Although cemented carbides have been manufactured by the powder metallurgy (P/M) technology for over a century now, systematic developmental efforts are still underway. In the present study, tool life improvements in metal grooving applications are the key objective. Four PVD-coated cemented carbides compositions, dedicated to groove steel, stainless steel, cast iron, and aluminium alloys, have been newly designed, along with their manufacturing conditions. Physical, mechanical and chemical characteristics—such as sintered density, modulus of elasticity, hardness, fracture toughness, WC grain size, and the chemical composition of the substrate material, as well as the chemical composition, microhardness, structure, and thickness of the coatings—have been studied. A series of grooving tests have also been conducted to assess whether modifications to the thus far marketed tool materials, tool geometries, and coatings can improve cutting performance. In order to compare the laboratory and application properties of the investigated materials with currently produced by reputable companies, commercial inserts have also been tested. The experimental results obtained indicate that the newly developed grooving inserts exhibit excellent microstructural characteristics, high hardness, fracture toughness, and wear resistance and that they show slightly longer tool life compared to the commercial ones. Full article

Thermal barrier coatings (TBCs) are effective protective and insulative coatings on hot section components of turbine engines. The quality and subsequent performance of the TBCs are strongly dependent on the adhesion between the coating and the metal substrate. The adhesion strength of TBCs varies depending on the substrate materials and coating, the coating technique used, the coating application parameters, the substrate surface treatments, and environmental conditions. Therefore, the roughness of the substrate surface has a significant effect on the performance of the TBC system. In this work, the roughness and microstructure of the 7YSZ (7 wt.% yttria-stabilised zirconia) top coat under different bond coat roughness treatments were studied. The purpose of this paper was to investigate the influence of the roughness of the bond coat on the adhesion of 7YSZ TBCs prepared by the electron beam–physical vapour deposition (EB-PVD) process. The VPA (vapour phase aluminium) bond coat was deposited on Inconel 718 nickel superalloy substrate using the above-the-pack technique. The ceramic top coat was applied to the bond coat using the EB-PVD process. The dependence between the TBC coating roughness and the bond coat roughness was determined. Adhesion strength measurements were performed according to the ASTM C 633 standard test method. The highest adhesion value observed in the tensile adhesion tests was 105 MPa. However, it was not determined whether the surface roughness of the bond coat affects the adhesion of the 7YSZ top coat. Full article

This study investigates the mechanical properties, surface integrity, and chemical configuration of PVD-coated high-speed steel (HSS) cutting tools, with a particular focus on titanium nitride (TiN) and titanium aluminium nitride (TiAlN) coatings. A range of characterisation methodologies were employed to examine the impact of pre-coating surface conditions on the resulting coatings. This impact includes the effects of gas bubble production and unequal distribution of elements, which are two unwanted occurrences. Notwithstanding these difficulties, coatings applied on surfaces that were highly polished exhibited more consistency in their mechanical and elemental characteristics, with a thickness ranging from 2 to 4 µm. The study of mechanical characteristics confirms a significant increase in hardness, from an initial value of roughly 1000 HV0.5 for untreated tools to 1300 HV0.5 for tools with physical vapour deposition (PVD) coatings. Although PVD coatings produced on an industrial scale might not exceed the quality of coatings manufactured in a laboratory, they do offer substantial enhancements in terms of hardness. This study highlights the significant importance of thorough surface preparation in achieving enhanced coating performance, hence contributing to the efforts to prolong the lifespan of tools and enhance their performance even under demanding operational circumstances. Full article

The field of protective coatings for industrial applications is continuously evolving, driven by a need for materials that offer exceptional hardness, enhanced wear resistance, and low friction coefficients. Conventional methods of coating development, such as physical vapour deposition (PVD) and chemical vapour deposition (CVD), often face challenges like the necessity of vacuum conditions, slow growth rates, and weak substrate adhesion, leading to inadequate interface bonding. This study introduces a novel approach utilising an integrated laser/sol–gel method for synthesising aluminium nitride (AlN) coatings on EN43 mild steel substrates which overcomes these limitations. The technique employs a high-intensity diode laser with optimal power and translation speeds to consolidate a pre-applied thin layer of sol–gel slurry consisting of aluminium hydroxide, graphite, and urea on the substrate. Chemical thermodynamic calculations were used to predict the slurry composition, along with identifying the critical temperature range and the essential enthalpy needed for the synthesis of aluminium nitride. A three-dimensional heat transfer model was developed to predict the important process parameters, such as scanning speed and laser power density, required to achieve the temperature ranges necessary for a successful deposition process. Optical and scanning electron microscopy techniques were used to examine the surface morphology and microstructure of the coating. Elemental energy-dispersive X-ray spectroscopy and an X-ray diffraction analysis confirmed the synthesis of an aluminium nitride coating with a thickness ranging from 4 to 5 µm. Furthermore, the detection of sub-micron crystalline aluminium nitride structures yielding a metal matrix composite interlayer was indicative of strong metallurgical bonding. Microhardness testing indicated a hardness value of approximately 876 HV. The coated samples with the highest quality exhibited a surface roughness, Ra, ranging from 1.8 to 2.1 µm. Additionally, the coatings demonstrated an exceptionally low coefficient of friction, recorded at less than 0.1. These results represent a significant step forward in this field, offering a cost-effective, efficient, and scalable solution for producing high-quality coatings with superior performance characteristics. Full article

This paper presents the results of research focused on increasing the lifespan of HPDC moulds for casting aluminium alloys by applying duplex PVD coatings in combination with laser texturing the base material before the coatings’ deposition. This article describes the HPDC process and the degradation mechanisms of the moulds that arose during this process. The PVD nanostructured coatings utilised, the methods of their deposition, and the evaluation of their wear resistance are defined in this paper. The surface texturing process is described alongside the description of the analysis of the wear of the functional parts of the mould after decommissioning, which was carried out by visual inspection and optical and light microscopy. Three types of PVD duplex coatings were analysed during our study. The coatings were deposited using the LARC technology method (lateral rotating cathode). Subsequently, the procedure of laser texturing in the form of dimple textures using a laser was proposed. The quality of the coatings was evaluated under tribological conditions by means of the “Ball on disc” method. Based on the experimental results, recommendations for practice are established. Full article

This study presents a comprehensive analysis of different coating materials on the POM substrate. Specifically, it investigated physical vapour deposition (PVD) coatings of aluminium (Al), chromium (Cr), and chromium nitride (CrN) of three various thicknesses. The deposition of Al was accomplished through a three-step process, particularly plasma activation, metallisation of Al by magnetron sputtering, and plasma polymerisation. The deposition of Cr was attained using the magnetron sputtering technique in a single step. For the deposition of CrN, a two-step process was employed. The first step involved the metallisation of Cr using magnetron sputtering, while the second step involved the vapour deposition of CrN, obtained through the reactive metallisation of Cr and nitrogen using magnetron sputtering. The focus of the research was to conduct comprehensive indentation tests to obtain the surface hardness of the analysed multilayer coatings, SEM analyses to examine surface morphology, and thorough adhesion analyses between the POM substrate and the appropriate PVD coating. Full article

A comprehensive experimental investigation of the noise evaluation of coated spur polymer gears made of POM was performed in this study. The three Physical Vapour Deposition (PVD) coatings investigated were aluminium (Al), chromium (Cr), and chromium nitrite (CrN). The gears were tested on an in-house-developed testing machine under a torque of 20 Nm and at a rotational speed of 1000 rpm. The noise measurements were performed with the tested gear pair on the testing device with a sound-proof acoustic foam used for the acoustic sound-proof insulation. The sound signal was analysed in time, frequency, and time–frequency domains and typical phenomena were identified in the signal. Experimental results showed that the noise level was higher for polymer gears with different coatings if compared to the polymer gears without coatings. With sound analysis in the time–frequency domain, precise degradation of the coatings could be noticed. In future studies, it would be appropriate to use a new method for signal analysis, e.g., high-order statistics and hybrid technique. Full article

H-13 steel surface was duplex-treated using Plasma Nitriding (PN) and PVD coatings to solve the thermal fatigue problem faced in die-casting applications. Chromium-based multilayer CrN/Cr (m-CrN) coatings and multi-component aluminium–titanium-based AlTiN (m-AlTiN) coatings were deposited using a cathodic arc deposition technique after plasma nitriding the H-13 steel surface with different case-depths of 50 µm and 200 µm. The structural, tribological, corrosion, and mechanical properties of the duplex-treated samples were studied. The thermal fatigue (TF) test was conducted by heating the sample to 600 °C and rapidly cooling it to room temperature, simulating the die-casting process conditions. After multiple cycles, it was observed that the oxide layer thickness formed was lower on duplex-treated samples compared to that on the uncoated plasma nitride sample. In addition, the mechanical properties were improved with the increase in PN diffusion depth. The duplex-treated samples showed better mechanical and thermal fatigue properties compared to untreated and only coated samples. The sample with m-AlTiN deposited on plasma nitrided H-13 with 200 µm case depth displays better thermal fatigue properties compared to the other samples. Full article

A comprehensive experimental investigation of the wear behaviour of coated spur polymer gears made of POM is performed in this study. Three different thicknesses of aluminium (Al) coatings were investigated and deposited by the Physical Vapour Deposition (PVD) process. The Al coating was deposited in three steps: By plasma activation, metallisation of the aluminium by the magnetron sputtering process, and plasma polymerisation. The wear of the gears was tested on an in-house developed testing rig for different torques (16, 20, and 24 Nm) and a rotational speed of 1000 rpm. The duration of the experiments was set to 13 h, when the tooth thickness and, consequently, the wear of the tooth flank were recorded. The experimental results showed that the influence of metallisation with aluminium surface coatings on the wear behaviour of the analysed polymer gear is not significantly important. The results also showed that the gears with a thicker aluminium coating showed greater wear than gears with a thinner coating or even without a coating. This is probably due to the fact that the aluminium particles that started to deviate during gear operation represented the abrasive material, which led to the faster wear of the contacting surfaces of the meshing gear flanks. Full article

This study aimed to investigate the influence of bimodal TiO₂/nanoTiO₂ coatings obtained in the PVD/ALD hybrid process on an Al-Si-Cu-type aluminium alloy on the physicochemical properties of the investigated materials. The reference materials were uncoated substrates and samples coated with TiO₂ coatings in single PVD and ALD processes. Tests were carried out on the morphology of coatings using scanning electron microscopy (SEM) and atomic force microscopy (AFM) to determine the structure of the tested coatings and their influence on physicochemical properties. The tests of physicochemical properties were carried out using the potentiodynamic and electrochemical impedance spectroscopy methods. The analysis of corrosion products obtained during the study of physicochemical properties was performed using SEM and EDS analysis. Based on the analysis of anode polarisation curves of the tested materials and Tafel analysis, it was found that a sample demonstrated the highest corrosion resistance with a bimodal coating-type TiO₂/nanoTiO₂, which had the lowest value of corrosion current and the highest value of polarisation resistance. The slightest corrosion resistance was characteristic for uncovered samples. Moreover, the influence of the tested coatings on the improvement of tribological contact of the surfaces of the coated materials with the counter-specimen made of cemented carbides was demonstrated. Full article

A comprehensive experimental investigation of the wear behaviour of coated spur polymer gears made of POM is performed in this study. The three physical vapour deposition (PVD) coatings investigated were aluminium (Al), chromium (Cr), and chromium nitrite (CrN). Al was deposited in three process steps: By plasma activation, metallisation of Al by the magnetron sputtering process, and by plasma polymerisation. Cr deposition was performed in only one step, namely, the metallization of Cr by the magnetron sputtering process. The deposition of CrN was carried out in two steps: the first involved the metallization of Cr by the magnetron sputtering process while the second step, vapour deposition, involved the reactive metallisation of Cr with nitrogen, also by the magnetron sputtering process. The gears were tested on an in-house developed testing rig for different torques (16, 20, 24 and 30 Nm) and rotational speed of 1000 rpm. The duration of the experiments was set to 13 h, when the tooth thickness, and, consequently, the wear of the tooth flank was recorded. The experimental results showed that the influence of metallisation with aluminium, chromium, and chromium nitrite surface coatings on the wear behaviour of the analysed polymer gear is not significant. This is probably due to the fact that the analysed coatings were, in all cases, very thin (less than 500 nm), and therefore did not influence the wear resistance significantly. In that respect, an additional testing using thicker coatings should be applied in the further research work. Full article

The impact of small deposits of calcium–magnesium–aluminium silicates (CMAS) on the top of thermal barrier coatings (TBCs) made of yttria-stabilised zirconia (YSZ) produced via electron-beam physical vapour deposition (EB-PVD) is shown to play a role in the microstructural and chemical stability of the coatings; hence, it also affects the thermal insulation potential of TBCs. Therefore, the present work investigates the degradation potential of minor CMAS deposits (from 0.25 to 5 mg·cm⁻²) annealed at 1250 °C for 1 h on a novel Er₂O₃-Y₂O₃ co-stabilised ZrO₂ (ErYSZ) EB-PVD TBC, which is compared to the standard YSZ coating. Due to the higher reactivity of ErYSZ coatings with CMAS, its penetration is limited in comparison with the standard YSZ coatings, hence resulting in a better thermal insulation of the former after ageing. Full article

Aluminium coatings that are formed by physical vapour deposition (PVD) on rolled steel products are more resistant to atmospheric and seawater corrosion than zinc coatings. We developed a coating thickness analyzer (CTA) with an X-ray fluorescence (XRF) measuring head, that is integrated into the PVD pilot line. In this study, to conduct measurements of elements with atomic numbers less than 20 while avoiding the problem of registration of light elements, the measuring head was integrated into a process vacuum chamber to maintain a vacuum during the measurements. To validate the proposed tool, cold-rolled steel strips of different grades are used as substrates, and aluminium was deposited on the surface via PVD in thicknesses ranging from 1 to 20 g/m². The thin-film thickness measurements during a pre-acceptance test were found to have a relative accuracy of less than 5% and a relative precision of less than 1–2%. The proposed CTA can be readily integrated in the factory’s automatic process control system and the real-time measurements in operating and calibration modes, and the status of all spectrometric equipment (X-ray tube, detector etc.) can be transmitted to the upper-level computer. Thus, the process engineer can properly control the deposition process. Full article

In this study, the effect of increasing aluminum content and magnetic steering field strength on the structure and wear behavior of arc PVD AlTiN coatings is discussed. Deposition was done by means of an industrial-scale PVD unit for tool coating. The aluminium content in the AlTi source material was increased from 67 to 73 at.%. We applied two settings of the magnetic field that steers the arc across the cathode surface thereby evaporating the AlTi alloy differently. The resulting coating thickness ranged from 3.5 to about 7 µm. Cemented tungsten carbide was used as substrate material. Coating properties like hardness, adhesion, and crystal phases were analyzed by indentation and X-ray diffraction, respectively. The wear behaviour of the different AlTiN hard coatings were investigated in two ways. In a first idealized test, cyclic impacting was done applying a constant force. The resulting wear pattern was quantified by an Alicona multi-focus microscope. A second wear test was done by metal cutting under realistic conditions. Fly milling of ductile cast iron (EN-GJS-700) was performed with regular interruptions in order to measure the increasing wear mark. As expected, aluminium contents above 67 at.% (in the metal fraction of the coating) lead to a decreased wear resistance as the soft hexagonal phase exceeds values of a few vol.%. However, it was found that the formation of the hexagonal phase can be effectively influenced and delayed by increasing the magnetic steering field at the cathode. The wear behavior observed in cyclic impact testing corresponds well to results obtained with the more complex loading situation encountered in milling. Full article

The lifetimes and the premature wear of machining tools impact on manufacturing efficiencies and productivities. A significant proportion of machining tool damage can be attributed to component wear. Here, titanium aluminium nitride (TiAlN) multi-layered with titanium diboride (TiB₂) prepared by PVD (Physical Vapour Deposition) sputtering onto H-13 substrates are studied as potential wear-resistant coatings for forging die applications. The TiB₂ content has been altered and two-sets of coating systems with a bilayer thickness either less than or greater than 1 μm are investigated by tribological and microstructural analysis. XRD analysis of the multilayers reveals the coatings to be predominately dominated by the TiAlN (200) peak, with additional peaks of TiN (200) and Ti (101) at a TiB₂ content of 9%. Progressive loads increasing to 100 N enabled the friction coefficients and the coating failure at a critical load to be determined. Friction coefficients of around 0.2 have been measured in a coating containing 9% TiB₂ at critical loads of approximately 70 N. Bi-directional wear tests reveal that bilayers with thicknesses greater than 1 μm have frictional coefficients that are approximately 50% lower than those where the bilayer is less than 1 μm. This is due to the greater ability of thicker bilayers to uniformly distribute the stress within the layers. There are two observed frictional coefficient regimes corresponding to a lower and higher rate of material loss. At the lower regime, with TiB₂ contents below 20%, material loss occurs mainly via delamination between the layers, whilst at compositions above this, material loss occurs via a break-up of material into finer particles that in combination with the higher loads results in greater material loss. The measured wear scar volumes for the TiAlN/TiB₂ multilayer coatings are approximately three times lower than those measured on the substrate, thus validating the increased wear resistance offered by these composite coatings. Full article
