Search Results (944)

Search Parameters:
Keywords = WeldForming

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
41 pages, 12580 KB
Article
Visualization of the Reverse Side of Cathode and Anode Spots in a Welding Arc
by Yulia I. Karlina, Andrey E. Balanovskiy, Georgy E. Kurdyumov, Vitaliy A. Gladkikh, Vladimir Yu. Konyukhov, Tatiana A. Oparina, Roman V. Kononenko and Viktor V. Kondratiev
Appl. Sci. 2026, 16(7), 3385; https://doi.org/10.3390/app16073385 - 31 Mar 2026
Viewed by 244
Abstract
Improving the quality of welded joints, as well as the advancement of equipment and materials, inevitably requires deep theoretical knowledge of the physical phenomena occurring in the arc column and in the cathode and anode regions. Achievements in the field of controlling metal [...] Read more.
Improving the quality of welded joints, as well as the advancement of equipment and materials, inevitably requires deep theoretical knowledge of the physical phenomena occurring in the arc column and in the cathode and anode regions. Achievements in the field of controlling metal transfer at the micro- and nanoscale through the regulation of current and voltage in welding power sources have encountered the problem of the formation of cathode and anode spots, which affect the stability of welding arcs and the quality of the weld. Under short current pulses and pauses, the stability of the arc discharge depends on the ability to form a cathode spot, melt the wire metal, and transfer it through the arc column. In this article, based on the generalization of known experimental facts and studies performed using a high-speed camera, it is shown that the current-carrying channel of the electric arc has a discrete structure consisting of a multitude of thin channels through which the main discharge current flows. The cathode spot of the arc discharge represents a highly heated and brightly luminous region on the cathode surface. Electron emission sustaining the discharge and the removal of cathode material occur from this region. A new method is proposed for investigating the reverse side of the cathode spot, which makes it possible to identify a structure consisting of individual cells or fragments of the cathode spot. For the first time, anode spots recorded with a high-speed camera are presented. An analysis of the spot structure is carried out. The parameters influencing the mobility of cathode and anode spots are determined. Based on the obtained experimental facts, a hypothesis is proposed regarding the non-uniform structure of cathode and anode spots in the arc discharge. Full article
Show Figures

Figure 1

23 pages, 14742 KB
Article
Study on Construction Techniques and Key Joints of Giant Arch Suspension Building
by Yuenan Jiang, Chengcheng Xu, Suola Shao and Wenping Wu
Buildings 2026, 16(7), 1313; https://doi.org/10.3390/buildings16071313 - 26 Mar 2026
Viewed by 291
Abstract
Arch-suspended structures represent a distinctive form of hybrid suspension system. By combining an arch with a suspended floor system, this structural typology leverages the inherent advantages of both components while mitigating the limitations of each when used independently. This synergy effectively reduces peak [...] Read more.
Arch-suspended structures represent a distinctive form of hybrid suspension system. By combining an arch with a suspended floor system, this structural typology leverages the inherent advantages of both components while mitigating the limitations of each when used independently. This synergy effectively reduces peak internal forces and flexural deformations in structural members. Although widely applied in bridge engineering, research on arch-suspended building structures remains scarce. This paper investigates the construction techniques employed for a large-scale arch-suspended building. The stability of temporary support systems during construction is verified, and the mechanical behavior of critical joints—including the composite slab hanging pillar, arch support, and arch roof—is examined through both experimental testing and numerical simulation. The results demonstrate that a partitioned and segmented construction method is feasible for such complex structures. Structural internal forces and deformations can be effectively controlled by installing tubular temporary supports on both sides of the hanging pillars and lattice temporary supports at the base. Step-by-step unloading of these temporary supports ensures their stability throughout the construction process. Furthermore, the welds in the composite slab hanging pillar effectively transfer tensile forces from the middle plate to the side plates, enabling composite action and collaborative load-bearing among the steel plates. When subjected to loads of 2 times and 4.3 times the design load, localized plasticity was observed in the arch support and arch roof, respectively, while the overall structural integrity remained secure. This study provides a valuable reference for the design and construction of innovative long-span building structures, offering insights that can inform the development and practical application of arch-suspended systems in future architectural projects. Full article
(This article belongs to the Special Issue Advances in Structural Systems and Construction Methods)
Show Figures

Figure 1

39 pages, 45534 KB
Article
Scalability and Welding Effects on the Dynamical Responses of Box Assembly with Removable Component Systems
by Ezekiel Granillo, Devin Binns, Daniel Rhodes and Abdessattar Abdelkefi
Appl. Sci. 2026, 16(7), 3146; https://doi.org/10.3390/app16073146 - 24 Mar 2026
Viewed by 255
Abstract
Scalability of the original test design for the box assembly with removable component (BARC) structure is of interest in the field of experimental structural analysis. As complex structures become increasingly difficult to test experimentally the larger they become, it is a common test [...] Read more.
Scalability of the original test design for the box assembly with removable component (BARC) structure is of interest in the field of experimental structural analysis. As complex structures become increasingly difficult to test experimentally the larger they become, it is a common test practice to use a scaled-down representative model to understand the characteristics of these systems. For complex structures with non-rigid boundary conditions, there exists a gap in understanding the effects of scalability and welding. To gain a better understanding of the outcomes of this phenomenon, the dynamical effects of upscaling the dimensions of the BARC structure are analyzed. Three variations of the BARC are investigated experimentally and computationally, namely, the original BARC system, the BARC system upscaled at 1.5 times the size of the original model, and the BARC system upscaled at two times the size of the original model. The original BARC is tested to investigate the properties of the predetermined boundary conditions. Because the upscaled BARC systems are manufactured using welding, an investigation of the variability of results due to welding imperfections is conducted to evaluate its effects on the vibrational properties of the systems. The dominant resonant frequencies of the three systems are identified through an impact hammer test. The results are then compared to those obtained through finite element analysis, in which both datasets show agreement. In general, as the BARC system is upscaled, the resonant frequencies decrease without inducing mode switching for the selected boundary conditions, indicating that the larger systems are less rigid. To understand the trends of nonlinear softening/hardening and nonlinear damping, forced vibration experiments conducted in the form of true random and controlled stepped-sine excitations are performed. The results show that, in general, as the BARC system is upscaled, changes in the nonlinear properties of the system are induced. With regard to the effects of using welding to manufacture BARC systems, the results prove that variations in welding can lead to non-negligible variations in the vibratory responses of the BARC system. Additionally, several types of harmonic vibrational testing are investigated to understand the physics behind their varied responses. Overall, this work shows that upscaling the BARC system can be beneficial to researchers who require a less rigid system for investigations and that manufacturing of BARC systems by welding can be a cost-effective alternative to subtractive manufacturing. Full article
(This article belongs to the Special Issue Nonlinear Dynamics in Mechanical Engineering and Thermal Engineering)
Show Figures

Figure 1

18 pages, 8085 KB
Article
Investigation of Microstructural Characterization and Tensile Deformation Mechanisms in Inconel 617 Welded Joints Produced by GTAW
by Mingyang Zhao, Lang Wang, Wenhao Ren, Yuxin Wang, Tao Zhang and Zhengzong Chen
Materials 2026, 19(6), 1251; https://doi.org/10.3390/ma19061251 - 21 Mar 2026
Viewed by 296
Abstract
The microstructural evolution and tensile behavior of Inconel 617 welded joints produced by gas tungsten arc welding (GTAW) with ERNiCrCoMo-1 filler were systematically investigated. Detailed microstructural characterization revealed that Cr-rich M23C6 and Ti-rich MC carbides are the dominant precipitates, while [...] Read more.
The microstructural evolution and tensile behavior of Inconel 617 welded joints produced by gas tungsten arc welding (GTAW) with ERNiCrCoMo-1 filler were systematically investigated. Detailed microstructural characterization revealed that Cr-rich M23C6 and Ti-rich MC carbides are the dominant precipitates, while Mo-rich M6C forms locally along grain boundaries after thermal exposure. The fusion and weld zones exhibit fine dendritic morphologies with uniformly distributed precipitates, resulting in significant strengthening through precipitation and dislocation–pinning mechanisms. Owing to the low heat input and compositional compatibility between the weld and base metals, the heat-affected zone remains extremely narrow and free of compositional transitions. The welded joint attains tensile strengths of 920 MPa at room temperature and 605.5 MPa at 750 °C, corresponding to joint efficiencies of 117% and 121%, respectively, with fracture consistently occurring in the base metal. Deformation analysis shows that plasticity at room temperature is governed by planar slip and dislocation entanglement, whereas deformation twinning predominates at elevated temperatures owing to the reduced stacking-fault energy and the pinning effect of M23C6 carbides. These results provide key insights into the deformation and strengthening mechanisms controlling the high-temperature performance of GTAW-welded Inconel 617 joints and offer guidance for their application in advanced nuclear and high-temperature energy systems. Full article
(This article belongs to the Section Metals and Alloys)
Show Figures

Graphical abstract

19 pages, 9075 KB
Article
In Situ Fabrication of Metal Matrix Composite Using Solid-State Mechanical Mixing
by Amlan Kar
J. Manuf. Mater. Process. 2026, 10(3), 100; https://doi.org/10.3390/jmmp10030100 - 16 Mar 2026
Viewed by 321
Abstract
Friction stir-welding (FSW) is widely recognized as a modern solid-state technology used to join dissimilar materials by solid-state mechanical mixing. Such mechanical mixing can be exploited to fabricate in situ composite structures through solid-state deformation mechanisms. The present investigation highlights the microstructural evolution [...] Read more.
Friction stir-welding (FSW) is widely recognized as a modern solid-state technology used to join dissimilar materials by solid-state mechanical mixing. Such mechanical mixing can be exploited to fabricate in situ composite structures through solid-state deformation mechanisms. The present investigation highlights the microstructural evolution and mechanical properties of an in situ composite structure fabricated by FSW of aluminum (Al) to titanium (Ti) incorporating a thin Nickel (Ni) interlayer. A 0.1 mm thick Ni foil was placed across the full butt interface between 4 mm thick Al and Ti plates before friction stir-welding. Properties of the composite were investigated in detail, and the results revealed that fragmented Ti and Ni particles of different sizes were consolidated in the weld nugget. Al, on the other hand, exhibited substantial microstructural refinement and developed an equiaxed microstructure with random grain orientation, mixed grain boundaries and low micro-strain accumulation in the weld nugget. At the processing temperature, Al reacted with both Ti and Ni to form multiple intermetallic compounds. Tensile testing indicated that the tensile properties of the weld were close to those of the base aluminum. This retention of mechanical properties in spite of recrystallization is attributed to the following mechanisms: (1) Ti and Ni undergo severe deformation, forming fine particles with varying sizes and shapes; (2) at particle interfaces, diffusion and chemical reactions produce interlayers and intermetallic compounds; (3) these particles are consolidated within dynamically recrystallized Al, imparting composite characteristics to the weld nugget; and (4) the particles containing intermetallic compounds act as dispersoids in the Al matrix. Quantitatively, the weld retained 98% (104.2 ± 3.3 MPa) UTS and 90% (17.1 ± 1.2) ductility of base aluminum, demonstrating the effectiveness of the Ni interlayer approach in controlling brittle intermetallic formation. Full article
Show Figures

Figure 1

15 pages, 4853 KB
Article
Microstructural Evolution Governing the Creep Resistance of Grade 92 Steel Under Wide-Temperature Heat Treatment: From Ferrite Recovery to Dynamic Precipitation Strengthening
by Yinsheng He, Hongyu Zhou, Liming Xu and Keesam Shin
Materials 2026, 19(6), 1101; https://doi.org/10.3390/ma19061101 - 12 Mar 2026
Viewed by 231
Abstract
Thermal excursions during post-weld heat treatment (PWHT) and on-site fabrication frequently compromise the integrity of Grade 92 steel. While hardness fluctuations are documented, the correlation between initial properties and long-term creep stability remains controversial. This study aims to evaluate the relationship between thermal [...] Read more.
Thermal excursions during post-weld heat treatment (PWHT) and on-site fabrication frequently compromise the integrity of Grade 92 steel. While hardness fluctuations are documented, the correlation between initial properties and long-term creep stability remains controversial. This study aims to evaluate the relationship between thermal history and subsequent creep performance. Heat treatments of T92 steel across a wide temperature range (760–1000 °C) were performed, followed by creep tests at 600 °C/130 MPa and microstructural characterization. Results reveal a non-monotonic evolution of hardness and strength, reaching a minimum at 850 °C due to martensitic lath recovery into ferrite, but nearly doubling the as-received (AR) values above 900 °C due to fresh martensite formation. Creep life drops to a minimum at 850 °C and recovers to the AR level at 950 °C. A significant “decoupling” occurs at 1000 °C, where the sample possesses the highest hardness but only exhibits one-fourth the life of the 950 °C sample. Superior performance stems from the retained M23C6 and its dynamic precipitation, which pins dislocations to form micro-lath structures. Conversely, 1000 °C facilitates full carbide dissolution, accelerating dislocation recovery. These findings emphasize precise PWHT control and demonstrate that a 950 °C rejuvenation treatment can restore over-tempered or damaged components. Full article
Show Figures

Figure 1

23 pages, 4812 KB
Article
Development of Simplified Mechanical Model for Welding Deformation in Multi-Pass Welding
by Wenda Wang, Shintaro Maeda, Kazuki Ikushima and Masakazu Shibahara
J. Manuf. Mater. Process. 2026, 10(3), 96; https://doi.org/10.3390/jmmp10030096 - 12 Mar 2026
Viewed by 308
Abstract
This paper proposes a simplified mechanical model to estimate transverse shrinkage and angular distortion in multi-pass butt welding. The simplified mechanical model is first derived for an I-groove joint by representing the heated weld region with one-dimensional bar elements and by enforcing force [...] Read more.
This paper proposes a simplified mechanical model to estimate transverse shrinkage and angular distortion in multi-pass butt welding. The simplified mechanical model is first derived for an I-groove joint by representing the heated weld region with one-dimensional bar elements and by enforcing force equilibrium to obtain closed-form expressions for pass-by-pass deformation increments and cumulative deformation. For non-I-groove joints, the same simplified mechanical model is applied by updating the layer partition and geometric parameters for each pass based on the pass-wise high-temperature region; the inherent shrinkage of each pass is evaluated from the heat input and an equivalent heated-layer thickness. The simplified mechanical model is validated for V-groove multi-pass joints by comparison with thermo-elastic-plastic finite element (FE) analyses and available experimental data, and for X-groove multi-pass joints by comparison with thermo-elastic-plastic FE analyses. In addition, a parametric study on the V-groove angle (40°–70°) for SUS316L demonstrates that the model captures the increasing trend of final transverse shrinkage with groove angle without a pronounced degradation in prediction accuracy. The results show that the simplified mechanical model reproduces both deformation histories and final values with good accuracy while using only a small set of input parameters and negligible computational cost, making it useful for early-stage welding procedure planning and quick parameter studies. Full article
Show Figures

Figure 1

13 pages, 47055 KB
Article
Properties of Laser-Welded Zr-Al-Co-Nb Bulk Metallic Glass
by Huei-Sen Wang, Chih-Chun Hsieh, Hou-Guang Chen, Shao-Chi Wu, Jason Shian-Ching Jang and Kuo-Jung Lee
Materials 2026, 19(6), 1078; https://doi.org/10.3390/ma19061078 - 11 Mar 2026
Viewed by 269
Abstract
In this study, the Nd:YAG laser process was employed with preselected welding parameters and varying initial welding temperatures (including room temperature, 10 °C, and 0 °C) for spot welding of (Zr53Al17Co29)Nb1 bulk metallic glass. Following welding, [...] Read more.
In this study, the Nd:YAG laser process was employed with preselected welding parameters and varying initial welding temperatures (including room temperature, 10 °C, and 0 °C) for spot welding of (Zr53Al17Co29)Nb1 bulk metallic glass. Following welding, the microstructure—including the parent material, heat-affected zone (HAZ), and weld fusion zone (WFZ)—as well as the microhardness, thermal properties, and corrosion resistance of the welds, were systematically investigated. Owing to the low glass-forming ability of the alloy, a small amount of Zr6CoAl2 phase was observed within the amorphous matrix at the center of the bulk metallic glass cast plate. After the laser welding, sub-micron or nanoscale Zr(AlxCo1−x)2 phases have formed in the HAZ of all welded samples, which significantly influenced the microhardness, thermal properties, and corrosion resistance in this region. As the initial welding temperature decreased, both the volume fraction and the density of the Zr(AlxCo1−x)2 phase were reduced. Notably, for the weld performed at the lowest initial temperature of 0 °C, small crystalline phases were detected only at approximately 70 μm below the surface of the HAZ. To clarify the effect of IWTs on corrosion resistance, welded samples were immersed in 6 M HCl at 35 °C for 72–120 h. Surface morphologies after corrosion were examined by SEM in the PM, HAZ, and WFZ. No evident pitting was detected after 72 h of immersion. After 120 h, pitting corrosion was observed on the HAZ surfaces of welds subjected to RT and 10 °C IWTs, whereas no obvious pitting was found at an IWT of 0 °C. The pit size and density in the HAZ increased with increasing IWT. In contrast, no pitting was observed in the WFZ under any IWT condition. Full article
(This article belongs to the Special Issue Properties and Behaviors of Metallic Materials)
Show Figures

Graphical abstract

16 pages, 6279 KB
Article
Joinability and Performance of Double-Flush Riveted and Resistance-Welded Lap Joints in High-Strength Steel Sheets
by Rui F. V. Sampaio, João P. M. Pragana, Ivo M. F. Bragança, Carlos M. A. Silva and Paulo A. F. Martins
J. Manuf. Mater. Process. 2026, 10(3), 91; https://doi.org/10.3390/jmmp10030091 - 4 Mar 2026
Viewed by 411
Abstract
The applicability of two different joining processes for producing lap joints from high-strength steel sheets is investigated, reflecting their increasing use in advanced lightweight structures with demanding performance requirements. The work is primarily focused on the joining-by-forming process known as double-flush riveting, evaluated [...] Read more.
The applicability of two different joining processes for producing lap joints from high-strength steel sheets is investigated, reflecting their increasing use in advanced lightweight structures with demanding performance requirements. The work is primarily focused on the joining-by-forming process known as double-flush riveting, evaluated in two variants: one utilizing forged holes and the other employing machined holes. The performance of these two variants is compared with conventional fusion-based resistance spot welding using lap joints fabricated from 2 mm high-strength low-alloy S500MC steel sheets under varying geometric and process conditions, with support from finite element modelling. Results indicate that both double-flush riveting variants produce similar joint cross-sectional geometries, but the machined hole variant simplifies sheet preparation and eliminates the need for a progressive tooling system. Tensile lap-shear and peel test results reveal that double-flush riveted joints with forged holes exhibit superior strength, attributed to strain hardening in the forged regions. Furthermore, for nuggets and rivets of equivalent size, both double-flush riveting variants surpass resistance spot welding in terms of the mechanical strength of the final joints. These results suggest that double-flush riveting represents a promising alternative for assembling high-strength steel sheets in lightweight structural applications. Full article
(This article belongs to the Special Issue Innovative Approaches in Metal Forming and Joining Technologies)
Show Figures

Figure 1

20 pages, 4913 KB
Article
A Study of Tau-Robot Configuration for Friction Stir Welding
by Despoina Almpani and George-Christopher Vosniakos
Machines 2026, 14(3), 289; https://doi.org/10.3390/machines14030289 - 4 Mar 2026
Viewed by 299
Abstract
This paper examines the use of high-rigidity Tau-robots in friction stir welding, where process loads are very high. The rigidity of Tau-robots increases at the expense of the workspace. Therefore, the right configuration of the Tau-robot is sought to reconcile rigidity and workspace [...] Read more.
This paper examines the use of high-rigidity Tau-robots in friction stir welding, where process loads are very high. The rigidity of Tau-robots increases at the expense of the workspace. Therefore, the right configuration of the Tau-robot is sought to reconcile rigidity and workspace requirements. This is studied by use of kinematics, followed by static and modal analysis. In particular, by extending an existing kinematic model employing free vectors, the robot workspace was derived in non-dimensional parametric form and was then maximized through evolutionary optimization. However, finite element static and modal analysis that were carried out subsequently may prove, as in a case demonstrated here, that the optimized configuration may not withstand high loads, typically axial forces of 15 kN and torques of 80 Nm, and it may also be susceptible to forced vibrations in the typical spindle rotation range up to 3000 rpm. As a rectification measure, it was shown how a modified configuration by placing robot kinematic chain bases further apart and shortening robot links achieves higher rigidity, axial displacement being reduced by one or two orders of magnitude to below 1 mm and increases critical modal frequency 3 to 5 times depending on the workspace position, of course sacrificing part of the workspace, i.e., reducing it 3-fold to enclose welding lines in a rectangle of dimensions 700 × 800 mm. In the quest for the appropriate robot configuration desired dimensions of parts to be welded and available standard components are briefly considered, too. Full article
Show Figures

Figure 1

77 pages, 14413 KB
Review
Welding Techniques and Microstructural Control for Dissimilar Cu/Al Joints
by Dong Jin, Juan Pu, Xiaohui Shi, Xiangping Xu, Zhaoqi Zhang and Fei Long
Crystals 2026, 16(3), 172; https://doi.org/10.3390/cryst16030172 - 2 Mar 2026
Viewed by 833
Abstract
Welding copper (Cu) and aluminum (Al) is highly demanded for lightweight and cost-effective manufacturing. However, it faces significant challenges. First, substantial differences in physical properties may lead to high residual stresses and distortion. Second, brittle intermetallic compounds (IMCs) readily form at the interface, [...] Read more.
Welding copper (Cu) and aluminum (Al) is highly demanded for lightweight and cost-effective manufacturing. However, it faces significant challenges. First, substantial differences in physical properties may lead to high residual stresses and distortion. Second, brittle intermetallic compounds (IMCs) readily form at the interface, severely compromising the joint’s mechanical properties and electrical conductivity. Third, the native oxide film on Al impedes effective wetting and bonding. Therefore, effective control over the interfacial microstructure of the welded joint is essential. This review provides a critical analysis and comparison of several typical welding techniques, including laser welding (LW), friction stir welding (FSW), ultrasonic welding (UW), brazing and soldering, and welding–brazing. These analyses focus on their process characteristics, joint microstructures, and corresponding formation mechanisms. Furthermore, this review synthesizes key strategies for enhancing joint quality, including process parameter optimization, introduction of functional interlayers, and external assistance, aimed at optimizing joint microstructure and minimizing defects. Based on the analysis, this work provides comparative insights into process selection and microstructure control, and highlights future directions: advancing novel methods such as magnetic pulse welding and transient liquid phase bonding; developing intelligent real-time process control to suppress brittle IMCs and associated defects; promoting sustainable practices and establishing standardized performance evaluation; and systematically investigating long-term reliability to support the industrial application of robust Cu/Al joints. Full article
(This article belongs to the Special Issue Surface Modification Treatments of Metallic Materials (2nd Edition))
Show Figures

Figure 1

29 pages, 19648 KB
Article
Unveiling the Mechanism of Heat-Input Control and Low-Carbon Welding Consumables on Suppression of Transition Zone Hard/Brittle Layers in Stainless Steel Clad Joints
by Fei Feng, Yanqing Fu and Jinsan Ju
Buildings 2026, 16(5), 975; https://doi.org/10.3390/buildings16050975 - 2 Mar 2026
Viewed by 257
Abstract
The formation of hard/brittle layers (HBLs) forming in proximity to the transition-layer interface during the welding process of stainless steel clad plates constitutes a pivotal element in determining the limitations on joint homogeneity and toughness. In order to elucidate their formation mechanisms and [...] Read more.
The formation of hard/brittle layers (HBLs) forming in proximity to the transition-layer interface during the welding process of stainless steel clad plates constitutes a pivotal element in determining the limitations on joint homogeneity and toughness. In order to elucidate their formation mechanisms and develop viable suppression routes, S31603/Q420qENH clad plates were utilised to fabricate five butt joints. This was achieved by varying the carbon content of the welding consumables and the heat input in the transition layer. A programme was conducted that combined microstructural and microhardness characterisation, mechanical testing, and numerical welding simulations. The findings indicate that base-layer consumables with comparatively elevated carbon content (w(C) ≥ 0.06%) expeditiously engender a constricted, localised hardened band in close proximity to the transition-layer interface. This is characterised by the predominance of martensite and Cr-rich compounds of the MxCry type, which function as the principal genesis of bending cracks. Conversely, the utilisation of low-carbon welding consumables has been shown to markedly reduce interfacial carbon activity and C-Cr segregation, thereby suppressing the precipitation of MxCry phases and effectively decreasing the overall thickness of the HBLs. Further numerical analysis shows that moderately increasing the transition-layer heat input lowers the T8/5 cooling rate and shifts the cooling path away from the martensite region. This transforms the interfacial microstructure from a localised hardened band into a more uniform, graded structure. These findings provide an engineerable process-control strategy for enhancing both microstructural uniformity and toughness in stainless steel clad joints. Full article
Show Figures

Figure 1

46 pages, 5499 KB
Review
Duplex-Phase Fe-Mn-Al-C Low-Density Steels: A Review on Their Alloy Design, Processing, Mechanical and Application Performances
by Peng Chen, Yan Lin, Liu-Jiang Yue, Rong Chen, Yi Wang, Ting-Jun Zhang and Xiao-Wu Li
Materials 2026, 19(5), 953; https://doi.org/10.3390/ma19050953 - 1 Mar 2026
Viewed by 420
Abstract
Duplex-phase low-density steels are attracting interest for lightweight structural applications, as reducing vehicle mass is an effective route to lower fuel consumption and emissions. This review summarizes recent progress in alloy design, processing, microstructure control, and performance of duplex-phase low-density steels. The roles [...] Read more.
Duplex-phase low-density steels are attracting interest for lightweight structural applications, as reducing vehicle mass is an effective route to lower fuel consumption and emissions. This review summarizes recent progress in alloy design, processing, microstructure control, and performance of duplex-phase low-density steels. The roles of major alloying elements are discussed in terms of phase stability and precipitation tendency, followed by an overview of typical processing routes from melting to hot and cold rolling and subsequent heat treatments used to tailor phase fractions and defect structures. Strengthening mechanisms are reviewed with emphasis on precipitation control, including the beneficial contribution of fine intragranular κ′ precipitates and the ductility penalty associated with coarse intergranular κ* films, as well as the use of B2-based particles for high specific strength. Deformation behavior is then discussed in terms of transformation-/twinning-induced plasticity (TRIP/TWIP), planar versus wavy slip, and strain partitioning between ferrite and austenite. Finally, key challenges are outlined, including quantitative interface-based mechanism description, gaps in service property data, stable industrial production and compositional uniformity, and the development of forming and welding windows for engineering implementation. Full article
Show Figures

Graphical abstract

25 pages, 4798 KB
Article
Mechanical Analysis and Verification Research on Asymmetric Four-Point Bending for the JCO Forming Process of LSAW Pipes
by Zhiyuan Zhang, Yi Liu, Zhiwen Lu, Junfang Shen, Yan Gao and Yize Chen
Materials 2026, 19(5), 914; https://doi.org/10.3390/ma19050914 - 27 Feb 2026
Viewed by 266
Abstract
Large-diameter longitudinal submerged arc welded (LSAW) pipes represent a critical component of long-distance oil and gas transmission pipelines. To enhance the forming efficiency of the JCO (J-shape to C-shape to O-shape) forming process for LSAW pipes, and to reduce residual straight segment in [...] Read more.
Large-diameter longitudinal submerged arc welded (LSAW) pipes represent a critical component of long-distance oil and gas transmission pipelines. To enhance the forming efficiency of the JCO (J-shape to C-shape to O-shape) forming process for LSAW pipes, and to reduce residual straight segment in order to minimize the ovality of the formed pipes, an asymmetric four-point air bending (AFB) process was proposed. In this process, one end of the sheet contacts the dies with a straight segment, while the other end contacts a circular arc segment. The distribution of bending moments and mechanical model under different bending stages were analyzed, and analytical formulas for the main forming indexes before and after springback were derived. Experimental and finite element simulation verification were conducted for the AFB process. The results indicated that the error between the experimental and simulation results and the theoretical results was small, and the variation trends were consistent. Furthermore, the ellipticity of the pipes formed by the AFB process was less than 0.66%, which is obviously lower than that of the pipe formed by the symmetric four-point air bending (SFB) process. The forming quality and production efficiency of the pipe is improved, thereby proving the feasibility and reliability of the AFB process and promoting the development of LSAW pipe JCO forming processes. Full article
(This article belongs to the Section Mechanics of Materials)
Show Figures

Figure 1

13 pages, 2846 KB
Article
Application of an Ultrasonic Vibration-Assisted Drawing Process to a Submersible Linear Motor Core
by Han Hu, Miaoyan Cao, Pengfei Song, Lijun Wu and Xubin Han
Machines 2026, 14(3), 259; https://doi.org/10.3390/machines14030259 - 25 Feb 2026
Viewed by 434
Abstract
The cylindrical submerged linear motor with the primary core used in traditional welded stacked 50ww470 non-silicon steel sheets faces many shortcomings. These include its structure being complex and difficult to manufacture, the process requiring stages such as steel sheet blanking, stacking, and welding, [...] Read more.
The cylindrical submerged linear motor with the primary core used in traditional welded stacked 50ww470 non-silicon steel sheets faces many shortcomings. These include its structure being complex and difficult to manufacture, the process requiring stages such as steel sheet blanking, stacking, and welding, and the iron core exhibiting large magnetic resistance and generating a lot of heat when the motor is working, reducing the motor efficiency. Therefore, an ultrasonic vibration-assisted (UVA) deep drawing process for multilayer sheets was proposed to replace the traditional process. The finite element analysis was carried out on single-layer sheet drawing. Using Abaqus software, we verified that UVA could improve the uniformity of the wall thickness of formed parts, and reduce wall thickness thinning and rebound; the core forming height is so low that there will be a larger rebound after forming. The “split ring” method was used to verify that ultrasonic vibration can suppress the rebound of the formed part. As the bottom of the core was made of six layers of silicon steel sheets, laminated and welded, the feasibility of different solutions was investigated by setting up a UVA deep drawing experimental platform to study single-, double-, three- and six-layer-sheets, and the forming quality and forming forces were analyzed. The final forming process was determined to require two deep-drawing three-layer sheets, and the forming part was successfully manufactured. Full article
(This article belongs to the Section Advanced Manufacturing)
Show Figures

Figure 1
