Search Results (1,437)

Search Parameters:
Keywords = W-band

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
24 pages, 10544 KB
Article
Synthetic Seismic Accelerogram Generation via Wavelet- Decomposed Conditional Generative Adversarial Networks
by Antonio Rocca, Luigi Laura and Marco Parrillo
Sensors 2026, 26(12), 3725; https://doi.org/10.3390/s26123725 - 11 Jun 2026
Viewed by 90
Abstract
The generation of synthetic seismic accelerograms is a critical problem in earthquake engineering, where the scarcity of strong-motion records, particularly for high-magnitude and near-fault scenarios, limits the reliability of structural analyses and probabilistic seismic hazard assessments. This paper presents a proof-of-concept wavelet-decomposed conditional [...] Read more.
The generation of synthetic seismic accelerograms is a critical problem in earthquake engineering, where the scarcity of strong-motion records, particularly for high-magnitude and near-fault scenarios, limits the reliability of structural analyses and probabilistic seismic hazard assessments. This paper presents a proof-of-concept wavelet-decomposed conditional Generative Adversarial Network (WD-cGAN) for the synthesis of seismic accelerograms that reproduce the physical and statistical properties of real ground-motion records. Unlike prior GAN-based approaches that rely on Fourier-domain decomposition, the proposed architecture decomposes each training signal into N wavelet sub-bands (experimentally N=7, six detail sub-bands D1–D6 and one approximation sub-band A6) using the Daubechies-4 (db4) discrete wavelet transform (DWT), assigning each sub-band to a dedicated discriminator. A novel energy-based weighting scheme αi modulates the relative contribution of each discriminator to the total generator loss, ensuring that physically dominant, low-frequency bands, which carry the bulk of seismic energy, receive proportionally higher training emphasis. Seismic moment magnitude Mw serves as the primary conditioning variable, enabling targeted synthesis for specific hazard scenarios. The model is implemented in Python v3.9 using PyTorch v.2.10 and trained on accelerograms drawn from the Italian INGV/ITACA v4.0 archive. Preliminary evaluation on 500 synthetic accelerograms across five magnitude classes provides evidence that the proposed wavelet-domain multi-discriminator scheme reproduces the essential spectral shape and non-stationary temporal structure of real ground-motion records within the considered magnitude range; full quantitative validation on a larger and more diverse corpus, rigorous comparison with competing methods, and extended multi-parameter conditioning are identified as the principal avenues for future work. Full article
(This article belongs to the Special Issue AI-Driven Intelligent Communication)
27 pages, 13236 KB
Article
A Novel Low-Power Mixed-Mode Universal Filter Design Using Multiple-Input Operational Transconductance Amplifiers
by Fabian Khateb, Pichai Suksaibul, Tomasz Kulej and Montree Kumngern
Technologies 2026, 14(6), 352; https://doi.org/10.3390/technologies14060352 - 11 Jun 2026
Viewed by 106
Abstract
This study introduces an innovative mixed-mode universal biquad filter implemented using multiple-input operational transconductance amplifiers (MI-OTAs). Based on the advantage of OTAs, which possess multiple inputs, the proposed mixed-mode universal filter using MI-OTAs can implement both non-inverting and inverting standard filtering functions such [...] Read more.
This study introduces an innovative mixed-mode universal biquad filter implemented using multiple-input operational transconductance amplifiers (MI-OTAs). Based on the advantage of OTAs, which possess multiple inputs, the proposed mixed-mode universal filter using MI-OTAs can implement both non-inverting and inverting standard filtering functions such as low-pass, high-pass, band-pass, band-stop, and all-pass filters in voltage-mode, transadmittance-mode, current-mode, and transimpedance-mode, which is the maximum capability of mixed-mode universal filters. The natural frequency of all filtering functions can be electronically controlled. Based on the multiple-input bulk-driven MOS transistor (MOST) technique, the OTA can also operate at very low supply voltage and provide wide-input voltage swing. The technique of MOST, operating in the weak inversion region, is used to achieve the low-power consumption of OTA. The MI-OTA circuit and mixed-mode universal filter were designed and simulated using Cadence Virtuoso, utilizing TSMC’s 65-nm CMOS technology. At a 0.5 V supply voltage, the filter demonstrated a simulated power consumption of 450 nW at a natural frequency of 156 Hz. In these ranges of power consumption and natural frequency, it can be expected that the proposed filter can be built as an versatile integrated circuit for low-frequency applications such as bio-signal processing. The design parameters were successfully validated through both post-layout extractions and discrete hardware prototyping utilizing commercially available LM13700N ICs. Full article
Show Figures

Figure 1

17 pages, 3060 KB
Article
Influence of Maltodextrin on the Physicochemical Properties of Chitosan- and Starch-Based Biopolymeric Matrices Blend for Active Packaging
by Mariangel Caro-Reyes, Carolina Arias-Gutiérrez, María Esther Treviño-Martínez, Aldo Rafael Vazquez-Arce, José Alfredo Beristain-Bautista, Carolina Caicedo and Abril Fonseca-García
Appl. Sci. 2026, 16(12), 5769; https://doi.org/10.3390/app16125769 - 8 Jun 2026
Viewed by 109
Abstract
Advances in polysaccharide-based polymer matrices have expanded the possibilities for developing controlled-release systems for bioactive compounds. This study evaluated the effect of incorporating maltodextrin (0, 1, 3, and 5% w/w) into films composed of thermoplastic starch (5%) and chitosan (2%) [...] Read more.
Advances in polysaccharide-based polymer matrices have expanded the possibilities for developing controlled-release systems for bioactive compounds. This study evaluated the effect of incorporating maltodextrin (0, 1, 3, and 5% w/w) into films composed of thermoplastic starch (5%) and chitosan (2%) was evaluated with the aim of improving their structural, thermal, mechanical, and surface properties. The films were obtained by solvent casting and characterized by XRD, TGA-DSC, FTIR, SEM, contact angle, and mechanical analysis. X-ray diffraction revealed greater organization in sample TPS-CH-M3 compared with TPS-CH-M0 (23,316.7) and TPS-CH-M5 (18,941.4), indicating a balanced semicrystalline structure. Thermal analyses showed an increase in the glass transition temperature from 63.0 °C to 72.6 °C and a shift in the main degradation step from 308 °C to 311 °C, indicating greater thermal stability. The contact angle decreased from 89.5° to 74°, confirming increased hydrophilicity. SEM micrographs revealed a homogeneous surface in TPS-CH-M0 and controlled roughness in TPS-CH-M3. Mechanical tests recorded the highest tensile strength (12.5 MPa) and elongation (18%) for TPS-CH-M3. FTIR spectra revealed physical interactions without the formation of new chemical bands, while colorimetry showed an increase in yellow hue, suggesting potential applications related to photosensitive materials. Overall, the incorporation of 3% maltodextrin optimized the functional properties of the matrices for potential controlled-release applications. Full article
(This article belongs to the Section Materials Science and Engineering)
Show Figures

Figure 1

19 pages, 5754 KB
Article
Characterization of Novel Partially Bio-Based, Waste-Derived Composites for Thermal and Acoustic Performance in Buildings
by Mohamed Ali, Redhwan Almuzaiqer, Hassan Alshehri, Mohammed A. Alanazi, Turki Almudhhi and Abdullah Nuhait
Polymers 2026, 18(11), 1401; https://doi.org/10.3390/polym18111401 - 4 Jun 2026
Viewed by 341
Abstract
New partially bio-based, waste-derived composites are manufactured from date palm surface fibers (DPSF), waste coffee filters (CFP), and disposable medical isolation gowns (MIG). These three disposable raw materials fill landfills and create an environmental problem. Therefore, the objective of this current study is [...] Read more.
New partially bio-based, waste-derived composites are manufactured from date palm surface fibers (DPSF), waste coffee filters (CFP), and disposable medical isolation gowns (MIG). These three disposable raw materials fill landfills and create an environmental problem. Therefore, the objective of this current study is to use such materials in creating promised thermal insulation and sound absorption boards. Six hybrid composites with different compositions were made using Polyvinyl acetate (PVA) wood adhesive as a binder. Three of them were made of DPSF and MIG, and the other three were composed of DPSF and the CFP. Different tests were performed on the developed composites, such as thermal conductivity measurements, sound absorption and noise reduction determination, surface morphology image analysis, thermogravimetric analysis, and three-point bending tests. The results showed that the thermal conductivity coefficients for the hybrids DPSF + MIG and DPSF + CFP are in the ranges 0.0493–0.0613 W/(m·K) and 0.052–0.065 W/(m·K), respectively, over the temperature range 24–82 °C. The sound absorption coefficient (SAC) is greater than 0.4 for all composites at frequency bands greater than 500 Hz. The noise reduction coefficient (NRC) is ≥0.45 for all composites. Surface morphology images of the composites were also reported. The results also show that the composites are thermally stable at temperatures up to 258.3 °C. The flexural modulus ranges between 5.0 and 8.46 MPa for the medical isolation gown composites and 2.49 and 5.57 MPa for the coffee filter paper composites. The hybrid composites have a lower moisture content of 0.51% to 2.5%. These promising results support the use of these composites for thermal insulation and sound absorption in building construction as alternatives to conventional thermal insulations derived from crude fuels. Full article
Show Figures

Figure 1

22 pages, 8918 KB
Article
FTIR Spectroscopy Coupled with Principal Component Analysis for Rapid Screening of Melamine Adulteration in Brown Rice Flour
by Cristina Pintilii, Leonard Mihaly Cozmuta, Zsolt Szakacs and Anca Mihaly Cozmuta
Molecules 2026, 31(11), 1912; https://doi.org/10.3390/molecules31111912 - 2 Jun 2026
Viewed by 254
Abstract
Food adulteration with melamine represents a serious threat to food safety due to its toxic effects and its ability to falsely elevate protein values measured by nitrogen-based methods. Visual inspection and visible reflectance spectroscopy are unsuitable for identifying low-level adulteration. This study evaluates [...] Read more.
Food adulteration with melamine represents a serious threat to food safety due to its toxic effects and its ability to falsely elevate protein values measured by nitrogen-based methods. Visual inspection and visible reflectance spectroscopy are unsuitable for identifying low-level adulteration. This study evaluates Fourier Transform Infrared (FTIR) spectroscopy combined with chemometric tools for the identification of melamine in brown rice flour adulterated at 0–2.00% (w/w). Under the tested conditions, no clear FTIR-detectable interactions between melamine and starch or proteins were observed, suggesting that melamine primarily acts as a physical admixture. Characteristic melamine absorption bands were identified at 3466, 3415, 1431, and 810 cm−1. Spectral normalization and second-order derivative processing improved sensitivity and enabled quantitative calibration models. The method achieved a limit of detection of 1408 mg/kg. Although this value is above the regulatory threshold of 2.5 mg/kg, the approach provides a rapid, non-destructive screening tool for identifying highly adulterated samples and prioritizing them for confirmatory chromatographic or mass spectrometric analysis. Overall, FTIR spectroscopy combined with chemometric analysis offers an efficient first-line approach for identification of melamine adulteration in brown rice flour. Full article
(This article belongs to the Special Issue Application of Spectroscopy and Chemometrics in Food Analysis)
Show Figures

Figure 1

18 pages, 18915 KB
Article
A 140 GHz Two-Channel Transmitter in 40 nm Bulk CMOS
by Junkyu Lee, Changjung Lee, Jaegwan Kim and Munkyo Seo
Electronics 2026, 15(11), 2349; https://doi.org/10.3390/electronics15112349 - 28 May 2026
Viewed by 190
Abstract
This paper presents a 140 GHz two-channel transmitter in 40 nm bulk CMOS technology for D-band wireless communication systems. The transmitter employs a direct upconversion architecture with IQ Gilbert cell mixers and a shared ×9 frequency multiplier for local oscillator (LO) generation. [...] Read more.
This paper presents a 140 GHz two-channel transmitter in 40 nm bulk CMOS technology for D-band wireless communication systems. The transmitter employs a direct upconversion architecture with IQ Gilbert cell mixers and a shared ×9 frequency multiplier for local oscillator (LO) generation. The Lange coupler generates quadrature LO signals for I and Q paths, while the two-way four-stage differential power amplifier with cascade topology provides high output power. On-wafer measurement at 140 GHz LO frequency demonstrates a 9.9 dB conversion gain with a 5.5–6.1 GHz 3 dB bandwidth. The measured saturated output power is 10.1 dBm with an output 1 dB compression point of 6.5 dBm. The IQ imbalance remains within 2 dB across the 3 dB bandwidth. The fabricated transmitter occupies a chip area of 1.68 mm2 and consumes 435 mW from a 1 V supply. The power density of 6.09 mW/mm2 is the highest among reported CMOS-based D-band transmitters. The dual-channel architecture with shared LO generation enables MIMO transmission, spatial multiplexing, and diversity techniques while maintaining compact size and competitive power efficiency for high data rate wireless applications in the D-band frequency range. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

26 pages, 3385 KB
Article
Evaluation of the Properties of NaC/PVA/CA Composite Films for Grape Packaging
by Sema Samatya Yılmaz, Melek Demirel, Selda Daler, Rezzan Kasım, Mehmet Ufuk Kasım and Ayşe Aytaç
Coatings 2026, 16(6), 642; https://doi.org/10.3390/coatings16060642 - 25 May 2026
Viewed by 384
Abstract
In this study glycerol-plasticized sodium caseinate/polyvinyl alcohol NaC/PVA composite films were prepared by solution casting, and the effects of incorporating caffeic acid powder at different concentrations 0% 2.5% 5% and 15% w/w on structural mechanical barrier and postharvest performance were investigated. [...] Read more.
In this study glycerol-plasticized sodium caseinate/polyvinyl alcohol NaC/PVA composite films were prepared by solution casting, and the effects of incorporating caffeic acid powder at different concentrations 0% 2.5% 5% and 15% w/w on structural mechanical barrier and postharvest performance were investigated. Caffeic acid (CA) (3,4-dihydroxycinnamic acid) is a naturally occurring phenolic compound commonly found in plant tissues and food sources such as apples, blueberries, and coffee. FTIR analysis revealed that shifts and broadening in OH bands indicated hydrogen bonding interactions between caffeic acid and the polymer matrix influencing structural organization. The pure NaC/PVA film exhibited high WVTR due to glycerol while maintaining low OTR. Adding 2.5% caffeic acid reduced WVTR but increased OTR through structural disruption. At 5% a continuous hydrogen-bonded network formed, restricting chain mobility and reducing free volume, thus lowering WVTR and OTR while preserving mechanical integrity. SEM micrographs revealed that high CA concentrations, particularly at 15%, led to aggregation-induced partial phase separation and consequent performance loss. Packaging treatments mainly affected physical and color attributes rather than primary metabolites. The NaC/PVA/5CA reduced weight loss and delayed sugar accumulation compared with NaC/PVA. Sugars peaked earlier in NaC/PVA but increased continuously in NaC/PVA/5CA, reaching maximum at the final storage stage. These findings indicate concentration-dependent mechanisms and highlight the potential of caffeic acid-based active packaging to regulate metabolism and extend postharvest quality. Overall results support its application in sustainable packaging systems for improved shelf life management. Full article
Show Figures

Figure 1

17 pages, 5267 KB
Article
A 3.3–8.0 GHz Wideband LNA with a 0.81–1.09 dB Noise Figure in 0.15 µm GaAs pHEMT Technology
by Seonghun Jo, Ishath Harshika Hewa Maddumage, Jaehun Lee, Gwanghyeon Jeong and Dong-Ho Lee
Electronics 2026, 15(11), 2259; https://doi.org/10.3390/electronics15112259 - 23 May 2026
Viewed by 490
Abstract
This paper presents the design and fabrication of a wideband low-noise amplifier (LNA) covering C-band, using the 0.15 µm GaAs pHEMT process. To achieve both low noise performance and wide matching characteristics, a two-stage cascaded architecture is implemented. In the first stage, circular [...] Read more.
This paper presents the design and fabrication of a wideband low-noise amplifier (LNA) covering C-band, using the 0.15 µm GaAs pHEMT process. To achieve both low noise performance and wide matching characteristics, a two-stage cascaded architecture is implemented. In the first stage, circular inductors and an inductive source degeneration technique are employed to minimize the noise figure (NF) while ensuring wideband input matching. Furthermore, an RC feedback structure is incorporated to effectively enhance the stability of the amplifier. The proposed LNA operates under a supply voltage of 3.3 V and a gate bias of 0.35 V, with a total DC power consumption of 69.3 mW. The fabricated MMIC occupies a total chip area of 1.98 mm2, including the probing pads. Measurement results demonstrate that the LNA achieves an NF of 0.81–1.09 dB and a gain of over 20.1 dB in the frequency range of 3.3–8.0 GHz. The input and output return losses are maintained over 10 dB and 9.7 dB, respectively. Full article
(This article belongs to the Special Issue RF/Microwave Integrated Circuits Design and Application)
Show Figures

Figure 1

15 pages, 12002 KB
Article
Miniaturized Flexible Corrosion-Resistant Tag Antenna with Folding Arm Based on Graphene Film
by Meng Zeng, Xin Zhao, Hongyu Zhou, Jinling Li, Rongguo Song, Haoran Zu and Daping He
Micromachines 2026, 17(5), 634; https://doi.org/10.3390/mi17050634 - 21 May 2026
Viewed by 266
Abstract
Radio frequency identification (RFID) technology has been widely adopted in a variety of practical applications. Usually, the size of a passive tag antenna largely determines the read performance of tag. However, excessively large tag antennas can hinder their practical application and a tag [...] Read more.
Radio frequency identification (RFID) technology has been widely adopted in a variety of practical applications. Usually, the size of a passive tag antenna largely determines the read performance of tag. However, excessively large tag antennas can hinder their practical application and a tag that is too small has poor performance. In this paper, a compact, flexible and corrosion-resistant folding dipole tag antenna is proposed, which has a geometrical dimension of 24 mm × 13 mm (0.074λ0×0.040λ0). It is designed on only one surface of a flexible polyethylene terephthalate (PET) substrate, which can be folded. The paper proposes a single-sided laser-patterned GAF/PET flexible RFID tag that is mechanically folded to form a backside dipole arm without vias, targeting compact and corrosion-resistant UHF RFID operation. Changing the size of the folding arm can effectively adjust the resonant frequency and impedance of the tag antenna. A stepped radiation arm is used to extend the current path and lower the resonance frequency. The capacitance and inductance effects introduced by loading a T match for reducing the resonant frequency of the tag to the useful UHF RFID band. Finally, it can achieve a power transfer coefficient of 99.9% and exhibit high impedance matching between the tag antenna and the chip. The proposed tag antenna uses graphene-assembled film (GAF) as its conductor material. Thanks to the physicochemical properties of GAF, the proposed tag antenna maintains stable radiation performance even after prolonged exposure to acidic (5 wt%), alkaline (5 wt%), and salt (5 wt%) corrosion, as well as more than 1000 mechanical bending cycles. When the EIRP of the reader is 2.2 W, the maximum read range of the tag in the 800–1000 MHz is 1.38 m. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

20 pages, 5678 KB
Article
An Ultra-Wide Gain Range Dual-Mode Variable Gain Amplifier
by Jiahao Tian, Bei Cao, Hongyue Sun, Jiaheng Li and Jiahao Li
Electronics 2026, 15(10), 2103; https://doi.org/10.3390/electronics15102103 - 14 May 2026
Viewed by 206
Abstract
A dual-mode variable gain amplifier (VGA) with a wide-dynamic-range is proposed in this paper. The VGA is designed in a 0.18 μm CMOS process, and it has a body-driven variable load cell and binary gain array structure to implement both the digitally stepped [...] Read more.
A dual-mode variable gain amplifier (VGA) with a wide-dynamic-range is proposed in this paper. The VGA is designed in a 0.18 μm CMOS process, and it has a body-driven variable load cell and binary gain array structure to implement both the digitally stepped programmable gain amplifier (PGA) mode and the analog-controlled VGA mode. This design removes additional digital conversion modules when integrated into an automatic gain control (AGC) loop, which simplifies the whole system architecture significantly. The design is also able to address several limitations of conventional VGAs, such as a single control mode, low AGC compatibility, and a narrow gain range. The simulation results after post-layout indicate that at PGA mode, the design has an ultra-wide gain band of −0.03 to 126.9 dB with a constant gain step of 1 dB. And in VGA mode, it allows smooth, continuous gain adjustment over a large range of −25.3 dB to 187.4 dB. The bandwidth of −3 dB is more than 45 MHz in both modes. The whole VGA uses 1.026 mW and has a core size of 0.011 mm2. The output 1-dB compression point (OP1dB) was −1.57 dBm at minimum gain in the PGA mode and −4.02 dBm in the VGA mode. Besides, PVT analysis, Monte Carlo simulations and AGC system-level verification are evident enough to prove that the suggested VGA has high immunity to PVT (Process, Voltage, Temperature) variations, stable processes and high practicality in engineering applications. Full article
Show Figures

Figure 1

13 pages, 1346 KB
Article
High-Stability Thulium-Doped All-Fiber Laser at 2050 nm
by Hanchuang Peng, Zhipeng Ding, Di Xin, Fengxin Dong, Xuyan Zhou, Hongbo Zhang and Wanhua Zheng
Photonics 2026, 13(5), 482; https://doi.org/10.3390/photonics13050482 - 13 May 2026
Viewed by 577
Abstract
High-power thulium-doped fiber lasers (TDFLs) operating near 2050 nm are of great interest for applications including atmospheric gas sensing and free-space optical communication owing to the favorable atmospheric transmission and the strong absorption bands of carbon dioxide (CO2). Here, we report [...] Read more.
High-power thulium-doped fiber lasers (TDFLs) operating near 2050 nm are of great interest for applications including atmospheric gas sensing and free-space optical communication owing to the favorable atmospheric transmission and the strong absorption bands of carbon dioxide (CO2). Here, we report an all-fiber high-power TDFL based on a 793 nm-pumped master oscillator power amplifier (MOPA) architecture. The system comprises a custom-built linear-cavity seed laser and two amplification stages. With a maximum pump power of 818 W, the final amplifier delivers 501 W at 2050 nm with a slope efficiency of 51%. Stable operation is confirmed over two hours at full power, with an RMS power fluctuation of only 0.47%. The measured beam quality factors M2 are 1.31 and 1.27 in the horizontal and vertical directions, respectively, indicating near-diffraction-limited performance. The demonstrated system combines high output power, excellent stability, and good beam quality, and thus provides a promising laser source for 2 μm high-performance applications. Full article
(This article belongs to the Special Issue Progress in Ultra-Stable Laser Source and Future Prospects)
Show Figures

Figure 1

26 pages, 19839 KB
Article
Theoretical Investigation of Twist-Angle-Dependent Photoelectric Properties in Twisted Bilayer WSe2
by Yunpei Ma, Yuchun Wang, Haiwei Zhang, Jing Yu and Jingang Wang
Molecules 2026, 31(10), 1627; https://doi.org/10.3390/molecules31101627 - 12 May 2026
Viewed by 482
Abstract
The twist angle serves as a geometric tuning parameter in two-dimensional layered materials, enabling modulation of interlayer coupling and band structures without altering the chemical composition. In this work, six commensurate twisted bilayer WSe2 configurations with rotation angles of 0°, 9.4°, 13.14°, [...] Read more.
The twist angle serves as a geometric tuning parameter in two-dimensional layered materials, enabling modulation of interlayer coupling and band structures without altering the chemical composition. In this work, six commensurate twisted bilayer WSe2 configurations with rotation angles of 0°, 9.4°, 13.14°, 21.9°, 27.8°, and 60° were systematically investigated using first-principles density functional theory. Structural optimization, together with calculations of electronic structures, density of states, charge redistribution, effective masses, and optical properties, was performed. The results show that AA (0°) and 2H (60°) stackings exhibit the largest and smallest interlayer separations, respectively, whereas intermediate twist angles yield similar average spacings but distinct local stacking registries. All configurations remain indirect-gap semiconductors, with the valence band maximum located at K and the conduction band minimum near the Q point along the K–Γ path. The band gap increases from 1.450 eV at 0° to 1.579 eV at 27.8°, before decreasing to 1.333 eV at 60°, indicating strong twist-angle modulation of interlayer coupling. Density-of-states analysis shows that the valence-band edge mainly originates from Se-p and W-d hybridized states, whereas the conduction-band edge is dominated by W-d states, with intermediate angles exhibiting enhanced band folding and localization features. Charge-density analyses further reveal notable interfacial charge redistribution, which is most pronounced at 9.4°. Optical responses in the in-plane directions are nearly identical and significantly stronger than those along the out-of-plane direction. Optical absorption mainly occurs in the ultraviolet region, with band-edge features appearing in the near-infrared range. Intermediate twist angles exhibit broader dielectric responses in the visible region and extended long-wavelength tails, indicating enhanced interband transition channels. These results demonstrate that twist-angle engineering enables effective tuning of electronic and optical properties in bilayer WSe2, providing theoretical guidance for the design of tunable optoelectronic devices. Full article
(This article belongs to the Section Materials Chemistry)
Show Figures

Figure 1

17 pages, 26381 KB
Article
A High-Efficiency 2 W Ka-Band GaAs Power Amplifier with Phase Compensation for 5G Phased Array Systems
by Dongyang Yan, Yang Zhang, Dries Peumans, Mark Ingels and Piet Wambacq
Electronics 2026, 15(10), 2053; https://doi.org/10.3390/electronics15102053 - 11 May 2026
Viewed by 309
Abstract
This work presents a high-efficiency and linear Ka-band power amplifier (PA) designed in a 0.13 μm depletion-mode GaAs pHEMT process, targeting 5G phased-array systems. To minimize passive losses, the output matching network employs an all-transmission-line architecture. Phase mismatches among output branches [...] Read more.
This work presents a high-efficiency and linear Ka-band power amplifier (PA) designed in a 0.13 μm depletion-mode GaAs pHEMT process, targeting 5G phased-array systems. To minimize passive losses, the output matching network employs an all-transmission-line architecture. Phase mismatches among output branches are compensated directly within the interstage and output matching networks via tailored distributed and capacitive components. Device-level reliability is proactively addressed by maintaining adequate voltage headroom under worst-case load mismatch, based on voltage standing wave ratio (VSWR) analysis. The amplifier achieves a peak small-signal gain of 15.8 dB at 27 GHz. Under continuous-wave excitation at 27 GHz, it delivers 32.9 dBm output power at the 1-dB compression point with 32.8% power-added efficiency (PAE), reaching a peak saturated output of 33.2 dBm and 35.9% PAE. When driven by a 64-QAM signal with a 250 MHz symbol rate, the PA maintains an average output power of 26.3 dBm and an average PAE of 12.2%, with an rms EVM of 3.4% and an SNR of 25.5 dB. Full article
Show Figures

Figure 1

13 pages, 1659 KB
Article
Metasurface-Enhanced Tellurium Thin-Film Mid-Infrared Photodetector
by Yuanze Hong, Zhixiang Xie, Yuhang Hu, Zhipeng Wei, Xiaohua Wang and Lin Pan
Photonics 2026, 13(5), 474; https://doi.org/10.3390/photonics13050474 - 10 May 2026
Viewed by 456
Abstract
The design of photodetectors tailored to specific wavelengths in the mid-infrared (MIR) band serves as a foundational enabler for advancements in scientific research, industrial inspection, and environmental monitoring. Metasurfaces, composed of artificially engineered subwavelength unit cells, enable precise tailoring of light–matter interactions, achieving [...] Read more.
The design of photodetectors tailored to specific wavelengths in the mid-infrared (MIR) band serves as a foundational enabler for advancements in scientific research, industrial inspection, and environmental monitoring. Metasurfaces, composed of artificially engineered subwavelength unit cells, enable precise tailoring of light–matter interactions, achieving near-unity absorption at target wavelengths and thereby significantly boosting the sensitivity and spectral selectivity of MIR photodetectors. In this study, we developed a double-C open-loop metasurface and optimized its geometric parameters to realize high-efficiency absorption at 4 μm and 6 μm. Utilizing Te thin films fabricated via magnetron sputtering, we constructed a metasurface-enhanced mid-infrared photodetector based on Te thin films. The optimized metasurface structure enhances the light absorption of the Te thin film by a factor of eight within the target wavelength band. Ultimately, the metasurface-enhanced Te-based device achieved responsivities of 10.5 A/W and 13.7 A/W at 4 μm and 6 μm, respectively, representing enhancements of 3.6-fold and 3-fold compared to the initial Te thin-film device. This work provides a critical reference for enhancing the detection performance of infrared photodetectors at specific wavelengths through precise nanophotonic design. Full article
(This article belongs to the Special Issue Optical Metasurfaces for Next-Generation Communication and Sensing)
Show Figures

Figure 1

14 pages, 5355 KB
Article
Synergistic Sn-Induced Band Convergence in Mn-Doped p-Type PbTe Enables High Thermoelectric Performance
by Zhilong Zhao, Xiang An, Fan Feng, Jiaxing Luo, Zijian Lin, Chuke Zhao and Ran Ang
Materials 2026, 19(10), 1947; https://doi.org/10.3390/ma19101947 - 9 May 2026
Viewed by 251
Abstract
The inherent coupling of electrical and thermal transport parameters poses a significant challenge for enhancing the thermoelectric figure of merit (zT) in PbTe-based materials. Herein, we report a synergistic co-doping strategy employing Mn and Sn in p-type PbTe to simultaneously optimize [...] Read more.
The inherent coupling of electrical and thermal transport parameters poses a significant challenge for enhancing the thermoelectric figure of merit (zT) in PbTe-based materials. Herein, we report a synergistic co-doping strategy employing Mn and Sn in p-type PbTe to simultaneously optimize the band structure and suppress lattice thermal conductivity. Sn incorporation not only induces additional Pb vacancies, thereby increasing hole carrier concentration, but also facilitates the enhanced solubility of Na dopants within the matrix, as confirmed by microscopic and compositional analyses. More importantly, the cooperative effect of Mn and Sn substantially enhances convergence between the L and Σ valence bands, leading to an increased density-of-states effective mass and a pronounced enhancement of the Seebeck coefficient. Meanwhile, multiscale lattice defects introduced by co-doping effectively scatter phonons over a broad frequency spectrum, reducing the lattice thermal conductivity to near the theoretical minimum (~0.5 W m−1 K−1). As a result, the Pb0.91−xNa0.04Mn0.04SnxTe system achieves an exceptional peak zT of ~2.2 at 823 K, a high room-temperature zT of ~0.4, and a favorable average zT of ~1.3 over the temperature range of 303–823 K. Notably, the room-temperature zT of ~0.4 represents the highest value reported to date for p-type PbTe in the room-temperature region. This work demonstrates that Mn and Sn co-doping provides a compelling pathway for realizing both high peak and average thermoelectric performance, advancing PbTe-based materials toward practical waste-heat recovery applications. Full article
Show Figures

Graphical abstract
