In the last decade, countries have experienced increased solar radiation, leading to an increase in the use of solar photovoltaic (PV) systems to boost renewable energy generation. However, the high solar penetration into these systems can disrupt the normal operation of the distribution grid. Thus, a major concern is the impact of these units on power quality indices. To improve these units, one approach is to design more efficient power inverters. This study introduces a pulse width modulation (PWM) technique for multilevel power inverters, employing a sine wave as the carrier wave and an amplitude over-modulated triangular wave as the modulator (PSTM-PWM). The proposed technique improves the waveform quality and increases the AC voltage output of the multilevel inverter compared with that from conventional PWM techniques. In addition, it ensures compliance with the EN50160 standard. These improvements are achieved with a lower modulation order than that used in traditional techniques, resulting in reduced losses in multilevel power inverters. The proposed approach is then implemented using a five-level cascaded H-bridge inverter. In addition, a comparative analysis of the efficiency of multilevel power inverters was performed, contrasting classical modulation techniques with the proposed approach for various modulation orders. The results demonstrate a significant improvement in both total harmonic distortion (THD) and power inverter efficiency. Full article

This paper deals with the design and control of an enhanced grid-tied photovoltaic (PV) cascaded H-Bridge (CHB) inverter, which suffers from issues related to operation in the overmodulation region in the case of a deep mismatch configuration of PV generators (PVGs). This can lead to reduced system performance in terms of maximum power point tracking (MPPT) efficiency, or even instability (i.e., a lack of control action). The proposed solution is to insert into the cascade a power cell fed by a battery energy storage system (BESS) with the aim of providing an additional power contribution. The latter is useful to reduce the modulation index of the cell, delivering more power than the others when a preset threshold is crossed. Moreover, a suitable hybrid modulation method is used to achieve the desired result. A simulated performance in a PLECS environment proves the viability of the proposed solution and the effectiveness of the adopted control strategy. Full article

Transformerless inverters (TIs) are becoming increasingly popular in solar photovoltaic (PV) applications due to their enhanced efficiency and cost-effectiveness. Unlike transformer-based inverters, TIs, which lack transformers and additional components, offer significant advantages in terms of reduced weight, compactness, and lower costs. Research studies have demonstrated that multilevel TIs can achieve lower total harmonic distortion (THD), reduced switching stresses, and higher AC output voltage levels suitable for high voltage applications. However, achieving these outcomes simultaneously with maximum power ratings and the lowest switching frequencies poses a challenge for TI topologies. In light of these challenges, this research proposes the implementation of a 13-level single-source switched-capacitor boost multilevel inverter (SSCBMLI) designed for solar PV systems. The SSCBMLI consists of a single DC power source, switched-capacitor (SC) units, and a full H-bridge. Compared to other existing 13-level multilevel inverter (MLI) configurations, the proposed SSCBMLI utilizes the fewest components to minimize development costs. Moreover, the SSCBMLI offers voltage boosting and can drive high inductive loads, self-voltage-balanced capacitors, an adaptable topology structure, and reliable system performance. Simulations and experimental tests are conducted using PLECS 4.5 and SIMULINK to assess the performance of the proposed SSCBMLI under varying modulation indices, source powers, and loads. A comparative analysis is then conducted to evaluate the SSCBMLI against existing inverter topologies. Full article

The paper proposes an original single-phase transformerless three-level (S-PT) photovoltaic (PV) inverter in the cascade H bridge (CHB) configuration. The DC-link voltage of the inverter is created by two serial voltage sources with a voltage twice as low as the DC-link voltage. An appropriate V_CC DC-link voltage is generated by a two-phase DC-DC boost converter, fed from the string panel output at a level determined by the maximum power point tracking (MPPT) algorithm. Two symmetrical sources with V_CC/2 are formed by a divider of two series-connected capacitors of large and the same capacitance. The common mode (CM) voltage of the proposed inverter is constant, and the voltage stresses across all switches, diodes and gate drive circuits are half of the DC-link voltage. The principles of operation of the S-PT inverter, an implementation of a complete gate control system with galvanic isolation for all IGBTs, are also presented. The proposed inverter topologies have been implemented using high-speed IGBTs and simulated in PSPICE, as well as being experimentally validated. Full article

The single-phase photovoltaic energy storage inverter represents a pivotal component within photovoltaic energy storage systems. Its operational dynamics are often intricate due to its inherent characteristics and the prevalent usage of nonlinear switching elements, leading to nonlinear characteristic bifurcation such as bifurcation and chaos. In this paper, a deep investigation of a single-phase H-bridge photovoltaic energy storage inverter under proportional–integral (PI) control is made, and a sinusoidal delayed feedback control (SDFC) strategy to mitigate the nonlinear characteristics is proposed. A frequency domain mapping model of the system is established, then, by analyzing the Jacobian matrix and equilibrium points, the bifurcation diagram is formed, and finally, the stable operational domains are determined under double and triple bifurcation parameters. Through simulation experiments, the efficacy of this strategy is validated. The findings show that through the control strategy, the stable operational envelope of the inverter can be greatly expanded and the nonlinear dynamic phenomena can be notably suppressed. Full article

The cascaded H-bridge (CHB) inverter has become pivotal in grid-connected photovoltaic (PV) systems owing to its numerous benefits. Typically, DC–DC converters are employed to boost the input voltage in grid-connected systems to meet the grid’s higher voltage requirements, but this approach increases equipment size and cost. To enhance inverter efficiency, this paper proposes a boost-type, three-phase CHB PV grid-connected inverter. This design can raise the input voltage and satisfy grid requirements with only a few additional components. Additionally, PV environmental fluctuations can cause variations in PV power generation, leading to a power imbalance in the inverter and potentially affecting the stability of the PV system. Based on this, we consider grid voltage fluctuations induced by unbalanced power output from the inverter and propose an improved control method based on the superposition of zero-sequence components. Finally, we construct a simulation model and conduct experimental verification using the MATLAB/Simulink platform. The validation results demonstrate that this topology reduces equipment volume and effectively enhances the efficiency of PV power generation systems. Furthermore, the designed control method ensures system stability while effectively mitigating power imbalances caused by PV module and grid voltage fluctuations. Full article

This study presents a standalone solar power system that incorporates a photovoltaic (PV) module, a boost converter, an H-bridge inverter, a low-pass filter (LPF), and a microcontroller unit (MCU). A novel cake sweetness maximum power point tracking (CS MPPT) algorithm and adjustable frequency and duty cycle (AFDC) control strategy has been proposed and efficiently applied to the solar power system for optimizing the system efficiency and output power quality. The experimental results show that the proposed CS MPPT algorithm achieves an efficiency of 99% under both the uniform irradiance conditions (UIC) and partial shading conditions (PSC). Subsequently, the AFDC control strategy is applied to the H-bridge inverter which improves the output AC voltage and AC current and thereby improving the power quality. The system ensures a stable 110 V_rms/60 Hz AC output voltage with only 2% total voltage harmonic distortion of voltage (THD_v), and produces a high-quality output voltage with reduced LPF volume and better economic benefits. The comparative analysis demonstrates that the characteristics and the performances of the CS MPPT algorithm in combination with the AFDC control strategy is better than the existing several maximum power point tracking (MPPT) techniques and inverter control strategies. The research output affirms the potential of the proposed solar power system to fulfill the actual daily needs of electricity by harnessing the maximum power from PV modules. Full article

The paper deals with a grid-connected single-phase battery charger integrated with photovoltaic generators (PVGs). The circuit topology consists of a multilevel architecture based on a Cascaded H-Bridge (CHB) rectifier. Its main task is to charge the batteries, primarily from the PVGs, by also assuring to keep their state-of-charge (SOC) balanced. Nevertheless, when the battery SOC overcomes a predefined upper limit, beyond which the charging process could be interrupted, the available PV power can no longer be transferred to the batteries. Therefore, to avoid an undesired curtailment of PV power production, this latter can be supplied to the grid by inverting the system operation. The paper shows how to achieve this result by implementing a dedicated control action based on a multi-step procedure. Numerical investigations are carried out on a 19-level CHB converter implemented in the PLECS environment to validate the feasibility and effectiveness of the proposed control technique. Full article

The key goal of this effort is to develop an efficient control system for a three-phase cascaded H-bridge multilevel inverter powered by the photovoltaic (PV) system. The power for the system is generated through the use of PV modules, which serve as DC inputs for the cascaded H-bridge multilevel inverter. The authors aim to achieve a nearly sinusoidal signal at the voltage level and are specifically focused on minimizing the total harmonic distortion (THD) to the smallest possible value. Hence, an advanced N-level space vector modulation (SVM) is developed to ensure an appropriate control for the cascaded inverter. The aim is to design an effective control strategy to increase inverter efficacy and, thus, supply the best output quality. In addition, a robust approach to the maximum power point (MPP) tracking (MPPT) technique is developed based on an adaptive perturb and observe (P&O) algorithm to ensure superior tracking of the MPP. The developed algorithm eliminates 90% of the power curve area in the search space process and only maintains 10% of the area that includes the MPP. Each PV system employs its own improved MPPT control. The numerical results confirm that the enhanced P&O algorithm attains a precise response with superior efficiency and a fast response under the fast alteration of environmental conditions. Hence, the energy loss is reduced. The simulation results validate the effectiveness of this study, highlighting the high efficiency of the control strategy and the enhanced performance of the proposed scheme with lesser THD values. Full article

With accelerating grid decarbonization and technological breakthroughs, grid-connected photovoltaic (PV) systems are continuously connected to distribution networks at all voltage levels. As the grid interaction interfaces between PV panels and the distribution network, PV inverters must operate flawlessly to avoid energy and financial losses. As the failure of semiconductor switches is the leading cause of abnormal operation of PV inverters and typically cannot be detected by internal protection circuits, this paper aims to develop a method for the autonomous diagnosis of semiconductor power switch open-circuit faults in three-phase grid-connected PV inverters. In this study, a ReliefF-mRMR-based multi-domain feature selection method is designed to ensure the completeness of the fault characteristics. An NGO-HKELM-based classification method is proposed to guarantee the desired balance between generalization and exploration capability. The proposed method overcomes the common problems of poor training efficiency and imbalances between generalization and exploration capabilities. The performance of the proposed method is verified with the detection of switch OC faults in a three-phase H-bridge inverter and neutral-point-clamped inverter, with diagnostic accuracy of 100% and 99.46% respectively. Full article

Single-phase inverters are widely employed in renewable energy applications. However, their inherent 2ω-ripple power can substantially affect system performance, leading to fluctuations in the maximum power points (MPP) of photovoltaic (PV) systems and shortening the lifespans of fuel cell (FC) systems. To alleviate input ripple, a three-leg quasi-Z-source inverter (QZSI) and its associated control strategy are proposed. The QZSI consists of a quasi-Z-source network, an H-Bridge inverter, and an active power filter (APF). The active filtering structure comprises filtering capacitors and the third bridge leg. The proposed control strategy consists of three loops: open-loop simple boost control, output voltage control, and 2ω-ripple suppression control. Open-loop simple boost control is utilized for shoot-through state modulation, output voltage control is applied to the two bridge-legs of the H-Bridge, and the additional third bridge-leg adopts a quasi-PR control (QPR) method that injects specific frequency harmonic voltage and suppresses newly generated low-frequency components of the input current. This method effectively avoids the drawbacks of utilizing passive filtering strategies, such as high-value impedance networks, low power density, and weak system stability. A simulation platform of 300W 144VDC/110VAC50Hz is constructed. The simulation results indicate that the addition of the third bridge leg under full load conditions reduces the input-side inductor current ripple ΔI from 1.89 A with passive filtering to 0.513 A, representing a reduction of 72.86%. The second harmonic ripple of the input current is reduced from 18.2% to 4.5%, and the fourth harmonic ripple is reduced from 16.5% to 2.1%. The DC bus voltage ripple ΔV_PN falls from 70.75 V to 6.54 V, representing a reduction of 90.76%. The Total Harmonic Distortion (THD) of the output voltage and current are both less than 1%. The simulation results validated the feasibility of the proposed approach. Full article

Aiming at the slow-scale nonlinear behaviors of a dual-loop control H-bridge photovoltaic inverter, a slow-scale nonlinear control method based on time-delay feedback control is proposed. Firstly, a feedback signal is formed by the difference between the current error signal and its own delay, and the feedback signal is made to pass through a proportion link so as to obtain a time-delay control signal. Then, based on the necessary conditions of the stability criterion, the value range of the delay feedback proportional coefficient is quickly determined, and the best delay time is chosen by determining the variation curve of the largest Lyapunov exponent. Finally, based on the double-loop PI regulation, the time-delay control signal is added to the original control signal to form the final control signal applied to the inverter. The results obtained show that the slow-scale nonlinear behaviors in the system can be absolutely eliminated, and the stable operation domain of the inverter can be remarkably expanded. When the sun irradiance and temperature change, the proposed control method still has a good control effect and shows strong robustness. In addition, the complex calculation in determining the control coefficient and delay time can be avoided by the method. Full article

The effects of partial shading or dust accumulation on the panels of photovoltaic systems connected to the grid can generate a considerable reduction in energy performance, being necessary to provide the appropriate voltage to the grid regardless of the irradiance level. This paper addresses this problem and presents a comprehensive control strategy and its implementation for a grid-connected microinverter composed of a push–pull converter followed by an H-bridge inverter. In the push–pull converter, a hybrid MPPT algorithm and a PI control enable work in the MPP of the PV panel. In the H-bridge inverter, a cascade control consisting of a PI control and a predictive control allows the connection to the grid. A proof-of-concept prototype is implemented in order to validate the proposal. Experimental tests were performed by connecting the microinverter to a PV panel and a programmable photovoltaic panel emulator to check the MPPT performance. Furthermore, partial shading conditions were simulated on the dc source to check if the global maximum power point is reached. Experimental results demonstrate the feasibility of the topology and the control approach, obtaining MPPT performance in the topology above 99% at different power and voltage levels on the MPPT, even in the presence of partial shading conditions. Full article

This paper describes the use of a Cascaded H-Bridge Multilevel Inverter to deal with the problem of partial shading in a photovoltaic system connected to the grid. Combined with the topology, it proposes the use of a virtual synchronous generator for power sharing between photovoltaic arrays and to ensure the connection to the power grid even in extreme shading situations with no power buffer. The experimental results demonstrate the feasibility of the strategy adopted and the limitations to overcome. Full article

The photovoltaic (PV) system center inverter architecture comprises various conventional array topologies such as simple-series (S-S), parallel (P), series-parallel (S-P), total-cross-tied (T-C-T), bridge-linked (B-L), and honey-comb (H-C). The conventional PV array topologies under non-uniform operating conditions (NUOCs) produce a higher amount of mismatching power loss and represent multiple maximum-power-points (M-P-Ps) in the output characteristics. The performance of T-C-T topology is found superior among the conventional topologies under NUOCs. However, T-C-T topology’s main limitations are higher redundancy, more number of electrical connections, higher cabling loss, poor performance during row-wise shading patterns, and more number of switches and sensors for the re-configuration of PV modules. This paper proposes the various optimal hybrid PV array topologies to overcome the limitations of conventional T-C-T array topology. The proposed hybrid topologies are such as series-parallel-cross-tied (S-P-C-T), bridge-link-cross-tied (B-L-C-T), honey-comb-cross-tied (H-C-C-T), series-parallel-total-cross-tied (S-P-T-C-T), bridge-link-total-cross-tied (B-L-T-C-T), honey-comb-total-cross-tied (H-C-T-C-T), and bridge-link-honey-comb (B-L-H-C). The proposed hybrid topologies performance is evaluated and compared with the conventional topologies under various NUOCs. The parameters used for the comparative study are open-circuit voltage, short-circuit current, global-maximum-power-point (GMPP), local-maximum-power-point (LMPP), number of LMPPs, and fill factor (FF). Furthermore, the mismatched power loss and the conversion efficiency of conventional and hybrid array topologies are also determined. Based on the results, it is found that the hybrid array topologies maximize the power output by mitigating the effect of NUOCs and reducing the number of LMPPs. Full article
