Search Results (22)

[011] poled relaxor-PT single crystals provide superior piezoelectric constants and electromechanical coupling factors in the 32 crystal directions, and also exhibit high electrical stability under compressive stresses and temperature changes. In particular, Mn-doped Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ (Mn:PIN-PMN-PT) single crystals show a superior coercive field (E_C ≥ 8.0 kV/cm) and mechanical quality factor (Q_m ≥ 1030), making them suitable for high-power transducers. The high-power characteristics of [011] poled single crystals have been verified from a material perspective; thus, further investigation is required from a transducer perspective. In this study, the high-power characteristics of piezoelectric transducers based on [011] poled PIN-PMN-PT and [011] poled Mn:PIN-PMN-PT single crystals were investigated. To analyze the driving limits of the single crystals, the polarization–electric field (P–E) curves, as a function of the driving electric field, were measured. The results showed that [011] poled Mn:PIN-PMN-PT single crystals demonstrate lower energy loss and THD (Total Harmonic Distortion), directly relating to the driving efficiency and linearity of the transducer. Additionally, [011] poled Mn:PIN-PMN-PT crystals provide excellent stability under the compressive stress and temperature changes. To analyze the high-power characteristics of [011] poled single-crystal transducers, two types of barrel-stave transducers, based on [011] poled PIN-PMN-PT and [011] poled Mn:PIN-PMN-PT, were designed and fabricated. The changes in the impedance and transmitting voltage response with respect to the driving electric fields were measured, and the energy loss and THD of the transducers with respect to the driving electric fields were examined to assess the driving limit of the [011] poled single-crystal transducer. The high-power characteristic tests confirmed the stability of [011] poled Mn:PIN-PMN-PT single crystals and verified their potential for high-power transducer applications. Full article

Piezoelectric composites, which consist of piezoelectric materials and polymers, are widely employed in various applications such as underwater sonar transducers and medical diagnostic ultrasonic transducers. Acoustic transducers based on piezoelectric composites can have high sensitivity with broad bandwidth. In recent studies, it is demonstrated that 2-2 composites based on single crystals provide further increased sensitivity and wide bandwidth. In order to utilize a 2-2 composite in acoustic sensors, it is required to demonstrate the full material coefficients of the 2-2 composite. In this study, we investigated an analytic solution for determining equivalent material coefficients of a 2-2 composite. Impedance spectrums of the single-phase resonators with equivalent material coefficients and 2-2 composite resonators were compared by the finite element method in order to verify the analytic solutions. Furthermore, the equivalent material coefficients derived from the analytic solution were also verified by comparing the measured and the simulated impedance spectrums. The difference in resonance and anti-resonance frequencies between the measured and simulated impedance spectrums was around 0.5% and 1.2%. By utilizing the analytic solutions in this study, it is possible to accurately derive full equivalent material coefficients of a 2-2 composite, which are essential for the development of acoustic sensors. Full article

Waste heat is inherent to industrial activities, IT services (e.g., data centers and microprocessors), human mobility, and many other common processes. The power lost each year in this way has been estimated in the 1000 TWh in the EU which, owing to skyrocketing energy prices and not least the urgent need for decarbonizing the economy, has engendered tremendous research efforts among scientists and engineers to recover/recycle this waste energy. Beyond established thermal engineering solutions for waste heat, advances in multifunctional materials open new paradigms for waste heat harvesting. Two smart material types are of particular focus and interest at present; these are thermoelectric and pyroelectric materials, which can both transform heat to electrical power, though via different effects. The present paper summarizes our research work on a new class of pyroelectric materials, namely <111> oriented (1 − x)(Pb(Mg_1/3Nb_2/3)O₃–xPbTiO₃ (PMN-PT) and x-Pb(In_1/2 Nb_1/2)O₃-y-Pb(Mg_1/3 Nb_2/3)O₃-(1 − x − y)-PbTiO₃ (PIN-PMN-PT) single crystals that exhibit some of the highest pyroelectric properties ever measured. First, a figure of merit for pyroelectric energy harvesting is derived, followed by a detailed assessment of the properties of the said crystals and how they depend on structure, poling, thickness, and temperature. The properties are further contrasted with those of conventional pyroelectric crystals. It is concluded that the PMN-PT-base single crystals are best suited for harvesting devices with a working temperature range from 40 to 100 °C, which encompasses waste heat generated by data centers and some chemical and industrial processes, affording the highest figure of merit among pyroelectric materials. Full article

Temperature–field phase diagrams in the [001]_c and [011]_c directions in the cubic coordinate in 24%Pb(In_1/2Nb_1/2)O₃–46%Pb(Mg_1/3Nb_2/3)O₃–30%PbTiO₃ (24PIN–46PMN–30PT) and 31PIN–43PMN–26PT near the morphotropic phase boundary have been clarified by measuring the temperature dependences of permittivity under an electric field. Field-induced intermediate orthorhombic and tetragonal phases have been newly found in 24PIN–46PMN–30PT and 31PIN–43PMN–26PT, respectively. The temperature dependences of the remanent polarization have also been determined by polarization–electric field (P–E) hysteresis loop evaluation. On the basis of our experimental results, the phase transition and dielectric anisotropy in PIN–PMN–PT have been discussed. Full article

Relaxor ferroelectrics play a vital role as functional components in electromechanical devices. The observation of micro-scale domain structure evolution under electric bias in relaxor ferroelectrics has posed challenges due to their complex domain morphology characterized by small-sized domains. The present study aims to investigate the dielectric diffusion–relaxation characteristics, domain structure, and domain switching evolution under electric bias in high-performance single crystals of Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-33PbTiO₃. The findings reveal the presence of strip-like domain patterns that interlock irregular small-sized nanodomains in PIN-PMN-33PT single crystals. Furthermore, the sample undergoes three distinct stages under electric bias, including the nucleation of new domains, the gradual forward expansion of domains, and the lateral expansion of domains. These observations provide valuable insights for understanding and exploring domain engineering techniques in relaxor ferroelectrics. Full article

Piezoelectric composites, which consist of a piezoelectric material and a polymer, have been extensively studied for the applications of underwater sonar sensors and medical diagnostic ultrasonic transducers. Acoustic sensors utilizing piezoelectric composites can have a high sensitivity and wide bandwidth because of their high piezoelectric coefficient and low acoustic impedance compared to single-phase piezoelectric materials. In this study, a thickness-mode driving hydrophone utilizing a 2-2 piezoelectric single crystal composite was examined. From the theoretical and numerical analysis, material properties that determine the bandwidth and sensitivity of the thickness-mode piezoelectric plate were derived, and the voltage sensitivity of piezoelectric plates with various configurations was compared. It was shown that the 2-2 composite with [011] poled single crystals and epoxy polymers can provide high sensitivity and wide bandwidth when used for hydrophones with a thickness resonance mode. The hydrophone element was designed and fabricated to have a thickness mode at a frequency around 220 kHz by attaching a composite plate of quarter-wavelength thickness to a hard baffle. The fabricated hydrophone demonstrated an open circuit voltage sensitivity of more than −180 dB re 1 V/μPa at the resonance frequency and a −3 dB bandwidth of more than 55 kHz. The theoretical and experimental studies show that the 2-2 single crystal composite can have a high sensitivity and wide bandwidth compared to other configurations of piezoelectric elements when they are used for thickness-mode hydrophones. Full article

xPb(In_1/2Nb_1/2)O₃-(1−x−y)Pb(Mg_1/3Nb_2/3)O₃−yPbTiO₃ (PIN–PMN–PT) bulks possess excellent electromechanical coupling and dielectric properties, but the corresponding epitaxial PIN–PMN–PT thin films have not yet been explored. This paper adopts a nonlinear thermodynamics analysis to investigate the influences of misfit strains on the phase structures, electromechanical properties, and electrocaloric responses in epitaxial PIN–PMN–PT thin films. The misfit strain–temperature phase diagram was constructed. The results reveal that the PIN–PMN–PT thin films may exist in tetragonal c-, orthorhombic aa-, monoclinic M-, and paraelectric PE phases. It is also found that the c-M and aa-PE phase boundaries exhibit a superior dielectric constant ${\epsilon }_{11}$ which reached 1.979 × 10⁶ with u_m = −0.494%, as well as the c-M phase boundary showing a large piezoelectric response d₁₅ which reached 1.64 × 10⁵ pm/V. In comparison, the c-PE and M-aa phase boundaries exhibit a superior dielectric constant ε₃₃ over 1 × 10⁵ around um = 0.316% and the piezoelectric response d₃₃ reached 7235 pm/V. The large electrocaloric responses appear near the paraelectric- ferroelectric phase boundary. These insights offer a guidance for experiments in epitaxial PIN–PMN–PT thin films. Full article

Mn-doped Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ (Mn:PIN-PMN-PT) single crystals are attractive piezoelectric materials owing to their high mechanical quality factor. However, the single crystal boules grown by the conventional Bridgman method show compositional variation along the growth direction. In particular, the Mn content exhibits large variation due to its severe segregation. To improve the compositional uniformity, we applied the continuous-feeding Bridgman method to the growth of a Mn:PIN-PMN-PT single crystal boule. Then, the composition and property distributions of the boule along the growth direction were evaluated. The results showed that excellent composition and property uniformity were carried out over 80mm in boule length. The ranges of the electromechanical coupling coefficient (k₃₃) and the piezoelectric coefficient (d₃₃) were 0.931–0.934 and 1352–1517 pC/N, respectively. The ranges of the mechanical quality factor (Qm₃₁) and the depolarization field (E_d) were 417–535 and 785–859 V/mm, respectively. The Qm₃₁ and the E_d values were higher than those of the non-doped PIN-PMN-PT single crystals. The continuous-feeding Bridgman method is therefore an effective technique for improving the uniformity of the Mn content. As a result, the Mn:PIN-PMN-PT single crystal grown by the continuous-feeding Bridgman method possesses excellent property uniformity with characteristics suitable for high power piezoelectric applications. Full article

Laser scanners with mechanically driven mirrors have exhibited increasing potential for various applications, such as displays and laser radar. Resonant scanners are the predominantly used scanners; however, non-resonant scanners are required for applications where point-to-point driving is desirable. Because a non-resonant drive cannot amplify the drive angle owing to the resonance phenomenon, high values are difficult to achieve for the main performance metrics of the scanners: mirror area, drive angle, and operating frequency. In this paper, we present a two-axis scanner with a piezoelectric actuator made of a piezoelectric single-crystal Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ as the actuation force source. The scanner contains a circular mirror with a diameter of 7 mm and achieves an average static mechanical deflection angle amplitude of 20.8° in two axes with a resonant frequency of 559 Hz. It is equipped with a transmission mechanism that can decouple each axis to achieve high linearity; in our study, the nonlinearity error was less than 1°. Full article

The performance of a piezoelectric actuator for active noise cancellation depends primarily on the quality of the actuator material and its design approach, i.e., single-layer or multi-layer actuators, stacks, benders, or amplified actuators. In this paper, material selection and multiphysics modeling were performed to develop an optimal piezoelectric plate actuator for active noise cancellation. The material selection process was analyzed using two multi-criteria decision making (MCDM) approaches for material selection, i.e., figure of merit (FOM) for actuators and the technique for order of performance by similarity to ideal solution (TOPSIS). Of the 12 state-of-the-art piezoelectric actuator materials considered in this article, PMN–28% PT is the best material according to TOPSIS analysis, while $\left[Pb\left(I{n}_{\raisebox{1ex}{$1$}\!\left/ \!\raisebox{-1ex}{$2$}\right.}N{b}_{\raisebox{1ex}{$1$}\!\left/ \!\raisebox{-1ex}{$2$}\right.}\right)O_3\right]24\%-Pb\left(M{g}_{\raisebox{1ex}{$1$}\!\left/ \!\raisebox{-1ex}{$3$}\right.}N{b}_{\raisebox{1ex}{$1$}\!\left/ \!\raisebox{-1ex}{$3$}\right.}\right)O_3-PbTi{O}_3$ (PIN24%-PMN-PT) is the best material according to FOM analysis. The ranking of state-of-the-art piezoelectric material categories for actuators according to the two analysis is consistent and the category of monocrystalline piezoelectric materials has the highest actuation performance. The multiphysics modeling was performed using ANSYS Mechanical using two different approaches: one using Ansys Parametric Design Language (APDL) command fragments, the other installing the PiezoAndMEMS ACT extension in ANSYS. Static structure, modal, and harmonic response analyses were performed to determine an optimal pair of piezoelectric plates to be used as an actuator for active noise cancellation. A pair of plates of the same materials, but of different dimensions turns out to be the optimal piezoelectric plate actuator for active noise reduction, according to the two multiphysics modeling methods. Full article

Love wave sensors have attracted significant interest due to their high sensitivity and low attenuation. Love mode acoustic dispersion relation, highest normalized mass sensitivity, optimum normalized waveguide layer thickness, and temperature coefficients of frequency (TCF) were theoretically studied for the carbon fiber epoxy composites (CFEC)/Mn:0.24PIN-0.46PMN-0.30PT structure sensor. The highest normalized mass sensitivity exhibits a decreasing trend as the temperature increases from 25 °C to 55 °C. TCF can be improved by increasing the normalized layer thickness (h/λ); however, the temperature dependence of normalized mass sensitivity decreases. For the carbon fibers (CFs) in the CFEC waveguide along the propagation direction of Love wave, the device has a relatively small TCF of −10.92 ppm/°C at h/λ = 0.4001, where the normalized mass sensitivity is approximately 1.5 times that of a typical fused quartz/ST-quartz configuration device. The theoretical results imply that good temperature stability and high measurement precision were obtained from the device in the system CFEC/Mn:0.24PIN-0.46PMN-0.30PT with the CFs in the CFEC along the propagation direction of Love wave (x-axis). The ideal waveguide material requires a small elastic constant $c_{44}$; however, the ideal piezoelectric substrate requires large elastic constants $c_{44}^E$ and $c_{66}^E$. Full article

In this work, we present a grazing incidence X-ray diffraction study of the surface of a 0.24Pb(In_1/2Nb_1/2)O₃-Pb(Mg_1/3Nb_2/3)O₃-PbTiO₃ (PIN-PMN-PT) [011] poled rhombohedral single crystal. The near surface microstructure (the top several tens to hundreds of unit cells) was measured in situ under an applied electric field. The strains calculated from the change in lattice parameters have been compared to the macroscopic strain measured with a strain gauge affixed to the sample surface. The depth dependence of the electrostrain at the crystal surface was investigated as a function of temperature. The analysis revealed hidden sweet spots featuring unusually high strains that were observed as a function of depth, temperature and orientation of the lattice planes. Full article

Based on a modified dice-and-fill technique, a PIN-PMN-PT single crystal 1-3 composite with the kerf of 12 μm and pitch of 50 μm was prepared. The as-made piezoelectric composite material behaved with high piezoelectric constant (d₃₃ = 1500 pC/N), high electromechanical coefficient (k_t = 0.81), and low acoustic impedance (16.2 Mrayls). Using lithography and flexible circuit method, a 48-element phased array was successfully fabricated from such a piezoelectric composite. The array element was measured to have a central frequency of 20 MHz and a fractional bandwidth of approximately 77% at −6 dB. Of particular significance was that this PIN-PMN-PT single crystal 1-3 composite-based phased array exhibits a superior insertion loss compared with PMN-PT single crystal and PZT-5H-based 20 MHz phased arrays. The focusing and steering capabilities of the obtained phased array were demonstrated theoretically and experimentally. These promising results indicate that the PIN-PMN-PT single crystal 1-3 composite-based high frequency phased array is a good candidate for ultrasound imaging applications. Full article

The present study aimed to experimentally evaluate the mechanical properties of Pb(In_1/2Nb_1/2)O₃–Pb(Mg_1/3Nb_2/3)O₃–PbTiO₃ (PIN–PMN–PT) bulk single crystals with different crystallographic directions using the nanoindentation technique. The load–indentation depth curves, elastic and plastic deformations, hardnesses, and Young’s moduli of [100]- and [110]-oriented 0.28PIN–0.43PMN–0.29PT bulk single crystals were investigated. Our results show that with an increase in the maximum indentation depth h_max, the plastic residual percentage increased for both the [100]- and the [110]-oriented single crystals. At each h_max, the plastic residual percentage of the [100]-oriented PIN–PMN–PT single crystals was less than that of the [110]-oriented PIN–PMN–PT single crystals. At h_max from 500 nm to 2000 nm, the plastic deformation was larger than the elastic deformation, and the plastic residual percentage was larger than 50% for both the [100]- and the [110]-oriented single crystals. This means that the plastic deformation dominated in the indentation process of PIN–PMN–PT single crystals. The indentation size effect on the hardness of the PIN–PMN–PT single crystals was apparent in the nanoindentation process. Both the hardness and the Young’s modulus of the [100]-PIN–PMN–PT single crystals were greater than those of the [110]-PIN–PMN–PT single crystals, which indicates that the PIN–PMN–PT single crystals had anisotropic mechanical characteristics. Full article

Fe-substituted PMN-32PT relaxor ferroelectric crystals were grown by a high-temperature flux method. The effects of charged defects on the dielectric relaxor and conductivity mechanism were discussed in detail. The Fe-substituted PMN-32PT crystal showed a high coercive field (E_c = 765 V/mm), due to domain wall-pinning, induced by charged defect dipoles. Three dielectric anomaly peaks were observed, and the two dielectric relaxation peaks at low temperature were associated with the diffusion phase transition, while the high temperature one resulted from the short-range hopping of oxygen vacancies. At temperature T ≤ 150 °C, the dominating conduction carriers were electrons coming from the first ionization of oxygen vacancies. For the temperature range from 200 to 500 °C, the conductivity was composed of the bulk and interface between sample and electrode, and the oxygen vacancies were suggested to be the conduction mechanism. Above 550 °C, the trapped electrons from the Ti³⁺ center were excited and played a major role in electrical conduction. Our results are helpful for better understanding the relationship between dielectric relaxation and the conduction mechanism. Full article
