This study investigates the effects of anode and cathode inlet flow rates (ṁ) on the power performance of bipolar plates in a polymer electrolyte membrane fuel cell (PEMFC). The primary objective is to derive optimal flow rate conditions by comparatively analyzing concentration loss in the I−V curve and crossover phenomena at the anode, thereby establishing flow rates that prevent reactant depletion and water flooding. A single-cell computational model was constructed by assembling a commercial bipolar plate with a gas diffusion layer (GDL), catalyst layer (CL), and proton exchange membrane (PEM). The model simulates current density generated by electrochemical oxidation-reduction reactions. Hydrogen and oxygen were supplied at a 1:3 ratio under five proportional flow rate conditions: hydrogen (${\dot{m}}_{H_2}$ = 0.76–3.77 LPM) and oxygen (${\dot{m}}_{O_2}$ = 2.39–11.94 LPM). The Butler–Volmer equation was employed to model voltage drop due to overpotential, while numerical simulations incorporated contact resistivity, surface permeability, and porous media properties. Simulation results demonstrated a 24.40% increase in current density when raising ${\dot{m}}_{H_2}$ from 2.26 to 3.02 LPM and ${\dot{m}}_{O_2}$ from 7.17 to 9.56 LPM. Further increases to ${\dot{m}}_{H_2}$ = 3.77 LPM and ${\dot{m}}_{O_2}$ = 11.94 LPM yielded a 10.20% improvement, indicating that performance enhancements diminish beyond a critical threshold. Conversely, lower flow rates (${\dot{m}}_{H_2}$ = 0.76 and 1.5 LPM, ${\dot{m}}_{O_2}$ = 2.39 and 4.67 LPM) induced hydrogen-depleted regions, triggering crossover phenomena that exacerbated anode contamination and localized flooding. Full article

The development of bipolar plate materials with enhanced corrosion resistance and surface conductivity is critical for the commercial application of proton exchange membrane fuel cells (PEMFCs). The corrosion behavior and surface conductivity of electrochemically nitrided 446 stainless steel with and without the pretreatment of Cr-enrichment were investigated in the simulated PEMFC anode and cathode environments (i.e., 0.5 mol L⁻¹ H₂SO₄ + 2 ppm HF solution bubbled with hydrogen or air at 80 °C) using scanning electron microscopy (SEM), X-ray photoelectron spectroscopy (XPS), inductively coupled plasma–mass spectrometry (ICP-MS), and electrochemical measurement techniques. Extending the nitriding time from 5 to 30 min enhances the surface conductivity but reduces the corrosion resistance. After the pretreatment and 30 min of nitridation, a thin film formed on the specimen surface, which mainly consists of Cr-nitrides and -oxides with atomic fractions of 0.42 and 0.37, respectively. The Cr-enriched and nitrided specimen shows spontaneous passivation in both the simulated cathode and anode environments and higher corrosion potentials, lower passive current densities, and larger polarization resistances in comparison with the directly nitrided specimens. Its stable current densities are about 0.26 and −0.39 μA cm⁻² after 5 h of polarization tests at 0.6 V_SCE in the cathode environment and at −0.1 V_SCE in the anode environment, respectively. Its contact resistance is about 5.0 mΩ cm² under 1.4 MPa, which is close to that of the specimen directly nitrided for 120 min and slightly decreases after the potentiostatic polarization tests. These results indicate that Cr-rich pretreatment improves not only the corrosion resistance and surface conductivity of nitrided specimens but also the efficiency of electrochemical nitridation. Full article

The broad use of (stainless steel) SS 316 L bipolar plates (BPs) in proton exchange membrane fuel cells relies (PEMFC) on high conductivity and corrosion resistance. To enhance the properties of stainless steel, this study applies ion implantation and heat treatment to form a non-homogeneous modified layer on SS 316 L. The injection of C and Mo ions on the SS 316 L surface caused irradiation damage, producing holes. But with the heat treatment of the ion-implanted samples, the irradiation-damaged surface will be repaired to a certain extent. The corrosion current density (I_corr) of the 600 °C sample in the kinetic potential test (5.32 × 10⁻⁴ A/cm²) was 54% lower than that of the naked SS 316 L (1.17 × 10⁻³ A/cm²). In the electrostatic potential test, the corrosion current of the 600 °C sample stabilized at a low value (about 0.26 μA/cm²), with the lowest concentration of dissolved metal ions (Fe²⁺ 2.908 mg/L). After anodic electrostatic potential polarization, the interfacial contact resistance (ICR) of (Mo+C)_600-1 was much lower than that of the untreated SS 316 L. Heat treatment experiments show that samples treated at 600 °C for 1 h exhibit significantly higher conductivity and anodic corrosion resistance than naked SS 316 L. This improvement is mainly due to the heat treatment under these conditions, which facilitated the formation of Mo carbides from the implanted C and Mo elements. Ion implantation and heat treatment enhance stainless steel surface conductivity and passive film corrosion resistance. These findings are useful in altering stainless steel BPs. Full article

High-temperature polymer-electrolyte membrane fuel cells (HT-PEMFCs) are a very important type of fuel cells since they operate at 150–200 °C, making it possible to use hydrogen contaminated with CO. However, the need to improve the stability and other properties of gas-diffusion electrodes still impedes their distribution. Self-supporting anodes based on carbon nanofibers (CNF) are prepared using the electrospinning method from a polyacrylonitrile solution containing zirconium salt, followed by pyrolysis. After the deposition of Pt nanoparticles on the CNF surface, the composite anodes are obtained. A new self-phosphorylating polybenzimidazole of the 6F family is applied to the Pt/CNF surface to improve the triple-phase boundary, gas transport, and proton conductivity of the anode. This polymer coating ensures a continuous interface between the anode and proton-conducting membrane. The polymer is investigated using CO₂ adsorption, TGA, DTA, FTIR, GPC, and gas permeability measurements. The anodes are studied using SEM, HAADF STEM, and CV. The operation of the membrane–electrode assembly in the H₂/air HT-PEMFC shows that the application of the new PBI of the 6F family with good gas permeability as a coating for the CNF anodes results in an enhancement of HT-PEMFC performance, reaching 500 mW/cm² at 1.3 A/cm² (at 180 °C), compared with the previously studied PBI-O-PhT-P polymer. Full article

In this study, the optimization of the operational parameters for a single proton exchange membrane fuel cell (PEMFC) was carried out using the Taguchi method and orthogonal array. The operating parameters were H₂ stoichiometry, air stoichiometry, cell temperature, and back pressure of the anode∙cathode, each with three levels. The performance of the PEMFC, operated according to the L₉ orthogonal arrangement, was evaluated through I–V curves at a step-up current loading ranging from 0.1 to 0.7 A/cm². The results indicated that the anode∙cathode back pressure had the greatest sensitivity to the output voltage compared to the other operating parameters. Increasing the back pressure resulted in higher current output densities at higher values than those applied in the orthogonal arrangement. As the back pressure increased, the output voltage tended to increase at each current density. However, for operating conditions above 150 kPa, the improvement in cell performance was either not significant or tended to decrease. Therefore, it can be concluded that the Taguchi method and orthogonal array are effective tools for selecting the optimal operating conditions for PEMFC. Full article

High-temperature polymer-electrolyte membrane fuel cells (HT-PEM FC) are a very important type of fuel cell since they operate at 150–200 °C, allowing the use of hydrogen contaminated with CO. However, the need to improve stability and other properties of gas diffusion electrodes still hinders their distribution. Anodes based on a mat (self-supporting entire non-woven nanofiber material) of carbon nanofibers (CNF) were prepared by the electrospinning method from a polyacrylonitrile solution followed by thermal stabilization and pyrolysis of the mat. To improve their proton conductivity, Zr salt was introduced into the electrospinning solution. As a result, after subsequent deposition of Pt-nanoparticles, Zr-containing composite anodes were obtained. To improve the proton conductivity of the nanofiber surface of the composite anode and reach HT-PEMFC better performance, dilute solutions of Nafion^®, a polymer of intrinsic microporosity (PIM-1) and N-ethyl phosphonated polybenzimidazole (PBI-OPhT-P) were used to coat the CNF surface for the first time. These anodes were studied by electron microscopy and tested in membrane-electrode assembly for H₂/air HT-PEMFC. The use of CNF anodes coated with PBI-OPhT-P has been shown to improve the HT-PEMFC performance. Full article

Here, potential metallic bipolar plate (BP) materials were manufactured by laser coating NiCr-based alloys with different Ti additions on low carbon steel substrates. The titanium content within the coating varied between 1.5 and 12.5 wt%. Our present study focussed on electrochemically testing the laser cladded samples in a milder solution. The electrolyte used for all of the electrochemical tests consisted of a 0.1 M Na₂SO₄ solution (acidulated with H₂SO₄ at pH = 5) with the addition of 0.1 ppm F⁻. The corrosion resistance properties of the laser-cladded samples was evaluated using an electrochemical protocol, which consisted of the open circuit potential (OCP), electrochemical impedance spectroscopy (EIS) measurements, and potentiodynamic polarization, followed by potentiostatic polarization under simulated proton exchange membrane fuel cell (PEMFC) anodic and cathodic environments for 6 h each. After the samples were subjected to potentiostatic polarization, the EIS measurements and potentiodynamic polarization were repeated. The microstructure and chemical composition of the laser cladded samples were investigated by scanning electron microscopy (SEM) combined with energy-dispersive X-ray spectroscopy (EDX) analysis. Full article

In this research, titanium nitride (TiN) was applied to grade 1 titanium as a bipolar plate for a proton exchange membrane fuel cell (PEMFC). The TiN was deposited by the arc ion plating method (AIP) to investigate the electrochemical characteristics of the anode and cathode environments in the PEMFC. The corrosion experiments were conducted in an aqueous solution of pH 3 (H₂SO₄ + 0.1 ppm HF, 80 °C) determined by the Department of Energy (DoE). The hydrogen gas and air were bubbled to simulate the anode and cathode environments. The potentiodynamic polarization experiment showed that there was no active peak. The potentiostatic experiment showed that the current densities of the TiN-coated specimens were less than 1 μA/cm² in both the anode and cathode. As a result of observing the surface with an SEM before and after the potentiostatic experiment, only pinholes generated during the coating process were observed, and no corrosion damage was observed. Furthermore, electrochemical impedance spectroscopy (EIS) analysis showed that the coated specimens had a higher charge transfer resistance than the titanium substrate. In the case of interfacial contact resistance (ICR), the TiN-coated specimen displayed lower resistance than the titanium substrate and satisfied the DoE technical target of less than 10 mΩ·cm² at 140 N/cm². Full article

A 21.7 wt.% Pd—7.3 wt.% Zn/C electrocatalyst prepared via the wet impregnation (w.i.) method was deposited onto commercial carbon cloth (E-TEK) and tested towards its electrocatalytic performance as a cathode electrode material for oxygen reduction reaction (ORR) in a H₂ fueled single proton-exchange membrane fuel cell (PEMFC). A commercial PtRu electrode (E-TEK) was used as PEM anode for hydrogen oxidation reaction (HOR). The performance of the aforementioned PEMFC was compared with that of the same PEMFC with two different Pt-based cathodes, which were prepared by deposition onto commercial carbon cloth (E-TEK) of 29 wt.% Pt/C synthesized via w.i. and of commercial 29 wt.% Pt/C (TKK). The metal loading of the tested cathode electrodes was 0.5 mg_met cm⁻². Comparison was based both on polarization curves and on electrochemical impedance spectroscopy (EIS) measurements at varying cell potential. In terms of power density, the lowest and highest performance was exhibited by the PEMFC with the 21.7 wt.% Pd—7.3 wt.% Zn/C cathode and the PEMFC with the commercial 29 wt.% Pt/C (TKK) cathode electrode, respectively. This behavior was in accordance with the results of EIS measurements, which showed that the PEMFC with the 21.7 wt.% Pd—7.3 wt.% Zn/C cathode exhibited the highest polarization resistance. Full article

The performance of proton exchange membrane fuel cells (PEMFCs) is directly affected by the nonlinear variations in water content. To study the variation in water content and its effect on PEMFC performance, the water condensation rate (WCR) model is established, which determines the proportional relationship between evaporation and condensation rates in terms of the switch function, and the two-phase flow evolution and pressure drop are considered as well. The WCR model is imported into Fluent software through a user-defined function for simulation, and the test system is established under different operating conditions. Then, the contours of H₂O molar concentrations and polarization curves are analyzed and compared. The results show that the condensation rate value of the cathode channel is from 1.05 to 1.55 times higher than that of the anode channel. The WCR model can predict the variation in water content and improve the accuracy of the performance calculation by from 9% to 31%. The accuracy of the WCR model is especially improved, by 31%, at high current densities compared with the Fluent model when the inlet pressure is 30 kPa. Full article

A protonic ceramic fuel cell (PCFC) has great potential for medium temperature power generation. Its working process, however, is complicated and quite different from the traditional oxygen ionic solid oxide fuel cell (O²⁻-SOFC) and proton exchange membrane fuel cell (PEMFC). In this paper, a multi-physical model for the PCFC with H⁺/e⁻/O²⁻ mixed conducting cathode is established, in which the fuel- and oxidant-diffusing processes; electron-, oxygen ion-, and proton-conducting processes; three electrochemical reactions; and their coupling working details are carefully considered. Taking Ni-BZCY/BZCY/BZCY-LSCF PCFC as an example, the validation of the model is well verified by good agreements with the experiment i_op-V_op curves at different temperatures. The result shows that the cathodic electrochemical reactions will be concentrated to a small thickness near the electrolyte because of the greatly decreased ionic conductivity compared with the high electronic conductivity at an intermediate temperature. O²⁻ within the PCFC cathode is only an intermediate transform substance between the electrons and protons. Thus, there is a peak oxygen ion current distribution within the composite cathode of PCFC. The cathodic oxygen reduction half reaction is found to be a key factor to dominate the total PCFC voltage loss at the intermediate temperature zone. The concentration polarization of anode-supported PCFC is small, due to the vapors that are generated in the cathode side instead of anode side. Full article

The purpose of this study is to understand the impact of the thickness of Nafion membrane, which is a typical polymer electrolyte membrane (PEM) in Polymer Electrolyte Membrane Fuel Cells (PEMFCs), and relative humidity of supply gas on the distributions of H₂, O₂, H₂O concentration and current density on the interface between a Nafion membrane and anode catalyst layer or the interface between a Nafion membrane and cathode catalyst layer. The effect of the initial temperature of the cell (T_ini) is also investigated by the numerical simulation using the 3D model by COMSOL Multiphysics. As a result, the current density decreases along with the gas flow through the gas channel irrespective of the Nafion membrane thickness and T_ini, which can be explained by the concentration distribution of H₂ and O₂ consumed by electrochemical reaction. The molar concentration of H₂O decreases when the thickness of Nafion membrane increases, irrespective of T_ini and the relative humidity of the supply gas. The current density increases with the increase in relative humidity of the supply gas, irrespective of the Nafion membrane thickness and T_ini. This study recommends that a thinner Nafion membrane with well-humidified supply gas would promote high power generation at the target temperature of 363 K and 373 K. Full article

This work presents an OsRu-based electrocatalyst synthesis, by a rapid and efficient method through microwave irradiation. The outstanding electrocatalyst shows a dual catalytic activity, demonstrating both: hydrogen oxidation and oxygen reduction reactions. The material is structural and morphologically characterized by FT-IR, X-ray diffraction, EDS, and SEM, indicating nanoparticulated Os and Ru metallic phases with a crystallite size of ∼6 nm, calculated by the Scherrer equation. The metal nanoparticles are apparently deposited on a carbonaceous sponge-like morphology structure. Its electrochemical characterization is performed in 0.5 M H₂SO₄ by the rotating disk electrode technique, employing cyclic and linear sweep voltammetry. Two different ink treatments have been studied to improve the obtained polarization curves. The material is also tested in the presence of methanol for the oxygen reduction reaction, showing an important resistance to this contaminant, making it viable for its use in direct methanol fuel cells (DMFCs) as a cathode and in polymer electrolyte fuel cells (PEMFCs) as an anode as much as a cathode. Full article

The activity degradation of hydrogen-fed proton exchange membrane fuel cells (H₂-PEMFCs) in the presence of even trace amounts of carbon monoxide (CO) in the H₂ fuel is among the major drawbacks currently hindering their commercialization. Although significant progress has been made, the development of a practical anode electrocatalyst with both high CO tolerance and stability has still not occurred. Currently, efforts are being devoted to Pt-based electrocatalysts, including (i) alloys developed via novel synthesis methods, (ii) Pt combinations with metal oxides, (iii) core–shell structures, and (iv) surface-modified Pt/C catalysts. Additionally, the prospect of substituting the conventional carbon black support with advanced carbonaceous materials or metal oxides and carbides has been widely explored. In the present review, we provide a brief introduction to the fundamental aspects of CO tolerance, followed by a comprehensive presentation and thorough discussion of the recent strategies applied to enhance the CO tolerance and stability of anode electrocatalysts. The aim is to determine the progress made so far, highlight the most promising state-of-the-art CO-tolerant electrocatalysts, and identify the contributions of the novel strategies and the future challenges. Full article

In this paper, we experimentally investigated two high temperature polymer electrolyte membrane fuel cell (HT-PEMFC) stacks for their response to the presence of reformate impurities in an anode gas stream. The investigation was aimed at characterizing the effects of reformate impurities at the stack level, including in humidified conditions and identifying fault features for diagnosis purposes. Two HT-PEMFC stacks of 37 cells each with active areas of 165 ${\mathrm{cm}}^2$ were used with one stack containing a pre-doped membrane with a woven gas diffusion layer (GDL) and the other containing a post-doped membrane with non-woven GDL. Polarization curves and galvanostatic electrochemical impedance spectroscopy (EIS) were used for characterization. We found that both N₂ dilution and impurities in the anode feed affected mainly the charge transfer losses, especially on the anode side. We also found that humidification alleviated the poisoning effects of the impurities in the stack with pre-doped membrane electrode assemblies (MEA) and woven GDL but had detrimental effects on the stack with post-doped MEAs and non-woven GDL. We demonstrated that pure and dry hydrogen operation at the end of the tests resulted in significant recovery of the performance losses due to impurities for both stacks even after the humidified reformate operation. This implies that there was only limited acid loss during the test period of around 150 h for each stack. Full article
