This paper presents an optimized 868 MHz low-noise amplifier (LNA) based on a bipolar junction transistor (BJT), specifically designed for wake-up receivers operating in the sub-GHz band. The proposed LNA achieves low noise, high gain, and good impedance matching while consuming only $3.2$ mA from a $3.3$ V supply, resulting in a total power consumption of $10.56$ mW. Designing efficient sub-GHz LNAs for low-power applications involves a careful balance between multiple performance metrics. Higher gain typically requires increased biasing current, which can raise power consumption, while achieving a low noise figure often conflicts with input-matching constraints. The presented design addresses these trade-offs by leveraging the BFP740 BJT and employing a stub-based microstrip matching network to simultaneously optimize the gain, noise figure, and input–output matching. Simulation results, using both external lumped elements and microstrip techniques, show a forward gain ($S_{21}$) of $15.2$ dB at 868 MHz, with an input reflection coefficient ($S_{11}$) of $-6.9$ dB and an output reflection coefficient ($S_{22}$) of $-6.3$ dB. The amplifier achieves a minimum noise figure of approximately $1.77$ dB, which is notably low for this frequency band. These results demonstrate that the proposed LNA offers a compact, energy-efficient, and cost-effective solution, ideally suited for always-on, low-power wireless applications such as Internet of Things (IoT) devices and wireless sensor networks. Full article

Microsystems with capabilities of acoustic signal perception and recognition are widely used in unattended monitoring applications. In order to realize long-term and large-scale monitoring, microsystems with ultra-low power consumption are always required. Acoustic wake-up is one of the solutions to effectively reduce the power consumption of microsystems, especially for monitoring sparse events. This paper presents a review of acoustic wake-up technologies for microsystems. Acoustic sensing, acoustic recognition, and system working mode switching are the basis for constructing acoustic wake-up microsystems. First, state-of-the-art MEMS acoustic transducers suitable for acoustic wake-up microsystems are investigated, including MEMS microphones, MEMS hydrophones, and MEMS acoustic switches. Acoustic transducers with low power consumption, high sensitivity, low noise, and small size are attributes needed by the acoustic wake-up microsystem. Next, acoustic features and acoustic classification algorithms for target and event recognition are studied and summarized. More acoustic features and more computation are generally required to achieve better recognition performance while consuming more power. After that, four different system wake-up architectures are summarized. Acoustic wake-up microsystems with absolutely zero power consumption in sleep mode can be realized in the architecture of zero-power recognition and zero-power sleep. Applications of acoustic wake-up microsystems are then elaborated, which are closely related to scientific research and our daily life. Finally, challenges and future research directions of acoustic wake-up microsystems are elaborated. With breakthroughs in software and hardware technologies, acoustic wake-up microsystems can be deployed for ultra-long-term and ultra-large-scale use in various fields, and play important roles in the Internet of Things. Full article

The integration of wireless communication, e.g., in real- or quasi-real-time applications, is related to many challenges such as energy consumption, communication range, quality of service, and reliability. The improvement of wireless sensor networks (WSN) performance starts by enhancing the capabilities of each sensor node. To minimize latencies without increasing energy consumption, wake-up receiver (WuRx) nodes have been introduced in recent works since they can be always-on or power-gated with short latencies by a power consumption in the range of some microwatts. Compared to standard receiver technologies, they are usually characterized by drawbacks in terms of sensitivity. To overcome the limitation of the sensitivity of WuRxs, a design of a low noise amplifier (LNA) with several design specifications is required. The challenging task of the LNA design is to provide equitable trade-off performances such as gain, power consumption, the noise figure, stability, linearity, and impedance matching. The design of fast settling LNA for a duty-cycled WuRx front-end operating at a 868 MHz frequency band is investigated in this work. The paper details the trade-offs between design challenges and illustrates practical considerations for the simulation and implementation of a radio frequency (RF) circuit. The implemented LNA competes with many commercialized designs where it reaches single-stage 12 dB gain at a 1.8 V voltage supply and consumes only a 1.6 mA current. The obtained results could be made tunable by working with off-the-shelf components for different wake-up based application exigencies. Full article

The need to understand and manage our surroundings has led to increased interest in sensor networks for the continuous monitoring of events and processes of interest. To reduce the power consumption required for continuous monitoring, dedicated always-on wake-up detectors have been designed, with an emphasis on their low power consumption, simple and robust design, and reliable and accurate detection. An especially interesting application of these wake-up detectors is in detecting acoustic signals. In this paper, we present a study on the features and detectors applicable for the detection of sporadic acoustic events. We perform a state-of-the-art acoustic detector analysis, grouping the detectors based on the features they utilize and their implementations. This analysis shows that acoustic wake-up detectors predominantly utilize spectro-temporal (56%) and temporal features (36%). Following the state-of-the-art analysis, we select two detector architecture candidates for a case study on passing motor vehicle detection. We utilize our previously developed spectro-temporal decomposition detector and develop a novel level-crossing rate detector. The results of the case study shows that the proposed level-crossing rate detector has lower component count (44 compared to 70) and power consumption (9.1 µW compared to 34.6 µW) and is an optimal solution for SNRs over 0 dB. Full article

IEEE 802.11 consists of one of the most used wireless access technologies, which can be found in almost all consumer electronics devices available. Recently, Wake-up Radio (WuR) systems have emerged as a solution for energy-efficient communications. WuR mechanisms rely on using a secondary low-power radio interface that is always in the active operation mode and is in charge of switching the primary interface, used for main data exchange, from the power-saving state to the active mode. In this paper, we present a WuR solution based on IEEE 802.11 technology employing transmissions of legacy frames by an IEEE 802.11 standard-compliant transmitter during a Transmission Opportunity (TXOP) period. Unlike other proposals available in the literature, the WuR system presented in this paper exploits the PHY characteristics of modern IEEE 802.11 radios, where different signal bandwidths can be used on a per-packet basis. The proposal is validated through the Matlab software tool, and extensive simulation results are presented in a wide variety of scenario configurations. Moreover, insights are provided on the feasibility of the WuR proposal for its implementation in real hardware. Our approach allows the transmission of complex Wake-up Radio signals (i.e., including address field and other binary data) from legacy Wi-Fi devices (from IEEE 802.11n-2009 on), avoiding hardware or even firmware modifications intended to alter standard MAC/PHY behavior, and achieving a bit rate of up to 33 kbps. Full article

Cetacean monitoring is key to their protection. Understanding their behavior relies on multi-channel and high-sampling-rate underwater acoustic recordings for identifying and tracking them in a passive way. However, a lot of energy and data storage is required, requiring frequent human maintenance operations. To cope with these constraints, an ultra-low power mixed-signal always-on wake-up is proposed. Based on pulse-pattern analysis, it can be used for triggering a multi-channel high-performance recorder only when cetacean clicks are detected, thus increasing autonomy and saving storage space. This detector is implemented as a mixed architecture making the most of analog and digital primitives: this combination drastically improves power consumption by processing high-frequency data using analog features and lower-frequency ones in a digital way. Furthermore, a bioacoustic expert system is proposed for improving detection accuracy (in ultra-low-power) via state machines. Power consumption of the system is lower than 30 μW in always-on mode, allowing an autonomy of 2 years on a single CR2032 battery cell with a high detection accuracy. The receiver operating characteristic (ROC) curve obtained has an area under curve of $85\%$ using expert rules and $75\%$ without it. This implementation provides an excellent trade-off between detection accuracy and power consumption. Focused on sperm whales, it can be tuned to detect other species emitting pulse trains. This approach facilitates biodiversity studies, reducing maintenance operations and allowing the use of lighter, more compact and portable recording equipment, as large batteries are no longer required. Additionally, recording only useful data helps to reduce the dataset labeling time. Full article

This article presents a data-startable baseband logic featuring a gated oscillator clock and data recovery (GO-CDR) circuit for nanowatt wake-up and data receivers (WuRxs). At each data transition, the phase misalignment between the data coming from the analog front-end (AFE) and the clock is cleared by the GO-CDR circuit, thus allowing the reception of long data streams. Any free-running frequency mismatch between the GO and the bitrate does not limit the number of receivable bits, but only the maximum number of equal consecutive bits (N_m). To overcome this limitation, the proposed system includes a frequency calibration circuit, which reduces the frequency mismatch to ±0.5%, thus enabling the WuRx to be used with different encoding techniques up to N_m = 100. A full WuRx prototype, including an always-on clockless AFE operating in subthreshold, was fabricated with STMicroelectronics 90 nm BCD technology. The WuRx is supplied with 0.6 V, and the power consumption, excluding the calibration circuit, is 12.8 nW during the rest state and 17 nW at a 1 kbps data rate. With a 1 kbps On-Off Keying (OOK) modulated input and −35 dBm of input RF power after the input matching network (IMN), a 10⁻³ missed detection rate with a 0 bit error tolerance is measured, transmitting 63 bit packets with the N_m ranging from 1 to 63. The total sensitivity, including the estimated IMN gain at 100 MHz and 433 MHz, is −59.8 dBm and −52.3 dBm, respectively. In comparison with an ideal CDR, the degradation of the sensitivity due to the GO-CDR is 1.25 dBm. False alarm rate measurements lasting 24 h revealed zero overall false wake-ups. Full article

With the growth of the number of IoT devices, the need for changing batteries is becoming cumbersome and has a significant environmental impact. Therefore, batteryless and maintenance-free IoT solutions have emerged, where energy is harvested from the ambient environment. Energy harvesting is relevant mainly for the devices that have a low energy consumption in the range of thousands of micro-watts. Bluetooth Low Energy (BLE) is one of the most popular technologies and is highly suitable for such batteryless energy harvesting devices. Specifically, the BLE friendship feature allows a Low Power Node (LPN) to sleep most of the time. An associated friend node (FN) temporarily stores the LPN’s incoming data packets. The LPN wakes up and polls periodically to its FN retrieving the stored data. Unfortunately, the LPNs typically experience high downlink (DL) latency. To resolve the latency issue, we propose combining the batteryless LPN with a secondary ultra-low-power wake-up radio (WuR), which enables it to always listen for an incoming wake-up signal (WuS). The WuR allows the FN to notify the LPN when new DL data is available by sending a WuS. This removes the need for frequent polling by the LPN, and thus saves the little valuable energy available to the batteryless LPN. In this article, we compare the standard BLE duty-cycle based polling and WuR-based data communication between an FN and a batteryless energy-harvesting LPN. This study allows optimising the LPN configuration (such as capacitor size, polling interval) based on the packet arrival rate, desired packet delivery ratio and DL latency at different harvesting powers. The result shows that WuR-based communication performs best for high harvesting power (400 $\mathsf{\mu }$W and above) and supports Poisson packet arrival rates as low as 1 s with maximum PDR using a capacitor of 50 mF or more. Full article

IEEE 802.11 is one of the most commonly used radio access technologies, being present in almost all handheld devices with networking capabilities. However, its energy-hungry communication modes are a challenge for the increased battery lifetime of such devices and are an obstacle for its use in battery-constrained devices such as the ones defined by many Internet of Things applications. Wake-up Radio (WuR) systems have appeared as a solution for increasing the energy efficiency of communication technologies by employing a secondary low-power radio interface, which is always in the active state and switches the primary transceiver (used for main data communication) from the energy-saving to the active operation mode. The high market penetration of IEEE 802.11 technology, together with the benefits that WuR systems can bring to this widespread technology, motivates this article’s focus on IEEE 802.11-based WuR solutions. More specifically, we elaborate on the feasibility of such IEEE 802.11-based WuR solutions, and introduce the latest standardization efforts in this IEEE 802.11-based WuR domain, IEEE 802.11ba, which is a forthcoming IEEE 802.11 amendment, discussing its main features and potential use cases. As a use case consisting of green Wi-Fi application, we provide a proof-of-concept smart plug system implemented by a WuR that is activated remotely using IEEE 802.11 devices, evaluate its monetary and energy savings, and compare it with commercially available smart plug solutions. Finally, we discuss novel applications beyond the wake-up functionality that IEEE 802.11-enabled WuR devices can offer using a secondary radio, as well as applications that have not yet been considered by IEEE 802.11ba. As a result, we argue that the IEEE 802.11-based WuR solution will support a wide range of devices and deployments, for both low-rate and low-power communications, as well as high-rate transmissions. Full article

We present an always-on acoustic wake-up sensor interface, designed for prolonging the autonomy of energy-hungry hardware for underwater acoustic surveillance. Proposed design enables the detection of a passing ship by simultaneous listening up to three arbitrarily defined frequency-bands within the 2.5 kHz range, and generates a wake-up signal upon finding a match with a digitally preset template describing signal’s discriminatory time-frequency features. In this paper, we propose the architecture of such fully programmable, multichannel, mixed-signal wake- up circuit. We show the implementation of a PCB prototype, characterize its sensitivity, analyze its current consumption, and verify its response on real-world hydrophone recordings. It is demonstrated that the design consumes only 6.4 µA per channel (in total <20 µA) with ultra-low- power COTS components, while listening. Full article

Wireless sensor nodes are traditionally powered by individual batteries, and a significant effort has been devoted to maximizing the lifetime of these devices. However, as the batteries can only store a finite amount of energy, the network is still doomed to die, and changing the batteries is not always possible. A promising solution is to enable each node to harvest energy directly in its environment, using individual energy harvesters. Moreover, novel ultra-low power wake-up receivers, which allow continuous listening of the channel with negligible power consumption, are emerging. These devices enable asynchronous communication, further reducing the power consumption related to communication, which is typically one the most energy-consuming tasks in wireless sensor networks. Energy harvesting and wake-up receivers can be combined to significantly increase the energy efficiency of sensor networks. In this paper, we propose an energy manager for energy harvesting wireless sensor nodes and an asynchronous medium access control protocol, which exploits ultra-low power wake-up receivers. The two components are designed to work together and especially to fit the stringent constraints of wireless sensor nodes. The proposed approach has been implemented on a real hardware platform and tested in the field. Experimental results demonstrate the benefits of the proposed approach in terms of energy efficiency, power consumption and throughput, which can be up to more than two-times higher compared to traditional schemes. Full article

Energy harvester-integrated wireless devices are attractive for generating semi-permanent power from wasted energy in industrial environments. The energy-harvesting wireless devices may have difficulty in their communication with access points due to insufficient power supply for beacon recognition during network initialization. In this manuscript, we propose a novel method of beacon recognition based on wake-up control to reduce instantaneous power consumption in the initialization procedure. The proposed method applies a moving window for the periodic wake-up of the wireless devices. For unsynchronized wireless devices, beacons are always located in the same positions within each beacon interval even though the starting offsets are unknown. Using these characteristics, the moving window checks the existence of the beacon associated withspecified resources in a beacon interval, checks again for neighboring resources at the next beacon interval, and so on. This method can reduce instantaneous power and generates a surplus of charging time. Thus, the proposed method alleviates the problems of power insufficiency in the network initialization. The feasibility of the proposed method is evaluated using computer simulations of power shortage in various energy-harvesting conditions. Full article
