods, namely, a hybrid approach, which utilizes the finite element method (FEM) and the general orthogonality relation, and the semi-analytical approach, which combines the modal expansion technique with the orthogonal property of Lamb waves. Using the stress and displacement continuity conditions on the present (sub)waveguide interfaces, one can explicitly derive the global scattering matrix, which allows detailed analysis of the scattering process across the considered interfaces. Both methods are then adopted on a simple representation of a surface breaking crack in the form of a vertical notch, of which a certain section enables not only the reflection of the incident energy, but also its nonzero transfer. The presented results show very good conformity between both utilized approaches, thus leading to further development of an alternative technique. Full article

An experimental case study was carried out to investigate the shear performance of reinforced concrete beams with small circular openings under a cyclic anti-symmetric bending moment. The openings were strengthened by using a newly developed reinforcement continuously bent into rectangular and octagonal shapes, which was convenient for installation and effective for crack control. The presence of web opening reinforcement, the reinforcing method, and the web opening spacing were employed as main variables in the design of five specimens. The cyclic performance of all specimens was evaluated in terms of failure mode, crack pattern, strength and stiffness degradation, and strain distribution. Experimental results were discussed to assess the suitability of the proposed web opening reinforcement in RC web opening beams. It was confirmed that the proposed web opening reinforcement exhibited outstanding crack control and served as a shear resistance component in place of the concrete cross-section lost due to web openings. Finally, the shear strength of all specimens, obtained from the cyclic loading tests, were compared with those obtained from the equation proposed by Mansur (1998) and the Architectural Institute of Japan standard 2010. Full article

This paper focuses on the effects of transverse shear and root rotations in both symmetric and asymmetrical end-notched flexure (AENF) interlaminar fracture toughness tests. A theoretical model is developed, whereas the test specimen is subdivided into four regions joined by a rigid interface. The differential equations for the deflection and rotations of each region are solved within both the Euler–Bernoulli simple beam theory (SBT) and the more refined Timoshenko beam theory (TBT). A concise analytical equation is derived for the AENF deflection profile, compliance, and transverse shearing forces as a function of the specimen geometry, stacking sequence, delamination length, and fixture span. Modeling results are compared with numerical finite element analyses, obtaining a very good agreement. Performed analyses suggest that even in the case of symmetrical and unidirectional laminates considered as pure mode II fracture, a complex compression/tension and bending moment state is present, as well as a slight contribution of anti-planar shear at the vicinity of the crack tip. Full article

Software uses cryptography to provide confidentiality in communication and to provide authentication. Additionally, cryptographic algorithms can be used to protect software against cracking core algorithms in software implementation. Recently, malware and ransomware have begun to use encryption to protect their codes from analysis. As for the detection of cryptographic algorithms, previous works have had demerits in analyzing anti-reverse engineered binaries that can detect differences in analysis environments and normal execution. Here, we present a new symmetric-key cryptographic routine detection scheme using hardware tracing. In our experiments, patterns were successfully generated and detected for nine symmetric-key cryptographic algorithms. Additionally, the experimental results show that the false positive rate of our scheme is extremely low and the prototype implementation successfully bypasses anti-reversing techniques. Our work can be used to detect symmetric-key cryptographic routines in malware/ransomware with anti-reversing techniques. Full article
