The microbiological safety of milk can be ensured through heat processing; however, this method has a negative effect on the sensory profile of this food product. Emerging technologies could be used as an alternative process for guaranteeing innocuity and maintaining sensory changes. An alternative is to evaluate pulsed electric field (PEF) electroporation, which is a method of processing cells using short pulses of a strong electric field. PEF has the potential to be a type of alternative low-temperature pasteurization process that consists of high-frequency voltage pulsations. Specifically, the presented work is a proof of concept for the design of a converter capable of generating a PEF to feed a load that meets the impedance characteristics of milk. The proposed converter is simulated using PLECS software (4.9.6 version) under impedance change scenarios that emulate variations in milk throughout the entire process. This research proposes the modification of a classic Vienna rectifier (adding an MBC—Multilevel Boost Converter structure) to supply a pulsating signal that could be used for low-temperature processes of milk to guarantee proper pasteurization. The characteristics of the generated high-voltage pulse make it feasible to quickly process the real sample. The control law design considers a regulation loop to achieve a voltage in the range of kV and a switching-type control law that activates switches in MMC arrays. These switches are activated randomly to avoid transients that cause significant stress on them. Full article

Taking a Vienna rectifier as the research object, the power mathematical model based on a switching function is established according to its working principle. A sliding mode variable structure control algorithm based on the reaching law is examined in order to address the issues of the slow response speed and inadequate anti-interference of classical PI control in the face of abrupt changes in the DC-side load. In response to the sluggish convergence rate and inadequate chattering suppression of classical integer order sliding mode control, a fractional order exponential reaching law sliding mode, direct power control approach with rapid convergence is developed. The fractional calculus is introduced into the sliding mode control, and the dynamic performance and convergence speed of the control system are improved by increasing the degree of freedom of the fractional calculus operator. The method of including a balance factor in the zero-sequence component is employed to address the issue of the midpoint potential equilibrium in the Vienna rectifier. Ultimately, the suggested control is evaluated against classical PI control through simulation analysis and experimental validation. The findings indicate that the proposed technique exhibits rapid convergence, reduced control duration, and enhanced robustness, hence augmenting its resistance to interference. Full article

To address the challenges in establishing the state transfer matrix and the complexity of eigenvalue calculation in determining the multi-parameter stability boundaries of high-order nonlinear Vienna rectifiers, a novel numerical computation method is proposed in this paper. This method leverages a numerical stability criterion and a grid variable step search to efficiently calculate these stability boundaries. The small-signal model of the Vienna rectifier is derived by constructing the time-varying state transfer matrix using the periodic solution of the harmonic balance method. Eigenvalues are rapidly calculated via the periodic numerical solution of the state transfer matrix. The proposed parameter sensitivity-based grid variable step search method ensures a fast and accurate determination of stability boundaries. A hardware experimental setup is established to validate the stability boundaries of the Vienna rectifier under various parameter variations, including load, component, and control changes. The experimental results closely match the simulations, confirming the correctness and superiority of the proposed method. Full article

This paper proposes an improved zero-current distortion compensation (IZCDC) method for the Vienna rectifier. The conventional zero-current distortion compensation (ZCDC) method modifies the reference voltages by adding an offset voltage to compensate for the zero-current distortion (ZCD). However, the reference voltages occasionally exceed the linear modulation region by the offset voltage added at the driving start-point of the Vienna rectifier, where the modulation index of phase voltage is relatively large. This causes a hard-start of the Vienna rectifier accompanied by a serious surge and distortion in the phase current. In this paper, the IZCDC method is proposed for achieving the soft-start of the Vienna rectifier. When the overmodulation occurs, the proposed method modifies the conventional offset voltage to the IZCDC component, which is involved in the adjustment of the variance of the phase current, only for a certain phase among the three phases. As the IZCDC component regulates the variance of the phase current to zero, surge and distortion in the phase current can be mitigated. As a result, the Vienna rectifier starts its operation softly while ensuring its normal operation in the transients. The effectiveness of the proposed method is verified through simulations and experimental results. Full article

Due to the high permeability characteristics of power electronic devices connected to the distribution grid, the potential harmonic coupling problem cannot be ignored. The Vienna rectifier is widely utilized in electric vehicle charging stations and uninterruptible power supply (UPS) systems due to its high power factor, adaptable control strategies, and low voltage stress on power switches. In this paper, the three-level Vienna rectifier is studied, and the harmonic state-space (HSS) method is used to model the rectifier. The proposed model can reflect the harmonic transfer characteristics between the AC current and the DC output voltage at various frequencies. Finally, the model’s accuracy and the corresponding harmonic characteristics analysis are further verified by simulation and experimental test results. The results show that the harmonic state-space modeling used for Vienna rectifiers can reflect the harmonic dynamics of the AC and DC sides, which can be used in stability analysis, control parameter design, and other related fields. Full article

Regulating LED current and voltage is critical to maintaining a constant luminous flux in AC- or DC-powered LED lighting circuits. Today, users require constant current drivers that can provide a wide range of output voltages to drive different numbers of series-connected LED arrays. This work proposes an LED driver by combining an isolated SEPIC converter operating in the continuous conduction mode (CCM) and a modified Vienna rectifier. The proposed LED driver offers a single-switch control structure by adding a Vienna rectifier to the integrated SEPIC-FLYBACK converter. This driver structure provides many advantages over traditional bridge rectifier structures. The prototype circuit was tested in an 18 W continuous current mode (CCM) to verify its feasibility. As a result of the values obtained from both simulation and prototype circuit models, it has been shown to provide many of the following advantages: 95% high efficiency, high reliability, 4% low total harmonic distortion, 97% high power factor, and 70 V low switching voltage. This work meets class C 3-2 and IEC 61000 standards. Full article

This work presents the experimental validation of a 40 kW electric vehicle (EV) charger. The proposed system comprises two 20 kW modules connected in parallel at the input and output. Each module has two stages—as a grid converter Vienna Rectifier (VR) was chosen, and as an isolated DC/DC stage, two Series-Resonant Dual-Active-Bridges (SRDABs) in input-series-output-parallel (ISOP) configurations were applied. The AC/DC and DC/DC stages were enclosed in 2U rack standard housing. A bipolar DC-link with ±400 V DC voltage was employed to connect both stages of the charger module while the charger’s output is dedicated to serving 800 V batteries. VRs operated at 66 kHz switching frequency and the SRDABs operated at 100 kHz. The converters used in the charger structure were based on silicon carbide (SiC) power devices. The description and parameters of the built hardware prototypes of both—AC/DC and DC/DC—converters are provided. Moreover, the experimental validation of each stage and the whole charging system, including oscilloscope waveforms and power analyzer measurements at nominal power, are included. Such a configuration enables energy conversion with high efficiency without a negative impact on the grid and high-quality grid waveforms. Full article

This paper presents a novel single-phase modified Vienna rectifier (MVR) for the harmonic mitigation and power factor improvement of an induction heating (IH) system. The latter employs a high-frequency resonant inverter that is responsible for the generation of high-frequency harmonics, which, in turn, deteriorates the power quality. This mitigation must be done in accordance with harmonic regulations such as IEEE Std. 519-2014,IEC-555, and EN 61000-3-2, etc. Consequently, an MVR is placed between the power supply and the IH system. The proposed novel MVR topology overcomes the limitations of conventional Vienna rectifiers, such as their unbalanced voltage across output capacitors, high ripple at the output DC bus, and high THD in the supply current, etc. The efficacy of the proposed model has been verified by a series of simulations in PSIM. It is followed by a hardware validation using an Arduino Uno ATmega328 digital controller on a 1.2 kW experimental prototype of the IH system. The simulation and experimental results of the power quality indices comply with the IEEE-519 standards. Full article

Although a switched reluctance generator (SRG) is not the mainstream wind generator, it possesses the application potential and is worth developing for its many structural merits and high developed power ability. This paper presents a wind SRG-based bipolar DC microgrid having grid-connected and plug-in energy supporting functions. First, a surface-mounted permanent magnet synchronous motor (SPMSM)-driven wind turbine emulator (WTE) is established. Next, the wind SRG with an asymmetric bridge converter is developed. Good generating characteristics are obtained through proper designs of power circuit, commutation mechanism, external excitation source, voltage and current controllers. Third, a DC/DC boost interface converter and a bipolar voltage balancer are constructed to establish the 500 V microgrid bipolar DC-bus. To preserve the microgrid power supplying quality, a battery energy storage system (BESS) with bidirectional DC/DC interface converter is equipped. A dump load leg is added across the bus to limit the DC-bus voltage under energy surplus condition. In load side, a three-phase bidirectional load inverter is developed, which can be operated as a single-phase three-wire (1P3W) inverter or a three-phase three-wire (3P3W) inverter. Good sinusoidal voltage waveform and regulation characteristics are obtained using the proportional-resonant (PR) control. The microgrid to load and microgrid to grid operations are conductible. Finally, to further improve the powering reliability of microgrid, a three-phase T-type Vienna switch-mode rectifier (SMR) based plug-in energy supporting scheme is developed. When the microgrid energy shortage occurs, the possible harvested energy can be used to supply the microgrid. Full article

Emerging electric vehicle (EV) technology requires high-voltage energy storage systems, efficient electric motors, electrified power trains, and power converters. If we consider forecasts for EV demand and driving applications, this article comprehensively reviewed power converter topologies, control schemes, output power, reliability, losses, switching frequency, operations, charging systems, advantages, and disadvantages. This article is intended to help engineers and researchers forecast typical recharging/discharging durations, the lifetime of energy storage with the help of control systems and machine learning, and the performance probability of using AlGaN/GaN heterojunction-based high-electron-mobility transistors (HEMTs) in EV systems. The analysis of this extensive review paper suggests that the Vienna rectifier provides significant performance among all AC–DC rectifier converters. Moreover, the multi-device interleaved DC–DC boost converter is best suited for the DC–DC conversion stage. Among DC–AC converters, the third harmonic injected seven-level inverter is found to be one of the best in EV driving. Furthermore, the utilization of multi-level inverters can terminate the requirement of the intermediate DC–DC converter. In addition, the current status, opportunities, challenges, and applications of wireless power transfer in hybrid and all-electric vehicles were also discussed in this paper. Moreover, the adoption of wide bandgap semiconductors was considered. Because of their higher power density, breakdown voltage, and switching frequency characteristics, a light yet efficient power converter design can be achieved for EVs. Finally, the article’s intent was to provide a reference for engineers and researchers in the automobile industry for forecasting calculations. Full article

Vienna rectifiers are widely used, but they have problems of zero-crossing current distortion and midpoint potential imbalance. In this paper, an improved hybrid modulation strategy is proposed. According to the phase difference between the reference voltage vector and the input current vector, the dynamic current crossing distortion sector is divided at each phase current crossing, and the discontinuous pulse width modulation strategy is adopted in the sector to suppress the redundant small vector mutation and improve the current crossing distortion. To solve the problem of midpoint potential balance, a space vector modulation strategy is adopted outside the sector to control the midpoint potential balance by allocating the time of small vector action by voltage balance factor. Finally, the effectiveness of the proposed method is verified by simulation and experiment. Full article

Vienna converters have several advantages, including low construction costs, improved total harmonics, and considerable reliability. Generally, they are used in applications with a high switching frequency, particularly in telecommunications, and their use in power generation systems is recent but promising. They can be an interesting solution for medium and large wind power systems as they have the advantage of a high power density compared to traditional two-level converters. In this paper, a wind energy production system based on a Vienna rectifier and the permanent magnet synchronous generator (PMSG) is proposed. The main objective of this work is to evaluate the performance of the vector control strategy of the PMSG associated with the Vienna rectifier considering the real conditions of wind power systems. The feasibility and effectiveness of the proposed control strategy are evaluated through the simulations in MATLAB/Simulink and experimental tests based on a laboratory prototype. The outcomes present interesting performances in terms of dynamics and stability. Full article

Two of the main challenges of recent electric vehicles (EVs) are the charging time and high initial cost. To solve the problem associated with long charging time, the car manufacturers are moving from 400 V battery EV (BEV) to 800 V BEV, which enables the utilization of multi-level converters in EV applications. This paper presents a power conversion system consisting of a Vienna rectifier and a two/three level hybrid inverter as a machine-side inverter to drive a permanent-magnet synchronous motor (PMSM). The Vienna rectifier improves the quality of the grid-side current and provides a regulated DC-link voltage. The proposed inverter, known as a 10-switch inverter, offers high output current quality with a lower number of active switches, making it compact and cost-effective. The field-oriented control (FOC), along with the SPWM modulation, is implemented to control the system. A reliable and cost-effective PMSM drive system demands sensorless control; therefore, a sliding mode observer (SMO) is used to estimate the rotor position and velocity. The accuracy of the proposed system was proved through the simulation results from MATLAB/Simulink. Full article

This work aims to explore and evaluate the nonreversible AC/DC five-level structure from the point of view of its operational safety: high electrical security on internal destruction and continuity in operation. It only has low-voltage monotransistor cells (Si and SiC 600 V max) and is intrinsically tolerant to imperfection control and parasites, therefore naturally secure. The design and lab-test of fault monitoring and fault diagnosis with just one voltage sensor of a single-phase five-level VIENNA rectifier were proposed. This real-time diagnostic method allows for a safe stop or corrective control strategy based on the reconfiguration of the modulation. The reconstruction strategy allows for optimization of the current and voltage signals as well as power factor. A continuous post-fault operation can be achieved for critical applications. An experimental prototype 3 kW/230 VAC/800 VDC/32 kHz was created to validate the proposed fault diagnosis method and reconfiguration control method. Full article

The hybrid three-phase rectifiers (HTR) consist of parallel associations of two rectifiers (rectifier 1 and rectifier 2), each one of them with a distinct operation, while the sum of their input currents forms a sinusoidal or multilevel waveform. In general, rectifier 1 is a GRAETZ (full bridge) (can be combined with a BOOST converter) and rectifier 2 is combined with a DC-DC converter. In this HTR contest, this paper is intended to answer some important questions about those hybrid rectifiers. To obtain the correct answers, the study is conducted as an analysis of a systematic literature review. Thus, a search was carried out in the databases, mostly IEEE and IET, and 34 papers were selected as the best corresponding to the HTR theme. It is observed that the preferred form of power distribution in unidirectional hybrid three-phase rectifiers (UHTR) is $55\%P_o$ (rectifier 1) and $45\%P_o$ (rectifier 2). For the bidirectional hybrid three-phase rectifiers (BHTR), rectifier 1 preferably takes $90\%\mathrm{of}{P}_o$ and $10\%\mathrm{of}{P}_o$ is processed by rectifier 2. It is also observed that the UHTR that employ the single-ended primary-inductor converter (SEPIC) or VIENNA converter topologies in rectifier 2 can present sinusoidal input currents with low total harmonic distortion (THD) and high Power Factor (PF), even successfully complying with the international standards. The same can be said about the rectifier that employs a pulse-width (PWM) converter of BOOST topology in rectifier 2. In short, the HTR are interesting because they allow using the GRAETZ full bridge topology in rectifier 1, thus taking advantage of its characteristics, being simple, robust, and reliable. At the same time, the advantages of rectifier 2, i.e., high PF and low THD, are well used. In addition, this article also points out the future direction of research that is still unexplored in the literature, thus giving opportunities for future innovation. Full article
