Interfacial stress concentration induced by curing shrinkage during the manufacturing of epoxy resin is a primary trigger for micro-nano defect formation and electrical performance degradation in power equipment. To address the computational complexity of traditional viscoelastic models and the thermoelastic behavior wherein the stiffness of the epoxy resin varies with temperature during curing, this paper proposes an improved viscoelastic constitutive model incorporating a thermo-elastic factor. By coupling curing kinetics, heat conduction, chemical shrinkage, and mechanical effects, a multi-physics simulation framework is constructed to describe the complete epoxy curing process, thereby revealing the spatiotemporal evolution of curing stress deformation. To verify the model’s accuracy, an in situ monitoring system based on Fiber Bragg Grating (FBG) sensors was established. A temperature compensation method was utilized to effectively decouple temperature and stress within the complex exothermic curing environment. This study reveals a significant strain gradient effect during the resin curing process. Experimental measurements indicate strains of 21,609 με and 5800 με at the interface and surface, respectively, with numerical simulations exhibiting high agreement with the experimental data. This research not only provides an efficient simulation approach for predicting curing stress but also offers a theoretical basis for the crack-resistant structural design of high-performance epoxy-based power equipment. Full article

Facing the challenges in field monitoring of the mechanical response of geogrids in asphalt pavements, this study integrated two types of Fiber Bragg Grating (FBG) sensors, unarmored and armored, into geogrids using the pillar-stitching technique on industrial warp-knitting production lines. The integrated FBG-geogrid systems were comprehensively evaluated in both wound and flattened configurations, enabling the selection of a sensor type suitable for industrial production. After precise strain calibration, a full-scale field damage test was performed during the construction of the Qu-Gang Expressway in Hebei Province, China. The results demonstrate that the helical steel armor layer significantly enhances the mechanical durability of the FBG sensor. Specifically, the armored sensor maintained stable optical transmission over its entire 60-m length, with an average performance retention rate of 98.86% in the flattened state. Moreover, a strong linear correlation was established between the wavelength shift of the armored FBG sensor and the tensile strain of the geogrids. In contrast, the unarmored FBG sensor underwent irreversible shear deformation during production and contained at least two breakpoints. Additionally, a protection scheme employing fiberglass-reinforced silicone rubber on the hot side and standard silicone rubber on the cold side effectively shielded the sensors from high-temperature and compaction loads during asphalt paving. Consequently, the proposed FBG-geogrid integration method and the corresponding field protection strategy provide technical support for the real-time monitoring of geogrid performance in asphalt pavements and have significant engineering value. Full article

The increasing complexity and extended operational lifetimes of modern space infrastructure have significantly intensified the demand for reliable structural health monitoring (SHM) systems. However, the extreme space environment, characterized by radiation exposure, microgravity, ultra-high vacuum, and severe thermal cycling, imposes critical limitations on conventional electrical sensing technologies, leading to reduced measurement accuracy, instability, and long-term degradation. This review presents a comprehensive analysis of fiber Bragg grating (FBG)-based sensing technologies as a promising solution for deformation monitoring in space infrastructure. The study investigates the fundamental operating principles of FBG sensors under space conditions and systematically classifies existing FBG-based SHM architectures, including point-based, multiplexed, long-distance, and hybrid sensing systems. Furthermore, the advantages of FBG sensors—such as immunity to electromagnetic interference, passive operation, and high-resolution multipoint sensing—are critically evaluated in comparison with traditional electrical sensors. In addition, key challenges affecting the performance of FBG systems in space environments are analyzed, including radiation-induced wavelength drift, temperature–strain cross-sensitivity, signal attenuation, and long-term stability issues. The paper also highlights recent advances in interrogation techniques and network architectures that enable reliable in situ and real-time deformation monitoring of space structures. The results demonstrate that FBG-based sensing systems provide a scalable and robust framework for SHM in extreme environments while also revealing existing limitations and open research challenges. This work establishes a structured foundation for the development of next-generation intelligent monitoring systems for space infrastructure. Full article

Single-frequency fiber lasers (SFFLs) are essential for applications such as gravitational wave detection, high-precision spectroscopy, and inertial confinement fusion, requiring narrow linewidth, low noise, and high output power. Here, we present a comparative study of 1 μm waveband distributed Bragg reflector (DBR) SFFLs with varying cavity parameters. Numerically, we investigate the effects of key cavity parameters on laser performance by plotting contour maps of output power versus grating reflectivity and lasing wavelength. We also simulate intensity noise transfer functions from pump fluctuations. Increasing pump power shifts the relaxation oscillation peak to higher frequency and reduces its amplitude, which originates from the higher intracavity photon density that speeds up the damping of perturbations. Experimentally, we construct two lasers using 6.5 mm and 10.5 mm YDFs spliced between FBG pairs. These lasers employ low-reflectivity FBGs centered at 1053 nm and 1064 nm, with reflectivities of 74% and 55%, respectively. The corresponding maximum output powers are 29.7 mW and 197 mW. The 1053 nm SFFL exhibits a relative intensity noise (RIN) of −102 dBc/Hz at 2.07 MHz, a linewidth of 12.52 kHz, and a mode-hop-free tuning range of 0.64 nm. Although increasing the pump power suppresses the relaxation oscillation peak, it broadens the linewidth due to laser phase noise degradation caused by pump noise-induced temperature fluctuations in the gain fiber. For SFFLs, the output powers should be selected according to the specific application, as a higher output power inherently leads to a broader linewidth. These insights are essential for optimizing such lasers and underscore their strong potential for future applications. Full article

A 70 MPa Type IV hydrogen composite pressure vessel (CPV) was instrumented with embedded Fiber Bragg Grating (FBG) sensors to realize in situ strain monitoring during hydraulic fatigue cycles. FBG arrays were co-wound with carbon fibers during the filament winding process, forming an integrated multi-point sensing network within the composite layers. Hydraulic fatigue tests were conducted under pressure cycling between 2 MPa and 87.5 MPa, reaching 48,000 cycles. The embedded FBG sensors were able to stably record cyclic strain evolution with peak amplitudes of approximately 6000 με in the hoop layer and 3500 με in the helical layer under hydraulic cycling. The hoop layers exhibited gradually decreasing strain amplitudes from the inner to outer regions, while the helical layer maintained stable signal performance. Analysis of fiber survival times indicated that the FBGs embedded in helical layers remained functional throughout the entire test, confirming the long-term monitoring capability under high-pressure oil environments. This study demonstrates a practical embedded-sensing approach compatible with the filament-winding process, providing experimental support for fatigue-life evaluation and in-service safety monitoring of high-pressure hydrogen storage vessels. Full article

Accurate impact localization on spacecraft structural panels subjected to contact loading by on-orbit servicing robots is critical for real-time structural health monitoring (SHM), yet remains challenging due to heterogeneous elastic wave propagation in complex aluminum structures with stiffener ribs and bonded joints. Conventional Received Signal Strength Indicator (RSSI)-based weighted centroid methods rely on fixed path-loss exponents that cannot accommodate spatially varying wave attenuation, resulting in position-dependent localization errors that worsen significantly near structural discontinuities. This paper proposes a Crow Search Algorithm (CSA)-optimized adaptive weighted centroid algorithm using distributed Fiber Bragg Grating (FBG) sensors, featuring three principal innovations: (i) a novel FBG wavelength-shift-to-RSSI amplitude mapping derived from elastic wave attenuation theory, bridging optical fiber sensing with centroid localization; (ii) per-event online weight optimization via CSA that adapts sensor contributions to each individual impact’s strain-wave signature; and (iii) a multi-objective fitness function simultaneously optimizing localization accuracy, noise robustness, and temporal consistency. The proposed method is validated across 200 impact events distributed over five representative positions on a 1 m³ Al6061 satellite-like structure with 64 FBG sensors (8 × 8 grid, 125 mm pitch), under three Gaussian noise levels (σ = 1%, 3%, 5% of signal RMS), and benchmarked against classical weighted centroid (WC), PSO-WC, GA-WC, DE-WC, and GWO-WC using paired t-tests (p < 0.01). CSA-WC achieves a mean localization error of 4.63 mm—an 83.29% improvement over classical WC and the lowest error among all five compared algorithms—with an average computation time of 0.14 s per event, satisfying real-time monitoring requirements. Full article

Tube boilers are extensively employed in oil and gas refineries, as well as in petroleum, energy, and power generation industries, where they serve critical functions in local steam-generation units and combined-cycle gas turbine (CCGT) plants. However, these boilers are prone to defects arising from waterside corrosion (e.g., thinning of U-bend tubes), fireside corrosion, and material degradation caused by stress or creeping. Among these issues, wall thinning of tube bends is particularly severe, as it results in localized metal loss, reduced structural integrity, and an elevated risk of tube rupture or failure under high-temperature and high-pressure operating conditions. Such failures can significantly compromise boiler safety and efficiency, potentially leading to forced outages, costly unplanned repairs, or catastrophic damage if not detected in time. The current condition-monitoring policy for U-bends relies on scheduled preventive maintenance and unscheduled corrective interventions. In practice, this involves randomly checking approximately 10–20% of the tubes through spot scanning, partial scanning, or full scanning, with repairs typically carried out only after an undetected failure occurs. Such maintenance strategies generally require plant shutdowns, making the process time-consuming, labor-intensive, and ultimately not cost-effective. This paper reviews existing solutions, technologies, and research addressing the problem, and introduces femtosecond laser micromachined fiber optic sensors as a transformative approach for real-time monitoring of wall thickness reduction in U-bend boiler tubes, thereby opening pathways for further research. Full article

Background/Objectives: Type 2 diabetes mellitus (T2-DM) is a continuing national and global health challenge. Retinoic acid (RA), the major transcription-regulating ligand, plays a critical role in energy metabolism, and pancreatic β-cell homeostasis. However, human data linking circulating RA levels to T2-DM and its clinical outcomes are sparse and inconsistent. In this ethically approved cross-sectional study of consented hospital-diagnosed adult T2-DM patients (n = 292) and matched healthy controls (n = 64), variation in plasma RA levels and its relationship with disease and patient characteristics were investigated. Methods: RA concentrations assayed via specific ELISA were related to glycemic control indices [fasting blood glucose (FBG) and HbA1c], the triglyceride–glucose ratio for insulin resistance (TyG-IR), treatment modalities, and complications derived from patients’ medical records. Results: RA concentrations were substantially lower in patients with T2-DM (mean ± SD 2.63 ± 1.54 ng/mL) than in controls (5.21 ± 4.3 ng/mL; p < 0.001). Within the diabetic cohort, RA was inversely correlated with indices of glycemic dysregulation and insulin resistance. Plasma RA exhibited strong discriminatory performance for distinguishing diabetic patients from healthy adults. Its AUC is 0.870 (p < 0.0001 and 95% CI = 0.832–0.902) with a sensitivity of 79.7% and a specificity of 81.3%, at an optimal cutoff of ≤3.061 ng/mL. Conclusions: Circulating RA is associated with metabolic perturbations that define T2-DM, and therefore is promising as a clinically useful biomarker. It may reflect pathophysiological processes linking nutrient signaling, energy handling and β-cell function in T2-DM that merit further evaluation. Full article

Reliable detection of internal defects in pressure vessel structures remains essential for structural safety and condition-based maintenance. This study presents a low-complexity structural health monitoring framework based on fiber Bragg grating (FBG) sensing and multiresolution wavelet analysis for void detection in curved pressure vessel structures under guided wave excitation. Guided waves are introduced using piezoelectric actuators, while the FBG sensors capture the resulting strain-induced wavelength variations. Due to the limited bandwidth of the optical interrogator, the recorded signals represent the strain envelope response associated with guided wave interaction rather than the resolved ultrasonic carrier waveform. To characterize defect-induced changes, the acquired signals are analyzed using continuous wavelet transform (CWT) for time–frequency interpretation, and discrete wavelet transform (DWT) and wavelet packet transform (WPT) for energy-based multiresolution feature extraction. Experimental results show that void defects lead to consistent redistribution of wavelet-domain energy and increased non-stationarity in the measured strain responses. These trends are further supported by finite-element simulations, which reproduce similar energy redistribution patterns between intact and damaged cases. The proposed framework provides a physically interpretable and computationally efficient approach for defect detection using low-bandwidth FBG sensing, without reliance on high-speed acquisition or data-intensive learning models. The results demonstrate the feasibility of using energy-based multiresolution analysis of FBG strain signals for practical and scalable structural health monitoring of pressure vessel systems. Full article

Spectral interrogation of fiber Bragg gratings (FBGs) in the ~850 nm band remains relatively uncommon, largely due to the limited availability of commercial instruments and the restricted applicability of conventional interrogation schemes in this wavelength range. This work presents a practical and high-precision wavelength demodulation method for 850 nm FBG sensing based on an imaging Charge-Coupled Device (CCD) spectrometer. A Czerny–Turner (C–T) optical configuration is employed for spatial spectral dispersion, and the optical system is theoretically analyzed and optimized using ZEMAX to balance spectral resolution, optical throughput, and compactness. A polynomial wavelength–pixel calibration model is established, and Gaussian fitting is adopted for robust peak-position extraction under multimode fiber conditions. Experimental validation is carried out using four serially cascaded FBGs distributed over 830–880 nm. The wavelength–pixel calibration yields an RMS residual of 0.46 nm. Within a strain range of 0–2000 με, the average wavelength demodulation bias of a single FBG is 6.8 pm, with a wavelength demodulation RMS error of 86.9 pm and a measured strain sensitivity of 0.72 pm/με. The results demonstrate that the proposed CCD-based imaging interrogation scheme is feasible for 850 nm FBG sensing and enables accurate wavelength demodulation in this relatively underexplored band. Since the system is implemented using standard off-the-shelf components, it also provides a practical technical route for the deployment of FBG sensing systems in engineering applications. Full article

Accurately and promptly acquiring the load history characteristics of impact events on composite aircraft structures is crucial for identifying impact-induced damage and developing high-fidelity digital twin models. To address this need, we propose a method for reconstructing the impact load history on composite structures, leveraging Generalized Cross-Validation (GCV) and a Fiber Bragg Grating (FBG) pattern. An equivalent expansion technique based on discretized time-domain sparse strain sampling is developed to mitigate the local distortion of impact response signals, a common issue arising from the low sampling rates of quasi-distributed FBG. By incorporating Tikhonov regularization, the ill-posed nature of the impact frequency response matrix is effectively managed. Furthermore, an adaptive optimization method based on the GCV criterion is introduced to overcome the limitations of manually selecting regularization parameters and the associated constraints on noise suppression. The results show that the proposed GCV-based reconstruction method achieves an average peak relative error of 11.4% and an average root mean square error of 0.36 N for the reconstructed impact load, demonstrating that the proposed method synergistically enhances both the reconstruction of the overall impact load waveform profile and the precise characterization of transient details, even with low-rate sampling. This provides robust technical support for health monitoring and condition-based maintenance of composite structures. Full article

Reliable in situ temperature monitoring is essential for the safe operation of liquid-nitrogen-cooled superconducting cables, yet conventional electrical sensors are often difficult to scale to multi-point deployment in cryogenic, high-current environments. This work presents a fiber Bragg grating (FBG) sensing solution for in situ temperature monitoring of superconducting cables in liquid nitrogen. An FBG array packaged with a polyimide-coated fiber inside a 3 mm stainless-steel tube is deployed along the cable centerline to provide multi-point temperature measurements of the cable core. The system is validated under liquid-nitrogen immersion with a 2000 A current turn-on/turn-off test, with a 1 Hz update rate and a steady-state temperature fluctuation within ±0.1 °C. Experimental results show a continuous temperature decrease during liquid-nitrogen cooling, followed by a cryogenic plateau, during which a spatially consistent 0.6–0.7 °C current-induced temperature rise is observed across multiple sensing points in the present 2000 A turn-on/turn-off test, followed by recovery after current shutoff. Small-amplitude fluctuations during the plateau are attributed to packaging-dependent thermal coupling between the centerline-deployed sensor and the cable core. These results indicate that the proposed FBG-based approach enables reliable cryogenic thermometry for superconducting cables in liquid nitrogen and provides a practical tool for in situ operational condition assessment. Full article

In this paper, we propose a high-sensitivity fiber Bragg grating (FBG) pressure sensor based on an X-shaped mechanical transducer that converts external pressure into predominantly axial strain, thereby helping to alleviate bending-dominant spectral distortion and improve measurement stability. A theoretical model is developed to describe the relationship between applied force, pressure, and grating wavelength shift. Experimental optimization was conducted by varying Ethylene Propylene Diene Monomer (EPDM) thickness, bonding materials, and contact area to achieve sensitivities of 0.291 nm/N, 0.409 nm/N, and 0.462 nm/N, respectively, within the investigated force range of 0–10 N. For measuring the under water pressure, the sensor exhibits a high sensitivity of 0.596 nm/kPa within the investigated pressure range of 0–6 kPa. The results demonstrate the nice sensing performance with high sensitivity, good linearity, and excellent repeatability. This work provides an effective approach for high-performance FBG-based pressure sensing in underwater and harsh environments. Full article

The determination of the arc rating of arc-resistant materials for the manufacture of personal protective clothing is conducted by measuring the incident and transmitted energies through calorimetry using thermocouples coupled to copper discs during the electric arc events. In this study, custom calorimeters were constructed by incorporating both a thermocouple wire and an embedded optical-fiber temperature sensor, and the arc ratings of different fabrics were determined in terms of their arc-thermal-performance value (ATPV). The results revealed differences between the measurements obtained with the two sensor types. Notably, the absence of electromagnetic interferences generated by the arc current and the enhanced time response achieved with the optical-fiber temperature sensor signal led to an ATPV arc rating approximately 27% lower than that measured with the thermocouple. These findings underscore the importance of investigating the current methodology used for determining arc ratings to ensure accurate measurement of incident and transmitted energy. Full article

Wearable data gloves often suffer from electromagnetic interference, insufficient substrate stability, and limited capability for multi-degree-of-freedom motion measurement. To address these limitations, a flexible glove incorporating a hybrid POF-FBG sensing scheme was designed and fabricated. Plastic optical fibers (POFs) were side-polished and patterned with long-period gratings to improve sensitivity to wrist flexion-extension and abduction-adduction. Then fiber Bragg gratings (FBGs) were embedded in a polydimethylsiloxane substrate and encapsulated using thermoplastic polyurethane fixtures to reduce the influence of skin stretching and improve measurement accuracy of finger-joint angle. Moreover, a thermoplastic polyurethane skeleton with an adaptive sliding-rail structure was 3D printed to maintain the stability of the sensor placement at the joints. Experimental results demonstrated the mean absolute errors of 4.06°, 1.38° and 1.70° for wrist flexion-extension, abduction-adduction and finger-joint bending, respectively, along with excellent gesture classification using a support vector machine algorithm, which indicates great potential in virtual reality interaction and hand rehabilitation applications. Full article
