Search Results (36)

The development of technology has driven a rising need for high-accuracy and high-efficiency manufacturing of low-volume products. Incremental forming technology, characterized by die-free flexibility and low production costs, can effectively replace stamping processes for manufacturing customized small-batch products. However, high-performance aluminum alloys generally exhibit poor room-temperature plasticity but excellent high-temperature plasticity, necessitating the integration of thermal-assisted methods for manufacturing such products. However, the temperature of the forming region will excessively rise without temperature control, which will affect the forming performance of the material in hot incremental sheet forming of AA2024-T4 aluminum alloy. This study focuses on AA2024-T4 aluminum alloy and proposes a uniform temperature control method for the electric hot tube-assisted incremental sheet forming process, incorporating an adaptive fuzzy PID algorithm. The temperature difference of the forming region is lower than 6% under the various temperatures. On this basis, the forming limit angle and the microstructure state of the material are analyzed, and the grain feature of the material exhibits significantly refined grains and the uniform fine grain distribution under 180 °C with the temperature control of the adaptive fuzzy PID algorithm. Full article

This work investigates the role of friction in the numerical prediction of formability for ultra-thin aluminum sheets made of the EN AW 8006-O alloy. Nakazima-type hemispherical punch stretching tests were conducted under lubricated conditions to assess the influence of interface tribology on thickness distribution and failure behavior. The experimental activity included tensile testing for material parameter identification and coefficient of friction (COF) measurements according to ASTM D1894 to characterize interface friction. These parameters were then implemented into a finite element model developed in PAM-STAMP. The simulation results were compared with experimental thickness profiles, and showed good agreement when calibrated friction coefficients were used. The analysis highlights the sensitivity of sheet deformation to frictional conditions, and demonstrates that accurate tribological input significantly improves predictive accuracy. The proposed workflow offers a reliable and efficient methodology for simulating forming processes involving ultra-thin aluminum foils, with potential applications in the food packaging industry. Full article

Aluminum alloy hot stamping technology has quickly become a research hotspot for many scholars due to its ability to solve key challenges such as poor formability, large rebound, and low dimensional accuracy of aluminum alloy sheets at room temperature. This work systematically reviews the progress of Hot-Forming-Quenching (HFQ^®) technology and its optimization processes. The effects of key forming parameters are summarized, including temperature, forming rate, friction, and crimping force on the forming properties of aluminum alloys. Additionally, an ontological model of thermal deformation behavior and damage evolution during hot forming is analyzed. A multifactorial strength prediction model, integrating grain size and reinforcement mechanisms, is highlighted for its ability to accurately predict post-forming yield strength. To address the limitations of HFQ^®, optimization methods for solid solution and aging heat-treatment stages are categorized and evaluated, along with their advantages and disadvantages. Furthermore, the latest advancements in two innovative hot stamping processes (Low-Temperature Hot Form and Quench (LT-HFQ^®) and pre-hardened hot forming (PHF)) are reviewed. LT-HFQ^® improves formability by pre-cooling the sheet while maintaining solution treatment, while PHF utilizes pre-hardened aluminum alloys, enabling brief heating, forming, and quenching to significantly reduce cycle time while ensuring component strength. Finally, by summarizing current technological progress and challenges, future directions for aluminum alloy hot stamping are outlined, including advancements in forming processes, material modeling, and optimization through multidisciplinary collaboration and artificial intelligence to drive further innovation. Full article

Bistable microstructures are promising for implementation in many mictroelectromechanical system (MEMS)-based applications due to their ability to stay in several equilibrium states, high tunability and unprecedented sensitivity to external stimuli. As opposed to the extensively investigated one-dimensional curved beam-type devices of this kind, microfabrication of non-planar two-dimensional bistable structures, such as plates or shells, represents a remarkable challenge. Recently reported by us, a new moldless stamping procedure, based on pressing a soft stamp over a thin suspended metallic film, was demonstrated to be a feasible direction for the fabrication of initially curved micro plates. However, reliable implementation of this fabrication paradigm and its further development requires better understanding of the role of the process parameters, and of the effect of both the plate and the stamp material properties on the shape of the formed shell and on the postfabrication residual stresses, and therefore on the shell behavior. The need for an appropriate choice of these parameters requires the development of a systematic modeling approach to the stamping process. Here, we report on a finite element (FE)-based methodology for modeling the processing sequences of a successfully fabricated aluminum (Al) micro shell of realistic geometry. The model accounts for the elasto-plastic behavior of the plate material, the nonlinear material behavior of the foam and the contact between them. It was found that the stamping pressure and the plate material parameters are the key parameters affecting the residual shell curvature as well as its shape. Consistently with previously presented experimental results, we show that the fabrication procedure partially relieves the prestresses emerging during preceding fabrication steps, leaving a nontrivial distribution of residual stresses in the formed shell. The presented analysis approach and results provide tools for designers and manufacturers of systems including micro structural elements of shell type. Full article

The hot forming-quenching integrated process (HFQ^®) organically combines the deformation and heat treatment, which can improve the forming performance of aluminum alloy while ensuring the final strength of formed parts. Thermal deformation in HFQ^® has a non-negligible influence on precipitation behavior in subsequent artificial aging treatment and affects the mechanical properties of the formed parts. In this study, the relationship between the precipitation behavior and thermal deformation ratios was investigated. Results indicated that the formation temperatures of η′ and η decreased with an increasing deformation ratio; however, the former decreased more than the latter. The activation energy of η′ precipitation decreased linearly with increasing deformation ratio. Additionally, the phase transition fraction of η′ increased with the deformation ratio, leading to shorter times required to reach equivalent phase transition fractions. Deformation accelerated the phase transition of η′, and greater deformation resulted in a shorter transition time. The aging time required for peak Vickers hardness decreased with increasing deformation ratio, reflecting the promotion of precipitated phase formation and transformation by introduced dislocations. Consequently, peak hardness and yield strength were achieved in shorter aging times. In terms of industrial applications, this discovery offers significant advantages for shortening the production cycle of the hot stamping process and reducing production costs. Full article

In this research, the vibration damping characteristics of the laminated aluminum sheets (LAS) were evaluated in a sheet specimen and an automotive dash panel and compared with those of the monolithic aluminum sheet (MAS). The LAS was fabricated with two 5xxx series aluminum alloy (AA) sheets (AA5052-O) with a thickness of 0.7 mm by inserting an acryl-based adhesive in between. The automotive dash panels were manufactured by multi-step stamping processes for the LAS and the MAS with a similar thickness. The shaker vibration test in a sheet specimen and the impact hammer test in an automotive dash panel were conducted to measure the frequency response function (FRF) of LAS, compared with those of MAS. The results show that the frequency response function made by the LAS has less noise and fluctuation than that of the MAS in a sheet specimen and an automotive dash panel. The damping ratios in a sheet specimen and an automotive dash panel made by the LAS have higher values than those of the MAS. This proves that the LAS has better vibration damping characteristics and a larger damping effect than the MAS in a sheet specimen and an automotive dash panel. Full article

Deep drawing has been practiced in various manufacturing industries for many years. With the aid of stamping equipment, materials are sheared to different shapes and dimensions for users. Meanwhile, through artificial intelligence (AI) training, machines can make decisions or perform various functions. The aim of this study is to discuss the geometric and process parameters for A7075 in deep drawing and derive the formable regions of sound products for different forming parameters. Four parameters—forming temperature, punch speed, blank diameter and thickness—are used to investigate their effects on the forming results. Through finite element simulation, a database is established and used for machine learning (ML) training and validation to derive an AI prediction model. Importing the forming parameters into this prediction model can obtain the forming results rapidly. To validate the formable regions of sound products, several experiments are conducted and the results are compared with the prediction results to verify the feasibility of applying ML to deep drawing processes of aluminum alloy A7075 and the reliability of the AI prediction model. Full article

Concurrently improving the formability and post-formed strength of Al-Zn-Mg alloy sheets is crucial for producing high-strength parts with complex shapes. A novel process of aging warm-forming (AWF) to form solution heat-treated and water-quenched aluminum alloy sheets is proposed in this paper. The as-quenched AA 7075 sheet was first pre-aged and then formed at the desired temperature. The automotive paint–bake process was then utilized as the second aging step to achieve the target strength of the formed part. Additionally, the post-formed strength and warm formability of specimens under the AWF process conditions, as well as the warm-forming of various heat-treated Al-Zn-Mg alloy sheets proposed in previous studies, were compared through tensile and limit dome height tests. Precipitate characteristics of specimens subjected to different warm-forming process conditions were examined to understand their impact on warm formability. The warm formability of Al-Zn-Mg alloy sheets was significantly enhanced, and the post-formed strength achieved was more than 90% of the strength of as-received AA 7075-T6 sheets under the AWF process condition. The results demonstrated the feasibility of this novel AWF process to manufacture Al-Zn-Mg alloy stamped parts for improved spring-back, formability, and good overall post-formed strength. The results also indicate that microstructural characteristics in Al-Zn-Mg alloy sheets under different warm-forming process conditions have a noticeable influence on warm formability and final mechanical properties. Full article

Hot stamping (or press hardening) is a new technology that is widely used in the production of advanced high-strength steel parts for automotive applications. Electrochemical measurements, including potentiodynamic polarization and electrochemical impedance spectroscopy (EIS), and accelerated corrosion tests (the neutral salt spray test and periodic immersion test) were conducted on press-hardened samples produced from uncoated (cold-rolled and cold strip production (CSP) hot-rolled) and Al–Si-coated press-hardened steels to elucidate their distinct anti-corrosion mechanisms. The cross-sectional micromorphology and element distribution of three types of press-hardened steels after a neutral salt spray test were observed using scanning electron microscopy (SEM) and energy-dispersive X-ray analysis (EDAX). The corrosion resistance of Al–Si-coated press-hardened steel was found to be significantly diminished following the hot stamping process due to the presence of microcracks and elevated iron content in the coating subsequent to austenitizing heat treatment. On the other hand, the corrosion resistance of uncoated press-hardened sheets produced from cold-rolled and CSP hot-rolled press-hardened steel was found to be proximal due to their nearly identical composition and microstructure (fully martensite) after the hot stamping process. Considering the high efficiency and energy-saving properties of hot-rolled press-hardened steel, it holds the potential to replace cold-rolled and even aluminum–silicon-coated press-hardened steel in automobile manufacturing. Full article

Tailoring the properties of hot-stamped components offers the potential to enhance crash performance while simultaneously improving downstream joining processes. In recent years, an innovative technology suited for achieving tailored properties involving the utilization of a specialized furnace chamber, known as the TemperBox^®, has been introduced. Within this chamber, a cooled aluminum mask shields specific areas of the blank from incoming heat radiation and concurrently absorbs the blank’s own radiation. The duration of the heat radiation exchange can influence the diffusion-dependent phase transformation and, consequently, the resulting mechanical properties. Hence, the intermediate cooling duration assumes a pivotal role as a parameter, as is investigated in this study. To examine the effects, specimens of the steel 22MnB5 AS150 are subjected to intermediate cooling of varying durations, followed by forming and partial quenching. The temperature profile of the blank during intermediate cooling prior to forming and quenching is analyzed. Subsequently, the tailored hot-stamped components are assessed for hardness, strength, ductility, and thickness strain. The study reveals that with increasing duration of partial intermediate cooling and targeted radiation exchange, a homogeneous ferritic–pearlitic structure is formed from an austenitic structure. This uniform structure of ferrite and pearlite is reflected in lower hardness and strength values, along with improved ductility. Additionally, this paper introduces a simulation methodology designed to calculate the dynamics of thermal radiation and the kinetics of phase transformation. Full article

The present work introduces a laser-induced cavitation bubble technique for forming an axisymmetric structure (i.e., microgroove) and the dynamics of a cavitation bubble from initial expansion to the collapse stages that were also simulated. Furthermore, the shock wave signals and dynamic properties of the cavitation bubble were recorded using a hydrophone and a high-speed camera. The experiments on microgrooves formed by laser-induced cavitation bubble stamping were carried out, and the effects of laser energy, the initial position of the bubble, and the number of impacts on the microformability of aluminum sheets are discussed. The depth of the microgroove was investigated using experiments, and it was found that the process can serve as a rapid technique for impressing microfeatures on thin-sheet metals. The experimental results showed that as the initial position of the bubble increased, the deformation depth decreased. As the laser energy and number of impacts increased, the deformation depth increased. The results of the response surface experiments showed that a laser energy of 27 mJ, 3 impacts, and a bubble position of 3 mm were optimal for the process. By using the optimal parameters, flat and smooth microgrooves with a forming depth of 102.54 µm were successfully fabricated. Furthermore, the maximum thickness thinning of the microgroove section occurred at the entrance areas, and this area had the greatest hardness. This also indicated that the greatest amount of plastic deformation of the material and grain refinement occurred in this area. On the other hand, the aluminum foil did not undergo oxidation during the plastic deformation process. These results demonstrated that laser-induced bubble stamping is an advanced micromachining method with promising applications. Full article

In this study, 220 AA7075-T6 B-pillars were fabricated using a thoroughly instrumented hot-stamping press under varied conditions. Feature engineering work identified nineteen attributes of the hot-stamping process as impacting four characteristics of the obtained B-pillars: electrical conductivity (%IACS), mechanical strength, distortion, and the presence of visible defects. Pearson correlation suggests an important correlation between the heating phase and the mechanical strength, as well as the %IACS values. As for distortion, the influence of the stamping phase is more obvious. Finally, no correlation was obtained between the hot stamping attributes and the presence of visible cracks. This is mainly due to the pre-assembly phase, i.e., Friction Stir Welding, which will be considered in future works. Full article

This article investigates the impact of temperature regimes, corresponding to various climatic zones, on the manufacturing process and operation of beverage can ends made of aluminum alloy AA5182. The production process of aluminum beverage can ends involves multiple steps, including melting, rolling, and stamping, where different temperatures can influence both the production process and the properties of the final product. Furthermore, the mechanical behavior of the final product is affected by the aging process of alloy AA5182, which progresses at varying rates depending on the temperature conditions during storage. The objective of this study is to simulate the production process under various climatic conditions using the finite element method (FEM) and experimentally investigate the dependence of the strength of alloy AA5182 can ends on storage time and temperature. The findings of the study reveal that, under temperature conditions corresponding to warmer climates, the punching force can be reduced by approximately 15% compared to production in colder climates. Additionally, the strength of the finished can exhibits a decrease of about 10% during a month of storage in a warm climate, while no significant decrease was observed in colder climates. These results hold practical significance for the beverage production industry, as the manufacturing and operation of beverage cans are localized in diverse climatic zones. Full article

In the forming process of fiber-reinforced metal laminates (FMLs) product, the exploratory compound forming technology, including hot stamping of aluminum alloy and laying process of fiber prepreg which is named HFQ-FMLs was proposed to solve the puzzles such as weak rigidity, low strength and integration deformation with large difficulty, and the feasibility and mechanical properties of the innovative forming process were studied. Firstly, based on the modified metal volume fraction formula, the theoretical values of the mechanical properties of the HFQ-FMLs plates were calculated. Compared with the experimental results, the minimum error is 1%, proving that the HFQ-FMLs technology scheme is feasible. Secondly, three kinds of metal sheets with different heat treatments and specimens by HFQ-FMLs were carried out for the tensile tests, the mechanical properties distributions were demonstrated, and the influence regularity of the strain rate and rolling direction on the stress analysis was considered at the same time. As can be seen from the distribution of yield strength and tensile strength, the yield stress of metal sheets obtained by HFQ-FMLs technology along the 45° is superior to the raw material and can increase by 46% under strain rate = 0.01 s⁻¹. While, because the vacuum thermal curing treatment makes the aluminum alloy happen double aging, the metal sheet strength dropped, and the jointing strength between the metal and fiber prepreg became weak too, which made the strength limit of the new material improve weakly. Thirdly, the fractured style of the FMLs under different conditions was studied qualitatively. It is helpful to achieve the development rule of defects, optimize the craft route, and avoid deformation failure. Full article

Friction during contact between metals can be very complex in pulse current-assisted forming. Based on stamping process characteristics, a reciprocating friction tester was designed to study the friction characteristics between AA7075 aluminum alloy and P20 steel under different current densities. Origin software was used to process the experimental data, and a current friction coefficient model was established for the pulse current densities. The results show that the friction coefficient of the aluminum alloy sheet decreased with the increase in the pulse current density (2–10 A/mm²). After that, the friction mechanism was determined by observing microscopic morphology and SEM: some oxide cracked on the friction surface when the current was large. Finally, finite element simulations with Abaqus software and a cylindrical case validated the constant and current friction coefficient models. The thickness distribution patterns of the fixed friction coefficient and the current coefficient model were compared with an actual cylindrical drawing part. The results indicate that the new current friction model had a better fit than the fixed one. The simulation results are consistent with the actual verification results. The maximum thinning was at the corner of the stamping die, which improved the simulation accuracy by 7.31%. This indicates the effectiveness of the pulse current friction model. Full article
