The prediction of the ultimate bending capacity of the rectangular concrete-filled steel tube (RCFST) beams strengthened with U-shaped carbon fiber reinforced polymer (CFRP) sheets is limited to using the existing empirical models. Thus, this study aims to develop a new theoretical model based on a stress block model to predict the ultimate bending capacity (M_u) of the RCFST beams strengthened with a U-shaped CFRP-wrapping scheme. For this purpose, 28 finite element (FE) models of CFRP-strengthened RCFST beams had been analyzed for further investigation of the flexural behavior and longitudinal stresses distributed along with the beam’s components (steel tube, concrete core, and CFRP layers). The main parameters investigated are concrete compressive strength, steel yield strength, number of CFRP layers, and CFRP-wrapping-depth ratio. In addition, the M_u values obtained from the FE models of the current study and those from the existing experimental tests performed by others are used to verify the corresponding values that are theoretically predicted by the new model. The comparison showed that the proposed model is moderately conservative, as the predicted values of M_u are, on average, up to 10% lower than those obtained from experimental tests and FE analysis. Full article

Strengthening lapped spliced reinforced concrete (RC) beams using tiny-diameter steel wires as near-surface-mounted (NSM) rods has not been carried out previously. Thus, the purpose of this work is to examine the behavior of RC beams with insufficient lap splices that are strengthened by NSM steel wires with different schemes to improve durability, efficiency, and effectiveness. At the middle of the beam, a splice length equal to 25 times the diameter of the rebar was used to join two tension bars. Many different schemes were implemented in strengthening the splice region, such as attaching longitudinal wires to the sides and/or bottom of the beam in different quantities with/without end anchorage, placing perpendicular and inclined U-shaped wires at the splice region in different quantities, and implementing a network of intersecting and opposite wires in two different directions. The effect of variables on the behavior of strengthened beams was studied. The findings proved that when the longitudinal wire reinforcement-to-lapped rebars area ratio was 9.4%, 18.7%, and 28%, the ultimate load of the beams was improved by 15.71%, 71.43%, and 104.57%, respectively. When the transverse U-shaped wire reinforcement ratio was 0.036, 0.051, 0.064, 0.075, and 0.150, the ultimate load of the beams was improved by 3.7%, 20%, 31.4%, 50%, and 80%, respectively, and the ultimate deflection was enhanced by 2%, 32%, 19%, 67%, and 62.4% compared to the unstrengthened beam. Full article

Because of the degradation of building materials and the increased design load, concrete parts continually require repair. Special cementitious matrix components, Strain Hardening Cementitious Composites (SHCC), have exceptional ductility, strength growth during cracking, and recurrent controlled-opening crack formation. The purpose of this study was to improve the qualities of SHCC by reinforcing it with steel metal mesh. This study examined the optimization and effects of shear strengthening on the shear capacity of both damaged and undamaged reinforced concrete beams by employing SHCC internally reinforced with steel mesh fabric (SMF). Under bending loading, eight reinforced concrete beams were evaluated. Four of them were loaded to shear crack before any strengthening could be performed. The beams were 1500 mm in length, 200 mm in height, and 120 mm in width, and one, two, or three SMFs were applied. The beams’ whole shear span had external strengthening applied on both sides. Additionally, layers of strengthening in the U-shape were applied. The walls of the strengthening were thirty millimeters thick. The failure, load-deflection response, ultimate load, ultimate displacement, and energy absorbance of the tested beams were determined and discussed. Compared to an unstrengthened beam, the ultimate load of undamaged beams increased by 47%, 57%, and 90% when reinforced with 1, 2, or 3 layers of SMF, respectively, within the SHCC. Additionally, incorporating one, two, or three SMF layers within the SHCC improved the deflection of strengthened undamaged beams by 52%, 87%, and 116%, respectively. For damaged beams, the maximum load was approximately 11% lower than that of their undamaged counterparts, regardless of the number of SMF layers used in the SHCC strengthening. Applying one, two, or three layers of SMFs within the strengthening layer led to increases of the ratios of 163, 334, and 426%, respectively, in the energy absorbed by the strengthened beams in comparison to the control beam. The shear strength of the strengthened beams was determined through analytical modeling by implementing a correction factor (α = 0.5) to take into consideration the debonding action between the SHCC layer and the beam sides. This factor significantly improved the predictive accuracy of the analytical models by matching the mean ratio of the analytical findings to the experimental predictions. Full article

This study conducted experiments to investigate the flexural behavior of steel–concrete composite beams with U-shaped sections, utilizing cold-formed lipped channels as web components. To enhance both flexural and shear performance, trapezoidal plates were added to the lower sides of the composite beams. A total of ten specimens were fabricated, with variables defined according to the following criteria: presence of bottom tension reinforcement and bottom studs, thickness of the trapezoidal side plates (6 mm and 8 mm), and the welding method. Four-point bending tests were conducted, and all specimens exhibited typical flexural failure at the ultimate state. Specimens with bottom tension reinforcement, specifically those in the H5-T6 and H5-T8 series, demonstrated increases in ultimate load of 28.8% and 33.5%, respectively, compared to specimens without tension reinforcement. The use of lipped channels enabled full composite action between the concrete and the steel web components, eliminating the need for stud anchors. Additionally, it was confirmed that the plastic neutral axis, reflecting the material test strengths, was located within the concrete slab as intended. This study also compared the design flexural strengths, calculated using the yield stress distribution method from structural steel design standards such as AISC 360 and KDS 14, with the experimental flexural strengths. The comparison was used to evaluate the applicability of current design standards. Full article

In this manuscript, a novel approach to topology optimization is proposed which integrates considerations of uncertain load positions, thereby enhancing the reliability-based design within the context of structural engineering. Extending the conventional framework to encompass imperfect geometrically nonlinear analyses, this research discovers the intricate interplay between nonlinearity and uncertainty, shedding light on their combined effects on probabilistic analysis. A key innovation lies in treating load position as a stochastic variable, augmenting the existing parameters, such as volume fraction, material properties, and geometric imperfections, to capture the full spectrum of variability inherent in real-world conditions. To address these uncertainties, normal distributions are adopted for all relevant parameters, leveraging their computational efficacy, simplicity, and ease of implementation, which are particularly crucial in the context of complex optimization algorithms and extensive analyses. The proposed methodology undergoes rigorous validation against benchmark problems, ensuring its efficacy and reliability. Through a series of structural examples, including U-shaped plates, 3D L-shaped beams, and steel I-beams, the implications of considering imperfect geometrically nonlinear analyses within the framework of reliability-based topology optimization are explored, with a specific focus on the probabilistic aspect of load position uncertainty. The findings highlight the significant influence of probabilistic design methodologies on topology optimization, with the defined constraints serving as crucial conditions that govern the optimal topologies and their corresponding stress distributions. Full article

The phenomenon of peripheral rock instability is more common in crushed bedrock roadways, and the fundamental reason for this lies in the significantly different characteristics of its peripheral rock stress field. Taking the newly dug belt inclined shaft of PingDingShan TianAn Coal Co., Ltd. No. 6 Mine as the engineering background, a mechanical model of a broken perimeter rock roadway was established by using classical rock mechanics theory. Stress distribution around the roadway of the broken perimeter rock medium was systematically analyzed, and radial and tangential stress formulas of the broken perimeter rock were deduced. Through the formula calculation, it was deduced that there was a stress drop in the intact surrounding rock outside the disturbed zone, and the radial stress of the intact surrounding rock in its deep part was relatively increased, while the tangential stress was relatively decreased. The existence of crushed surrounding rock increased the minimum principal stress and decreased the maximum principal stress of the unfractured surrounding rock, which proves that a well-maintained disturbed zone can play a lining role. Thus, a “U-shaped steel + inverted arch + bottom arch linkage beam + floor bolt compensation” support program was proposed. This joint support program easily forms a closed support structure, which is more effective in controlling the deformation of tunnel perimeter rock. The support structure can effectively resist the deformation of the surrounding rock and enhance bottom drum resistance. Through numerical simulation, it was concluded that the horizontal displacement of the two gangs was reduced by 70%, and the displacement of the top and bottom plates was reduced by 77% after optimization of the support, which effectively controlled the stability of the broken surrounding rock. Full article

In the present work, a study of the fatigue strength of two materials widely used in the production of molds, namely, the AISI P20 and AISI H13 steels, is presented. The tests were performed at a constant amplitude with a stress ratio of R = 0 using samples where U-shaped notches were filled with laser beam fusion deposition. Three different sets of deposition parameters for each material were analyzed. Fatigue strength results are presented as S-N curves obtained for filled and non-filled materials. In addition to the assessment of the fatigue strength, metallography, hardness, and the fracture surface of the specimens tested were also evaluated. In general, a high number of metallurgic defects was detected, and consequently, a decrease in the mechanical properties of the materials was observed, especially the fatigue strength. However, the parameter optimization of the repairing laser process produced repaired zones with good metallurgical quality, leading to higher fatigue strength in both of the high-strength steels analyzed. Full article

In this paper, a new type of assembling rivet-fastened rectangular hollow flange beams (ARHFBs) is proposed. The cross-section of the ARHFB consists of two U-shaped and C-shaped components connected by self-locking rivets to form two rectangular hollow flanges. To study the performance and strength of the ARHFB as a flexural member, eight four-point bending tests and more than 40 simulation studies were carried out. The details, results, and comparison of the four-point bending tests, especially the characteristics of the test bench and the lateral support, are presented in this paper. ARHFB sections with varied rivet spacing, web depth, and flange width were experimentally studied. Additionally, a parametric study of ARHFB was conducted using finite element models verified by test results. The influence of span on the loading capacity of ARHFB was discussed. ARHFB can be used in large-span buildings. A more economical ARHFB component selection method was given. The depth of the flange, the strength of the web, and the thickness of the web are important parameters of ARHFB. The loading capacity obtained from the test was compared with the predicted values of the design formulas in the American Iron and Steel Institute (AISI) and the Chinese design standard for cold-rolled steel (GB50018). The calculation and verification of ARHFB flange buckling and lateral torsional buckling were also considered. It is recommended that GB50018 be used to predict the flexural capacity of ARHFBs. Full article

A cold-formed, thin-walled steel/fast-growing timber composite system has recently been presented for low-rise buildings. It aims to increase the use of fast-growing wood as a green building material in structures, thus contributing to the transformation of traditional buildings. This study proposed a composite I-beam combined with fast-growing radiata pine and cold-formed thin-walled U-shaped steel. A four-point bending test was used to measure the bending properties of steel–timber composite I-beams under various connection methods. Based on experimental results, this study examined the specimen’s failure mechanism, mechanical properties, and strain development. In addition, a method for calculating flexural bearing capacity based on the superposition principle and transformed section method was suggested. It is evident from the results that fast-growing timber and cold-formed thin-walled steel can have significant composite effects. Different connecting methods significantly impact beams’ failure mode, stiffness, and bearing capacity. Furthermore, the theoretical method for calculating the flexural bearing capacity of composite beams differs from the test value by less than 10%. This paper’s research encourages the applications of fast-growing wood as light residential components, and it serves as a reference for the development, production, and engineering of steel–timber composite structural systems. Full article

The seismic behavior of the end-plate connections between a steel beam and the weak axis of the H-shaped steel column using a U-shaped connector was investigated using numerical analysis. Finite element (FE) models were established using ABAQUS 6.14 software, and the applicability of the modeling approach was verified by comparing the numerical results with the relevant experimental results. This parametric study of the joint was carried out to analyze the effects of the thickness of the U-shaped connectors, the thickness of the end-plates, the axial compression ratio of the columns, and the linear stiffness ratio of the beam to the column. The results show that the U-shaped connector set in the weak axis of the H-shaped column can form a box-shaped panel zone with the column flange and web. The volume of the panel zone and its resistance to shear deformation are increased through this connection. Finally, the recommended reasonable ranges for the thickness of the U-shaped connector, the thickness of the end-plates, the axial compression ratio of the columns, and the linear stiffness ratio of the beam to the column are proposed in this paper. Full article

In this investigation, a U-shaped connection (U-C) was introduced for a prefabricated steel plate shear wall with beam-only connections. This design replaces a portion of shear bolts with tension bolts to enhance bolt efficiency and reduce the overall bolt count, and it is suitable for a prefabricated high-rise steel structure. Four 1/3 scale specimens were designed, and an array of performance aspects including failure modes, hysteretic behavior, skeleton curves, energy dissipation capacity, stiffness degradation, and key performance indicators were systematically investigated through a combination of quasi-static tests and finite element analyses. The results showed that the combination arrangement of tensile and shear bolts in U-C effectively reduced the usage of bolts used and reduced installation costs; under low cycle reciprocating loads, the ultimate bearing capacity and energy dissipation capacity of a beam-only-connected prefabricated steel plate shear wall with U-shaped connection (BPSW-U) had slightly decreased compared with the prefabricated steel plate shear wall with discontinuous cover-plate connection (DCPC). Nevertheless, the BPSW-U excelled in preserving the integrity of the frame beams, channeling structural plastic deformations primarily into the infilled steel plate. This design feature ensures that post-earthquake functionality recovery can be achieved by simply replacing the infilled steel plate. Full article

This study aimed to evaluate the static response of prestressed reinforced concrete beams strengthened in their flexure and shear properties using different strengthening techniques, steel plates, and externally bonded woven carbon fiber fabric (WCFF). The experimental work involved testing twenty large-scale prestressed reinforced concrete beams with a length of 3000 mm, and cross-sections measuring 400 mm in height and 200 mm in breadth were cast in the factory and tested in the laboratory. Four beams without prestressing served as the reference beams; two unbonded pre-tensioned beams served as the control beams, and the remaining fourteen beams were strengthened with steel plates and externally bonded woven carbon fiber fabric (WCFF). Eight of the beams were strengthened with 4 mm thick steel plates and tested under a monotonically increasing load with manual readings recorded. The remaining six beams were strengthened with 0.5 mm thick WCFF and tested under a monotonically increasing load with manual readings recorded. The variables considered included the strengthening techniques (FRP composite sheets, steel plates), the types of strengthening (slices, U-shaped), and the flexural and shear capacities of the strengthened beams. All the implemented strengthening techniques yielded enhancements in both the flexural and shear strength outcomes of the beams compared to their respective controls. The most significant increase in load capacity, whether in terms of ultimate load or first crack load, for the prestressed concrete beams’ flexure properties occurred when strengthening with U-shaped steel plates. Additionally, the greatest reduction in deflection at the point of reaching the maximum load for the prestressed concrete beams, in terms of their flexure properties, was observed when strengthening with U-shaped steel plates. Similarly, the maximum load increase for the prestressed concrete beams, in terms of their shear properties, was achieved through strengthening with U-shaped woven carbon fiber fabric wrapping. Furthermore, a finite element model was created to simulate various experimental specimens. The finite element model’s results exhibited harmony with the experimental results, affirming the efficacy of the presented finite element model. Full article

A composite beam is a structural member that behaves as a single unit by using shear connectors between a concrete slab and an I-shaped steel girder. The composite ratio is crucial and is determined by the shear connectors’ ability to withstand the horizontal shear forces between the concrete and steel girder. In this study, a U-shaped composite beam was designed, which differs from conventional composite beams as it allows the use of a steel girder as a formwork. Moreover, angle-type shear connectors, instead of stud-type connectors, were employed. Based on this design, large-scale U-shaped composite beams with angle-type shear connectors were fabricated, and load tests were conducted to analyze the behavior after composite action and the influence of shear connector spacing. Additionally, the strength of the angle-type shear connectors used in this paper was evaluated through finite element analysis. Finally, a strength evaluation method for composite beams of this configuration is proposed. Full article

A structure may be exposed to a range of unexpected loads throughout its full life cycle. Partially precast concrete (PC) beams refer to the process of manufacturing concrete beams in which one part of the component is pre−fabricated in a factory and the other part is completed at the construction site. Through the test, it is possible to better ensure the safety and dependability of the PC composite beams under impact load by examining the reinforcement effect, structural toughness, and damage mode of PC composite beams with bonded steel. Additionally, a scientific basis and practical guidance are provided for the actual project. Their impact resistance can significantly affect the overall safety of a structure when subjected to an impact load. Three of the four PC beams used in this investigation were strengthened with steel plates. Residual flexural bearing capacity tests and drop weight impact tests were then conducted. The impacts of steel plate thickness and U−shaped steel plate hoops on the failure mechanism and dynamic response of the component were investigated. The dynamic responses obtained from the experiments included the displacement–time history curve, impact force, and support reaction force. In order to explore the failure mechanism of the partially precast beam during the impact process, a staged analysis was conducted based on the failure mode and dynamic response characteristic values of each curve. Residual flexural bearing capacity tests were used to examine the residual flexural bearing capacity of PC beams strengthened with bonded steel plates. The results of the research reveal that the failure mechanisms of each test beam are bending–shear failures. With the increase in bonded steel thickness, the peak mid−span displacement reduced by 6.55%, the residual mid−span displacement decreased by 29.53%, and the residual flexural bearing capacity improved by 25.02%. With the adoption of U−shaped steel plate hoops, the residual flexural bearing capacity significantly increased while the peak mid−span and residual mid−span displacements both decreased. Full article

The contribution of GFRP (glass fiber reinforced polymer) fabric to the bending behavior of steel RHS (rectangular hollow section) beams was investigated by experimental and numerical studies. In the first part of the study, small-scale RHS profiles were strengthened with GFRP fabrics in ten different configurations in the experimental study. The bending behavior of the profiles was determined by three-point bending tests, and the best strengthening configuration was decided. The numerical models were verified with the experimental results. In the second part, real-size RHS beams were strengthened with the optimum strengthening configuration. In the results of the study, it was determined that the U-shaped strengthening provided the maximum contribution to the RHS beams bending behavior. The minimum GFRP size to be used in strengthening is important, as an insufficient GFRP length leads to GFRP failure, and the number of layers should be increased for more load capacity. A total of 25% of the net beam span was determined to be the minimum GRFP length. In full-size beams, a double-layer GFRP increased the maximum load-bearing capacity by 7%. Formulas were obtained to determine the contribution of single and double-layered U-shaped GFRP to the shape factors of the RHS. With the formulations, the plastic moment capacity can be determined. Full article
