This study presents a comprehensive performance evaluation of field-programmable gate array (FPGA), graphics processing unit (GPU), and central processing unit (CPU) platforms for implementing finite impulse response (FIR) filters in semiconductor-based digital signal processing (DSP) systems. Utilizing a standardized FIR filter designed with the Kaiser window method, we compare computational efficiency, latency, and energy consumption across the ZYNQ XC7Z020 FPGA, Tesla K80 GPU, and Arm-based CPU, achieving processing times of 0.004 s, 0.008 s, and 0.107 s, respectively, with FPGA power consumption of 1.431 W and comparable energy profiles for GPU and CPU. The FPGA is 27 times faster than the CPU and 2 times faster than the GPU, demonstrating its suitability for low-latency DSP tasks. A detailed analysis of resource utilization and scalability underscores the FPGA’s reconfigurability for optimized DSP implementations. This work provides novel insights into platform-specific optimizations, addressing the demand for energy-efficient solutions in edge computing and IoT applications, with implications for advancing sustainable DSP architectures. Full article

Precise analysis of electroencephalogram (EEG) signals is critical for advancing the understanding of neurological conditions and mapping brain activity. However, accurately visualizing brain regions and behavioral patterns from neural signals remains a significant challenge. The present study proposes a novel methodology for the automated calculation of the average power of EEG signals, with a particular focus on the beta frequency band which is known for its pronounced activity during cognitive tasks such as 2D content engagement. An optimization algorithm is employed to determine the most appropriate digital filter type and order for EEG signal processing, thereby enhancing both signal clarity and interpretability. To validate the proposed methodology, an experiment was conducted with 22 students, during which EEG data were recorded while participants engaged in cognitive tasks. The collected data were processed using MATLAB (version R2023a) and the EEGLAB toolbox (version 2022.1) to evaluate various filters, including finite impulse response (FIR) and infinite impulse response (IIR) Butterworth and IIR Chebyshev filters with a 0.5% passband ripple. Results indicate that the IIR Chebyshev filter, configured with a 0.5% passband ripple and a fourth-order design, outperformed the alternatives by effectively reducing average power while preserving signal fidelity. This optimized filtering approach significantly improves the accuracy of neural signal visualizations, thereby facilitating the creation of detailed brain activity maps. By refining the analysis of EEG signals, the proposed method enhances the detection of specific neural behaviors and deepens the understanding of functional brain regions. Moreover, it bolsters the reliability of real-time brain activity monitoring, potentially advancing neurological diagnostics and insights into cognitive processes. These findings suggest that the technique holds considerable promise for future applications in brain–computer interfaces and advanced neurological assessments, offering a valuable tool for both clinical practice and research exploration. Full article

This study introduces a mechatronic biomedical device engineered for concurrent acquisition and analysis of four cardiac non-invasive signals: Electrocardiogram (ECG), Phonocardiogram (PCG), Impedance Cardiogram (ICG), and Photoplethysmogram (PPG). The system enables assessment of individual and simultaneous waveforms, allowing for detailed scrutiny of cardiac electrical and mechanical dynamics, encompassing heart rate variability, systolic time intervals, pre-ejection period (PEP), and aortic valve opening and closing timings (ET) through an application programmed with MATLAB App Designer, which applies derivative filters, smoothing, and FIR digital filters and evaluates the delay of each one, allowing the synchronization of all signals. These metrics are indispensable for deriving critical hemodynamic indices such as Stroke Volume (SV) and Cardiac Output (CO), paramount in the diagnostic armamentarium against cardiovascular pathologies. The device integrates an assembly of components including five electrodes, operational and instrumental amplifiers, infrared opto-couplers, accelerometers, and advanced filtering subsystems, synergistically tailored for precision and fidelity in signal processing. Rigorous validation utilizing a cohort of healthy subjects and benchmarking against established commercial instrumentation substantiates an accuracy threshold below 4.3% and an Interclass Correlation Coefficient (ICC) surpassing 0.9, attesting to the instrument’s exceptional reliability and robustness in quantification. These findings underscore the clinical potency and technical prowess of the developed device, empowering healthcare practitioners with an advanced toolset for refined diagnosis and management of cardiovascular disorders. Full article

Passive pulse shaping at frequencies above 1 GHz is mainly achieved through frequency-domain processing using filters. Unfortunately, the conventional frequency domain approach does not allow precise control of the impulse response of the filter, therefore, setting limitations to the pulse shaping accuracy. Sub-nanosecond pulse expansion that preserves steep pulse transitions is one of the ultra-wideband (UWB) applications where frequency domain approaches do not provide satisfactory results. This paper proposes a highly innovative approach based on time-domain signal processing using a set of parallel microstrip delay lines connected in a network accompanied by a splitter at the input and a combiner at the output. The proposed design, analogous to finite impulse response (FIR) filters in digital signal processing (DSP), provides fine-grained control over time-domain characteristics and supports the implementation of complex functions, including pulse expansion. This paper presents a detailed analysis of previous work and theoretical considerations regarding the advantages and limitations of UWB pulse time-domain processing. Moreover, detailed HFSS simulations of components, such as a microstrip pulse splitter, delay lines, a combiner, and their combinations, are presented. Finally, the results of the experimental validation of the device, fabricated on an FR-4 substrate, are presented. Technology for effective implementation of a pulse splitter, delay lines, and a pulse combiner, as well as their matching, can be considered as key findings of the given research. Limitations associated with matching and delay estimation for pulsed UWB signals are highlighted. Full article

In this work, an analytical method in the frequency domain is proposed for the design of two-dimensional digital FIR differentiators. This technique uses an approximation based on two methods: the Chebyshev series and the Fourier series, which, finally, lead to a trigonometric polynomial, which is a remarkably precise approximation of the transfer function of the ideal differentiator. The digital differentiator is applied to three test images, one greyscale image and two binary images, and simulation results show its performance in the processing task. Also, based on the fact that this 2D differentiator is separable on the two frequency axes, we propose an efficient implementation at the system level, using polyphase filtering. The designed digital differentiator is very accurate and efficient, having a high level of parallelism and reduced computational complexity. Full article

This paper presents a highly efficient, low-power, compact mixed-signal sinusoidal current generator (CG) integrated circuit (IC) designed for bioelectrical impedance spectroscopy (BIS) with low total harmonic distortion (THD). The proposed system employs a 9-bit sine wave lookup table (LUT) which is simplified to a 4-bit data stream through a third-order digital delta–sigma modulator (ΔΣM). Unlike conventional analog low-pass filters (LPF), which statically limit bandwidth, the finite impulse response (FIR) filter attenuates high-frequency noise according to the operating frequency, allowing the frequency range of the sinusoidal signal to vary. Additionally, the output of the FIR filter is applied to a 6-bit capacitive digital-to-analog converter (CDAC) with data-weighted averaging (DWA), enabling dynamic capacitor matching and seamless interfacing. The sinusoidal CG IC, fabricated using a 65 nm CMOS process, produces a 5 μA amplitude and operates over a wide frequency range of 0.6 to 20 kHz. This highly synthesizable CG achieves a THD of 0.04%, consumes 19.2 μW of power, and occupies an area of 0.0798 mm². These attributes make the CG IC highly suitable for compact, low-power bio-impedance applications. Full article

This paper presents a programmable digital filtering unit dedicated to operating with signals from infrared (IR) detection modules. The designed device is quite useful for increasing the signal-to-noise ratio due to the reduction in noise and interference from detector–amplifier circuits or external radiation sources. Moreover, the developed device is flexible due to the possibility of programming the desired filter types and their responses. In the circuit, an advanced field-programmable gate array FPGA chip was used to ensure an adequate number of resources that are necessary to implement an effective filtration process. The proposed circuity was assisted by a 32-bit microcontroller to perform controlling functions and could operate at frequency sampling of up to 40 MSa/s with 16-bit resolution. In addition, in our application, the sampling frequency decimation enabled obtaining relatively narrow passband characteristics also in the low frequency range. The filtered signal was available in real time at the digital-to-analog converter output. In the paper, we showed results of simulations and real measurements of filters implementation in the FPGA device. Moreover, we also presented a practical application of the proposed circuit in cooperation with an InAsSb mid-IR detector module, where its self-noise was effectively reduced. The presented device can be regarded as an attractive alternative to the lock-in technique, artificial intelligence algorithms, or wavelet transform in applications where their use is impossible or problematic. Comparing the presented device with the previous proposal, a higher signal-to-noise ratio improvement and wider bandwidth of operation were obtained. Full article

A digitizer is considered one of the fundamental components of an earthquake monitoring system. In this paper, we design and implement a high accuracy seismic digitizer. The implemented digitizer consists of several blocks, i.e., the analog-to-digital converter (ADC), GPS receiver, and microprocessor. Three finite impulse response (FIR) filters are used to decimate the sampling rate of the input seismic data according to user needs. A graphical user interface (GUI) has been designed for enabling the user to monitor the seismic waveform in real time, and process and adjust the parameters of the acquisition unit. The system casing is designed to resist harsh conditions of the environment. The prototype can represent the three component sensors data in the standard MiniSEED format. The digitizer stream seismic data from the remote station to the main center is based on TCP/IP connection. This protocol ensures data transmission without any losses as long as the data still exist in the ring buffer. The prototype was calibrated by real field testing. The prototype digitizer is integrated with the Egyptian National Seismic Network (ENSN), where a commercial instrument is already installed. Case studies shows that, for the same event, the prototype station improves the solution of the ENSN by giving accurate timing and seismic event parameters. Field test results shows that the event arrival time and the amplitude are approximately the same between the prototype digitizer and the calibrated digitizer. Furthermore, the frequency contents are similar between the two digitizers. Therefore, the prototype digitizer captures the main seismic parameters accurately, irrespective of noise existence. Full article

In this article, we describe a performance comparison conducted between several digital filters intended to mitigate the intrinsic noise observed in magnetometers. The considered filters were used to smooth the control signals derived from the magnetometers, which were present in an autonomous forestry machine. Three moving average FIR filters, based on rectangular Bartlett and Hanning windows, and an exponential moving average IIR filter were selected and analyzed. The trade-off between the noise reduction factor and the latency of the proposed filters was also investigated, taking into account the crucial importance of latency on real-time applications and control algorithms. Thus, a maximum latency value was used in the filter design procedure instead of the usual filter order. The experimental results and simulations show that the linear decay moving average (LDMA) and the raised cosine moving average (RCMA) filters outperformed the simple moving average (SMA) and the exponential moving average (EMA) in terms of noise reduction, for a fixed latency value, allowing a more accurate heading angle calculation and position control mechanism for autonomous and unmanned ground vehicles (UGVs). Full article

A low-complexity multibeam wideband transmit beamformer using a 2D sparse FIR filter design capable of multiple beams is proposed as a digital building block for fully digital beamformers. The 2D sparse FIR filter has multiple trapezoid-shaped passbands pertaining to wideband beams aimed at particular directions. The proposed multibeam digital beamformer drives a uniform linear array of wideband antenna elements to achieve the wideband multibeam transmit-mode signals desired by the communication system. The 2D sparse FIR filter is designed to be optimal in the minimax sense using convex optimization techniques. Full-wave electromagnetic simulations using real antenna models confirm that the proposed wideband transmit beamformer can achieve multibeam transmission in the 1.3–2.8 GHz frequency range, with more than 70% fractional bandwidth. Furthermore, the adoption of the wideband transmit multibeam beamformer leads to a significant reduction in digital arithmetic (computational) complexity compared with previously reported wideband transmit beamformers of similar transfer function type, without deteriorating beam directionality and causing increases in the side-lobe level. The proposed sparse 2D FIR multibeam beamformer architecture is well-suited for both sub-6 GHz (legacy) band transmit beamforming, frequency range three (FR3) beamforming up to 28 GHz, and mmWave operation for emerging 5G/6G applications. Full article

The BC501A sensor is a liquid scintillator frequently used in nuclear physics for detecting fast neutrons. This paper describes a hardware implementation of digital pulse shape analysis (DPSA) for real-time analysis. DPSA is an algorithm that extracts the physically relevant parameters from the detected BC501A signals. The hardware solution is implemented in a MicroTCA system that provides the physical, mechanical, electrical, and cooling support for an AMC board (NAMC-ZYNQ-FMC) with a Xilinx ZYNQ Ultrascale-MP SoC. The Xilinx FPGA programmable logic implements a JESD204B interface to high-speed ADCs. The physical and datalink JESD204B layers are implemented using hardware description language (HDL), while the Xilinx high-level synthesis language (HLS) is used for the transport and application layers. The DPSA algorithm is a JESD204B application layer that includes a FIR filter and a constant fraction discriminator (CFD) function, a baseline calculation function, a peak detection function, and an energy calculation function. This architecture achieves an analysis mean time of less than 100 µs per signal with an FPGA resource utilization of about 50% of its most used resources. This paper presents a high-performance DPSA embedded system that interfaces with a 1 GS/s ADC and performs accurate calculations with relatively low latency. Full article

This paper introduces a computationally inexpensive technique for moving target detection in challenging outdoor environments using millimeter-wave (mmWave) frequency-modulated continuous-wave (FMCW) radars leveraging traditional signal processing methodologies. Conventional learning-based techniques for moving target detection suffer when there are variations in environmental conditions. Hence, the work described here leverages robust digital signal processing (DSP) methods, including wavelet transform, FIR filtering, and peak detection, to efficiently address variations in reflective data. The evaluation of this method is conducted in an outdoor environment, which includes obstructions like woods and trees, producing an accuracy score of 92.0% and precision of 91.5%. Notably, this approach outperforms deep learning methods when it comes to operating in changing environments that project extreme data variations. Full article

The advancement in technology and the availability of specialized digital signal processing chips have made digital filter design and implementation more feasible in a variety of fields, including biomedical engineering. This paper makes two key contributions. First, it uses a genetic algorithm to optimize the coefficients of finite impulse response (FIR) filters. Second, it conducts a case study on using genetic algorithms to optimize FIR filters for electrocardiogram (ECG) biomedical signal noise removal. The goal of the proposed filter design approach is to achieve the desired signal bandwidth while minimizing the side lobe level and eliminating unwanted signals using a genetic algorithm. The results of a comprehensive analysis show that the genetic algorithm-based filter is more effective than conventional filter designs in terms of noise removal efficiency. Full article

Many works in the state of the art are interested in the increase of the camera depth of field (DoF) via the joint optimization of an optical component (typically a phase mask) and a digital processing step with an infinite deconvolution support or a neural network. This can be used either to see sharp objects from a greater distance or to reduce manufacturing costs due to tolerance regarding the sensor position. Here, we study the case of an embedded processing with only one convolution with a finite kernel size. The finite impulse response (FIR) filter coefficients are learned or computed based on a Wiener filter paradigm. It involves an optical model typical of codesigned systems for DoF extension and a scene power spectral density, which is either learned or modeled. We compare different FIR filters and present a method for dimensioning their sizes prior to a joint optimization. We also show that, among the filters compared, the learning approach enables an easy adaptation to a database, but the other approaches are equally robust. Full article

Auscultation of heart sounds is important to perform cardiovascular assessment. External noises may limit heart sound perception. In addition, heart sound bandwidth is concentrated at very low frequencies, where the human ear has poor sensitivity. Therefore, the acoustic perception of the operator can be significantly improved by shifting the heart sound spectrum toward higher frequencies. This study proposes a real-time frequency shifter based on the Hilbert transform. Key system components are the Hilbert transformer implemented as a Finite Impulse Response (FIR) filter, and a Direct Digital Frequency Synthesizer (DDFS), which allows agile modification of the frequency shift. The frequency shifter has been implemented on a VLIW Digital Signal Processor (DSP) by devising a novel piecewise quadratic approximation technique for efficient DDFS implementation. The performance has been compared with other DDFS implementations both considering piecewise linear technique and sine/cosine standard library functions of the DSP. Piecewise techniques allow a more than 50% reduction in execution time compared to the DSP library. Piecewise quadratic technique also allows a more than 50% reduction in total required memory size in comparison to the piecewise linear. The theoretical analysis of the dynamic power dissipation exhibits a more than 20% reduction using piecewise techniques with respect to the DSP library. The real-time operation has been also verified on the DSK6713 rapid prototyping board by Texas Instruments C6713 DSP. Audiologic tests have also been performed to assess the actual improvement of heart sound perception. To this aim, heart sound recordings were corrupted by additive white Gaussian noise, crowded street noise, and helicopter noise, with different signal-to-noise ratios. All recordings were collected from public databases. Statistical analyses of the audiological test results confirm that the proposed approach provides a clear improvement in heartbeat perception in noisy environments. Full article
