To overcome the large size of conventional high-gain antennas and the structural complexity of typical photonic crystal antennas, this paper proposes a cavity-free photonic crystal (PC) antenna driven by microwave-band Tamm plasmon polaritons (TPPs), which eliminates the conventional half-wavelength resonant cavity while maintaining a moderate total height (38.4 mm, ~2.1λ₀). The core innovation of this work lies in shifting the gain-enhancement paradigm from traditional bulky, volume-based spatial resonances to a direct 2-D interface feeding strategy. By rigorously satisfying the phase-matching condition between a one-dimensional PC and a highly reflective substrate, a strong TPP mode is excited. Distinct from conventional designs, we embed a simple microstrip patch exactly at this phase-matched boundary to directly exploit the extreme electric field localization of TPPs. This novel mechanism enables a cavity-free architecture that achieves highly directional emission without complex feeding networks or metallic cavities. Simulations and measurements exhibit excellent agreement. At 16.43 GHz, the measured peak gain reaches 16.4 dBi, with 3-dB beamwidths of 13.5° and 18.5°. Ultimately, this TPP-driven paradigm offers a practical solution tailored for advanced wireless communications and radio astronomy. Full article

We propose a 1D photonic crystal with nonlinear graphene–spacer–graphene truncation, which enables a tunable, non-monotonic, and intensity-dependent transmission response. By employing synthetic geometrical space to obtain Fermi arc states, the structure is designed to support a real-space topologically protected Tamm plasmon polariton, revealing an intensity-dependent transmission peak within the THz spectral range. As such, the proposed thin-film structure may serve as a nonlinear DBR element that can be integrated into a laser cavity to provide intensity-selective feedback, thereby facilitating controllable pulse shaping and enabling passive pulse formation mechanisms such as mode-locking or Q-switching. Due to its topological robustness, spectral scalability, and electrical tunability via graphene biasing, the platform provides a new route toward compact, reconfigurable nonlinear reflectors for efficient and controllable laser pulse generation, thereby extending the functionality of conventional saturable absorbers and semiconductor DBRs. Full article

This study explores the tunable characteristics of optical Tamm states (OTS) in a metal–distributed Bragg reflector (DBR) structure integrated with a monolayer of molybdenum disulfide (MoS₂). Through finite element simulations, we demonstrate that incorporating MoS₂ enhances electromagnetic field localization at the metal–DBR interface, facilitating enhanced exciton–photon interaction. As the number of DBR periods increases, the OTS resonance wavelength undergoes a blue shift and eventually stabilizes, which indicates a wavelength-locking behavior. Under external bias, the locking threshold is lowered, and the resonance wavelength exhibits a nearly linear blue shift of approximately ~1 nm/V. Moreover, absorptance varies non-monotonically with the metal thickness, reaching over 99% at a thickness of 25 nm, due to the combined effects of plasmonic confinement and MoS₂ excitonic enhancement. These findings demonstrate the potential of this structure for application in tunable photonic devices such as optical filters and modulators. Full article

Diabetes has become a global health challenge, driving the demand for innovative, non-invasive diagnostic technologies to improve glucose monitoring. Urinary glucose concentration, a reliable indicator of metabolic changes, provides a practical alternative for frequent monitoring without the discomfort of invasive methods. In this simulation-based study, we propose a novel asymmetric photonic structure that integrates Tamm plasmon polariton (TPP) modes and a cavity mode for high-precision refractive index sensing, with a conceptual focus on the potential detection of urinary glucose. The structure supports three distinct resonance modes, each with unique field localization. Both the TPP modes, confined at the metallic–dielectric interfaces, serve as stable references whose wavelengths are unaffected by refractive-index variations in human urine, whereas the cavity mode exhibits a redshift with increasing refractive index, enabling high responsiveness to analyte changes. The evaluation of sensing performance employs a sensitivity formulation that leverages either TPP mode as a reference and the cavity mode as a probe, thereby achieving dependable measurement and spectral stability. The optimized design achieves a sensitivity of 693 nm·RIU⁻¹ and a maximum figure of merit of 935 RIU⁻¹, indicating high detection resolution and spectral sharpness. The device allows both reflectance and transmittance measurements to ensure enhanced versatility. Moreover, the coupling between TPP and cavity modes demonstrates hybrid resonance, empowering applications such as polarization-sensitive or angle-dependent filtering. The figure of merit is analyzed further, considering resonance wavelength shifts and spectral sharpness, thus manifesting the structure’s robustness. Although this study does not provide experimental data such as calibration curves, recovery rates, or specificity validation, the proposed structure offers a promising conceptual framework for refractive index-based biosensing in human urine. The findings position the structure as a versatile platform for advanced photonic systems, offering precision, tunability, and multifunctionality beyond the demonstrated optical sensing capabilities. Full article

Topological photonic sensors have emerged as a breakthrough in modern optical sensing by integrating topological protection and light confinement mechanisms such as topological states, quasi-bound states in the continuum (quasi-BICs), and Tamm plasmon polaritons (TPPs). These devices exhibit exceptional sensitivity and high-Q resonances, making them ideal for high-precision environmental monitoring, biomedical diagnostics, and industrial sensing applications. This review explores the foundational physics and diverse sensor architectures, from refractive index sensors and biosensors to gas and thermal sensors, emphasizing their working principles and performance metrics. We further examine the challenges of achieving ultrahigh-Q operation in practical devices, limitations in multiparameter sensing, and design complexity. We propose physics-driven solutions to overcome these barriers, such as integrating Weyl semimetals, graphene-based heterostructures, and non-Hermitian photonic systems. This comparative study highlights the transformative impact of topological photonic sensors in achieving ultra-sensitive detection across multiple fields. Full article

This article provides a brief overview of the research on localized optical states called Tamm plasmons (TPs) and their potential applications, which have been extensively studied in recent decades. These states arise under the influence of incident light at the interface between a metal film and a medium with the properties of a Bragg mirror, or between two media with the properties of a Bragg mirror. The localization of the states in the interfacial region is a consequence of the negative dielectric constant of the metal and the presence of a photonic band gap of the Bragg reflector. Optically, TPs appear as resonant reflection dips or peaks in the transmission and absorption spectra in the region corresponding to the photonic band gap. The relative simplicity of creating a Tamm structure and the significant sensitivity of TPs to its parameters make them attractive for applications. The formation of broadband and tunable TP modes in hybrid structures containing, in particular, rugate filters and porous distributed Bragg reflectors are considered. Considerable attention is paid to TP designs that include liquid crystals, which allow for the remote tuning of the TP spectrum without the mechanical restructuring of the system. The application of TPs in sensors, thermal emitters, absorbers, laser generation, and the experimental capabilities of TP-liquid crystal devices are also discussed. Full article

Generally, the responsivities of hot-electron photodetectors (HE PDs) are mainly dependent on the device working wavelengths. Therefore, a common approach to altering device responsivities is to change the working wavelengths. Another strategy for manipulating electrical performances of HE PDs is to harness electric bias that can be used to regulate hot-electron harvesting at specified working wavelengths. However, the reliance on bias hampers the flexibility in device operations. In this study, we propose a purely planar design of HE PDs that contains the phase-change material Sb₂S₃, realizing reversibly alterable hot-electron photodetection without altering the working wavelengths. Optical simulations show that the designed device exhibits strong absorptance (>0.95) at the identical resonance wavelengths due to the excitations of Tamm plasmons (TPs), regardless of Sb₂S₃ phases. Detailed electrical calculations demonstrate that, by inducing Sb₂S₃ transitions between crystalline and amorphous phases back and forth, the device responsivities at TP wavelengths can be reversibly altered between 59.9 nA/mW to 128.7 nA/mW. Moreover, when device structural parameters are variable and biases are involved, the reversibly alterable hot-electron photodetection at specified TP wavelengths is maintained. Full article

Optical absorbers based on Tamm plasmon states are known for their simple structure and high operational efficiency. However, these absorbers often have limited absorption channels, and it is challenging to continuously adjust their light absorption rates. Here, we propose a Tamm plasmon state optical absorber composed of a layered stack structure consisting of one-dimensional topological photonic crystals and graphene nano-composite materials. Using the four-by-four transfer matrix method, we investigate the structural relationship of the absorber. Our results reveal that topological interface states (TISs) effectively excite the optical Tamm state (OTS), leading to multiple absorption peaks. This expands the number of absorption channels, with the coupling number of the TIS determining the transmission quality of these channels—a value further adjustable by the period number of the photonic crystals. Tuning the filling factor, refractive index, and thickness of the graphene nano-composite material allows for a wide range of control over the device’s absorption rate, from 0 to 1. Additionally, adjusting the defect layer thickness, incident angle, and Fermi energy enables us to control the absorber’s operational bandwidth and the switching of its absorption effect. This work presents a new approach to expanding the tunability of optoelectronic devices. Full article

Helicobacter pylori (H. pylori) is a common pathogen with a high prevalence of infection in human populations. The diagnosis of H. pylori infection is critical for its treatment, eradication, and prognosis. Biosensors have been demonstrated to be powerful for the rapid onsite detection of pathogens, particularly for point-of-care test (POCT) scenarios. In this work, we propose a novel optical biosensor, based on nanomaterial porous silicon (PSi) and photonic surface state Tamm Plasmon Polariton (TPP), for the detection of cytotoxin-associated antigen A (CagA) of H. pylori bacterium. We fabricated the PSi TPP biosensor, analyzed its optical characteristics, and demonstrated through experiments, with the sensing of the CagA antigen, that the TPP biosensor has a sensitivity of 100 pm/(ng/mL), a limit of detection of 0.05 ng/mL, and specificity in terms of positive-to-negative ratio that is greater than six. From these performance factors, it can be concluded that the TPP biosensor can serve as an effective tool for the diagnosis of H. pylori infection, either in analytical labs or in POCT applications. Full article

Optical hydrogen sensors offer high sensitivity, high accuracy, and non-invasive sensing capabilities, making them promising devices in various fields, including the construction of hydrogen fuel cells, storage and transportation, and aerospace. However, to achieve better sensitivity and faster reaction times, such sensors are often constructed as nano-arrays or nano-gratings, leading to increased manufacturing costs and complexity. In this study, we propose and demonstrate a highly sensitive hydrogen sensor based on a multilayer structure. The proposed structure consists of a Pd metal film and a photonic crystal with a defect layer, in which the photonic crystal is designed by an alternating arrangement of Ta₂O₅ and SiO₂, and the material comprising the defect layer is SiO₂. With a sensitivity of up to 16,020 at 670 nm, the proposed sensor relies on the coupling of Tamm plasmon polaritons and defect modes. The electric field distribution inside the structure is also provided in order to reveal its physical mechanism. Furthermore, we investigate the effects of the thickness of the defect layer and the angle of incident light on the sensor’s performance. The study results show that the sensor has good fault tolerance in either scenario. The findings of this study open up new possibilities for hydrogen sensor applications. Full article

In this work, we propose a sensor based on Tamm plasmonic resonance; the structure is composed of gold nanoribbons deposited on a Distributed Bragg Reflector (DBR) (SiO₂/Si₃N₄)₆. We have enhanced the sensitivity of our sensor from 40 nm/RIU to 200 nm/RIU for a refractive index change of 1% by replacing the last layer of Si₃N₄ in contact with gold with porous Si₃N₄ with a porosity of p = 40%. Full article

In this study, we demonstrate the potential capability to control Tamm plasmon-polaritons (TPP) by applying atomic layer deposition (ALD) as a highly precise technique for plasmonic applications. Applications in plasmonics usually require tens of nanometers or less thick layers; thus, ALD is a very suitable technique with monolayer-by-monolayer growth of angstrom resolution. Spectroscopic ellipsometry and polarized reflection intensity identified the TPP resonances in the photonic band gap (PBG) formed by periodically alternating silicon oxide and tantalum oxide layers. The sub-nanometer control of the Al₂O₃ layer by ALD allows precise tailoring of TPP resonances within a few nanometers of spectral shift. The employing of the ALD method for the fabrication of thin layers with sub-nanometer thickness accuracy in more complex structures proves to be a versatile platform for practical applications where tunable plasmonic resonances of high quality are required. Full article

The circular polarization of light flips its handedness after a conventional metallic mirror reflection. Therefore, a polarization-preserving metasurface is a crucially important element in a series of chiral photonic structures. They include tunable cholesteric LCs and anisotropic photonic crystals. Chiral structures are rich in interfacial localized modes including Tamm states. In this report, coupled modes formed as a result of the interaction between two chiral optical Tamm states or a chiral optical Tamm state and a chiral Tamm plasmon polariton are analytically and numerically investigated. It is shown that the effective control of coupled modes can be carried out by changing the pitch of the cholesteric and the angle between the optical axis of the cholesteric and the polarization-preserving anisotropic mirror. The influence of the metasurface period on the spectral characteristics of coupled modes is investigated. The possibility of realizing a bound state in the continuum of the Friedrich–Wintgen type, resulting from the destructive interference of coupled modes, which leads to the collapse of the resonance line corresponding to the chiral optical Tamm state, has been demonstrated. Full article

Tamm Plasmon Polariton (TPP) is a nanophotonic phenomenon that has attracted much attention due to its spatial strong field confinement, ease of mode excitation, and polarization independence. TPP has applications in sensing, storage, lasing, perfect absorber, solar cell, nonlinear optics, and many others. In this work, we demonstrate a biosensing platform based on TPP resonant mode. Both theoretical analyses based on the transfer matrix method and experimental validation through nonspecific detection of liquids of different refractive indices and specific detection of SARS-CoV-2 nucleocapsid protein (N-protein) are presented. Results show that the TPP biosensor has high sensitivity and good specificity. For N-protein detection, the sensitivity can be up to 1.5 nm/(µg/mL), and the limit of detection can reach down to 7 ng/mL with a spectrometer of 0.01 nm resolution in wavelength shift. Both nonspecific detection of R.I. liquids and specific detection of N-protein have been simulated and compared with experimental results to demonstrate consistency. This work paves the way for design, optimization, fabrication, characterization, and performance analysis of TPP based biosensors. Full article

The dynamic steering of a beam reflected from a photonic structure supporting Tamm plasmon polariton is demonstrated. The phase and amplitude of the reflected wave are adjusted by modulating the refractive index of a transparent conductive oxide layer by applying a bias voltage. It is shown that the proposed design allows for two-dimensional beam steering by deflecting the light beam along the polar and azimuthal angles. Full article
