Partial discharges (PDs) are one of the leading causes of catastrophic power transformer failures. To prevent such failures, online PD monitoring systems are increasingly being implemented. In this paper, to the best of the authors’ knowledge, a case study analysis of short-term PD monitoring is presented for the first time using a combination of acoustic emission and ultra-high-frequency methods. Studies have shown that this approach, supported by selected statistical methods for analyzing the convergence (such as the confusion matrix and agreement metrics) of acoustic and electromagnetic pulse detection, improves the reliability of PD detection. Furthermore, it was shown that short-term PD monitoring enables the identification of time windows during which discharges occur periodically and the determination of the transformer phase containing the PD source. This, in turn, facilitates the application of the time difference of arrival (TDoA) technique for the precise localization of transformer insulation defects. Full article

Ultrahigh-frequency (UHF) sensing is one of the most promising techniques for assessing the quality of power transformer insulation systems due to its capability to identify failures like partial discharges (PDs) by detecting the emitted UHF signals. However, there are still uncertainties regarding the frequency range that should be evaluated in measurements. For example, most publications have stated that UHF emissions range up to 3 GHz. However, a Cigré brochure revealed that the optimal spectrum is between 100 MHz and 1 GHz, and more recently, a study indicated that the optimal frequency range is between 400 MHz and 900 MHz. Since different faults require different maintenance actions, both science and industry have been developing systems that allow for failure-type identification. Hence, it is important to note that bandwidth reduction may impair classification systems, especially those that are frequency-based. This article combines three operational conditions of a power transformer (healthy state, electric arc failure, and partial discharges on bushing) with three different self-organized maps to carry out failure classification: the chromatic technique (CT), principal component analysis (PCA), and the shape analysis clustering technique (SACT). For each case, the frequency content of UHF signals was selected at three frequency bands: the full spectrum, Cigré brochure range, and between 400 MHz and 900 MHz. Therefore, the contributions of this work are to assess how spectrum band limitation may alter failure classification and to evaluate the effectiveness of signal processing methodologies based on the frequency content of UHF signals. Additionally, an advantage of this work is that it does not rely on training as is the case for some machine learning-based methods. The results indicate that the reduced frequency range was not a limiting factor for classifying the state of the operation condition of the power transformer. Therefore, there is the possibility of using lower frequency ranges, such as from 400 MHz to 900 MHz, contributing to the development of less costly data acquisition systems. Additionally, PCA was found to be the most promising technique despite the reduction in frequency band information. Full article

In order to analyze the law of unloading instability of deep rock mass, the unloading experiment of sandstone under different confining pressures was carried out, and the mechanical properties and acoustic emission characteristics of sandstone unloading failure under high stress were obtained. The results demonstrate that before unloading, the sandstone under low stress shows compression and elastic deformation, whereas that under high stress shows elastic deformation and plastic deformation. Moreover, the unloading behavior of sandstone under low stress is ductile, whereas that under high stress is brittle. Poisson’s ratio and elastic modulus have negative and positive correlation with initial confining pressure, respectively. During unloading, the higher the initial confining pressure is, the earlier the rock sample damage occurs. Prior to the accelerated damage stage, the unloading amount and AE cumulative count are inversely proportional and directly proportional to the initial confining pressure, respectively. The simultaneous occurrence of UHF, HF, MF, and LF in the AE power spectrum, as well as a steep increase in fractal dimension followed by a decrease, can be used as precursors to unloading instability in sandstone. Full article

Gas-insulated switchgears (GISs) are important pieces of power equipment used to improve the reliability of power facilities. As the number of GISs increases, more insulation failures occur every year. The most common cause of insulation failure is particles and foreign bodies producing a partial discharge (PD), which causes deterioration of the insulation materials and results in insulation breakdown. However, it is not easy to detect them by conventional PD and ultra-high frequency (UHF) PD measurements because it is difficult to apply the conventional method to the GISs in service, and the UHF method is not always applicable to GISs. Therefore, an appropriate method to detect particles and foreign bodies in GISs is needed. In this study, experimental validation was performed to detect particles moving in GISs using the acoustic emission (AE) method. Acoustic wave signals were produced by the particles moving on the surface of a flat plate when applying voltage. An AE sensor with a frequency range of 50 to 400 kHz was used, and a decoupler and low-noise amplifier were designed to detect the acoustic wave signals with high sensitivity. Twelve types of particles were used, and one was selected to confirm the detectable minimum output voltage. In an actual factory test, the output voltage of the acoustic wave signals was analyzed while considering the applied voltage and signal attenuation. Consequently, it was confirmed that the AE measuring system proposed in this paper could detect particles moving inside GISs. Full article

The article presents a novel on-line partial discharge (PD) monitoring system for power transformers, whose functioning is based on the simultaneous use of three unconventional methods of PD detection: high-frequency (HF), ultra-high frequency (UHF), and acoustic emission (AE). It is the first monitoring system equipped in an active dielectric window (ADW), which is a combined ultrasonic and electromagnetic PD sensor. The article discusses in detail the process of designing and building individual modules of hardware and software layers of the system, wherein the most attention was paid to the PD sensors, i.e., meandered planar inverted-F antenna (MPIFA), high-frequency current transformer (HFCT), and active dielectric window with ultrasonic transducer, which were optimized for detection of PDs occurring in oil-paper insulation. The prototype of the hybrid monitoring system was first checked on a 330 MVA large power transformer during the induced voltage test with partial discharge measurement (IVPD). Next, it was installed on a 31.5 MVA substation power transformer and integrated according to the standard IEC 61850 with SCADA (Supervisory Control and Data Acquisition) system registering voltage, active power, and oil temperature of the monitored unit. The obtained results showed high sensitivity of the manufactured PD sensors as well as the advantages of the simultaneous use of three techniques of PD detection and the possibility of discharge parameter correlation with other power transformer parameters. Full article

The aim is to evaluate specific absorption rate (SAR) values from exposure near handheld ultra-high frequency radiofrequency identification readers (UHF RFID guns—small electronic devices, or even portable computers with relevant accessories—emitting up to several watts of electromagnetic field (EMF) to search for RFID sensors (tags) attached to marked objects), in order to test the hypothesis that they have an insignificant environmental influence. Simulations of SAR in adult male and female models in seven exposure scenarios (gun near the head, arm, chest, hip/thigh of the operator searching for tags, or near to the chest and arm of the scanned person or a bystander). The results showed EMF exposure compliant with SAR limits for general public exposure (ICNIRP/European Recommendation 1999/519/EC) at emissions up to 1 W (reading range 3.5–11 m, depending on tag sensitivity). In the worst-case scenario, guns with a reading range exceeding 5 m (>2 W emission) may cause an SAR exceeding the general public limits in the palm of the user and the torso of the user, a bystander, or a scanned person; occupational exposure limits may be exceeded when emission >5 W. Users of electronic medical implants and pregnant women should be treated as individuals at particular risk in close proximity to guns, even at emissions of 1 W. Only UHF RFID guns emitting below 1 W may be considered as environmentally insignificant EMF sources. Full article

This paper presents the results of analysis of a solid dielectric’s influence on the phenomena associated with the signals emitted by surface partial discharges. Three types of electrode systems were tested, in which solid dielectrics made of pressboard, Teflon, and glass were used. The emission of such signals as radio waves in the Ultra high frequency (UHF) range and optical radiation was analyzed. The measurements were carried out in the insulation systems most commonly used in electrical power equipment, i.e., mineral oil and air. UHF and optical spectrophotometry methods were used to register the emitted signals. The obtained results indicate that the type of material from which the dielectric solid is made may have a potential impact on some ranges of emitted electromagnetic waves during the surface electrical discharges. The research topic undertaken is important in issues associated with high-voltage insulation systems and in particular with surface discharges, which are often the cause of their damage. Full article

The detection and location of partial discharge (PD) is of great significance in evaluating the insulation condition of power transformers. This paper presents an active dielectric window (ADW), which is a new concept of combined acoustic emission (AE) and electromagnetic PD detector intended for assembly in a transformer’s inspection hatch. The novelty of this design lies in the fact that all structural components of an ultrasonic transducer, i.e., the matching and backing layer, an active piezoelectric element with electrodes, and electrical leads, were built into a dielectric window. Due to the fact that its construction was optimized for work in mineral oil, it is characterized by much higher sensitivity of PD detection than a general-purpose AE sensor mounted outside a transformer tank. Laboratory tests showed that the amplitude of the AE pulses generated by creeping discharges, which were registered by the ADW, was around five times higher on average than the pulses registered by a commonly used contact transducer. A possibility of simultaneous detection of acoustic and electromagnetic pulses (with an integrated ultra-high frequency (UHF) antenna) is an important advantage of the ADW. It allows for an increase in the reliability of PD detection, the accuracy of defect location, and the effectiveness of disturbance identification. This paper describes in detail the applied methods of designing and modeling the ADW components, the manufacturing process of the prototype construction, and the results of preliminary laboratory tests, in which the detector’s sensitivity as well as the efficiency of the PD source location were evaluated. Full article

Spatial localization of emitting sources is especially interesting in different fields of application. The focus of an earthquake, the determination of cracks in solid structures, or the position of bones inside a body are some examples of the use of multilateration techniques applied to acoustic and vibratory signals. Radar, GPS and wireless sensors networks location are based on radiofrequency emissions and the techniques are the same as in the case of acoustic emissions. This paper is focused on the determination of the position of sources of partial discharges in electrical insulation for maintenance based on the condition of the electrical equipment. The use of this phenomenon is a mere example of the capabilities of the proposed method but it is very representative because the emission can be electromagnetic in the VHF and UHF ranges or acoustic. This paper presents a method to locate more than one source in space with only two receivers, one of them in a fixed position and the other describing a circumference around the first one. The signals arriving from the different sources to the antennas are first separated using a classification technique based on their spectral components. Then, the individualized time differences of arrival (TDOA) from the sources collected at different angles describe a function, angle versus TDOA, that has all the geometric information needed to locate the source. The paper will show how to derive these functions for any source analytically with the position of the source as unknown parameters. Then, it will be demonstrated that it is possible to fit the curve with experimental measurements of the TDOA to obtain the parameters of the position of each source. Finally, the technique is extended to the localization of the emitter in three dimensions. Full article

Spatial localization of emitting sources is especially interesting in different fields of application. The focus of an earthquake, the determination of cracks in solid structures or the position of bones inside a body are some examples of the use of multilateration techniques applied to acoustic and vibratory signals. Radar, GPS and wireless sensors networks location are based on radiofrequency emissions and the techniques are the same as in the case of acoustic emissions. This paper is focused on the determination of the position of sources of partial discharges inside electrical insulation for maintenance based on the condition of the electrical machine. The use of this phenomenon is a mere example of the capabilities of the proposed method because its emission can be electromagnetic in the UHF range or acoustic when the insulation is immersed in oil. Generally, when a pulse is radiated from a source, the wave will arrive to two receivers at different times. One of the advantages of measuring these time differences of arrival or TDOA is that it is not required a common clock as in other localization techniques based on the time of arrival (TOA) of the pulse to the receiver. With only two sensors, all the possible points in the plane that would give the same TDOA describe a hyperbola. Using an independent third receiver and calculating the intersection of the three hyperbolas will give the position of the source. Therefore, planar localization of emitters using multilateration techniques can be solved at least with three receivers. This paper presents a method to locate sources in a plane with only two receivers, one of them in a fixed position and the other is placed describing a circumference around the first one. The TDOA are measured at different angles completing a total turn and obtaining a function, angle versus TDOA, that has all the geometric information needed to locate the source. The paper will show how to derive this function analytically with two unknown parameters: the distance and bearing angle from the fixed receiver to the source. Then, it will be demonstrated that it is possible to fit the curve with experimental measurements of the TDOA to obtain the parameters of the position of the source. Full article
