This article presents the results of the tribological performance of 20MnCr5 (1.7147) tool steel countersamples produced by Direct Metal Laser Sintering (DMLS), as a potential material for inserts or working layers of sheet metal forming tools. Tribological tests were performed using a roller-block tribotester. The samples were sheet metals made of materials with significantly different properties: Inconel 625, titanium-stabilised stainless steel 321, EN AW-6061 T0 aluminium alloy, and pure copper. The samples and countersamples were analysed in terms of their wear resistance, coefficient of friction (COF), changes in friction force during testing, and surface morphology after tribological contact under dry friction conditions. The tests were performed on DMLSed countersamples in the as-received state. The largest gain of countersample mass was observed for the 20MnCr5/EN AW-6061 T0 friction pair. The sample mass loss in this combination was also the largest, amounting to 19.96% of the initial mass. On the other hand, in the 20MnCr5/Inconel 625 friction pair, no significant changes in the mass of materials were recorded. For the Inconel 625 sample, a mass loss of 0.04% was observed. The basic wear mechanism of the samples was identified as abrasive wear. The highest friction forces were observed in the 20MnCr5/Cu friction pair (COF = 0.913) and 20MnCr5/EN AW-6061 T0 friction pair (COF = 1.234). The other two samples (Inconel 625, 321 steel) showed a very stable value of the friction force during the roller-block test resulting in a COF between 0.194 and 0.213. Based on the changes in friction force, COFs, and mass changes in friction pair components during wear tests, it can be concluded that potential tools in the form of inserts or working layers manufactured using 3D printing technology, the DMLS method, without additional surface treatment can be successfully used for forming sheets of 321 steel and Inconel 625. Full article

Aluminium alloy foams have been widely used due to their excellent strength-to-weight ratio, low density, and outstanding properties such as high energy absorption and effective noise and heat insulation. In this study, aluminium machining chips have been used for foam production as a potential recycling method. The process has involved solution heat treatment followed by artificial ageing. Researchers have been analysing the microhardness of both the foam and the bulk material, as well as examining their microstructures. The maximum microhardness value of the bulk material has been found to be 158 ± 2 HV1 at an ageing temperature of 175 ± 1 °C for 2 ± 0.02 h. For the foams, the highest microhardness of 150 ± 2 HV1 has been achieved after ageing at 150 ± 1 °C for 9 ± 0.02 h. Experimental planning has been carried out using Design Expert software. The optimisation process has identified 150 ± 1 °C for 2 ± 0.02 h as the optimum condition for artificial ageing. Full article

The anodic oxide layer’s porosity is considered a functional feature, acting as a reservoir of lubricants. This feature enables the design of self-lubricating systems that effectively reduce friction and wear. To improve the tribological performance of Al₂O₃ anodic coatings on EN AW 5251 aluminium alloys, this paper presents a modification of the coating with tungsten disulfide (IF-WS₂) nanopowder and its effect on coating resistance. The wear properties of Al₂O₃/IF-WS₂ coatings in contact with a cast iron pin were investigated. The results include the analysis of the friction coefficient in the reciprocating motion without oil lubrication at two loads, the analysis of the wear intensity of the cast iron pin, the characterisation of wear scars, and the analysis of SGP parameters. Two-level factorial analysis showed that load and nanomodification significantly affected the load-bearing parameter Rk. Incorporation of the modifier, especially under higher loads, reduced the Rk value, thus improving the tribological durability of the contact pair. Both load and nanomodification had a notable impact on the coefficient of friction. The use of IF-WS₂-modified coatings reduced the coefficient, and higher loads further enhanced this effect, by approximately 9% at a load of 0.3 MPa and 15% at a load of 0.6 MPa, indicating improved lubricating conditions under greater contact stress. Full article

The aim of the research was to examine the effect of sandblasting the adherent surfaces on the shear strength of aluminium alloy–glass adhesive joints. An EN AW-1050A aluminium alloy and non-hardened soda-lime glass were used as samples. The sandblasting materials in the study were copper slag and glass beads. Due to the brittleness of the glass, an adhesive joint design was created to allow strength testing. The adhesive joints took the form of lap joints, where a glass sample was placed between two aluminium samples. The length of the glass sample corresponded to the length of the adhesive joint overlap. The bonding process of the glass samples was carried out in two stages in order to maintain the dimensions of the joint. The adhesive used in the test was a two-component epoxy adhesive prepared on the basis of bisphenol A and a polyamide curing agent mixed at a ratio of 80 g of curing agent per 100 g of epoxy resin. For each sandblasting agent, adhesive joints consisting of three variations of surface treatments were made: sandblasted aluminium alloy-sandblasted glass, sandblasted aluminium alloy-untreated glass, untreated aluminium alloy-sandblasted glass. The distance between the nozzle and treated surface was 10 ± 1 cm, and the pressure of sandblasting was 0.6 MPa. One sample of each material differing in surface preparation was selected for a topography analysis. The shear strength tests performed showed that sandblasting increased the strength of the adhesive joints of the glass and aluminium alloy. The highest strength was obtained for joints where both materials were prepared using copper slag sandblasting. This was confirmed through statistical analysis. Only for this type of joint, statistical significance relative to the other adhesive bonding variants was obtained. Full article

An EN AW-6082 aluminium alloy is one of the 6000 series aluminium alloys with the highest strength properties. Due to its favourable strength-to-density ratio, it is used, among others, in the automotive and aviation applications. It is also characterised by good formability, especially in the annealed condition. This article presents the results of investigations on the possibility of forming a 2 mm thick EN AW-6082 alloy sheet using the incremental sheet-forming process depending on the material condition (O, W, T4, T6). The microstructure of the material after heat treatment and the mechanical properties of the workpiece material in as-received state, as well as after forming, were examined. Additionally, for selected cases, additional heat treatment of the drawpieces was performed to improve their mechanical strength. The values of the limit-forming angle were determined for the materials tested. The values of this angle varied from 69° for the annealed sheet to 61° for the material in the T6 condition. The highest yield stress (YS) and ultimate tensile strength (UTS) were found for sheets (YS = 305 MPs and UTS = 324 MPa) and the artificially aged drawpieces (YS = 333 MPa and UTS = 390 MPa). Additional ageing after incremental sheet forming resulted in an increase in strength properties compared to drawpieces without additional heat treatment only in the case of drawpieces made of sheet metal after the solutionising and in T4 condition. Full article

The paper deals with the evaluation of the quality of Cu-Al-AlMg3 structural transition joints (STJ) made by explosion welding proposed for the renovation of galvanizer hangers. The three-layer joint consisted of electrolytic copper with a thickness of 25 mm, 2 mm of aluminium represented by the AW1050 alloy, and 25 mm of the EN AW 575 aluminium alloy. Light microscopy analysis confirmed the wavy pattern of both interfaces of the welded joint and significant plastic deformation in close proximity to the waves. Microhardness measurement revealed a partial strain hardening of the AW5754 copper-aluminium alloy near the interface and a significant increase in microhardness in the vortex zone of waves, reaching a value of up to 863 HV 0.025. Microcracks were also observed in these places. The intermetallic phase Al₂Cu was identified in the vortex zones by XRD analysis. As a continuous layer of intermetallic phase was not observed in the interface of the welded joint, it is possible to consider the used welding parameters as appropriate. A semi-quantitative EDX analysis revealed a diversity of chemical composition in the vortex zones, which does not correspond to the phase composition based on the equilibrium binary Al-Cu diagram due to non-equilibrium conditions in the formation of the welded joint interface. The bond strength of three-layer welded joint evaluated by the strength test ranged from 151 to 171 MPa, which represented approximately a two-fold increase in comparison to the ultimate tensile strength of alloy AW1050, while the failure occurred in all samples at the AW1050-AW5754 alloy interface. Full article

Collision welding is a promising approach for joining conventional materials in identical or dissimilar combinations without heat-related strength loss, thereby opening up new lightweight potential. Widespread application of this technology is still limited by an insufficient state of knowledge with respect to the underlying joining mechanisms. This paper applies collision welding to a material combination of DC04 steel and EN AW 6016 aluminium alloy. Firstly, the welding process window for the combination is determined by varying the collision speed and the collision angle, the two main influencing variables in collision welding, using a special model test rig. The process window area with the highest shear tensile strength of the welded joint is then determined using shear tensile tests and SEM images of the weld zone. The SEM investigations reveal four distinct metallographic structures in the weld zones, the area fractions of which are determined and correlated with collision angle and shear tensile strength. Full article

Similar to bulk metal forming, clinch joining is characterised by large plastic deformations and a variety of different 3D stress states, including severe compression. However, inherent to plastic forming is the nucleation and growth of defects, whose detrimental effects on the material behaviour can be described by continuum damage models and eventually lead to material failure. As the damage evolution strongly depends on the stress state, a stress-state-dependent model is utilised to correctly track the accumulation. To formulate and parameterise this model, besides classical experiments, so-called modified punch tests are also integrated herein to enhance the calibration of the failure model by capturing a larger range of stress states and metal-forming-specific loading conditions. Moreover, when highly ductile materials are considered, such as the dual-phase steel HCT590X and the aluminium alloy EN AW-6014 T4 investigated here, strong necking and localisation might occur prior to fracture. This can alter the stress state and affect the actual strain at failure. This influence is captured by coupling plasticity and damage to incorporate the damage-induced softening effect. Its relative importance is shown by conducting inverse parameter identifications to determine damage and failure parameters for both mentioned ductile metals based on up to 12 different experiments. Full article

Ensuring adequate reliability of the production process of packaging closures has made it necessary to study the effect of annealing and varnishing variants on the strength and structural properties of the stock material. As a test material, EN AW-5052-H28 aluminium alloy sheets with a thickness of 0.21 mm were used. The surface treatment of the test material involved varnishing the sheet metal surface using various varnishes and soaking the sheet metal. The coefficient of friction and the abrasion resistance of the coatings were determined using the T-21 ball-and-disc tribotester. The tested sheets were subjected to tribological analysis by the T-05 roller-block tribotester using countersamples made of Caldie and Sverker 21 tool steels. The results of the tests showed differences in mechanical and structural properties depending on the method of sample preparation. Based on the test results, significant differences in the adhesion of anti-wear coatings were found. The results revealed that the most favourable friction conditions are provided by the CrN coating. The (AlTi)N interlayer in the (AlTi)N/(AlCr)N coating adheres to the substrate over the entire tested area and no detachment from its surface was observed, which proves good bonding at the substrate/coating interface. The tested AlTiN/TiAlSiXN coating is characterised by a more homogeneous, compact microstructure compared to the (AlTi)N/(AlCr)N coating. Full article

The present study comprises an investigation involving thermodynamic analysis, microstructural characterisation, and a comparative examination of the solidification sequence in two different aluminium alloys: EN AW 6026 and EN AW 1370. These alloys were modified through the addition of pure indium and a master alloy consisting of indium and bismuth. The aim of this experiment was to evaluate the potential suitability of indium, either alone or in combination with bismuth, as a substitute for toxic lead in free-machining aluminium alloys. Thermodynamic analysis was carried out using Thermo-Calc TCAL-6 software, supplemented by differential scanning calorimetry (DSC) experiments. The microstructure of these modified alloys was characterised using SEM–EDS analysis. The results provide valuable insights into the formation of different phases and eutectics within the alloys studied. The results represent an important contribution to the development of innovative, lead-free aluminium alloys suitable for machining processes, especially for use in automatic CNC cutting machines. One of the most important findings of this research is the promising suitability of indium as a viable alternative to lead. This potential stems from indium’s ability to avoid interactions with other alloying elements and its tendency to solidify as homogeneously distributed particles with a low melting point. In contrast, the addition of bismuth does not improve the machinability of magnesium-containing aluminium alloys. This is primarily due to their interaction, which leads to the formation of the Mg₃Bi₂ phase, which solidifies as a eutectic with a high melting point. Consequently, the presence of bismuth appears to have a detrimental effect on the machining properties of the alloy when magnesium is present in the composition. Full article

The commonly used Gaussian intensity distribution during the laser-based processing of metals can negatively affect melt pool stability, which might lead to defects such as porosity, hot cracking, or poor surface quality. Hot cracking is a major factor in limiting production rates of high-strength aluminium alloys in laser-based processes such as welding or the powder bed fusion of metals (PBF-LB/M). Going away from a Gaussian intensity distribution to ring-shaped profiles allows for a more even heat distribution during processing, resulting in more stable melt pools and reduced defect formations. Therefore, the aim of this study is to investigate the influence of different laser beam profiles on the processing of high-strength aluminium alloys by using a multicore fiber laser, allowing for in-house beam shaping. Single weld tracks on the aluminium alloy EN AW-5083 are produced with varying laser powers and weld speeds, as well as different beam profiles, ranging from Gaussian intensity distribution to point/ring profiles. The molten cross sections are analyzed regarding their geometry and defects, and the surface roughness of the weld tracks is measured. By using point/ring beam profiles, the processing window can be significantly increased. Hot cracking is considerably reduced for weld speeds of up to 1000 mm/s compared to the Gaussian beam profile. Furthermore, the melt pool width and depth are more stable, with varying parameters for the point/ring profiles, while the Gaussian beam tends to keyhole formation at higher beam powers. Finally, a strong decrease in surface roughness for the point/ring profiles, accompanied by a significantly reduced humping effect, starting even at lower beam powers of 200 W, can be observed. Therefore, these results show the potential of beam shaping for further applications in laser-based processing of high-strength aluminium alloys. Full article

Friction occurring in the area of contact between the sheet metal and the tool in sheet metal forming is one of the factors determining the quality of the surface of the drawpiece and the formability of the workpiece. Knowledge of the friction conditions allows the optimal forming conditions to be determined in terms of lubrication and applied pressures. The article presents the results of experimental studies of friction in EN AW-2024-T3 Alclad sheets using a special device simulating the sheet–tool contact in the blank-holder area during SMF. The friction tests were carried out at various pressures, under dry friction, and with the use of typical oils with a wide range of viscosity. The effect of the friction process parameters on the COF and surface roughness parameters Rsk and Rku was analysed using analysis of variance. The model F-values imply that the regression models for all the output parameters were significant. A monotonic decrease in the COF with an increase in the mean contact pressure and lubricant viscosity was observed for both dry and lubricated conditions. DELVAC 1340 engine oil with the highest viscosity significantly lowered the COF. The lubrication efficiency with LAN46 machine oil and LVH22 hydraulic oil showed an upward trend with an increasing mean contact pressure. In general, friction reduces the value of average roughness, Ra, and skewness, Rsk. Meanwhile, friction under contact pressures in the analysed range (4.4–11.7 MPa) causes an increase in kurtosis, Rku. Full article

Laser structuring is by far the most investigated metal surface-pretreatment method for creating adhesion in polymer–metal hybrids. Especially, cone-like protrusions show excellent wetting behaviour as well as high compound strength. However, the processing time is extremely high. Therefore, this paper assesses a process strategy for creating pin structures with scalable height by single pulse drilling with an Nd/YVO₄ nanosecond laser system on EN AW-6082 aluminium alloy. The strength testing is carried out by butt-bonded hollow cylinder torsion. The samples are manufactured by heat-conduction thermal joining with polyamide 6. Ten different surface structures with two different ablation diameters are investigated and compared to cone-like protrusions in terms of processing time, wetting behaviour, shear strength and fracture behaviour. The experimental results show that pulse drilling pins structures with high aspect ratio reach-strength values close to cone-like protrusions but with 31 times higher processing rate. Full article

The aim of this paper is to analyse the effect of the selected geometric properties of thin-walled structures on post-machining deformations. In the study, EN AW-7075 T651 and EN AW-6082 T651 aluminium alloys were used to prepare specially designed thin-walled sample elements, i.e., elements with walls arranged in a semi-open and closed structure and with a dimension of 165 × 262 × 50.8 mm consisting of bottom and vertical stiffening walls and so-called ribs with a thickness of 1 mm. The measurements of the absolute deformations of the thin-walled bottom were performed with the use of a Vista coordinate-measuring machine by Zeiss with a PH10 head by Renishaw. Based on the obtained results, it was found that absolute deformation values were higher for walls arranged in a semi-open structure. It is related to a lower rigidity of the tested structure resulting from the lack of a stiffening wall, which is the so-called “rib”. Notwithstanding the geometry of the elements, greater absolute deformation values were recorded following conventional cutting methods. The use of high-speed cutting (HSC) provided positive outcomes in terms of minimising the deformation of thin-walled elements. Additionally, it was found that higher absolute deformations were obtained for EN AW-7075 T651 alloy. Full article

The paper presents an experimental and numerical analysis of EN AW 6082 T6 aluminium alloy columns exposed to high-temperature creep in transient conditions. Transient tests with columns subjected to a constant heating rate for a persistent external load in the form of the horizontal and transversal forces were carried out. A total of ten columns were examined with varying ratios of horizontal and transversal loads. The test results were compared to numerical results obtained from ANSYS 16.2. The coefficients for an ANSYS built-in Modified Time Hardening creep model were calibrated from the previously conducted tests on coupons and used as a base for the numerical analysis of the column. The study results reveal that creep reduces column load-bearing capacity, starting at temperatures above 150 °C. Furthermore, the level of reduction in the aluminium column capacity, which manifests itself as a runaway failure of the column between the creep and creep-free model, deviates with a difference exceeding 160% in vertical displacement upon failure, while the creep model correlates very well with the results obtained from the tested specimens in terms of failure time and the displacement ratio. Full article
