Grounding systems are critical for ensuring electrical safety, fault current dissipation, and electromagnetic compatibility in power installations across different voltage levels. This research presents a comparative study on the optimization of grounding configurations for 400 V, 10 kV, and 35 kV electrical installations, focusing on key performance parameters such as grounding resistance, step and touch voltages, and fault current dissipation efficiency. The study employs computational simulations using the finite element method (FEM) alongside empirical field measurements to evaluate the influence of soil resistivity, electrode materials, and grounding configurations, including rod electrodes, grids, deep-driven rods, and hybrid grounding systems. Results indicate that soil resistivity significantly affects grounding efficiency, with deep-driven rods providing superior performance in high-resistivity conditions, while grounding grids demonstrate enhanced fault current dissipation in substations. The integration of conductive backfill materials, such as bentonite and conductive concrete, further reduces grounding resistance and enhances system reliability. This study provides engineering insights into optimizing grounding systems based on installation voltage levels, cost considerations, and compliance with IEEE Std 80-2013 and IEC 60364-5-54. The findings contribute to the development of more resilient and cost-effective grounding strategies for electrical installations. Full article

This paper presents an interpretable and modular framework for energy management in smart buildings based on fuzzy logic and the IEEE Std 1855-2016. The proposed system builds upon the JFML-IoT library, enabling the integration and execution of fuzzy rule-based systems on resource-constrained IoT devices using a lightweight and extensible architecture. Unlike conventional data-driven controllers, this approach emphasizes semantic transparency, expert-driven control logic, and compliance with fuzzy markup standards. The system is designed to enhance both operational efficiency and user comfort through transparent and explainable decision-making. A four-layer architecture structures the system into Perception, Communication, Processing, and Application layers, supporting real-time decisions based on environmental data. The fuzzy logic rules are defined collaboratively with domain experts and encoded in Fuzzy Markup Language to ensure interoperability and formalization of expert knowledge. While adherence to IEEE Std 1855-2016 facilitates system integration and standardization, the scientific contribution lies in the deployment of an interpretable, IoT-based control system validated in real conditions. A case study is conducted in a realistic indoor environment, using temperature, humidity, illuminance, occupancy, and CO₂ sensors, along with HVAC and lighting actuators. The results demonstrate that the fuzzy inference engine generates context-aware control actions aligned with expert expectations. The proposed framework also opens possibilities for incorporating user-specific preferences and adaptive comfort strategies in future developments. Full article

Islanding detection remains a critical challenge for grid-connected distributed generation systems, as passive techniques suffer from inherent non-detection zones (NDZ), and active methods often degrade power quality. This paper introduces a hybrid detection strategy based on monitoring inherent grid harmonics via a Digital Lock-In Amplifier. By comparing real-time 5th and 7th harmonic amplitudes against their three-cycle-delayed values, the passive stage adaptively identifies potential islanding without fixed thresholds. Upon detecting significant relative variation, a brief injection of a non-characteristic 10th harmonic (limited to under 3% distortion for three line cycles) serves as active verification, ensuring robust discrimination between islanding and normal disturbances. Case studies demonstrate detection within 140 ms—faster than typical reclosing delays and well below the 2 s limit of IEEE std. 1547—while preserving current zero-crossings and enabling grid impedance estimation. The method’s resilience to grid disturbances and stiffness is validated through PSIM simulations and laboratory experiments, meeting IEEE 1547 and UL 1741 requirements. Comparative analysis shows superior accuracy and minimal power-quality impact relative to existing passive, active, and intelligent approaches. Full article

This paper analyzes the power quality in a 400 kWp grid-connected solar photovoltaic system with storage (BESS), considering standards IEEE Std 519TM, IEEE Std 1159TM, and IEC 61000-4-30. For system analysis, a photovoltaic array model is developed. Neplan-Smarter Tools software is used for model validation, and experimental measurements are performed on the actual photovoltaic system, recording total harmonic distortion (THDi/THDv). A class B power quality monitor was used to measure three-phase electrical variables: current, voltage, power, power factor, and THD. The THD level was generated at an energy level below 20% of the rated power, resulting in high THDi. The recorded THDv remained below 2.5%, which means that its value is limited by the IEEE 519 standard. When the BESS was connected to the PCC grid, the voltage level remained regulated, and the electrical system appeared to be stable. This paper contributes a methodology and procedure for measurement and power quality assessment, allowing for THD identification and enabling designers to configure better designs and energy system protections when integrating solar photovoltaic energy into an electrical distribution network. Full article

Poor PQ is a partial case of power system impact on society and the environment. Although the significance of good PQ is generally understood, the topic has not yet been sufficiently explored in the scientific literature. Firstly, this paper discusses the role of PQ in sustainable development by distinguishing economic, environmental, and social parts, including the existing PQ impact assessment methods. PQ problems must be studied through such prisms as financial losses of industrial companies, damage to end-use equipment, natural phenomena, interaction with animals, and social issues related to law, people’s well-being, health and safety. Secondly, this paper presents the results of the survey of Lithuanian industrial companies, which focuses on the assessment of industrial equipment immunity to both voltage sags and supply interruptions, as well as a unique methodology based on expert assessment, IEEE Std 1564-2014 and EN 50160:2010 voltage sag tables, matrix theory, a statistical hypothesis test, and convolution-based sample comparison that was developed for this purpose. The survey was carried out during the PQ monitoring campaign in the Lithuanian DSO grid, and is one of the few PQ surveys presented in the scientific literature. After counting the votes and introducing the rating system (with and without weights), the samples are compared both qualitatively and quantitatively in order to determine whether the PQ impact on various end-use equipment is similar or not. Full article

This study investigates the feasibility of utilizing the line loss power factor to assess the reactive, unbalanced, and harmonic line losses in low-voltage distribution networks and explores the method of calculating decoupled line loss values based on this factor. To achieve this objective, we establish preliminary definitions of single-phase and three-phase reactive, unbalanced, and harmonic line loss power factors, drawing upon the principles of electrical theory outlined in IEEE Standard 1459. These power factors serve as crucial indicators for evaluating the severity of line losses caused by reactive power, unbalance, and harmonic problems. Subsequently, the values of line loss attributed to reactive, unbalanced, and harmonic components are decoupled and quantified using the line loss power factor as a fundamental parameter. The effectiveness and accuracy of the proposed method were verified in Matlab simulation and physical experiments. Full article

This paper presents a current control design for stabilizing an inductive-capacitive-inductive (LCL)-filtered grid-connected inverter (GCI) system under uncertain grid impedance and distorted grid environment. To deal with the negative impact of grid impedance, LC-type grid impedance is considered in both the system model derivation and controller design process of an LCL-filtered GCI system. In addition, the integral and resonant control terms are also augmented into the system model in the synchronous reference frame to guarantee the reference tracking of zero steady-state error and good harmonic disturbance compensation of the grid-injected currents from GCI. By considering the effect of grid impedance on the control design process, an incomplete state feedback controller will be designed based on the linear-quadratic regulator (LQR) without damaging the asymptotic stabilization and robustness of the GCI system under uncertain grid impedance. By means of the closed-loop pole map evaluation, the asymptotic stability, robustness, and resonance-damping capability of the proposed current control scheme are confirmed even when all the system states are not available. In order to reduce the number of required sensors for the realization of the controller, a discrete-time current-type full-state observer is employed in this paper to estimate the system state variables with high precision. The feasibility and effectiveness of the proposed control scheme are demonstrated by the PSIM simulations and experiments by using a three-phase GCI prototype system under adverse grid conditions. The comprehensive evaluation results show that the designed control scheme maintains the stability and robustness of the LCL-filtered GCI when connecting to unexpected grids, such as harmonic distortion and L-type and LC-type grid impedances. As a result, the proposed control scheme successfully stabilizes the entire GCI system with high-quality grid-injected currents even when the GCI faces severe grid distortions and an extra grid dynamic caused by the L-type or LC-type grid impedance. Furthermore, low-order distortion harmonics come from the background grid voltages and are maintained as acceptable limits according to the IEEE Std. 1547-2003. Comparative test result with the conventional one also confirms the effectiveness of the proposed control scheme under LC-type grid impedance thanks to the consideration of LC grid impedance in the design process. Full article

There is growing concern regarding air pollutants (NOx, SOx, and PM) and carbon emissions from ocean-going vessels in harbor areas and the role of high-voltage shore connection (HVSC) systems in mitigating these emissions during vessel berthing. The HVSC operates as a TN grounding system in humid environments, and it needs a proper grounding design to ensure safety when faults occur. This article intends to examine the overvoltage resulting from fault currents and its implications for the safety of operators when a single line-to-ground fault takes place within the design of HVSC grounding systems. The assessment is carried out by employing actual scenarios and parameters from a container berth at Kaohsiung Harbor in Taiwan. Considering site conditions, such as the wet ground surface, human body resistance, and electric shock duration, the tolerable safe voltage level is derived using IEEE Std. 80 and IEC 60479-1. Based on the shore power system grounding architecture specified in IEEE/IEC 80005-1, an equivalent circuit model is constructed to calculate the fault currents using symmetrical component analysis. The actual touch voltages generated in various locations are analyzed under scenarios of connecting or disconnecting the equipotential bonding between the ship and the shore using neutral grounding resistor (NGR) designs. This article delves into the scenarios of electric shock that may occur during the operation of an actual container ship’s shore power system. It evaluates whether various contact voltage values exceed current international standards and verifies the grounding design and safety voltage specifications of IEEE/IEC 80005-1. According to the results of this study, the use of NGR and protective earthed neutral (PEN) conductors in HVSC is crucial. This can limit fault currents, reduce touch voltage, and ensure the safety of personnel and equipment. Therefore, ensuring and monitoring equipment conductors and adopting NGRs of appropriate sizes are crucial elements in maintaining electrical safety in HVSC systems. Full article

The precision with which directional overcurrent relays (DOCRs) are set up establishes the microgrid customers’ access to reliable and uninterrupted electricity. In order to avoid failure in DOCRs operation, it is critical to consider a single contingency (N-1 event) on the protection optimization setting problem (POSP). However, power systems may face cascading outages or simultaneous contingencies (N-K events), which greatly expand the problem’s complexity and scale. The effect of cascading events on this problem is an open research gap. Initially, this paper proposes a novel approach to reducing the scale of simultaneous events called the N-K events scale reduction technique (N-K-ESRT). Moreover, an innovative method named fuzzy zero-violation clustering is utilized to group these contingencies. Ultimately, the DOCRs’ decision parameters are generated by three optimization algorithms, namely interior point (IPA), simulated annealing, and pattern search. In all case studies (including a real industrial network called TESKO2 feeder, the IEEE Std. 399-1997, and the IEEE 14 bus systems), the capabilities of the proposed method are effectively validated based on the DOCR’s tripping time and the algorithm’s execution time. Full article

Transformers insulated with mineral oil tend to form gases, which might be caused by system faults or extended use. Based on an evaluation of the main failure analysis techniques using combustible gases, this study reviewed the conventional techniques for Dissolved Gas Analysis (DGA), present in the norms IEC 60599 and IEEE Std C57.104, and their failure analysis tendency. Furthermore, to illustrate distinct technique performances and failures, the performance of the following techniques was analyzed based on the IEC TC10 database: Dornenburg, Duval Triangle, Duval Pentagon, IEC ratio method, Key Gas, and Rogers. The objective of this work was to present relevant information to support students and professionals who work in failure analysis and/or assist in the development of new tools in the DGA field. Full article

The White Rabbit protocol allows synchronization and communication via an optical link in an integrated, modular, and scalable manner. It provides a solution to those applications that have very demanding requirements in terms of synchronization. Field-programmable gate arrays are used to implement the protocol; additionally, special hardware is needed to provide the necessary clock signals used by the dual-mixer time difference for precise phase measurement. In the present work, an expansion board that allows for White Rabbit functionality is presented. The expansion board contains the oscillators required by the White Rabbit protocol, one running at 125 MHz and another at 124.922 MHZ. The architecture of this board includes two oscillator systems for tests and comparison. One is based on VCOs and another on crystal oscillators running at the desired frequencies. In addition, it incorporates a temperature sensor, from where the medium access control address is extracted, an electrically erasable programmable read-only memory, a pulse-per-second output, and a USB UART to access the White Rabbit IP core at the field-programmable gate array. Finally, to ensure the quality of the layout design and guarantee the level of synchronization desired, the results of the power and signal integrity simulations are also presented. Full article

This study aims to design a compact antenna structure suitable for implantable devices, with a broad frequency range covering various bands such as the Industrial Scientific and Medical band (868–868.6 MHz, 902–928 MHz, 5.725–5.875 GHz), the Wireless Medical Telemetry Service (WMTS) band, a subset of the unlicensed 3.5–4.5 GHz ultra-wideband (UWB) that is free of interference, and various Wi-Fi spectra (3.6 GHz, 4.9 GHz, 5 GHz, 5.9 GHz, 6 GHz). The antenna supports both low and high frequencies for efficient data transfer and is compatible with various communication technologies. The antenna features an asynchronous-meandered radiator, a parasitic patch, and an open-ended square ring-shaped ground plane. The antenna is deployed deep inside the muscle layer of a rectangular phantom below the skin and fat layer at a depth of 7 mm for numerical simulation. Furthermore, the antenna is deployed in a cylindrical phantom and bent to check the suitability for different organs. A prototype of the antenna is created, and its reflection coefficient and radiation patterns are measured in fresh pork tissue. The proposed antenna is considered a suitable candidate for implantable technology compared to other designs reported in the literature. It can be observed that the proposed antenna in this study has the smallest volume (75 mm³) and widest bandwidth (181.8% for 0.86 GHz, 9.58% for 1.43 GHz, and 285.7% for the UWB subset and Wi-Fi). It also has the highest gain (−26 dBi for ISM, −14 dBi for WMTS, and −14.2 dBi for UWB subset and Wi-Fi) compared to other antennas in the literature. In addition, the SAR values for the proposed antenna are well below the safety limits prescribed by IEEE Std C95.1-1999, with SAR values of 0.409 W/Kg for 0.8 GHz, 0.534 W/Kg for 1.43 GHz, 0.529 W/Kg for 3.5 GHz, and 0.665 W/Kg for 5.5 GHz when the applied input power is 10 mW. Overall, the proposed antenna in this study demonstrates superior performance compared to existing tri-band implantable antennas in terms of size, bandwidth, gain, and SAR values. Full article

The dynamic monitoring, control, and protection of modern power systems in real time require time-stamped electrical measurements to accurately estimate the bus voltage phasors using the state estimation function under normal and abnormal conditions. These measurements can be acquired by time-synchronized devices, known as phasor measurement units (PMUs). PMUs can measure bus voltage and branch current phasors of a three-phase network, as well as the frequency and the rate of change of frequency (ROCOF), with high speed, accuracy and time stamping provided by global positioning system (GPS) at the coordinated universal time (UTC). Various phasor estimation algorithms have been proposed in the literature, while most of them are concentrated in the discrete Fourier transform (DFT) algorithm, where an integer number of samples multiple of the nominal frequency is required for the computations. In cases where the frequency of the power grid deviates from its nominal value, the raw application of the DFT approach can lead to large errors during phasor estimation. Another approach of the phasor estimation is based on the phase-locked loop (PLL) techniques, widely used in grid tie inverters. PLL techniques can track dynamically (continuous time) the estimated frequency to the time-variant frequency of the power grid. A brief introduction to the basic concepts of the synchrophasor definition is provided, while the main DFT methods for synchrophasor estimation according to recent literature are mentioned. PLL-based PMU techniques are reviewed for both steady-state and dynamic conditions according to IEEE standards. In conclusion, the performance of PLL-based PMU algorithms presented in this literature review is discussed. Full article

The design of a compliant, safe, and reliable substation earth grid is not a straightforward process; in most cases, it requires some additional measures to be taken due to various constraints that differ from environment to environment, such as soil resistivity, a high fault level, a limited surface area, construction budget, etc. The IEEE Std 80-2013 proposes various refinement methods that can be applied to address different situations. For this study, the current limiting method, current diversion method, and touch and step voltage increment method were applied using the Electrical Transient Analysis Program (ETAP). A power system was designed, where a fault current generated by the supply transformers and back-fed by the power system’s motors was exported to the earth grid. Using this fault current, various simulations were conducted to assess the performance of the earth grid. The analysis results show that the application of the current limiting method using neutral earthing resistors has a great impact on the design of the earth grid as this method significantly reduces the fault current injected into the earth grid. Furthermore, by applying the current diversion method, the amount of fault current injected into the earth grid is reduced by a fair amount, which improves the performance of the earth grid. Lastly, increasing the tolerable limits of touch and step voltages by reducing the fault clearance times significantly improves the compliance of the earth grid as the clearance time is reduced. From this study, it is therefore concluded that, by implementing the refinement methods depending on the design requirements and feasibility of the application, one can improve the compliance state of an earth grid. Full article

A new controller based on a fractional-order synergetic controller (FOSC) is proposed for a three-level T-type inverter using a shunt active power filter (SAPF). The SAPF is designed to compensate for the reactive power and eliminate the current harmonics caused by non-linear loads, in cases of distorted or unbalanced source voltages. The proposed FOSC technique with the designed parameters and defined macro-variable is a robust control technique that operates well in both transient and steady-state scenarios, ensuring fast convergence and closed-loop system stability. The FOSC technique utilizes a phase-locked loop (PLL) technique on a self-tuning filter (STF) to enhance the SAPF’s ability to compensate current harmonics and reactive power in all situations involving non-linear loads and source voltage variations according to IEEE Std. 519. The proposed control was implemented and verified using Matlab software, where the obtained results were compared with the results of the conventional control based on proportional-integral (PI) controllers in different operating conditions. The results indicate that the proposed FOSC technique outperformed the traditional control in terms of DC voltage tracking and the minimization of the total harmonic distortion of the current. Full article
