The force chain network within asphalt mixtures serves as the primary load-bearing structure to resist external forces. The objective of this study is to quantitatively characterize the contact force distribution and force chain topology structure. The discrete element method (DEM) was employed to construct simulation models for two stone matrix asphalt (SMA) and two open-graded friction course (OGFC) mixtures. Load distribution characteristics, including average contact force, load bearing contribution and contact force angle, and force chain topological network parameters, clustering coefficient, edge betweenness and average path length, were analyzed to elucidate the load transfer mechanisms. The findings of the present study demonstrate that the average contact force between aggregate–aggregate contact types in specific particle sizes significantly exceeds the average contact force of the same particle size aggregates. For SMA16 and OGFC16 asphalt mixtures, the load-bearing contribution of aggregates initially increases and then decreases with decreasing particle size, peaking at 13.2 mm. SMA13 and OGFC13 mixtures demonstrate a consistent decline in load bearing contribution with decreasing aggregate size. The analysis of the force chain network topology of the asphalt mixture reveals that SMA mixtures exhibited higher average clustering coefficients in force chain topological features in comparison to OGFC mixtures. It indicates that SMA gradations have superior skeletal load-bearing structures. While the maximum nominal aggregate size minimally influences the average path length with a relative change rate of 3%, the gradation type exerts a more substantial impact, exhibiting a relative change rate of 7% to 9%. These findings confirm that SMA mixtures have more stable load-bearing structures than OGFC mixtures. The proposed topological parameters effectively capture structural distinctions in force chain networks, offering insights for optimizing gradation design and enhancing mechanical performance. Full article

To investigate the influence of pavement texture on tire hydroplaning, this study utilized laser scanning to capture the surface characteristics of three asphalt mixtures—AC-13, SMA-13, and OGFC-13—across fifteen rutting plate specimens. Three-dimensional (3D) pavement models were reconstructed to incorporate realistic texture data. Finite element simulations, employing fluid-structure interaction and explicit dynamics in Abaqus, were conducted to model tire-water-pavement interactions. The results indicate that the anti-skid performance ranks as OGFC > SMA > AC. However, despite OGFC and SMA exhibiting comparable anti-skid metrics (e.g., pendulum friction value and mean texture depth), OGFC’s superior texture uniformity results in significantly better hydroplaning resistance. Additionally, tire tread depth critically influences hydroplaning speed. A novel Anti-Slip Comprehensive Texture Index (ACTI) was proposed to evaluate pavement texture uniformity, providing a more comprehensive assessment of anti-skid performance. These findings underscore the importance of texture uniformity in enhancing pavement safety under wet conditions. Full article

The skid resistance of asphalt pavement is vital for traffic safety and reducing accidents. Existing research using only wavelet transforms or fractal theory to study the pavement surface texture-skid resistance relationship has limitations. This paper integrates a wavelet transform and fractal theory to extract the multi-scale fractal features of pavement texture. It proposes an interpretable machine learning model for skid resistance assessments of sand-accumulated pavements. The three-dimensional (3D) texture of asphalt pavements is decomposed at multiple scales, and fractal and multifractal features are extracted to build a dataset. The performance of mainstream machine learning models is compared, and the eXtreme Gradient Boosting (XGBoost) model is optimized using the Covariance Matrix Adaptation Evolution Strategy (CMA-ES) algorithm. The SHapley Additive exPlanations (SHAP) method is used to analyze the optimal model’s interpretability. The results show that asphalt concrete with a maximum nominal particle size of 13 mm (AC-13) has the most concentrated fractal dimension, followed by open-graded friction course with a maximum nominal particle size of 9.5 mm (OGFC-10), with stone matrix asphalt with a maximum nominal particle size of 16 mm (SMA-16) being the most dispersed. The singular intensity difference of the multifractal (Δα) changes oppositely to the fractal dimension (D), and the fractal dimension difference of the multifractal (Δf) decreases with the number of wavelet decomposition layers. The CMA-ES-XGBoost model improves R² by 27.1%, 9%, and 3.4% over Linear Regression, Light Gradient Boosting Machine (LightGBM), and XGBoost, respectively. The 0.4–0.8 mm range fractal dimension most significantly impacts the model output, with complex interactions between features at different scales. Full article

The 3D reconstruction of asphalt pavement macrotexture holds significant engineering value for pavement quality assessment and performance monitoring. However, conventional 3D reconstruction methods face challenges, such as high equipment costs and operational complexity, limiting their widespread application in engineering practice. Meanwhile, current deep learning-based monocular image reconstruction for pavement texture remains in its early stages. To address these technical limitations, this study systematically prepared four types of asphalt mixture specimens (AC, SMA, OGFC, and PA) with a total of 14 gradations. High-precision equipment was used to simultaneously capture 2D RGB images and 3D RGB-D point cloud data of the surface texture. An innovative multi-scale feature fusion CNN model was developed based on an encoder–decoder architecture, along with an optimized training strategy for model parameters. For performance evaluation, multiple metrics were employed, including root mean square error (RMSE = 0.491), relative error (REL = 0.102), and accuracy at different thresholds (δ = 1/2/3: 0.931, 0.979, 0.990). The results demonstrate strong correlations between the reconstructed texture’s mean texture depth (MTD) and friction coefficient (f₈) with actual measurements (0.913 and 0.953, respectively), outperforming existing methods. This confirms that the proposed CNN model achieves precise 3D reconstruction of asphalt pavement macrotexture, effectively supporting skid resistance evaluation. To validate engineering applicability, field tests were conducted on pavements with various gradations. The model exhibited excellent robustness under different conditions. Furthermore, based on extensive field data, this study established a quantitative relationship between MTD and friction coefficient, developing a more accurate pavement skid resistance evaluation system to support maintenance decision-making. Full article

OGFC (open-graded friction course) steel slag ultra-thin wearing courses are a drainage-type layer used in preventive maintenance and have been successfully applied in road construction in China. However, research on the use of steel slag in ultra-thin wearing courses has mainly focused on macroscopic volumetric indicators and performance, often overlooking the impact of internal mesoscopic void characteristics. This study utilized X-ray CT to scan OGFC ultra-thin wearing course steel slag asphalt mixtures with varying void ratios. A custom digital image processing program was developed to comprehensively and quantitatively characterize the mesoscopic void features of the mixtures from multiple perspectives, analyzing their influence on macroscopic performance. The results show that the surface void ratio and void number exhibited opposite trends with respect to specimen height. Compared to conventional asphalt mixtures, the OGFC steel slag mixtures had a higher average surface void number; the maximum difference between the maximum and minimum surface voids rate reached up to 14.2%. As the equivalent void radius and fractal dimension increased, both the stability and dynamic stability of the mixtures decreased, and the maximum reduction in Marshall stability reached 32.4%. Previous macroscopic-scale studies have struggled to identify these internal mesoscopic void characteristics, and this research provides a deeper understanding of the mesoscopic void structure in OGFC ultra-thin wearing course steel slag asphalt mixtures. Full article

The skeleton structure composed of mineral aggregates is the main body to bear and transfer external loading in asphalt mixtures. To investigate the loading transfer mechanism of the mineral aggregate skeleton, the uniaxial penetration test and Discrete Element Method (DEM) were conducted for the Mineral Aggregate Mixture (MAM) to analyze its mechanical behavior. The three-dimensional strong force chain (SFC) was identified and evaluated based on the proposed recognition criterion and evaluation indices. The results indicate that 4.75 mm should be the boundary to distinguish the coarse and fine aggregates. The skeleton composed of aggregates located on SFCs has better bearing and transferring loading capacity due to its SFC number, average length, and total length decreasing with an increase in the aggregate size. Compared to SMA-16 and OGFC-16, AC-16 exhibits a higher number and total length of its SFC, a smaller average length of its SFC, and a lower average strength of its SFC. Consequently, AC-16 has a lower bearing and transferring loading capacity than that of SMA-16 and OGFC-16. In addition, approximately 90% of SFCs can only transfer external loading downward through 3–5 aggregates. The average direction angle of the SFC formed by fine aggregates is significantly higher than those formed by coarse aggregates. This indicates that the load transfer range of MAM composed of fine aggregates is noticeably larger, leading to lower loading transfer efficiency. Full article

An Open-Graded Friction Course (OGFC) presents a rough surface and a porous structure and provides skid resistance under wet conditions, differing from that of a dense graded mixture. This study explored the distribution of surface macrotexture with depth in OGFC. Using cross-sectional images and semantic image segmentation techniques, the internal structure, porosity, and void size distribution were analyzed to assess the effectiveness of rainfall drainage. Skid resistance was evaluated with a British Pendulum Tester, focusing on the influence of surface macrotexture and internal macrostructure, particularly with regard to contact depth. Results show that finer gradations increase surface roughness peaks, which are concentrated near the top surface. In contrast, coarser mixtures exhibit a greater effective contact depth and more peaks with higher curvature. Finer gradations also result in lower porosity, greater void dispersion, and smaller average void diameters. During heavy rainfall, OGFC-13 exhibits the highest friction coefficient due to its effective contact, surface roughness, and internal voids, which facilitate water expulsion. This research provides insights into the skid resistance mechanism of OGFC in wet conditions and offers practical guidance for selecting the optimal gradation. Full article

This research investigates the characterization of bituminous mixes utilizing microwave imaging and non-destructive testing. We studied the electromagnetic characteristics of various samples, including bituminous concrete (BC) and open-grade friction course (OGFC) samples. A novel ring filter with log-periodic feedlines, designed on the RT/Duroid 5880 substrate, was utilized within the frequency range of 0.3–0.7 GHz. The samples were assessed using average attenuation and group delay measures, which detailed clear electromagnetic characteristics. The samples’ flow value and specific gravity were correlated to these parameters. The calculated flow value and specific gravity (using the filter) and measured flow value and specific gravity (using the conventional method) coincided well. The filter could predict the parameters of the samples with a high accuracy of roughly 99.8% for the flow value and specific gravity, whereas the OGFC sample displayed an accuracy of 99.7%, correspondingly, as shown in high R² values. This demonstrates that the filter can precisely measure the parameters required for studying the interaction between the binder and aggregate in bituminous mixes without being invasive. The findings indicate a significant disparity between OGFC and BC samples in their responses to electromagnetic fields and their characteristics. This demonstrates the high sensitivity and significant value of microwave techniques in the study of bitumen and the construction of roadways. Full article

Permeable road pavements, due to their open-graded design, suffer from low structural strength, restricting their use in areas with light traffic volume and low bearing capacity. To expand application of permeable road pavements, accurate simulation of stress parameters used in pavement design is essential. A 3D finite element (3D FE) model was developed using ABAQUS/CAE 2021 to simulate pavement stress responses. Utilizing a 53 cm thick permeable road pavement and a 315/80 R22.5 wheel as prototypes, the model was calibrated and validated, with its accuracy confirmed through t-test statistical analysis. Simulations of wheel speeds at 11, 15, and 22 m/s revealed significant impact on pavement depths of 3 cm and 8 cm, while minimal effects were observed at depths of 13 cm and 33 cm. Notably, stress values at a depth of 3 cm with 15 m/s speed in the open-graded asphalt concrete (OGFC) surface layer exceeded those at the speed of 11 m/s, while at a depth of 8 cm in the porous asphalt concrete (PAC) base layer, an opposite performance was observed. This may be attributed to the higher elastic modulus of the OGFC surface layer, which results in different response trends to velocity changes. Overall, lower speeds increase stress responses and prolong action times for both layers, negatively affecting pavement performance. Increasing the moduli of layers is recommended for new permeable road pavements for low-speed traffic. Furthermore, considering the effects of heavy loads and changes in wheel speed, the recommended design depth for permeable road pavement is 30 cm. These conclusions provide a reference for the design of permeable road pavements to address climate change and improve performance. Full article

The use of an open-graded friction course (OGFC) as a road surface demonstrates significant advantages in reducing driving noise and improving road drainage and safety. This study aims to enhance the overall performance of OGFC-13 by incorporating double-adding fiber technology. Laboratory tests were conducted on six OGFC-13 mixes modified with varying fiber ratios of lignin fibers (LFs) and glass fibers (GFs). Both GF and LF significantly improved high-temperature performance, with dynamic stability values increasing proportionally to GF content. The LF:GF = 0.15:0.15 ratio achieved peak shearing strength, demonstrating better improvement over single-fiber modification. Furthermore, both fibers effectively enhanced resistance to cracking, with GF-reinforced specimens excelling in bending stress and LF-reinforced specimens demonstrating the highest flexural strain. Water stability evaluations highlighted the substantial positive impact of LF and GF, with simultaneous addition resulting in superior moisture stability compared to single-fiber modifications. Anti-stripping performance assessments indicated that the LF:GF = 3:0 ratio exhibited the best performance. In fatigue performance, both LF and GF enhanced fatigue life, with GF outperforming LF. The LF:GF = 0.15:0.15 ratio achieved a balanced fatigue performance. Results from the radar evaluation method underscored a more comprehensive improvement in road performance achieved through double-adding technology. The LF:GF = 0.15:0.15 ratio emerged as the optimal choice for overall road performance. Full article

Asphalt mixtures exhibit complex mechanical behaviors due to their multiphase internal structures. To provide better characterizations of asphalt pavements under various forms of potential distress, a two-dimensional (2D) finite element simulation based on images of asphalt mixtures can be used to increase computational efficiency and reduce labor consumption. Nonetheless, using a representative image to eliminate the influence of dimension reduction from three dimensions to two dimensions is of great significance for attaining a reliable simulation result. Therefore, in this study, we investigated the consequence of dimension reduction for open-graded asphalt mixtures (denoted as OGFC-16), including a comprehensive characterization of these 2D models in terms of their morphologies and the similarities between them. This study aimed to reveal the variation in a 2D finite element simulation when applied to open-graded asphalt mixtures. Structural compositions, gradations, the aspect ratios of aggregates, and aggregate orientations were counted and calculated. In addition, the cosine similarity and structural similarity index measure (SSIM) were also calculated. Consequently, we performed a statistical analysis on the aforementioned indicators to quantitatively identify the discrepancy in the 2D images caused by dimension reduction. The results demonstrate that this 2D simulation might not be sufficient for representing the realistic mechanical performance of asphalt mixtures due to the remarkable variations in the image morphologies in different 2D images. However, the basic rules of stress behavior within structures can be accurately simulated. A compensative methodology for conducting a 2D simulation of open-graded asphalt mixtures should be based on a morphological characterization, considering structural compositions and the structural similarity index measure. Full article

The optical reflection characteristics of asphalt pavement have an important influence on road-lighting design, and the macrotexture and microtexture of asphalt pavement significantly affect its reflection characteristics. To investigate the impact of texture parameters on the retroreflection coefficient of asphalt pavement, the texture indices of rutted plate specimens and field asphalt pavement were obtained by a pavement texture tester, including the macrotexture surface area (S₁), microtexture surface area (S₂), macrotexture distribution density (D₁), microtexture distribution density (D₂), root mean square slope (Δq), skewness (R_sk), and steepness (R_ku). The corresponding retroreflective coefficient R_L was measured by using a retroreflectometer. In the laboratory experiments, rutted specimens of AC-13, SMA-13, and OGFC-13 asphalt mixtures were formed. The changes in texture parameters and the retroreflection coefficient of rutting specimens before and after rolling were studied, and a factor-influence model between macro- and microtexture parameters and R_L was established, along with correlation models of the texture index and R_L. The results show that after the rutting test, S₁, S₂, D₁, D₂, Δq, and R_ku decreased, R_sk increased, and R_L increased. In the single-factor model, the parameters could be used to characterize R_L with high prediction accuracy, whereas for the onsite measurements, the parameters Δq, R_sk, and R_ku could well characterize R_L. The nonlinear model established, based on the BP neural network algorithm, improved the prediction accuracy. This research provides ideas for optimizing the reflection characteristics of asphalt pavement and a decision-making basis for road-lighting design. Full article

The ultrasonic test is a promising non-destructive testing technique for evaluating the properties of asphalt mixtures. To investigate the applicability and reliability of ultrasonic testing technology (UTT) in evaluating the performance of asphalt mixtures, ultrasonic tests, indirect tensile tests, compression tests, and dynamic modulus tests were carried out at various temperatures. Subsequently, the distribution characteristics of ultrasonic traveling parameters for asphalt mixtures were analyzed. The variation of ultrasonic pulse velocity and amplitude in dry and wet states with temperature was studied. Then, the correlation between the ultrasonic parameters and both the volume parameters and the mechanical performance parameters of asphalt mixtures was revealed, and the functional relationship between ultrasonic pulse velocity and compressive strength was established. Finally, the reliability of predicting high-frequency dynamic modulus by ultrasonic velocity was verified. The laboratory tests and analysis results indicate that both ultrasonic pulse velocity and amplitude in dry and wet conditions show a decreasing trend with an increase in temperature. Ultrasonic parameters are greatly influenced by asphalt content and mineral aggregate content of 9.5~13.2 mm and 13.2~16 mm. The dynamic modulus at a high-frequency load can be predicted by using ultrasonic velocity, and predicting the results for OGFC and SMA mixtures deduced by using the UPV at a high-frequency load have higher reliability. Full article

The change law of the temperature field of an open-graded friction course (OGFC) asphalt pavement was studied. The thermal conductivity of OGFC asphalt mixtures with different oil–stone ratios was measured using a thermal-conductivity tester. The relationship between the oil–stone ratio and thermal conductivity was established, which was then used as the boundary condition of the temperature field. Using mathematical and physical methods based on thermodynamics and heat-transfer principles, an analytical solution of the temperature field of the OGFC asphalt pavement structure was developed. Data from an outdoor test of large Marshall specimens were compared with the analytical solution of the temperature field to verify the correctness of the model. The results show that the analytical model of the OGFC asphalt pavement structure temperature field can predict the temperature changes at different oil–stone ratios, times, and depths (from the road surface). The differences between the predicted results and test data at 0.01, 0.02, and 0.03 m from the road surface were 0.5, 0.7, and 0.9 °C, respectively, confirming that this study can be used to provide reference information for the design of OGFC asphalt pavement structures. Full article

Due to the highly viscous characteristics of high viscosity modified bitumen (HVMB), the commonly used short-term aging schemes are not suitable for it. As such, the objective of this study is to introduce a suitable short-term aging scheme for HVMB by increasing the aging period and temperature. For this purpose, two kinds of commercial HVMB were aged via rolling thin-film oven test (RTFOT) and thin-film oven test (TFOT) at different aging periods and temperatures. At the same time, open-graded friction course (OGFC) mixtures prepared using HVMB were also aged via two aging schemes to simulate the short-term aging of bitumen at the mixing plant. With the aid of temperature sweep, frequency sweep, and multiple stress creep recovery tests, the rheological properties of short-term aged bitumen and the extracted bitumen were tested. By comparing the rheological properties of TFOT- and RTFOT-aged bitumen with those of extracted bitumen, suitable laboratory short-term aging schemes for HVMB were determined. Comparative results showed that aging the OGFC mixture in a 175 °C forced-draft oven for 2 h is suitable to simulate the short-term aging process of bitumen at the mixing plant. Compared with RTOFT, TFOT was more preferable for HVMB. Additionally, the recommended aging period and temperature for TFOT was 5 h and 178 °C, respectively. Full article
