Search Results (82)

To address the difficulty of locating small-hole leaks in buried natural gas pipelines, this study conducted a comprehensive theoretical and numerical analysis of the acoustic characteristics associated with such leakage events. A coupled flow–acoustic simulation framework was developed, integrating gas compressibility via the realizable k-ε and Large Eddy Simulation (LES) turbulence models, the Peng–Robinson equation of state, a broadband noise source model, and the Ffowcs Williams–Hawkings (FW-H) acoustic analogy. The effects of pipeline operating pressure (2–10 MPa), leakage hole diameter (1–6 mm), soil type (sandy, loam, and clay), and leakage orientation on the flow field, acoustic source behavior, and sound field distribution were systematically investigated. The results indicate that the leakage hole size and soil medium exert significant influence on both flow dynamics and acoustic propagation, while the pipeline pressure mainly affects the strength of the acoustic source. The leakage direction was found to have only a minor impact on the overall results. The leakage noise is primarily composed of dipole sources arising from gas–solid interactions and quadrupole sources generated by turbulent flow, with the frequency spectrum concentrated in the low-frequency range of 0–500 Hz. This research elucidates the acoustic characteristics of pipeline leakage under various conditions and provides a theoretical foundation for optimal sensor deployment and accurate localization in buried pipeline leak detection systems. Full article

To address the unclear coupling mechanism between bubble detachment behavior and acoustic characteristics in gas–liquid two-phase flow, this paper systematically studied bubble behavior and acoustic characteristics under different conditions by building a high-precision synchronous measurement system, combining acoustic signal analysis and bubble dynamics observation. The influence mechanism of liquid surface tension, dynamic viscosity, and orifice diameter on the critical gas flow velocity of bubble flow transition was analyzed, and a flow pattern classification criterion system was established. The experimental results showed that the bubble flow state could be divided into three states according to the characteristics of the acoustic signals: discrete bubble flow, single-chain bubble flow, and dual-stage chain bubble flow. The liquid surface tension and dynamic viscosity had no significant effect on the critical gas flow velocity of the transition from discrete bubble flow to single-chain bubble flow, but significantly increased the critical gas flow velocity of the transition from single-chain bubble flow to dual-stage chain bubble flow. The increase in the orifice diameter reduced the critical gas flow velocity of the two types of flow transition. In addition, the Weber number (We) and Galileo number (Ga) were introduced to construct a quantitative classification system of flow pattern, which provided theoretical support for the optimization of industrial gas–liquid two-phase flow. Full article

In the context of autonomous environmental monitoring, this study investigates a surface acoustic wave (SAW) sensor designed for selective carbon dioxide (CO₂) detection. The sensor is based on a LiTaO₃ piezoelectric substrate with copper interdigital transducers and a polyetherimide (PEI) layer, chosen for its high electromechanical coupling and strong CO₂ affinity. Finite element simulations were conducted to analyze the resonance frequency response under varying gas concentrations, film thicknesses, pressures, and temperatures. Results demonstrate a linear and sensitive frequency shift, with detection capability starting from 10 ppm. The sensor’s autonomy is ensured by a piezoelectric energy harvester composed of a cantilever beam structure with an attached seismic mass, where mechanical vibrations induce stress in a piezoelectric layer (PZT-5H or PVDF), generating electrical energy via the direct piezoelectric effect. Analytical and numerical analyses were performed to evaluate the influence of excitation frequency, material properties, and optimal load on power output. This integrated configuration offers a compact and energy-independent solution for real-time CO₂ monitoring in low-power or inaccessible environments. Full article

Accurate detection of downhole tubing leakage in gas wells is essential for planning effective repair operations and mitigating safety risks in annulus pressure buildup wells. Current localization methods employ autocorrelation analysis to exploit the time-delay features of acoustic signals traveling through the tubing–casing annulus. This allows non-invasive wellhead detection, avoiding costly tubing retrieval or production shutdowns. However, field data show that multiphase flow noise, overlapping reflected waves, and coupled multi-leakage points in the wellbore frequently introduce multi-peak interference in acoustic autocorrelation curves. Such interference severely compromises the accuracy of time parameter extraction. To resolve this issue, our study experimentally analyzes how leakage pressure differential, aperture size, depth, and multiplicity affect the autocorrelation coefficients of acoustic signals generated by leaks. It compares the effects of different noise reduction parameters on leakage localization accuracy and proposes a characteristic time selection principle for autocorrelation curves, providing a new solution for precise leakage localization under complex downhole conditions. Full article

In response to the limitations of experimental methods for detecting oil and gas well tubing leaks, this study developed a full-scale indoor simulation system for oil tubing leakage. The system consists of three components: a wellbore simulation device, a dynamic leakage simulation module, and a multi-parameter monitoring system. The wellbore simulator employs a jacketed structure to replicate real-world conditions, while the leakage module incorporates a precision flow control device to regulate leakage rates. The monitoring system integrates high-sensitivity acoustic sensors and pressure sensors. Through multi-condition experiments, the system simulated complex scenarios, including leakage apertures of 1–5 mm, different leakage positions relative to the annular liquid level, and multiple leakage point combinations. A comprehensive acoustic signal processing framework was established, incorporating time–domain features, frequency–domain characteristics, and time–frequency joint analysis. Experimental results indicate that when the leakage point is above the annular liquid level, the acoustic signals received at the wellhead exhibit high-frequency characteristics typical of gas turbulence. In contrast, leaks below the liquid level produce acoustic waves with distinct low-frequency fluid cavitation signatures, accompanied by noticeable medium-coupled attenuation during propagation. These differential features provide a foundation for accurately identifying leakage zones and confirm the feasibility of using acoustic detection technology to locate concealed leaks below the annular liquid level. The study offers experimental support for improving downhole leakage classification and early warning systems. Full article

La₃Ga₅SiO₁₄ (langasite, LGS)-based surface acoustic wave (SAW) devices are widely used for industrial health monitoring in harsh high-temperature environments. However, a conventional LGS-based SAW structure has a low quality factor (Q) due to its spurious resonant peaks. A hetero-acoustic layer (HAL)-based structure can effectively enhance the Q factor and the figure of merit (FOM) of SAWs due to its better energy confinement of SAWs. In this work, a HAL-based structure is proposed to achieve a high FOM and high-temperature resistance at the same time. Based on the finite element method (FEM) and coupling-of-model (COM) combined simulation, a systematic numerical investigation was conducted to find the optimal materials and structural parameters considering the viability of an actual fabricating process. After optimizing the layer number, an intermediate-layer material choice and structural parameters, Pt/(0°, 138.5°, 27°) LGS/YX-LGS/SiC HAL structure were chosen. The proposed structure achieves a Q factor and FOM improvement of more than 5 and 2.6 times higher than those of conventional SAW structures, which is important for the development of high temperature SAW sensors. These findings pave a viable method for improving the Q factor and FOM of LGS-based SAW and can provide material and device structural design guidance for fabrication and high-temperature applications in the future. Full article

The pressure oscillation caused by vortex–acoustic coupling is one of the main gain factors that results in the combustion instability of motors. Focusing on a solid rocket motor with a backward step configuration that can generate a corner vortex, this study aims to investigate the pressure oscillation characteristics in a combustion chamber under two-phase flow interactions through numerical simulations. The two-phase flow discrete phase model (DPM) was chosen to study particle motion and two-phase interactions. The numerical methodology was hence established by coupling the DPM with the large eddy simulation (LES) method. Taking the Clx motor as a reference and introducing aluminum oxide particles, two important particle parameters (diameter and concentration) and the key geometric parameters of the backward step were numerically studied. The numerical results show that both increased particle diameter and concentration can decrease the frequency and amplitude of pressure oscillations; additionally, the effects of geometric parameters on the pressure oscillations of the backward step, such as the downstream aspect ratio, the expansion ratio, and the step position, are basically consistent under both pure gas and two-phase flows. The influences of those geometric parameters are mainly reflected in defining the space for the development of upstream flow instability and the motion of downstream vortices. Compared with the pure-gas flow, the presence of aluminum oxide particles in two-phase flow globally decreases the vortex shedding frequency, the primary frequency, and the amplitude of pressure oscillations. It can also weaken the effects of vortex–acoustic coupling due to increased turbulent viscosity, which hinders the orderly development of vortices. Full article

The sensitivity of gas and water phases to DAS acoustic frequency bands can be used to interpret the production profile of horizontal wells. DAS typically collects acoustic signals in the kilohertz range, presenting a key challenge in identifying the sensitive frequency bands of the gas and water phases in the production well for accurate interpretation. In this study, a gas–water two-phase flow–acoustic coupling model for a horizontal well is developed by integrating a gas–water separation flow model with a pipeline acoustic model. The model simulates the sound pressure level (SPL) and amplitude variations of acoustic waves under different flow patterns, spatial locations, and gas–water ratio schemes. The results demonstrate that within the same flow pattern, an increase in the gas–water ratio significantly elevates acoustic amplitude and SPL peaks within the 5–50 Hz frequency band. Analysis of oil field DAS data reveals that the amplitude response range for stages with a lower gas–water ratio falls within 5–10 Hz, whereas stages with a higher gas–water ratio exhibit an amplitude response range of 10–50 Hz. Full article

This paper reports on a gas sensor based on two bulk acoustic wave (BAW) resonators electrically coupled with a tuneable capacitor. The weak coupling strength was tuned to its optimal value (achieving maximum sensitivity) by varying the capacitance (without complex filtering, a control circuit as required in the state of the art). A gas sensor was developed based on the electrically coupled BAW resonators by functionalizing one of the resonators with zeolitic imidazolate framework-8 (ZIF-8). It featured a quality (Q) factor of ~2.2 k in air and a resonance frequency of ~6.32 MHz. Such a simple coupling mechanism can be tuned and further extended to coupled resonators in other domains. Full article

This paper aims to conduct an acoustic analysis through noise measurements of a hybrid propulsion system intended for implementation on a drone, from which the main noise sources can be identified for further research on noise reduction techniques. Additionally, the noise was characterized by performing spectral analysis and identifying the tonal components that contribute to the overall noise. The propelling force system consists of a micro-turboshaft coupled with a gearbox connected to an electric generator. The propulsion system consists of a micro-turboshaft coupled with a gearbox connected to an electric generator. The electric current produced by the generator powers an electric ducted fan (EDF). The engineturbo-engine was tested in free-field conditions for noise generation at different speeds, and for this, an array of microphones was installed, positioned polarly around the system and near the intake and exhaust. Consequently, based on the test results, the acoustic directivity was plotted, revealing that the highest noise levels are at the front and rear of the engine. The noise level at a distance of 1.5 m from the turboengine exceeds 90 dBA at all tested speeds. Spectral analyses of both the far-field acoustic signals (measured with a polar microphone array) and the near-field signals (microphones positioned near the intake and exhaust) revealed that the primary contributors to the overall noise are the micromotor’s compressor, specifically the gas dynamic phenomena in the fan (BPF and 2× BPF). Thus, it was determined that at the intake level, the main noise contribution comes from the high-frequency components of the compressor, while at the exhaust level, the noise mainly originates from the combustion chamber, characterized by low-frequency components (up to 2 kHz). The findings from this study have practical applications in the design and development of quieter drone propulsion systems. By identifying and targeting the primary noise sources, engineers can implement effective noise reduction strategies, leading to drones that are less disruptive in urban environments and other noise-sensitive areas. This can enhance the acceptance and deployment of drone technology in various sectors, including logistics, surveillance, and environmental monitoring. Full article

As deep oil and gas resources and Carbon Capture and Storage (CCS) are developed, enhancing drilling efficiency in hard rock formations has emerged as a critical technology in oil and gas extraction. The advancement of ultrasonic, high-frequency vibration rock-breaking technology significantly facilitates efficient rock crushing. When subjected to ultrasonic high-frequency vibrations, the rock’s response is a crucial issue in implementing ultrasonic vibration rock crushing technology. This study employed numerical simulation and theoretical deduction methods, utilizing a multi-physics approach that couples solid mechanics with pressure acoustics. It integrated information on common influencing parameters of ultrasonic generators and reservoir rock properties to establish model parameters, analyze simulation results, and perform theoretical deductions. The research investigated the response patterns of different-sized rock samples under high-frequency ultrasound vibration excitation across various frequencies, amplitudes, and confining pressure conditions. Through the development of a three-dimensional model and the application of principles from solid mechanics and elastoplasticity, the study derived equations that describe the resonance frequencies of rock blocks under confining pressure as functions of relevant rock parameters. The findings indicate that ultrasonic vibrations can effectively induce rock displacement. Under excitation frequency sources, the rock exhibits a natural frequency correlated with the rock sample size. When the excitation frequency approximates the natural frequency, the rock resonates. At this point, the rock’s surface displacement is maximal. The rock undergoes tensile stress, leading to stress concentration that facilitates rock damage and fragmentation. Increasing the excitation amplitude enhances rock crushing, as it amplifies the maximum surface displacement under the same frequency excitation. Confining pressure exerts an inhibitory effect on the rock’s vibration response, but it does not alter the resonance frequency of the rock sample, a fact verified by both numerical simulation and theoretical results. Based on the research findings in this paper, it can help to optimize the parameters of ultrasonic vibration rock breaking in field application to achieve the best rock-breaking effect. Full article

The explosion-proof performance is an important index for oil-immersed transformers. The nitrogen-sealed transformer is a new type of transformer with nitrogen gas in the upper space, which can buffer against internal stress increase caused by arc faults. However, the pressure changes in the transformer under internal faults are unclear. The authors of this study propose a method based on finite element simulation to analyze the pressure changes and the stress on the tank. First, the calculation process of arc energy and the pressure of the bubbles caused by the arc are derived. Second, the dynamic pressure wave propagation model and acoustic-solid coupling model are established. Last, the finite element simulation model is built to analyze the pressure characteristics. Taking the winding turn-to-turn and phase-to-phase short circuit faults as the analysis situations, the pressure changes in the 110 kV/20 MVA nitrogen-sealed transformer are simulated. Due to the pressure wave refraction and reflection, the pressure changes show oscillatory characteristics with time after the occurrence of an internal short circuit fault. The pressure wave travels from the arc fault position to the periphery. Compared to the conventional transformer, the pressure changes with slower variations under an internal short circuit fault and the tank suffer less stress, which indicates that the nitrogen-sealed transformer is more effective in the explosion-proof performance. Full article

The coal and gas outburst and rockburst coupling disaster is becoming increasingly serious due to deep mining. To clarify the mechanism inducing the outburst–rockburst coupling disaster, a true triaxial single-sided unloading mechanical test was conducted with the aid of a true triaxial solid–thermal–gas coupling test device, an industrial computed tomography (CT) system, and an acoustic emission system. Through this test, the mechanical characteristics, meso crushing characteristics, and acoustic characteristics in the disaster formation process were obtained. Additionally, the outburst–rockburst coupling instability disaster law was verified by numerical simulation. The results demonstrated that the stress unloading degree of the coal body was negatively correlated with the initial gas pressure in the outburst–rockburst coupling disaster. The time domain parameter count and energy of acoustic emission exhibited a “bimodal” distribution pattern in the instability stage. The rockburst would occur when the peak value was in a “low-count and high-energy” state, while coal and gas outburst would occur when the peak value was in a “high-count and low-energy” state. The meso slice revealed that gas degradation promoted the development of microcracks in the coal body, and the penetration of cracks resulted in the main cracks of structural instability during rockburst. The coal and gas outburst was mainly attributed to the “cross” shear failure pattern of the coal body. These research findings may lay a foundation for the effective prevention and control of outburst–rockburst coupling disasters. Full article

Acoustic tomography utilizes sensor arrays to collect sound wave signals, enabling non-contact measurement of physical parameters within an area of interest. Compared to optical technologies, acoustic tomography offers the advantages of low cost, low maintenance, and easy installation. Current research in acoustic tomography mainly focuses on reconstruction algorithms for temperature fields, while monitoring the composition and concentration of gases is significant for ensuring safety and improving efficiency, such as in scenarios like boiler furnaces and aviation engine nozzles. In excitable gases, the speed of sound exhibits an S-shaped curve that changes with frequency, a characteristic that could be potentially useful for acoustic tomography. Therefore, this study primarily discusses the quantitative calculation of gas concentration and temperature based on the dispersion of the speed of sound. By employing graphic processing and pattern matching methods, a coupled relationship of the dispersion of the speed of sound with gas concentration and temperature is established. The projection intersection method is used to calculate the concentration and temperature of binary and ternary gas mixtures. Combined with the inversion method, a joint reconstruction method for gas concentration fields and temperature fields based on the dispersion of the speed of sound is developed. The feasibility of the proposed simultaneous reconstruction method for temperature and concentration fields is validated using numerical simulations. Additionally, an acoustic tomography experimental system was set up to conduct reconstruction experiments for binary gas concentration fields and temperature fields, confirming the effectiveness of the proposed method. Full article

Nitrides are the leading semiconductor material used for the fabrication of high electron mobility transistors (HEMTs). They exhibit piezoelectric properties, which, coupled with their high mechanical stiffness, expand their versatile applications into the fabrication of piezoelectric devices. Today, due to advances in device technology that result in a reduction in the size of individual transistor elements and due to increased structural complexity (e.g., multi-gate transistors), the integration of piezoelectric materials into HEMTs leads to an interesting occurrence, namely acoustic emission from the transistor gate due to piezoelectric effects. This could affect the device’s performance, reliability, and durability. However, this phenomenon has not yet been comprehensively described. This paper aims to examine this overlooked aspect of AlGaN/GaN HEMT operation, that is, the acoustic emission from the gate region of the device induced by piezoelectric effects. For this purpose, dedicated test structures were designed, consisting of two narrow 1.7 μm-wide metallization strips placed at distances ranging from 5 μm to 200 μm fabricated in AlGaN/GaN heterostructures to simulate and examine the gate behavior of the HEMT transistor. For comparison, the test device structures were also fabricated on sapphire, which is not a piezoelectric material. Measurements of acoustic and electrical interactions in the microwave range were carried out using the “on wafer” method with Picoprobe’s signal–ground–signal (SGS)-type microwave probes. The dependence of reflectance |S11| and transmittance |S21| vs. frequency was investigated, and the coupling capacitance was determined. An equivalent circuit model of the test structure was developed, and finite element method simulation was performed to study the distribution of the acoustic wave in the nitride layers and substrate for different frequencies using Comsol Multiphysics software. At frequencies up to 2–3 GHz, the formation of volume waves and a surface wave, capable of propagating over long distances (in the order of tens of micrometers) was observed. At higher frequencies, the resulting distribution of displacements as a result of numerous reflections and interferences was more complicated. However, there was always the possibility of a surface wave occurrence, even at large distances from the excitation source. At small gate distances, electrical interactions dominate. Above 100 µm, electrical interactions are comparable to acoustic ones. With further increases in distance, weakly attenuated surface waves will dominate. Full article
