Accurate, simple, cost-effective, and non-destructive estimation of heartwood content is essential for the sustainable management and commercial valuation of Pterocarpus santalinus L.f. (red sanders), one of the world’s most valuable tropical timber species. Conventional methods for heartwood assessment, including increment coring and destructive sampling, are invasive, time-consuming, and unsuitable for large-scale field applications. Electrical Resistance Tomography (ERT) offers a promising alternative by exploiting differences in electrical resistivity associated with variations in wood moisture content and anatomical characteristics. The present study standardized the application of ERT for the identification and quantification of heartwood in standing red sanders trees and validated its performance against conventional core sampling. Fifty-eight trees representing two diameter classes (10–20 cm and 20–30 cm) were evaluated using a PiCUS TreeTronic Electrical Resistance Tomograph, followed by increment core extraction at breast height for validation. Distinct resistivity gradients were observed, with higher electrical resistivity in the central heartwood region and lower resistivity in the peripheral sapwood. The resistivity values ranged from 153 to 1031 Ω in trees with diameters of 10–20 cm and from 342 to 1444 Ω in trees with diameters of 20–30 cm. Linear regression analysis showed excellent agreement between ERT-estimated and measured heartwood diameters (R² = 0.98), with an average similarity of 91.5%. The observed resistivity distribution closely reflected variations in moisture content, wood density, and anatomical structure across the stem radius. The findings demonstrate that ERT is a reliable and non-destructive technique for estimating heartwood content in standing red sanders trees. These results demonstrate that ERT can accurately estimate heartwood dimensions in standing Pterocarpus santalinus trees under the conditions of the present study and provide a reliable approach for non-destructive assessment of heartwood in this species. The technique has considerable potential for timber valuation, harvest planning, tree breeding, forest inventory, and conservation programs involving high-value tropical hardwood species. Full article

Field tests were conducted at a heterogeneous industrial site using one circulation well and six monitoring wells. Groundwater circulation well (GCW) extraction–injection (30 d), multi-component tracing (6 h), and circulation–oxidation (20 h) tests were performed to investigate the flow-field characteristics and their influence on multi-component solute transport. The results suggested that the extraction–injection circulation mode increased the flow rate of the single well from 0.5 m³/h to 3.5 m³/h, establishing a composite flow field with near-field circulation and far-field outward expansion. Short-term circulation achieved limited concentration attenuation primarily near the well with rebound. Long-term circulation elevated the average concentration attenuation rates of benzene from 13% in the short-term test to 61%, and chemical oxygen demand (COD) from 16% to 47%, expanding the remediation scope of the circulation well. Bromide tracer tests and an advection–dispersion equation characterized the heterogeneous flow field with preferential flow channels and slow migration zones. Furthermore, sulfate tracer transport was governed by adsorptive retardation and advective delivery. Circulation–oxidation tests showed that benzene and COD showed higher concentration attenuation than naphthalene. After cessation, benzene and COD concentration attenuation rates increased by 39% and 29% compared to the short-term test without oxidation. Electrical resistivity tomography (ERT) revealed the downward diffusion of the oxidant, suggesting that the circulation well system enhances oxidant transport and expands the oxidant-affected zone. This research provides field-scale diagnostic evidence and in situ diagnostic methodologies for GCW remediation at complex contaminated sites. Full article

This study presents and evaluates a system-level optimization of an electrical resistance tomography (ERT) measurement platform based on a ZYNQ-7020 all-programmable system-on-chip (APS-SoC). The design combines deterministic programmable-logic (PL) acquisition, processing-system (PS) configuration and communication scheduling, AXI/DMA data movement, Gigabit Ethernet transmission, and a seventh-order Butterworth excitation filter. FFT-based amplitude extraction and Tikhonov reconstruction remain on the host computer so that the reconstruction algorithm and regularization settings remain identical for the baseline and proposed systems; the present prototype is therefore not claimed as a fully standalone smart sensor. Under the same 16-electrode tap-water testing configuration, the average frame rate increased from 58.23 ± 1.88 FPS to 123.02 ± 1.62 FPS (mean ± sample standard deviation, n = 10), end-to-end latency decreased from 5.2 ms to 2.1 ms, SFDR increased from 68 dB to 95 dB, and SSIM increased from 0.72 to 0.94. In one representative static hardware record at 160 kHz, the calculated amplitude-stability SNR values were 65 dB and 100 dB for the baseline and proposed excitation paths, respectively, while total harmonic distortion decreased from 15.2% to 7.5%. These single-condition signal quality values are descriptive rather than uncertainty-bounded performance specifications. The image-quality differences are attributed primarily to cleaner boundary-voltage measurements with an unchanged reconstruction method, whereas the frame-rate gain reflects the combined PL/PS data path and Gigabit Ethernet upgrade. Full article

The Raša Fault is a prominent seismically active strike-slip fault within the Dinaric Fault System in SW Slovenia, seismotectonically estimated to be capable of producing earthquakes up to Mw = 7.4. Since the surface exposure of fault-related markers is discontinuous, and the near-surface expression of deformation is poorly constrained, there is a need to improve the detection of fault-related features in complex sedimentary environments. In such settings, signal attenuation, complex stratigraphy, and irregular fault-zone geometries often obscure subtle deformation features, limiting the interpretability of standard 2-D geophysical profiles. A pseudo 3-D Ground-Penetrating Radar (GPR) survey, along with complementary Electrical Resistivity Tomography (ERT) surveys and reprocessing of LiDAR (light detection and ranging) data to obtain high-resolution Digital Elevation Models (DEMs), was conducted in selected environments dominated by low-resistivity karstic deposits and highly heterogeneous fluvial sediments to assess and improve the capability to detect and characterize subtle shallow deformations associated with the Raša Fault. Tectonic geomorphological mapping facilitated the recognition of potentially active fault traces and the identification of Quaternary sedimentary and erosional features, where recent deformations are usually preserved and can be dated in further paleoseismological investigations. The analysis of dense GPR data and complementary ERT profiles enabled us to clearly image the fault deformation pattern and obtain quantitative information about the subsurface, showing details of faulting and related deformation structures not evident at the surface. Furthermore, it enabled the detection of fault zone complexity, revealing it as an irregular and laterally changing area with sediment infillings, rather than a single vertical discontinuity. The complexity of faulting in the near surface depends on many factors, including the competence and age of the faulted material, as well as the local geomorphology. This study has demonstrated the applicability of pseudo 3-D GPR surveying, combined with ERT profiles, for subsurface mapping of active strike-slip faults in karstic and fluvial sedimentary environments. The methodology can be recommended in particular for rapid and cost-effective investigation of sites with subtle surface evidence of active faulting in order to determine near-surface fault splaying. Full article

The Mao open-pit coal mine waste dump in Hequ, Shanxi, is a loose, anthropogenic mass accumulated over the original topography. Following a recent sliding and significant settlement event, this dump became the subject of intense stability concerns. Due to the high moisture sensitivity of its interlayered soil and coal gangue structure, rainfall infiltration can reduce internal effective stress, triggering slope instability. Although conventional geological surveys have mapped surface fractures, implementing precise, targeted drainage control requires characterizing the internal geometric structure and preferred seepage directions. To address this, this study integrates electrical resistivity tomography (ERT), surface nuclear magnetic resonance (SNMR), and spontaneous potential (SP) methods. Multiple ERT profiles (270–600 m long) were deployed across several benches at varying elevations, supplemented by fixed-point SNMR sounding over typical low-resistivity anomalies and dense SP grid scanning. The integrated results successfully delineate the internal architecture and seepage characteristics of the dump. Specifically, ERT imaging resolves the primary geoelectrical interface (tentatively inferred as the potential sliding surface) separating the overlying loose mass from the stable underlying strata while mapping the spatial extent of the inferred water accumulation zone (IWAZ). SNMR sounding quantitatively reveals a two-layer water-bearing structure at the specific sounding site, with a deep primary water-bearing zone at 45–80 m depth. Furthermore, SP inversions illuminate the seepage process, demonstrating that meteoric water deflects along the geoelectrical interface to converge laterally toward the central axis at approximately 42°, before transitioning into a high-angle vertical deep infiltration zone (61.7°) within the axial region. These findings suggest a potential engineering direction for remediating surficial fractures and designing subsurface drainage along this 1040 m bench axis, which would mitigate future landslide risks by reducing internal pore water pressure. Full article

Ion-adsorption rare earth deposits (IADs) constitute the primary global source of medium-to-heavy rare earth elements. The sustainable exploitation of these resources hinges on the precise characterization of the weathered crust architecture and its hydrogeological properties. Conventional drilling often fails to resolve the complex vertical heterogeneity of regolith profiles, thereby limiting orebody delineation and the optimization of in situ leaching (ISL). To address this, this study integrates Electrical Resistivity Tomography (ERT) with Archie’s Law and the Kozeny–Carman equation. Focusing on the YZK1 and YZK2 survey lines in the Dabu mining area, southern Jiangxi, we derived 2D distributions of porosity and permeability from resistivity inversions. Our results delineate the weathered crust into four distinct vertical strata: a surface accumulation layer, a completely-to-highly weathered granite layer, a moderately-to-slightly weathered layer, and fresh bedrock. Quantitatively, the completely-to-highly weathered layer exhibits a “low resistivity (10–700 Ω·m)–high porosity (8.7%–17%)–high permeability (0.04–1.2 mD)” mode, serving as the primary leachable reservoir. In contrast, the surface and moderately weathered layers display “high resistivity (>800 Ω·m)–low porosity (3.4%–6.4%)–low permeability (0.01–0.04 mD)” characteristics. Crucially, although the fractured bedrock zones on both YZK1 and YZK2 profiles exhibit similar absolute permeability values (~0.016 mD), they represent two distinct hydraulic architectures. On the YZK1 profile, the fractured zone acts as a relatively homogeneous potential leakage pathway. Conversely, the YZK2 profile displays significant vertical segmentation: the upper and lower margins function as permeable pathways, while the central core, likely infilled with fault gouge, acts as a sealing zone that impedes fluid flow. Consequently, resistivity data alone are insufficient to accurately assess hydraulic conductivity; joint interpretation incorporating both permeability and porosity is essential to definitively determine whether a fault zone acts as a “conduit” or a “barrier.” By transitioning from qualitative imaging to quantitative parameter evaluation, this study provides a robust technical paradigm for fine-scale exploration and ISL optimization in IADs. Full article

The presence of near-surface cavities poses a significant geohazard due to potential ground subsidence and structural collapse. To mitigate threats to urban stability, this study presents an integrated geophysical framework to locate and characterize abandoned mining galleries and exploitation voids near Linares (Jaén, Spain). The approach combines four complementary techniques: electrical resistivity tomography (ERT), ground-penetrating radar (GPR), frequency-domain electromagnetics (FDEM), and microgravity. The resulting multi-physics responses were cross-referenced with visible surface subsidence features and archival mine plans. Air-filled galleries and shafts generated highly pronounced high-resistivity anomalies. Shallow voids detected at depths of 2–5 m were undocumented in 19th-century mining maps, suggesting older historical origins, whereas deeper ERT profiles and structural disturbance trends (up to 30 m) correlated well with historical records. Within this framework, FDEM provided high-resolution lateral mapping, GPR excelled at resolving ultra-shallow structural boundaries, and ERT characterized deep gallery networks. Crucially, microgravity mitigated inversion non-uniqueness by directly confirming physical mass deficits over the anomalies. This integrated workflow overcomes individual resolution limits, offering a practical tool for land-use planning and early geohazard risk assessment in collapse-susceptible areas. Full article

Ground-penetrating radar (GPR) and electrical resistivity tomography (ERT) are physically complementary non-destructive evaluation methods for reinforced concrete, yet their integrated diagnostic use has been limited by the absence of controlled, ground-truth-validated calibration of the joint-signature space. This paper presents a laboratory calibration programme in which a single C30/37 reinforced concrete beam (3000 mm × 300 mm × 200 mm, three T12 bars at 35 mm cover, CEM I 42.5N, w/c = 0.50) was sequentially conditioned through four controlled deterioration states—intact reference (Model A), water-filled saw-cut crack (Model B), full saturation by seven-day top-surface ponding (Model C), and chloride-induced active corrosion (Model D). Seven RES2DINV inverted ERT sections at three electrode spacings (a = 7, 15, and 30 mm) and three 800 MHz GPR profiles were acquired across the four known ground-truth conditions. The intact-reference resistivity ρ₀ = 558 Ω·m (full-section median of the mlab dataset at a = 7 mm) and GPR-calibrated velocity v = 0.095 ± 0.008 m/ns (from hyperbola fitting at 35 mm rebar cover) establish the absolute baselines. The four conditions produce systematically distinct joint signatures: Model A exhibits uniform high resistivity with clean rebar hyperbolae and no anomalous reflections; Model B produces a localised ERT low-ρ anomaly (ρ_min = 1.46 Ω·m) co-located with a negative-polarity (R = −0.68) GPR crack-mouth reflection confirming water-fill; Model C produces pervasive low-ρ with a smooth depth gradient and 50–65% GPR amplitude attenuation (−6.0 to −9.1 dB); Model D produces the same bulk GPR signatures as Model C but with a critically different ERT spatial texture—a heterogeneous near-surface layer above a sharp boundary at z ≈ 40 mm with depth-preferential low-ρ concentrated at rebar level. This depth-preferential signature, quantified here by a reproducible Depth-Preferential Index (DPI), is the primary ERT-only diagnostic criterion distinguishing active corrosion from pervasive saturation. For the Model C versus Model D distinction, the GPR response is non-discriminating; this high-risk distinction is resolved exclusively by the ERT depth-preferential criterion. The calibration demonstrates that GPR and ERT are physically non-redundant in the strict sense: neither method alone can unambiguously discriminate all four states, but their combination yields correct classification within the controlled laboratory conditions and subject to the stated qualification conditions. The corrosion state was confirmed at the regime level (chloride above the depassivation threshold, under accelerated polarisation) but was not quantified electrochemically, so the depth-preferential signature is interpreted as an indirect spatial proxy for active corrosion rather than a measurement of corrosion rate. Seven failure modes are quantitatively characterised and embedded in the framework as a priori qualification conditions. The calibrated reference values (ρ₀, A₀, Stage 2 thresholds, depth-preferential criterion) are specific to the laboratory mix and curing history and require local Stage 1 recalibration for field application. Full article

Pumped-storage hydropower (PSH) remains the main grid-scale energy storage technology in Europe, yet much of the fleet is ageing and requires periodic verification against current geotechnical standards. The Dychów plant (88 MW, western Poland), in service since the 1930s and classified as national critical energy infrastructure, has a documented history of surface mass movements, including a 1997 landslide on the frontal dam. To reassess its condition, two earthen sections were analysed: lateral section of the frontal dam of the upper reservoir and the embankment of the derivation channel. Electrical resistivity tomography (ERT) profiles, measured using a gradient array in 2023 and further detailed in 2024 along the same GNSS-fixed lines, imaged the internal structure of both sections. The resistivity cross-sections, verified against shallow control boreholes and archival geological data, supplied the geometry of the finite-element (FEM) models in ZSoil: the confirmed layer boundaries became the material zones, and piezometric observations set the groundwater boundary conditions. The safety factor SF was then computed with the shear-strength reduction technique for four calculation variants and two groundwater scenarios per section. The resulting SF equals 1.75 for the side section of the frontal dam area and ranges from 1.80 to 2.10 for the channel embankment. A parametric reduction in the friction angle of saturated medium sand gives limit values of φ = 12.3° (dam) and φ = 20.3° (embankment), which are clearly below realistic in situ values. Overall, both structures meet the SF ≥ 1.50 requirement for Class I hydraulic structures. The ERT-to-FEM workflow offers a non-invasive and repeatable tool for the periodic reassessment of ageing PSH infrastructure, which continues to balance variable renewable generation. Full article

The phreatic surface and seepage field are key factors causing instability in tailings storage facilities (TSFs). In this study, electrical resistivity tomography (ERT) was used to determine the internal structure and phreatic surface of the TSF of Husab Mine. The seepage pathways at the southeast and northwest corners of the TSF were identified and the seepage mechanisms were analyzed. In order to discharge the slurry, outlets equipped with valves were installed on the tailings embankment. During the deposition process, time-lapse electrical resistivity tomography (TL-ERT) was conducted to monitor the infiltration of water around the W13 outlet. The results show that the tailings sediments were divided into three layers based on resistivity values. The top layer consisted of shallow, unsaturated tailings material, while the middle layer comprised saturated tailings material. The thickness of the saturated zone gradually increased from the dam toward the decant pool. The bottom layer consisted of the geomembrane liner and natural sediments. Two seepage locations, named the Lebusa corner and Alister corner, were located at the southeast and northwest corners of the TSF, respectively. Seepage occurred because clarified water originating from the decant pool migrated through the saturated zone of the tailings pond, along the base of the tailings embankment. Upon encountering the starter dam, the water was impeded and subsequently emerged as seepage at the junction between the starter dam and the tailings embankment. TL-ERT monitoring shows that the extent of increased moisture was approximately 60 m horizontally and roughly 10 m vertically due to deposition at the W13 outlet. Full article

Water scarcity in Chile has been exacerbated by a decline in precipitation and an increase in water demand. This has prompted a search for strategies to increase water supply, whether through aquifer recharge or reservoir construction. In this study, aquifer recharge was evaluated through rainwater harvesting systems (RWHS) and direct injection into rural wells in the Ñuble Region. Three wells were selected in the Ñuble Region (Ñiquén, San Carlos, and Coihueco) using hydrogeological and operational criteria. To characterize the hydrogeology of the area, local piezometric data, geophysical surveys using electrical resistivity tomography (ERT), and seismoelectric tests were considered. This enabled the identification of aquifers with water levels between 2.6 and 23 m depth across the different geological units of the territory. The hydrological design was based on a frequency analysis of annual precipitation (1991–2020), which yielded design rainfall values between 442 and 694 mm. The implemented RWHS demonstrated injection capacities between 0.9 and 1.4 L·s⁻¹. The results show that rainwater harvesting combined with direct aquifer recharge represents a viable alternative for improving water security, with potential for territorial scaling through regional public policies. Full article

Concealed shallow karst along long-distance pipeline corridors can trigger subsidence, uneven settlement, and leakage, creating environmental and infrastructure hazards. In the Huyuanxi area (Fuyang District, Hangzhou, Zhejiang, China), strong electromagnetic interference and limited site access motivated an integrated electrical resistivity tomography (ERT) plus ambient-noise microtremor (SPAC) workflow for shallow-karst screening. Three ERT lines (900 m each) were deployed along the pipeline axis and at ±15 m offsets with 10 m spacing using a WDJD-4 system (100 V constant-voltage; Wenner array, 30 layers), followed by resistivity inversion; Res2Dinv v3.65 was adopted as the inversion software. The L2 norm was selected for the objective function, and the error model was set to the default error floor plus 5%. The regularization parameter was set as λ = 0.01, and adaptive gridding was used for the mesh with a minimum cell size of 0.5 m × 0.5 m. The number of iterations was set to 15, with a final root mean square (RMS) misfit of 3.2%. The depth of investigation (DOI) was calculated via the built-in algorithm of the software, yielding a maximum value of 30 m. Low-resistivity anomalies were used to focus eight perpendicular microtremor profiles (3 m spacing) acquired with SmartSolo IGU-16HR 1C and 10 geophones (5 Hz; 1 ms sampling interval) in a nested SPAC array (0.5/1/2 m radii); processing removed segments with SNR < 3 and inverted 2-D Vs structure by damped least-squares. Resistivity sections show 50–8600 Ω·m near surface, including a <100 Ω·m fracture-zone anomaly (28–30 m wide; 8–18 m depth) and a cavity-zone anomaly (55–70 m wide; 10–20 m depth). Joint interpretation places karst development mainly at 10–25 m depth near the bedrock–cover interface (~16 m). At HYXK3, microtremor versus shear-wave logging yielded a void-layer bottom depth of 21.28 m versus 20.12 m (5.76% error) and Vs of 457 versus 446 m/s (2.40% error). Example profiles show microtremor-derived depths (18.3/14.5/18.7 m) consistent with ERT (16.8/15.1/19.5 m; 4.1–8.1% errors). Drilling verification accuracy was approximately 81.7%, precision approximately 90%, recall approximately 74.0%, and the F1-score 81.1% supporting practical corridor risk screening under complex field constraints. Full article

Accurate characterization of subsurface stratigraphy is essential for reliable landslide stability assessment. However, stratigraphic models constructed solely from sparse borehole data are often constrained by incomplete spatial coverage and substantial interpretive uncertainty. To address this issue, this study developed an integrated probabilistic stratigraphic modeling framework that combines borehole data with electrical resistivity tomography (ERT) data. In the proposed framework, borehole logs provide direct lithological labels and spatial prior information, while the inverted ERT resistivity profile is introduced as a continuous geophysical constraint. Specifically, logarithmic resistivity and the borehole-derived expected stratigraphic configuration were combined into a support vector machine classifier to establish a nonlinear mapping between geophysical responses and stratigraphic categories. A bootstrapping strategy was also used to quantify the stratigraphic uncertainty. The proposed method was then applied to the Panzhuangzu Landslide in Henan Province, China. Based on the probabilistic stratigraphic models, multiple plausible stratigraphic realizations were generated, and their corresponding stability responses are evaluated through numerical analysis. Monte Carlo simulations were further performed to examine how stratigraphic uncertainty propagates into landslide stability predictions. The results show that incorporating ERT data improves the geological plausibility of the inferred stratigraphy. Compared with the borehole-only case, the results obtained from the integrated framework exhibited reduced uncertainty in both the inferred stratigraphic model and the corresponding landslide stability assessment. These findings indicate that the proposed borehole–geophysical data fusion method can provide a more reliable geological basis for landslide stability analysis. Full article

High-speed railway embankments constructed over karst-prone ground conditions are often challenged by weak soils and subsurface cavities, which can lead to instability and excessive settlement. This study presents a full-scale field investigation conducted in the El-Gharbaniyat area, west of Alexandria, Egypt, where a pile–cap ground improvement system was implemented to support a high-speed railway embankment founded on clayey and silty soils overlying fractured limestone. A comprehensive site investigation program was performed, including 28 boreholes and integrated geophysical surveys using Electrical Resistivity Tomography (ERT) and Seismic Tomography (ST), enabling improved identification of weak zones and cavity-prone formations. Based on these findings, a pile–cap system was designed using reinforced concrete piles of 0.60 m diameter and an average length of 29 m, arranged in a 4 × 4 m grid and capped with reinforced concrete footings to ensure efficient load transfer to deeper competent strata. The system performance was validated through laboratory testing and full-scale in situ pile load tests. The average 28-day compressive strength of 122 tested piles reached approximately 50 MPa, exceeding the design value by approximately 30%. Load test results showed settlements ranging from 1.08 to 2.76 mm at the working load (2200 kN) and 2.16 to 5.10 mm at the maximum load (3300 kN), all well below allowable limits. Comparative evaluation indicated that the proposed system achieves significant material savings (>90%), lower treatment cost (150 USD/m²), reduced carbon emission (5.7 t per pile), and shorter construction duration (7 h per pile). These findings confirm that the pile–cap system provides a robust, cost-effective, and environmentally efficient solution for ground improvement in karst environments. Full article

Accurate multiphase flow measurement in horizontal wells is fundamentally challenged by the antagonistic electrical responses of water and gas: Electrical Resistance Tomography (ERT) loses sensitivity to thin liquid films, while Electrical Capacitance Tomography (ECT) suffers signal saturation in conductive water, preventing either modality from covering the full operating envelope alone. This study proposes a physics-guided hybrid modeling framework that integrates multi-modal ERT/ECT sensing to achieve high-precision flowrate inversion. The framework utilizes a corrected multi-modal fusion algorithm, achieving a liquid holdup MAPE of 2.5 ± 0.5% representing a nearly two-fold improvement over the best single-modality system (Direct ERT, 4.5%). For velocity estimation, an optimized cross-correlation method yields results with ± 3.0% error, incorporating multi-sensor and multi-sequence fusion. A key finding is that deep neural networks exhibit Architectural Phase Specialization: multi-branch architectures (MB-DNN) perform strongly on localized, heterogeneous liquid structures (2.0% liquid error), whereas fully-connected architectures (FC-DNN) excel at capturing the global patterns of the continuous gas core (1.2% gas error). By hybridizing a calibrated drift-flux physical model with these phase-specialized DNNs, the framework achieves overall averaged errors of 1.8% for gas and 1.5% for liquid across the full experimental envelope. The proposed framework was evaluated on 444,313 experimental samples and subsequently validated in a three-month industrial trial at the Puguang gas field under extreme conditions (26 MPa, 80 °C), where it maintained a prediction error of ± 2.3%. This work establishes a scalable, physically consistent paradigm for intelligent hydrocarbon production monitoring. Full article
