The converter valve is the core component of the ultra-high voltage direct current (UHVDC) transmission system, and its fault detection is very important to ensure the safe and stable operation of the transmission system. However, the voiceprint signals collected by converter stations under complex operating conditions are often affected by background noise, spikes, and nonlinear interference. Traditional methods make it difficult to achieve high-precision detection due to the lack of feature extraction ability and poor noise robustness. This paper proposes a fault-aware variational self-encoder model (FAVAE-AS) based on a weak correlation between attention and self-supervised learning. It extracts probability features via a conditional variational autoencoder, strengthens feature representation using multi-layer convolution and residual connections, and introduces a weak correlation attention mechanism to capture global time point relationships. A self-supervised learning module with six signal transformations improves generalization, while KL divergence-based correlation inconsistency quantization with dynamic thresholds enables accurate anomaly detection. Experiments show that FAVAE-AS achieves 0.925 accuracy in fault detection, which is 5% higher than previous methods, and has strong robustness. This research provides critical technical support for UHVDC system safety by addressing converter valve acoustic anomaly detection. It proposes an extensible framework for industrial intelligent maintenance. Full article

This paper presents an enhanced fault prediction framework for synchronous condensers in UHVDC transmission systems, integrating Large Language Models (LLMs) with optimized Wavelet Packet Transform (WPT) for improved diagnostic accuracy. The framework innovatively employs LLMs to automatically optimize WPT parameters, addressing the limitations of traditional manual parameter selection methods. By incorporating a Multi-Head Attention Gated Recurrent Unit (MHA-GRU) network, the system achieves superior temporal feature learning and fault pattern recognition. Through intelligent parameter optimization and advanced feature extraction, the LLM component intelligently selects optimal wavelet decomposition levels and frequency bands, while the MHA-GRU network processes the extracted features for accurate fault classification. Experimental results on a high-capacity synchronous condenser demonstrate the framework’s effectiveness in detecting rotor, air-gap, and stator faults across diverse operational conditions. The system maintains efficient real-time processing capabilities while significantly reducing false alarm rates compared to conventional methods. This comprehensive approach to fault prediction and diagnosis represents a significant advancement in synchronous condenser fault prediction, offering improved accuracy, reduced processing time, and enhanced reliability for UHVDC transmission system maintenance. Full article

The thyristor is the key device for the converter of the ultra-high-voltage DC (UHVDC) project to realize AC–DC conversion. The reliability of thyristors is directly related to the safe operation of the UHVDC transmission system. Due to the complex operating environment of the thyristor, there are many interrelated parameters that may affect the aging state of thyristors. To extract useful information from the massive high-dimensional data and further obtain the aging state of thyristors, a supervised tensor domain classification (STDC) method based on the adaptive syn-thetic sampling method, the gradient-boosting decision tree, and tensor domain theory is proposed in this paper. Firstly, the algorithm applies the continuous medium theory to analogize the aging state points of the thyristor to the mass points in the continuous medium. Then, the algorithm applies the concept of the tensor domain to identify the aging state of the thyristor and to transform the original state-identification problem into the state classification surface determination of the tensor domain. Secondly, a temporal fuzzy clustering algorithm is applied to realize automatic positioning of the classification surface of each tensor sub-domain. Furthermore, to solve the problem of unbalanced sample size between aging class data and normal class data in the state-identification domain, the improved adaptive synthetic sampling algorithm is applied to preprocess the data. The gradient-boosting decision tree algorithm is applied to solve the multi-classification problem of the thyristor. Finally, the comparison between the algorithm proposed and the conventional algorithm is performed through the field-test data provided by the CSG EHV Power Transmission Company of China’s Southern Power Grid. It is verified that the evaluation method proposed has higher recognition accuracy and can effectively classify the thyristor states. Full article

Ultra high voltage direct current (UHVDC) transmission is an effective means of long-distance transmission of renewable power generation, which has obtained a lot of research and practical applications. The commutation failure is a common DC transmission fault, which will cause the voltage amplitude of the sending ac grid in UHVDC system to first decrease then increase. The existing transient mathematical models of the wind power generation system (WPGS) are difficult to apply to scenarios where the grid voltage changes continuously. A mathematical model suitable for commutation failure is established to analyze the transient reactive power characteristics of the doubly fed induction generator (DFIG)-based WPGS with the consideration of the crowbar circuit trigger. The correctness of the mathematical model is validated by an experiment based on the control hardware-in-loop (CHIL) platform. Based on the proposed mathematical model, the influence of the crowbar parameters on the reactive power output of the DFIG is analyzed, and the selection of crowbar parameters to suppress the overvoltage of the sending ac grid is investigated. A simulation model is built based on Matlab/Simulink to verify the overvoltage suppression effect of the proposed selection scheme. Full article

Epoxy resin-impregnated insulation paper (RIP) composites are used as the inner insulation of dry condenser bushing in the ultra-high voltage direct current (UHVDC) power transmission system. To improve the dielectric properties and heat conductivity of RIP, hexagonal boron nitride (h-BN) nano-flakes are added to the insulation paper at concentrations of 0–50 wt % before impregnation with pure epoxy resin. X-ray diffraction (XRD), scanning electron microscopy (SEM) observations, thermal conductivity as well as the typical dielectric properties of direct current (DC) volume conductivity. DC breakdown strength and space charge characteristics were obtained. The maximum of nano-h-BN modified heat conductivity reach 0.478 W/(m·K), increased by 139% compared with unmodified RIP. The DC breakdown electric field strength of the nano-h-BN modified RIP does not reduce much. The conductivity of nano-h-BN modified is less sensitive to temperature. As well, the space charge is suppressed when the content is 50 wt %. Therefore, the nano-h-BN modified RIP is potentially useful in practical dry DC bushing application. Full article

Ultra-high voltage direct current (UHVDC) systems under hierarchical connection schemes (HCSs) linked to AC grids with different voltage levels (500 and 1000 kV) have been a great concern for power utilities to transfer bulk power. They have some operating issues like cascaded commutation failures and longer fault recovery time under certain fault conditions. Since STATCOM has the ability to effectively regulate AC busbar voltages, thus it is considered in this paper to improve the operating characteristics of UHVDC-HCS systems. To further improve the operating characteristics, a coordinated control between an UHVDC-HCS system and STATCOM is presented. To validate the effectiveness of coordinated control, the comparison between different control modes such as reactive power control (Q-control) and voltage control (V-control) in the outer loop control of STATCOM are conducted in detail. Various indices like commutation failure immunity index (CFII) and commutation failure probability index (CFPI) are also comprehensively evaluated in order to investigate robustness of the adopted coordinated control. An UHVDC-HCS system with multiple STATCOMs on the inverter side (500 kV bus) is developed in PSCAD/EMTDC. The impact of coordinated control on commutation failure phenomena and fault recovery time during single and three phase AC faults is analyzed. The analysis shows that coordinated control with V-control mode of STATCOM exhibits better performance in enhancing the operating characteristics of UHVDC-HCS system by improving the CFII, effectively reducing the CFPI and fault recovery time under various AC faults. Full article

Epoxy resin-impregnated insulation paper (RIP) composites are used as the inner insulation of dry condenser bushing in the ultra-high voltage direct current (UHVDC) power transmission system. To improve the dielectric properties of RIP, nano-SiO₂ is added to the insulation paper at concentrations of 0–4wt % before impregnation with pure epoxy resin. X-ray diffraction (XRD), scanning electron microscopy observations as well as the typical dielectric properties of relative permittivity, DC volume conductivity, DC breakdown strength, and thermally stimulated depolarization current (TSDC), were obtained. The effects of trap parameters on the breakdown field strength and volume conductivity were investigated. The DC breakdown electric field strength of the sample increased as the trap level increased. The maximum DC breakdown strength of nano-SiO₂-modified RIP was increased by 10.6% the nano-SiO₂ content of 2 wt %. The relative permittivity and DC volume conductivity were first decreased and then increased with increasing nano-SiO₂ content. These changes occurred near the interfaces between nano-SiO₂ and RIP. The increased DC breakdown strength was mainly attributed to the increased trap level. Full article

With the increasing demand of transmitting bulk-power over long-distance, the ultra high-voltage direct-current (UHVDC) transmission systems become an attractive option. Nowadays, not only the line commutated converter (LCC) based systems, but also the modular multilevel converter (MMC) based systems have reached UHVDC levels. The converter stations of UHVDC systems normally utilize two series-connected valve-groups to reduce the difficulties of device manufacturing and transportation. This high-voltage and low-voltage valve-group configuration allows the UHVDC systems to achieve a full-voltage to half-voltage operation which increases the flexibility of the systems. However, the existing research only focuses on the full-voltage to half-voltage control of LCC-UHVDC systems. The control strategies for hybrid LCC/MMC UHVDC systems are underresearched. Moreover, the approaches to reduce the load-shedding caused by the full-voltage to half-voltage control for both LCC and hybrid LCC/MMC based UHVDC systems have not been investigated. In this paper, full-voltage to half-voltage control strategies for both LCC and hybrid LCC/MMC based UHVDC systems have been proposed. Moreover, to avoid load-shedding caused by the half-voltage operation, a power rescheduling method that re-sets the power references of the half-voltage operating and full-voltage operating poles has been proposed. The proposed full-voltage to half-voltage control strategies and power rescheduling method can achieve a stable and fast control process with a minimum power loss. The proposed methods have been verified through the time-domain simulations conducted in PSCAD/EMTDC. Full article

In recent years, the ultra-high voltage direct current (UHVDC) transmission system has been developed rapidly for its significant long-distance, high-capacity and low-loss properties. Equipment failures and overall outages of the UHVDC system have increasingly vital influence on the power supply of the receiving end grid. To improve the reliability level of UHVDC systems, a quantitative selection and configuration approach of redundant structures is proposed in this paper, which is based on multi-state reliability equivalence. Specifically, considering the symmetry characteristic of an UHVDC system, a state space model is established as a monopole rather than a bipole, which effectively reduces the state space dimensions to be considered by deducing the reliability merging operator of two poles. Considering the standby effect of AC filters and the recovery effect of converter units, the number of available converter units and corresponding probability are expressed with in universal generating function (UGF) form. Then, a sensitivity analysis is performed to quantify the impact of component reliability parameters on system reliability and determine the most specific devices that should be configured in the redundant structure. Finally, a cost-benefit analysis is utilized to help determine the optimal scheme of redundant devices. Case studies are conducted to demonstrate the effectiveness and accuracy of the proposed method. Based on the numerical results, configuring a set of redundant transformers is indicated to be of the greatest significance to improve the reliability level of UHVDC transmission systems. Full article

Large-scale wind-thermal-bundled power that is transmitted by mixed ultra-high voltage direct current (UHVDC)/ultra-high voltage alternating current (UHVAC) systems has become crucial for large-scale wind farms in China. Equations describing the electromagnetic power characteristics under short circuits for UHVAC lines and UHVDC blocks are derived based on an analysis of the external characteristics of a doubly fed wind farm and UHVDC systems. The effect of wind power penetration ratio on rotor angle transient stability is analysed, and the optimal wind power penetration ratio under the constraint of rotor angle transient stability is determined. The effects of system parameters, such as the UHVDC transmission capacity and the reactance of UHVAC lines on the optimal wind power penetration ratio are discussed. The trend of rotor angle stability varies from a monotonic deterioration to concave, and the optimal wind power penetration ratio increases from 0 to 30% under an UHVDC block when the reactance of UHVAC lines increases from 0.005 to 0.02. The optimal wind power penetration ratio under a short circuit increases from 40% to 60% when the reactance of UHVAC lines decreases from 0.02 to 0.006 and decreases from 40% to 30% when the capacity of UHVDC decreases from 3200 MW to 1600 MW. The analysis is verified by simulating an actual system in China’s Northwest Power Grid. Full article

The ultra high voltage direct current (UHVDC) transmission system has advantages in delivering electrical energy over long distance at high capacity. UHVDC converter transformer is a key apparatus and its insulation state greatly affects the safe operation of the transmission system. Partial discharge (PD) characteristics of oil-pressboard insulation under combined AC-DC voltage are the foundation for analyzing the insulation state of UHVDC converter transformers. The defect pattern recognition based on PD characteristics is an important part of the state monitoring of converter transformers. In this paper, PD characteristics are investigated with the established experimental platform of three defect models (needle-plate, surface discharge and air gap) under 1:1 combined AC-DC voltage. The different PD behaviors of three defect models are discussed and explained through simulation of electric field strength distribution and discharge mechanism. For the recognition of defect types when multiple types of sources coexist, the Random Forests algorithm is used for recognition. In order to reduce the computational layer and the loss of information caused by the extraction of traditional features, the preprocessed single PD pulses and phase information are chosen to be the features for learning and test. Zero-padding method is discussed for normalizing the features. Based on the experimental data, Random Forests and Least Squares Support Vector Machine are compared in the performance of computing time, recognition accuracy and adaptability. It is proved that Random Forests is more suitable for big data analysis. Full article

The multi-infeed effective short-circuit ratio (MESCR) is widely used in indicating the strength of multi-infeed AC/DC power systems. However, when the widely used MESCR was adopted to evaluate the stability margin of the Eastern China Grid including three infeed ultra-high-voltage DC (UHVDC) and five high-voltage DC transmission lines in 2016, the MESCR result indicated the system was strong enough but in fact occasionally collapses after the N-1 contingency. To determine the reason for this conflict, this paper theoretically analyzes the limitations of the existing MESCR. The theoretical analysis reveals that when a large amount of capacitor compensations are concentratively installed in the system, the conventional MESCR will not be able to reflect the capacitor compensations’ influence on the system stability, and no matter how many capacitors are installed or where the capacitors are installed, the MESCR almost retains the same value; namely, the MESCR is saturated in such systems. To address the saturation problem of conventional MESCR, this paper proposes an improved multi-infeed effective short-circuit ratio (IMESCR) which considers the influences of all capacitor compensations by converting all capacitors installed throughout the system to virtual capacitors at the DC inverter station. Case studies are carried out based on the New England 39-bus system and the Eastern China Grid, respectively. The simulation results verify the theoretical analysis of the MESCR’s limitations in evaluating the stability of power systems with massive capacitors installed, and proves that the proposed IMESCR could accurately indicate the strength of AC/DC power systems. Therefore, the proposed IMESCR provides a new index for evaluating the stability margin of power systems with massive capacitor compensations installed. Full article

In order to improve the fault monitoring performance of grounding electrode lines in ultra-high voltage DC (UHVDC) transmission systems, a novel fault monitoring approach based on the high-frequency voltage standing-wave ratio (VSWR) is proposed in this paper. The VSWR is defined considering a lossless transmission line, and the characteristics of the VSWR under different conditions are analyzed. It is shown that the VSWR equals 1 when the terminal resistance completely matches the characteristic impedance of the line, and when a short circuit fault occurs on the grounding electrode line, the VSWR will be greater than 1. The VSWR will approach positive infinity under metallic earth fault conditions, whereas the VSWR in non-metallic earth faults will be smaller. Based on these analytical results, a fault supervision criterion is formulated. The effectiveness of the proposed VSWR-based fault supervision technique is verified with a typical UHVDC project established in Power Systems Computer Aided Design/Electromagnetic Transients including DC(PSCAD/EMTDC). Simulation results indicate that the proposed strategy can reliably identify the grounding electrode line fault and has strong anti-fault resistance capability. Full article

A space charge density wireless measurement system based on the idea of distributed measurement is proposed for collecting and monitoring the space charge density in an ultra-high-voltage direct-current (UHVDC) environment. The proposed system architecture is composed of a number of wireless nodes connected with space charge density sensors and a base station. The space charge density sensor based on atmospheric ion counter method is elaborated and developed, and the ARM microprocessor and Zigbee radio frequency module are applied. The wireless network communication quality and the relationship between energy consumption and transmission distance in the complicated electromagnetic environment is tested. Based on the experimental results, the proposed measurement system demonstrates that it can adapt to the complex electromagnetic environment under the UHVDC transmission lines and can accurately measure the space charge density. Full article
