Microplastics (MP) have been found not only in the environment but also in living beings, including humans. As an initial step in MP detection, a method is proposed to measure the effective refractive index of a solution containing 5 µm diameter spherical polystyrene particles (SPSP) in distilled water, based on the surface plasmon resonance (SPR) technique and Mie scattering theory. The reflectances of the samples are obtained with their resonance angles and depths that must be normalized and adjusted according to the reference of the air and the distilled water, to subsequently find their effective refraction index corresponding to the Mie scattering theory. The system has an optical sensor with a Kretschmann–Raether configuration, consisting of a semicircular prism, a thin gold film, and a glass cell for solution samples with different concentrations (0.00, 0.20, 0.05, 0.50, and 1.00%). The experimental result provided a good linear fit with an R² = 0.9856 and a sensitivity of 7.2863 × ${10}^{-5}$ RIU/% (refractive index unit per percentage of fill fraction). The limits of detection (LOD) and limit of quantification (LOQ) were determined to be 0.001% and 0.0035%, respectively. The developed optomechatronic system and its applications based on the SPR and Scattering enabled the effective measurement of the refractive index and concentration of solutions containing 5 µm diameter SPSP in distilled water. Full article

This study investigates the change in both the angular position and width of the reflectance minimum of an SPR sensor in the Kretschmann configuration when optical vortices instead of plane waves are used for illumination. An analytical expression of the reflectance is obtained for incident Laguerre–Gaussian beams, considering only the first-order approximation of the Fresnel reflection coefficient in a Taylor series. Numerical simulations reveal that the detection performance of SPR sensors is practically unaffected if optical vortices of this type are used as sources, even if the topological charges of the vortices are quite large. On the other hand, the use of optical vortices in SPR sensors could be very advantageous for positioning and manipulating analyte molecules on the surface of the sensor. Full article

In this paper, we propose an innovative approach based on the wavelength optimization of a light source for a simple, high-performance surface plasmon resonance (SPR) sensor utilizing comprehensive reflectance analysis in the angular domain. The proposed structure consists of a glass substrate, an adhesion layer of titanium dioxide, a silver plasmonic layer, and a 2D material. Analysis is performed in the Kretschmann configuration for liquid analyte sensing. Sensing parameters such as the refractive index (RI) sensitivity, the reflectance minimum, and the figure of merit (FOM) are investigated in the first step of this study as a function of the thickness of the silver layer together with the RI of a coupling prism. Next, utilizing the results offering a fused silica prism, the thickness of the silver layer and the wavelength of the light source are optimized for the structure with the addition of a 2D material, black phosphorus (BP), which is studied along different principal directions, the zigzag and armchair directions. In addition, a new approach of adjusting the source wavelength using a one-dimensional photonic crystal combined with an LED, is presented. Based on this analysis, for the reference structure at a wavelength of 632.8 nm, the optimized silver layer thickness is 50 nm, and the achieved RI sensitivity ranges from 193.9 to 251.5 degrees per RI unit (deg/RIU), with the highest FOM reaching 52.3 RIU⁻¹. In addition, for the modified structure with BP, the achieved RI sensitivity varies in the range of 269.1–351.2 deg/RIU at the optimized wavelength of 628 nm, with the highest FOM reaching 44.7 RIU⁻¹ for the zigzag direction. Due to the optimization and adjusting the wavelength of the source, the results obtained for the proposed SPR structure could have significant implications for the development of more sensitive and efficient sensors employing a simple plasmonic structure. Full article

This study presents a numerical investigation of surface plasmon resonance (SPR) sensors based on multilayer configurations incorporating BK7, silver, silicon nitride (Si₃N₄), and black phosphorus (BP). Using the transfer matrix method, the optical performance of four architectures was evaluated under refractive index perturbations consistent with values reported in prior theoretical and experimental studies. The sensor response was characterized through metrics such as angular sensitivity, resonance shift, full width at half maximum, attenuation, and derived figures including detection accuracy and limit of detection. Parametric optimization was performed for the thickness of each functional layer to enhance sensing performance. Among all configurations, those incorporating both Si₃N₄ and BP demonstrated the highest angular sensitivity, reaching up to 394.46°/RIU. These enhancements were accompanied by increased attenuation and spectral broadening, revealing trade-offs in sensor design. The results, based entirely on numerical modeling, provide a comparative framework for guiding SPR sensor optimization under idealized optical conditions. Full article

This study presents a black phosphorus-based surface plasmon resonance (SPR) biosensor for malaria detection, integrating silicon nitride (Si₃N₄) and single-stranded DNA (ssDNA) to enhance sensitivity and molecular recognition. The biosensor configurations were optimized through numerical simulations, evaluating metal thickness, dielectric layer thickness, and the number of black phosphorus layers to achieve maximum performance. The optimized system (Opt-Sys₄) exhibited high sensitivity (464.4°/RIU for early-stage malaria) and improved detection accuracy, outperforming conventional SPR sensors. Performance was assessed across malaria progression stages, demonstrating a clear resonance shift, increased attenuation, and enhanced biomolecular interactions. Key metrics, including the figure of merit, limit of detection, and comprehensive sensitivity factor, confirmed the sensor’s superior performance. Comparative analysis against state-of-the-art SPR biosensors further validated their capability for highly sensitive and specific malaria detection. These findings establish a promising plasmonic biosensing platform for early malaria diagnosis, potentially improving disease management in resource-limited settings. Full article

This study presents a numerical investigation of surface plasmon resonance (SPR) biosensors incorporating silicon nitride (Si₃N₄) and molybdenum disulfide (MoS₂) for HIV DNA hybridization detection. By optimizing the thickness of Ag and Si₃N₄ and the number of MoS₂ layers, two configurations, Sys₂ (Ag-Si₃N₄) and Sys₃ (Ag-Si₃N₄-MoS₂), were selected for comparative analysis. Performance metrics, including the resonance angle shift, sensitivity, detection accuracy, and quality factor, demonstrated that Sys₂ achieved the highest sensitivity of 210.9°/RIU and an enhanced figure of merit (86.98 RIU⁻¹), surpassing state-of-the-art SPR sensors. Although Sys₃ exhibited a lower sensitivity of 158.1°/RIU due to MoS₂-induced optical losses, it provided a lower limit of detection, suggesting a trade-off between sensitivity and spectral broadening. Compared to previous SPR biosensors, the proposed configurations achieve superior sensitivity while maintaining stability and selectivity, positioning them as promising candidates for next-generation nucleic acid detection platforms. Full article

This work identifies and models the inline devices in an experimental surface-plasmon resonance spectroscopy setup to determine the system’s transfer function. This allows for the comparison of theoretical and experimental responses and the analysis of the dynamics of the components of an analyte placed on the sensor at the nanometer scale. The transfer functions of individual components, including the light source, polarizers, spectrometer, optical fibers, and the SPR sensor, were determined experimentally and theoretically. The theoretical model employed Planck’s law for the light source, manufacturer specifications for some components, and experimental characterization for others, such as the polarizers and optical fibers. The SPR sensor was modeled using characteristic matrix theory, incorporating the optical constants of the prism, gold film, chromium adhesive layer, and analyte. The combined transfer functions created a comprehensive model of the entire experimental system. This model successfully reproduced the experimental SPR spectrum with a similarity greater than 95%. The system’s operational range was also extended, constrained by the signal-to-noise ratio at the spectrum’s edges. The detailed model allows for the accurate correction of the measured spectra, which will be essential for the further analysis of nanosuspensions and molecules dissolved in liquids. Full article

Methylene blue is a cationic organic dye commonly found in wastewater, groundwater, and surface water due to industrial discharge into the environment. This emerging pollutant is notably persistent and can pose risks to both human health and the environment. In this study, we developed a Surface Plasmon Resonance Biosensor employing a BK7 prism coated with 3 nm chromium and 50 nm of gold in the Kretschmann configuration, specifically for the detection of methylene blue. For the first time, laccases immobilized on a gold surface were utilized as bio-receptors for this organic dye. The enzyme was immobilized using carbodiimide bonds with EDC/NHS crosslinkers, allowing for the analysis of samples with minimal preparation. The method demonstrated validation with a limit of detection (LOD) of 4.61 mg L⁻¹ and a limit of quantification (LOQ) of 15.37 mg L⁻¹, a working range of 0–100 mg L⁻¹, and an R² value of 0.9614 during real-time analysis. A rainwater sample spiked with methylene blue yielded a recovery rate of 122.46 ± 4.41%. The biosensor maintained a stable signal over 17 cycles and remained effective for 30 days at room temperature. Full article

In this study, we theoretically study the optical bistability (OB) of reflected light beams at visible light frequencies by using a Kretschmann–Raether (KR) configuration where double-layer MoS₂ is inserted. This OB phenomenon results from the local field enhancement owing to the excitation of metal surface plasmon polaritons (SPPs) and the introduction of the double-layer MoS₂. By considering the third-order conductivity of MoS₂, we obtain a threshold electric field with an incident electric field of 10⁷ V/m levels. Furthermore, the influences of the structural parameters on the hysteretic behavior as well as the threshold of OB are clarified. This tunable OB phenomenon will provide possible options for nonlinear optical bistable devices. Full article

This paper presents a new biosensor design based on the Kretschmann configuration, for the detection of analytes at different refractive indices. Our studied design consists of a TiO₂/SiO₂ bi-layer sandwiched between a BK7 prism and a bimetallic layer of Ag/Au plasmonic materials, covered by a layer of black phosphorus placed below the analyte-containing detection medium. The different layers of our structure and analyte detection were optimized using the angular interrogation method. High performance was achieved, with a sensitivity of 240 deg/RIU and a quality factor of 34.7 RIU⁻¹. This biosensor can detect analytes with a wide refractive index range between 1.330 and 1.347, such as glucose detection in urine samples using a refractive index variation of ${10}^{-3}$. This capability offers a wide range of applications for biomedical and biochemical detection and selectivity. Full article

The surface plasmon resonance (SPR) signal, generated from the Kretschmann configuration, has been developed as an effective detection technology in chemical and biological sensors. The sensitivity of SPR signals to changes in the surrounding media makes it a valuable tool, as even a slight variation in refractive index can cause a significant change in SPR signals, such as phase, intensity, and resonance angle. However, the detection of ultralow changes in refractive index, which occur in chemical reactions or biological actions, remains a challenge for conventional SPR sensors due to their limited sensitivity. To overcome this limitation, we theoretically propose a novel guided-wave SPR (GWSPR) configuration coated with a few-layer blue phosphorene (blueP)/MoS₂ hybrid structure. This configuration aims to enhance the electric field and subsequently achieve a significant improvement in sensitivity. The results of our study demonstrate that the proposed blueP/MoS₂-based GWSPR sensor exhibits a high sensitivity of 290°/RIU, which represents an impressive enhancement of approximately 82.4% compared to the conventional Au-based SPR sensor. This advancement addresses the challenge of detecting ultralow changes in refractive index and offers significant potential for enhancing the performance of chemical and biological sensors. Full article

Dielectric nanoparticles coated with metals (half-shell or semi-shell structures) have attracted attention as potential composite plasmonic nanomaterials with large optical anisotropy and absorption cross-sections. Structures approximately 100 nm in size can excite plasmons in the visible and near-infrared ranges, highlighting their distinct optical properties. This study employed metal semi-shell structures (metal: gold, dielectric: silica) in the Kretschmann configuration to experimentally and numerically demonstrate the optical determination of single-structure orientations through a finite-difference time-domain method. Gold semi-shell structures were fabricated through deposition and etching. These structures were removed from their substrate in ultrapure water and randomly dropped onto a thin gold substrate. In the single structure, we experimentally observed changes in the scattering light spectrum based on the optical geometry of the gold semi-shell at wavelengths ranging from 530 to 700 nm. The obtained results closely resembled those of a simulation and confirmed the presence of eigenmodes in the orientation through electric field analysis. These observations allow for the cost-effective and rapid determination of the orientations of numerous structures that are approximately 100 nm in size, solely through optical methods. This technique is a valuable development for measurement applications in nanostructure orientation control and functionality enhancement. Full article

This numerical research presents a simple hybrid structure comprised of TiO₂-Cu-BaTiO₃ for a modified Kretschmann configuration that exhibits high sensitivity and high resolution for biosensing applications through an angular interrogation method. Recently, copper (Cu) emerged as an exceptional choice as a plasmonic metal for developing surface plasmon sensors (SPR) with high resolution as it yields finer, thinner SPR curves than Ag and Au. As copper is prone to oxidation, especially in ambient conditions, the proposed structure involves the utilization of barium titanate (BaTiO₃) film as a protection layer that not only preserves Cu film from oxidizing but enhances the performance of the sensor to a great extent. Numerical results also show that the utilization of a thin adhesive layer of titanium dioxide (TiO₂) between the prism base and Cu film not only induces strong interaction between them but also enhances the performance of the sensor. Such a configuration, upon suitable optimization of the thickness of each layer, is found to enhance sensitivity as high as 552°/RIU with a figure of merit (FOM) of 136.97 RIU⁻¹. This suggested biosensor design with enhanced sensitivity is expected to enable long-term detection with greater accuracy and sensitivity even when using Cu as a plasmonic metal. Full article

In this paper, three different structures of surface plasmon resonance (SPR) sensors based on the Kretschmann configuration: Au/SiO₂ thin film structure, Au/SiO₂ nanospheres and Au/SiO₂ nanorods are designed by adding three different forms of SiO₂ materials behind the gold film of conventional Au-based SPR sensors. The effects of SiO₂ shapes on the SPR sensor are investigated through modeling and simulation with the refractive index of the media to be measured ranging from 1.330 to 1.365. The results show that the sensitivity of Au/SiO₂ nanospheres could be as high as 2875.4 nm/RIU, which is 25.96% higher than that of the sensor with a gold array. More interestingly, the increase in sensor sensitivity is attributed to the change in SiO₂ material morphology. Therefore, this paper mainly explores the influence of the shape of the sensor-sensitizing material on the performance of the sensor. Full article
