Search Results (16)

Search Parameters:
Keywords = RX-band noise

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 3238 KiB
Article
Multilayer Printed Circuit Board Design Based on Copper Paste Sintering Technology for Satellite Communication Receiving Phased Array
by Sicheng Sun, Yijiu Zhao, Sitao Mei, Naixin Zhou and Yongling Ban
Electronics 2025, 14(2), 322; https://doi.org/10.3390/electronics14020322 - 15 Jan 2025
Viewed by 1143
Abstract
A 2048-element dual-polarized receive (RX) phased array for Ku-band (10.7–12.7 GHz) satellite communication (SATCOM) is presented in this paper. The design of the multilayer printed circuit board (PCB) it uses adopts a novel copper paste sintering interconnection technology that allows for [...] Read more.
A 2048-element dual-polarized receive (RX) phased array for Ku-band (10.7–12.7 GHz) satellite communication (SATCOM) is presented in this paper. The design of the multilayer printed circuit board (PCB) it uses adopts a novel copper paste sintering interconnection technology that allows for more flexibility in the design of vias and can reduce the PCB’s lamination number. This technology is more suitable for manufacturing multilayer and complex PCBs than traditional processes. The array is designed to consist of sixteen 8 × 16 element subarrays, each based on the silicon RX beamformer and multilayer PCB. Dual-polarized antenna elements are arranged in a regular rectangle with a spacing of 0.5 for a wavelength of 12.7 GHz, thus achieving a scanning range of ±70° in all planes. By adjusting the amplitude and phase of two line polarizations with cross-polarization levels better than −25 dB at boresight, the array can generate linear or circular polarization. Moreover, the antenna gain-to-noise temperature is above 12 dB/K (Tant = 20 K) at boresight. The aperture of the 2048-element RX phased array is 768 × 450 mm. With its low profile, the array is appropriate for usage in Ku-band SATCOM terminals. Full article
Show Figures

Figure 1

8 pages, 3626 KiB
Communication
Analysis and Design of Low-Noise Radio-Frequency Power Amplifier Supply Modulator for Frequency Division Duplex Cellular Systems
by Ji-Seon Paek
Electronics 2024, 13(23), 4635; https://doi.org/10.3390/electronics13234635 - 25 Nov 2024
Cited by 1 | Viewed by 1049
Abstract
This paper describes an analysis of power supply rejection and noise improvement techniques for an envelope-tracking power amplifier. Although the envelope-tracking technique improves efficiency, its power supply rejection ratio is much lower than that of average power tracking or a fixed-supply power amplifier. [...] Read more.
This paper describes an analysis of power supply rejection and noise improvement techniques for an envelope-tracking power amplifier. Although the envelope-tracking technique improves efficiency, its power supply rejection ratio is much lower than that of average power tracking or a fixed-supply power amplifier. In FDD systems with the envelope-tracking technique, the low power supply rejection ratio generates much output noise in the RX band and degrades the receiver’s sensitivity. An SM is designed by using a 130 nm CMOS process, and the chip die area is 2 × 2 mm2 with a 25-pin wafer-level chip-scale package. The designed SM achieved peak efficiencies of 78–83% for LTE signals with a 5.8 dB PAPR and various channel bandwidths. For the low-output-noise-supply modulator, noise reduction techniques using resonant-frequency tuning and a notch filter are employed, and the measured results show maximum 1.8/5/5.3/3.8/3 dB noise reduction in LTE bands B17/B5/B2/B3/B7, respectively. Full article
(This article belongs to the Special Issue Millimeter-Wave/Terahertz Integrated Circuit Design)
Show Figures

Figure 1

20 pages, 1627 KiB
Article
Dynamic Spectrum Co-Access in Multicarrier-Based Cognitive Radio Using Graph Theory Through Practical Channel
by Ehab F. Badran, Amr A. Bashir, Hassan Nadir Kheirallah and Hania H. Farag
Appl. Sci. 2024, 14(23), 10868; https://doi.org/10.3390/app142310868 - 23 Nov 2024
Viewed by 1231
Abstract
In this paper, we propose an underlay cognitive radio (CR) system that includes subscribers, termed secondary users (SUs), which are designed to coexist with the spectrum owners, termed primary users (PUs). The suggested network includes the PUs system and the SUs system. The [...] Read more.
In this paper, we propose an underlay cognitive radio (CR) system that includes subscribers, termed secondary users (SUs), which are designed to coexist with the spectrum owners, termed primary users (PUs). The suggested network includes the PUs system and the SUs system. The coexistence between them is achieved by using a novel dynamic spectrum co-access multicarrier-based cognitive radio (DSCA-MC-CR) technique. The proposal uses a quadrature phase shift keying (QPSK) modulation technique within the orthogonal frequency-division multiplexing (OFDM) scheme that maximizes the system data rate and prevents data inter-symbol interference (ISI). The proposed CR transmitter station (TX) and the CR receiver node (RX) can use an advanced smart antenna system, i.e., a multiple-input and multiple-output (MIMO) system that provides high immunity against channel impairments and provides a high data rate through its different combining techniques. The proposed CR system is applicable to coexist within different existing communication applications like fifth-generation (5G) applications, emergence applications like the Internet of Things (IoT), narrow-band (NB) applications, and wide-band (WB) applications. The coexistence between the PUs system and the SUs system is based on using power donation from the SUs system to improve the quality of the PU signal-to-interference-and-noise ratios (SINRs). The green communication concept achieved in this proposal is compared with similar DSCA proposals from the literature. The simulations of the proposed technique show enhancement in the PUs system throughput and data rate along with the better performance of the SUs system. Full article
Show Figures

Figure 1

23 pages, 21723 KiB
Article
Dual-Band Low-Noise Amplifier for GNSS Applications
by Daniel Pietron, Tomasz Borejko and Witold Adam Pleskacz
Electronics 2024, 13(20), 4130; https://doi.org/10.3390/electronics13204130 - 21 Oct 2024
Cited by 1 | Viewed by 1952
Abstract
A new dual-band low-noise amplifier (LNA) operating at L1/E1 1.575 GHz and L5/E5 1.192 GHz center frequencies for global navigation satellite system receivers is proposed. A doubled common-source amplifier architecture is used with a single input, shared gate inductor, and two outputs to [...] Read more.
A new dual-band low-noise amplifier (LNA) operating at L1/E1 1.575 GHz and L5/E5 1.192 GHz center frequencies for global navigation satellite system receivers is proposed. A doubled common-source amplifier architecture is used with a single input, shared gate inductor, and two outputs to split the RF signal into separate RX channels. The main advantage of the proposed circuit is compatibility with widespread multi-band antennas with single RF connectors dedicated to high-precision applications, as well as the possibility to use cheap SAW filters with small footprints to build low-cost, highly accurate GNSS receiver modules. The input and both outputs are well matched to 50 Ω impedance. The LNA is designed with a 110 nm CMOS process, consuming 6.13 mA current from a 1.5 V supply. The measured noise figures and voltage gains of the dual-band LNA are, respectively, NF1/NF5 = 3.23/3.5 dB and G1/G5 = 21.22/18.2 dB in the band of interest for each channel. The measured impedance matching at the input (S11) and output (S22) of the dual-band low-frequency amplifier is as follows: S11_L1 = −23.89, S11_L5 = −8.42, S22_L1 = −12.65, S22_L5 = −15.08. The one-decibel compression points are L1 band PdB1 = −37.71 dBm and L5 band PdB5 = −34.72 dBm, respectively. Full article
(This article belongs to the Special Issue New Advances in Semiconductor Devices/Circuits)
Show Figures

Figure 1

16 pages, 11312 KiB
Article
Fully Integrated 24-GHz 1TX-2RX Transceiver for Compact FMCW Radar Applications
by Goo-Han Ko, Seung-Jin Moon, Seong-Hoon Kim, Jeong-Geun Kim and Donghyun Baek
Sensors 2024, 24(5), 1460; https://doi.org/10.3390/s24051460 - 23 Feb 2024
Cited by 3 | Viewed by 3116
Abstract
A fully integrated 24-GHz radar transceiver with one transmitter (TX) and two receivers (RXs) for compact frequency modulated continuous wave (FMCW) radar applications is here presented. The FMCW synthesizer was realized using a fractional-N phase-locked loop (PLL) and programmable chirp generator, which are [...] Read more.
A fully integrated 24-GHz radar transceiver with one transmitter (TX) and two receivers (RXs) for compact frequency modulated continuous wave (FMCW) radar applications is here presented. The FMCW synthesizer was realized using a fractional-N phase-locked loop (PLL) and programmable chirp generator, which are completely integrated in the proposed transceiver. The measured output phase noise of the synthesizer is −80 dBc/Hz at 100 kHz offset. The TX consists of a three-bit bridged t-type attenuator for gain control, a two-stage drive amplifier (DA) and a one-stage power amplifier (PA). The TX chain provides an output power of 13 dBm while achieving <0.5 dB output power variation within the range of 24 to 24.25 GHz. The RX with a direct conversion I-Q structure is composed of a two-stage low noise amplifier (LNA), I-Q generator, mixer, transimpedance amplifier (TIA), a two-stage biquad band pass filter (BPF), and a differential-to-single (DTS) amplifier. The TIA and the BPF employ a DC offset cancellation (DCOC) circuit to suppress the strong reflection signal and TX-RX leakage. The RX chain exhibits an overall gain of 100 dB. The proposed radar transceiver is fabricated using a 65 nm CMOS technology. The transceiver consumes 220 mW from a 1 V supply voltage and has 4.84 mm2 die size including all pads. The prototype FMCW radar is realized with the proposed transceiver and Yagi antenna to verify the radar functionality, such as the distance and angle of targets. Full article
Show Figures

Figure 1

13 pages, 5203 KiB
Article
Anomaly Detection of Remote Sensing Images Based on the Channel Attention Mechanism and LRX
by Huinan Guo, Hua Wang, Xiaodong Song and Zhongling Ruan
Appl. Sci. 2023, 13(12), 6988; https://doi.org/10.3390/app13126988 - 9 Jun 2023
Cited by 2 | Viewed by 2827
Abstract
Anomaly detection of remote sensing images has gained significant attention in remote sensing image processing due to their rich spectral information. The Local RX (LRX) algorithm, derived from the Reed–Xiaoli (RX) algorithm, is a hyperspectral anomaly detection method that focuses on identifying anomalous [...] Read more.
Anomaly detection of remote sensing images has gained significant attention in remote sensing image processing due to their rich spectral information. The Local RX (LRX) algorithm, derived from the Reed–Xiaoli (RX) algorithm, is a hyperspectral anomaly detection method that focuses on identifying anomalous pixels in hyperspectral images by exploiting local statistics and background modeling. However, it is still susceptible to the noises in the Hyperspectral Images (HSIs), which limits its detection performance. To address this problem, a hyperspectral anomaly detection algorithm based on channel attention mechanism and LRX is proposed in this paper. The HSI is feed into the auto-encoder network that is constrained by the channel attention module to generate a more representative reconstructed image that better captures the characteristics of different land covers and has less noises. The channel attention module in the auto-encoder network aims to explore the effective spectral bands corresponding to different land covers. Subsequently, the LRX algorithm is utilized for anomaly detection on the reconstructed image obtained from the auto-encoder network with the channel attention mechanism, which avoids the influence of noises on the anomaly detection results and improves the anomaly detection performance. The experiments are conducted on three HSIs to verify the performance of the proposed method. The proposed hyperspectral anomaly detection method achieves higher Area Under Curve (AUC) values of 0.9871, 0.9916 and 0.9642 on HYDICE urban dataset, AVIRIS aircraft dataset and Salinas Valley dataset, respectively, compared with other six methods. The experimental results demonstrate that the proposed algorithm has better anomaly detection performance than LRX and other algorithms. Full article
(This article belongs to the Special Issue AI-Based Image Processing)
Show Figures

Figure 1

15 pages, 6298 KiB
Article
An S-Band-Receiving Phased-Array Antenna with a Phase-Deviation-Minimized Calibration Method for LEO Satellite Ground Station Applications
by Dong-Hyo Lee, Jung-Won Seo, Myeong-Shin Lee, Daewon Chung, Dongkook Lee, Jae-Hoon Bang, Bagas Satriyotomo and Seongmin Pyo
Electronics 2022, 11(23), 3847; https://doi.org/10.3390/electronics11233847 - 22 Nov 2022
Cited by 3 | Viewed by 6015
Abstract
This study presents a new S-band-receiving phased-array antenna with a phase-deviation-minimized calibration method for the ground station of a low Earth orbit (LEO) satellite. The proposed antenna consists of 16 subarrays, 16 beamforming receiving RF modules (BF-RFMs), a power/control board, and a 16-way [...] Read more.
This study presents a new S-band-receiving phased-array antenna with a phase-deviation-minimized calibration method for the ground station of a low Earth orbit (LEO) satellite. The proposed antenna consists of 16 subarrays, 16 beamforming receiving RF modules (BF-RFMs), a power/control board, and a 16-way feed network. The subarray was achieved by joining two 8 × 1 arrays with a two-way power combiner. The 16-element antenna subarrays showed a gain of 16.1 dBi and a reflection coefficient of less than −10 dB from 2.12 GHz to 2.45 GHz. The BF-RFM, which consists of three low-noise amplifiers (LNAs), a power combiner, a phase shifter, and a digital attenuator, was designed and fabricated. The BF-RFMs were provided by the power/control board and showed a gain of 30.8 ± 0.8 dB, an amplitude root-mean-square (RMS) error from 0.25 dB to 0.28 dB, and a phase RMS error from 1.8° to 2.5° over the Rx frequency range. The arrangement procedures of the 16 BF-RFMs are presented to increase beam pointing accuracy at the desired angle. A commercial 16-way feed network was employed to combine all the output ports of the 16 BF-RFMs. The assembled antenna, which has dimensions of 1.58 m × 1.58 m × 0.2 m, was measured by partial and full scans in the near-field scanning system. The back-projected algorithm was employed to calibrate the antenna’s gain patterns in the partial scan. The implemented phased-array antenna had a gain greater than 28.14 dBi, sidelobe levels less than −17.1 dB, and beam pointing errors less than 0.07° over the beam pointing angle of −20~+20°. Based on the implemented antenna system, we conducted a field test using KOMPSAT-5, which is actually operating in South Korea, in order to verify the performance of the low Earth orbit (LEO) satellite ground station system. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

24 pages, 6726 KiB
Article
Design and Implementation of Low Noise Amplifier Operating at 868 MHz for Duty Cycled Wake-Up Receiver Front-End
by Ilef Ketata, Sarah Ouerghemmi, Ahmed Fakhfakh and Faouzi Derbel
Electronics 2022, 11(19), 3235; https://doi.org/10.3390/electronics11193235 - 8 Oct 2022
Cited by 18 | Viewed by 7841
Abstract
The integration of wireless communication, e.g., in real- or quasi-real-time applications, is related to many challenges such as energy consumption, communication range, quality of service, and reliability. The improvement of wireless sensor networks (WSN) performance starts by enhancing the capabilities of each sensor [...] Read more.
The integration of wireless communication, e.g., in real- or quasi-real-time applications, is related to many challenges such as energy consumption, communication range, quality of service, and reliability. The improvement of wireless sensor networks (WSN) performance starts by enhancing the capabilities of each sensor node. To minimize latencies without increasing energy consumption, wake-up receiver (WuRx) nodes have been introduced in recent works since they can be always-on or power-gated with short latencies by a power consumption in the range of some microwatts. Compared to standard receiver technologies, they are usually characterized by drawbacks in terms of sensitivity. To overcome the limitation of the sensitivity of WuRxs, a design of a low noise amplifier (LNA) with several design specifications is required. The challenging task of the LNA design is to provide equitable trade-off performances such as gain, power consumption, the noise figure, stability, linearity, and impedance matching. The design of fast settling LNA for a duty-cycled WuRx front-end operating at a 868 MHz frequency band is investigated in this work. The paper details the trade-offs between design challenges and illustrates practical considerations for the simulation and implementation of a radio frequency (RF) circuit. The implemented LNA competes with many commercialized designs where it reaches single-stage 12 dB gain at a 1.8 V voltage supply and consumes only a 1.6 mA current. The obtained results could be made tunable by working with off-the-shelf components for different wake-up based application exigencies. Full article
Show Figures

Figure 1

10 pages, 3473 KiB
Article
Advances in Ku-Band GaN Single Chip Front End for Space SARs: From System Specifications to Technology Selection
by Francesco Scappaviva, Gianni Bosi, Andrea Biondi, Sara D’Angelo, Luca Cariani, Valeria Vadalà, Antonio Raffo, Davide Resca, Elisa Cipriani and Giorgio Vannini
Electronics 2022, 11(19), 2998; https://doi.org/10.3390/electronics11192998 - 21 Sep 2022
Cited by 6 | Viewed by 5439
Abstract
In this paper, a single-chip front-end (SCFE) operating in Ku-band (12–17 GHz) is presented. It is designed exploiting a GaN on SiC technology featured by 150 nm gate length provided by UMS foundry. This MMIC integrates high power and low noise amplification functions [...] Read more.
In this paper, a single-chip front-end (SCFE) operating in Ku-band (12–17 GHz) is presented. It is designed exploiting a GaN on SiC technology featured by 150 nm gate length provided by UMS foundry. This MMIC integrates high power and low noise amplification functions enabled by a single-pole double-throw (SPDT) switch, occupying a total area of 20 mm2. The transmitting chain (Tx) presents a 39 dBm output power, a power added efficiency (PAE) higher than 30% and a 22 dB power gain. The receive path (Rx) offers a low noise figure (NF) lower than 2.8 dB with 25 dB of linear gain. The Rx port output power leakage is limited on chip to be below 15 dBm even at high compression levels. Finally, a complete characterization of the SCFE in the Rx and Tx modes is presented, also showing the measurement of the recovery time in the presence of large-signal interferences. Full article
(This article belongs to the Special Issue Power Amplifier for Wireless Communication)
Show Figures

Figure 1

11 pages, 28988 KiB
Article
Educational Low-Cost C-Band FMCW Radar System Comprising Commercial Off-the-Shelf Components for Indoor Through-Wall Object Detection
by Hyunmin Jeong and Sangkil Kim
Electronics 2021, 10(22), 2758; https://doi.org/10.3390/electronics10222758 - 11 Nov 2021
Cited by 8 | Viewed by 5829
Abstract
This paper presents an educational low-cost C-band frequency-modulated continuous wave (FMCW) radar system for use in indoor through-wall metal detection. Indoor remote-sensing applications, such as through-wall detection and positioning, are essential for the comprehensive realization of the internet of things or super-connected societies. [...] Read more.
This paper presents an educational low-cost C-band frequency-modulated continuous wave (FMCW) radar system for use in indoor through-wall metal detection. Indoor remote-sensing applications, such as through-wall detection and positioning, are essential for the comprehensive realization of the internet of things or super-connected societies. The proposed system comprises a two-stage radio-frequency power amplifier, a voltage-controlled oscillator, circuits for frequency modulation and system synchronization, a mixer, a 3-dB power divider, a low-noise amplifier, and two cylindrical horn antennas (Tx/Rx antennas). The antenna yields gain values in the 6.8~7.8 range when operating in the 5.83~5.94 GHz frequency band. The backscattered Tx signal is sampled at 4.5 kHz using the Arduino UNO analog-to-digital converter. Thereafter, the sampled signal is transferred to the MATLAB platform and analyzed using a customized FMCW radar algorithm. The proposed system is built using commercial off-the-shelf components, and it can detect targets within a 56.3 m radius in indoor environments. In this study, the system could successfully detect targets through a 4 cm-thick ply board with a measurement accuracy of less than 10 cm. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1

10 pages, 3868 KiB
Technical Note
Indoor Experiments of Bistatic/Multistatic GB-SAR with One-Stationary and One-Moving Antennae
by Hoonyol Lee and Jihyun Moon
Remote Sens. 2021, 13(18), 3733; https://doi.org/10.3390/rs13183733 - 17 Sep 2021
Cited by 2 | Viewed by 2022
Abstract
Ground-based synthetic aperture radar (GB-SAR) is a useful tool to simulate advanced SAR systems with its flexibility on RF system and SAR configuration. This paper reports an indoor experiment of bistatic/multistatic GB-SAR operated in Ku-band with two antennae: one antenna was stationary on [...] Read more.
Ground-based synthetic aperture radar (GB-SAR) is a useful tool to simulate advanced SAR systems with its flexibility on RF system and SAR configuration. This paper reports an indoor experiment of bistatic/multistatic GB-SAR operated in Ku-band with two antennae: one antenna was stationary on the ground and the other was moving along a linear rail. Multiple bistatic GB-SAR images were taken with various stationary antenna positions, and then averaged to simulate a multistatic GB-SAR configuration composed of a moving Tx antenna along a rail and multiple stationary Rx antennae with various viewing angles. This configuration simulates the use of a spaceborne/airborne SAR system as a transmitting antenna and multiple ground-based stationary antennae as receiving antennae to obtain omni-directional scattering images. This SAR geometry with one-stationary and one-moving antennae configuration was analyzed and a time-domain SAR focusing algorithm was adjusted to this geometry. Being stationary for one antenna, the Doppler rate was analyzed to be half of the monostatic case, and the azimuth resolution was doubled. Image quality was enhanced by identifying and reducing azimuth ambiguity. By averaging multiple bistatic images from various stationary antenna positions, a multistatic GB-SAR image was achieved to have better image swath and reduced speckle noise. Full article
(This article belongs to the Section Remote Sensing Communications)
Show Figures

Graphical abstract

23 pages, 1251 KiB
Article
Performance Analysis of Two-Hop mmWave Relay Nodes over the 5G NR Uplink Signal
by Randy Verdecia-Peña and José I. Alonso
Appl. Sci. 2021, 11(13), 5828; https://doi.org/10.3390/app11135828 - 23 Jun 2021
Cited by 9 | Viewed by 3332
Abstract
In this paper, the uplink in a two-hop 5G new radio co-operative system using Relay Nodes (RNs) in millimeter bands has been simulated and studied. We focus on an uplink Amplify-and-Forward Relay Node (A&F RN) and Decode-and-Forward Relay Node (D&F RN) with an [...] Read more.
In this paper, the uplink in a two-hop 5G new radio co-operative system using Relay Nodes (RNs) in millimeter bands has been simulated and studied. We focus on an uplink Amplify-and-Forward Relay Node (A&F RN) and Decode-and-Forward Relay Node (D&F RN) with an mmWave-band transceiver chain (Tx/Rx). We study two uplink mmWave MIMO D&F relaying protocols assuming, firstly, the complete knowledge of the uplink channel and, secondly, the uplink channel estimation through a Least Square (LS) algorithm. To verify the benefits of the proposed uplink mmWave MIMO co-operative network, a link-level co-operative simulator has been developed using MatlabTM and SimulinkTM software, where an indoor-to-outdoor scenario and mmWave transceiver with off-the shelf components are considered. The main novelty of this link-level co-operative simulator and the implemented relay nodes is the usage of signals with 5G NR features, such as UL-SCH transport channel coding and PUSCH generation, which are the other main contributions of this article. Based on the numerical results in terms of the achievable Bit Error Rate (BER) and throughput, we show that the two-hop uplink co-operative network substantially improves the performance in the communications between the NR-User Equipment (NR-UE) and the logical 5G Radio Node (gNodeB). For example, the results from using uplink mmWave NR-D&F protocols far exceed those achieved with the uplink mmWave NR-A&F algorithm; in the case of the 64-QAM modulation scheme for the SISO technique, an improvement of 6.5 Mbps was achieved using the D&F PCE protocol, taking into account that the 256-QAM constellation is higher by 4.05 Mbps. On the other hand, an average throughput enhancement of 28.77 Mbps was achieved when an uplink mmWave (2 × 4 × 4) D&F PCE strategy was used versus an uplink mmWave SISO D&F LS protocol for a Signal-to-Noise Ratio (SNR) = 20 dB and 64-QAM signal. However, an improvement of 56.42 Mbps was reached when a 256-QAM modulation scheme was employed. Furthermore, this paper introduces the first study to develop an uplink mmWave MIMO 5G co-operative network platform through a Software Defined Radio (SDR) from a practical implementation point of view. Full article
Show Figures

Figure 1

19 pages, 1037 KiB
Article
A Two-Hop mmWave MIMO NR-Relay Nodes to Enhance the Average System Throughput and BER in Outdoor-to-Indoor Environments
by Randy Verdecia-Peña and José I. Alonso
Sensors 2021, 21(4), 1372; https://doi.org/10.3390/s21041372 - 16 Feb 2021
Cited by 10 | Viewed by 3283
Abstract
Millimeter-Wave (mmWave) bands are receiving enormous attention in 5G mobile communications, due to the capability to provide a multi-gigabit transmission rate. In this paper, a two-hop architecture for 5G communications with the capacity to support high end-to-end performance due to the use of [...] Read more.
Millimeter-Wave (mmWave) bands are receiving enormous attention in 5G mobile communications, due to the capability to provide a multi-gigabit transmission rate. In this paper, a two-hop architecture for 5G communications with the capacity to support high end-to-end performance due to the use of Relay Nodes (RNs) in mmWave-bands is presented. One of the novelties of the paper is the implementation of Amplify-and-Forward (A&F) and Decode-and-Forward (D&F) RNs along with a mmWave-band transceiver chain (Tx/Rx). In addition, two approaches for channel estimation were implemented at the D&F RN for decoding the backhaul link. One of them assumes complete knowledge of the channel (PCE), and the other one performs the channel estimation through Least Square (LS) estimator. A large number of simulations, using MATLABTM and SimulinkTM software, were performed to verify the potential benefits of the proposal two-hop 5G architecture in an outdoor-to-indoor scenario. The main novelty in performing these simulations is the use of signals with 5G features, as DL-SCH transport channel coding, PDSCH generation, and SS Burst generation, which is another of the main contributions of the paper. On the other hand, mmWave transmitter and receiver chains were designed and implemented with off-the shelf components. The simulations show that the two-hop network substantially improves the Key Performance Indicators (KPIs), Bit Error Rate (BER), and Throughput, in the communications between the logical 5G Radio Node (gNodeB), and the New Radio User Equipment (NR-UE). For example, a throughput improvement of 22 Mbps is obtained when a 4 × 4 × 2 MIMO D&F with LS architecture is used versus a SISO D&F with PCE architecture for Signal-to-Noise Ratio (SNR) = 20 dB and 64-QAM signal. This improvement reaches 96 Mbps if a 256-QAM signal is considered. The improvement in BER is 11 dB and 10.5 dB, respectively, for both cases. This work also shows that the obtained results with D&F RNs are better than with A&F RNs. For example, an improvement of 17 Mbps in the use of SISO D&F with LS vs. SISO A&F, for the 64-QAM signal is obtained. Besides, this paper constitutes a first step to the implementation of a mmWave MIMO 5G cooperative network platform. Full article
Show Figures

Graphical abstract

17 pages, 5828 KiB
Article
A Linearity Improvement Front End with Subharmonic Current Commutating Passive Mixer for 2.4 GHz Direct Conversion Receiver in 0.13 μm CMOS Technology
by Dongquan Huo, Luhong Mao, Liji Wu and Xiangmin Zhang
Electronics 2020, 9(9), 1369; https://doi.org/10.3390/electronics9091369 - 24 Aug 2020
Cited by 2 | Viewed by 3767
Abstract
Direct conversion receiver (DCR) architecture is a promising candidate in the radio frequency (RF) front end because of its low power consumption, low cost and ease of integration. However, flicker noise and direct current (DC) offset are large issues. Owing to the local [...] Read more.
Direct conversion receiver (DCR) architecture is a promising candidate in the radio frequency (RF) front end because of its low power consumption, low cost and ease of integration. However, flicker noise and direct current (DC) offset are large issues. Owing to the local oscillator (LO) frequency, which is half of the RF frequency, and the absence of a DC bias current that introduces no flicker noise, the subharmonic passive mixer (SHPM) core topology front end overcomes the shortcoming effectively. When more and more receivers (RX) and transmitters (TX) are integrated into one chip, the linearity of the receiver front end becomes a very important performer that handles the TX and RX feedthrough. Another reason for the requirement of good linearity is the massive electromagnetic interference that exists in the atmosphere. This paper presents a linearity-improved RF front end with a feedforward body bias (FBB) subharmonic mixer core topology that satisfies modern RF front end demands. A novel complementary derivative superposition (DS) method is presented in low noise amplifier (LNA) design to cancel both the third- and second-order nonlinearities. To the best knowledge of the authors, this is the first time FBB technology is used in the SHPM core to improve linearity. A Volterra series is introduced to provide an analytical formula for the FBB of the SHPM core. The design was fabricated in a 0.13 μm complementary metal oxide semiconductor (CMOS) process with a chip area of 750 μm × 1270 μm. At a 2.4 GHz working frequency, the measurement result shows a conversion gain of 36 dB, double side band (DSB) noise figure (NF) of 6.8 dB, third-order intermodulation intercept point (IIP3) of 2 dBm, LO–RF isolation of 90 dB and 0.8 mW DC offset with 14.4 mW power consumption at 1.2 V supply voltage. These results exhibit better LO–RF feedthrough and DC offset, good gain and NF, moderate IIP3 and the highest figure of merit compared to the state-of-the-art publications. Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

16 pages, 1506 KiB
Article
Mobility Management Based on Beam-Level Measurement Report in 5G Massive MIMO Cellular Networks
by Younghoon Jo, Jaechan Lim and Daehyoung Hong
Electronics 2020, 9(5), 865; https://doi.org/10.3390/electronics9050865 - 23 May 2020
Cited by 9 | Viewed by 5690
Abstract
Massive multiple-input-multiple-output (MMIMO) in the mmWave band is an essential technique to achieve the desired performance for 5G new radio (NR) systems. To employ mmWave MMIMO technology, an important challenge is maintaining seamless mobility to users because we need to consider beam-switching within [...] Read more.
Massive multiple-input-multiple-output (MMIMO) in the mmWave band is an essential technique to achieve the desired performance for 5G new radio (NR) systems. To employ mmWave MMIMO technology, an important challenge is maintaining seamless mobility to users because we need to consider beam-switching within a cell besides the handover between cells. For mobility management in 5G NR systems, 3GPP specified a beam-level-mobility scheme that includes beam pairing and maintenance between a transmitter (Tx) and receiver (Rx) pair. We propose a unific-measurement report based mobility management scheme for improved radio-link-failure (RLF) rate and the accuracy of the Tx-Rx-beam-pair (TRP) selection with low overhead in 5G mmWave MMIMO networks where both handover and beam-switching are required. Furthermore, we modeled a finite-state-machine (FSM) for a user terminal to evaluate performance gain based on a system-level-simulation (SLS). We use the FSM-based Monte-Carlo SLS for the experiment and compare the performance of the proposed scheme with that of existing schemes in the scenario where both beam and cell-level-mobility are necessary. We show that the proposed scheme achieves an improvement in terms of the 3-dB loss probabilities representing the accuracy of the TRP selection, signal-to-interference-and-noise-ratio (SINR), and RLF rates with a lower signaling overhead compared to existing methods. Full article
(This article belongs to the Section Microwave and Wireless Communications)
Show Figures

Figure 1
