Search Results (70)

Due to the coupling of DC and AC components, the ion flow field of HVDC and HVAC transmission lines in the same corridor or even the same tower is complex and time-dependent. In order to effectively analyze the ground-level electric field of hybrid transmission lines, the Krylov subspace methods with pre-conditioning treatment are used to solve the discretization equations. By optimizing the coefficient matrix, the calculation efficiency of the iterative process of the electric field in the time domain is greatly increased. Based on the limit of electric field, radio interference and audible noise applied in China, the main factor influencing the design of hybrid transmission lines is determined in terms of electromagnetic environment. After the ground-level electric field of transmission lines with different configurations is analyzed, the minimum height and corridor width of double-circuit 500 kV HVAC lines and one-circuit ±800 kV HVDC lines in the same corridor are obtained. The research provides valuable practical recommendations for optimal tower configurations, minimum heights, and corridor widths under various electromagnetic constraints. Full article

This paper proposes a family of high-efficiency DC-DC boost converters employing voltage-doubling coupled-inductor technology with a low component count. By varying the homonymous winding connections of the coupled inductor, three topologies are developed: parallel (PWCDVD-CLBC), series (SWCDVD-CLBC), and flipped-parallel (FPWCDVD-CLBC). These converters achieve high-voltage gain, continuous input current, and low-voltage stress across components. The PWCDVD-CLBC and FPWCDVD-CLBC configurations exhibit voltage gains proportional to the turn ratio, while the SWCDVD-CLBC shows an inverse relation, enabling reduced turn ratios. Detailed operational principles, mathematical analysis, and performance advantages are presented. A comparative evaluation demonstrates a higher voltage gain, realizes continuous input current, and has lower voltage stresses. The experimental results validate the theoretical analysis and confirm the feasibility and efficiency of the proposed designs. Full article

In recent years, the number of transistors on electronic chips has surpassed Moore’s law, resulting in overheating and energy consumption problems in data centers (DCs). Chip-level microchannel cooling is expected to address these challenges. Grooved heat sinks with droplet-shaped fins were introduced to modify the overall capability of the cooling system. The degree of impact of the distribution of grooves and fins was analyzed and optimized using the Taguchi method. Moreover, the coupling effect of flow and temperature fields was explained using the field synergy theory. The key findings are as follows: for thermal resistance, pump power, and overall efficiency, the influence degree is the number of combined units > number of fins in each unit > distribution of the combined units. The optimal configuration of 21 combined units arranged from dense to sparse with one fin in each unit achieves 14.05% lower thermal resistance and 8.5% higher overall efficiency than the initial heat sink. The optimal configuration of five combined units arranged from sparse to dense with one fin in each unit reduces the power energy consumption by 27.61%. After optimization, the synergy angle between the velocity vector and temperature gradient is reduced by 4.29% compared to the smooth heat sink. The coupling effect between flow and heat transport is strengthened. The optimized configuration can better balance heat dissipation and energy consumption, improve the comprehensive capability of cooling system, provide a feasible solution to solve the problems of local overheating and high energy consumption in DCs. Full article

This paper presents a highly linear two-stage InGaP/GaAs power amplifier integrated circuit (PAIC) using a dynamic predistorter for 5G small-cell applications. The proposed predistorter, based on a diode-connected transistor, utilizes a supply voltage to accurately control the linearization characteristics by adjusting its dc current. It is connected in parallel with an inter-stage of the two-stage PAIC through a series configuration of a resistor and an inductor, and features a shunt capacitor at the base of the transistor. These passive components have been optimized to enhance the linearization performance by managing the RF signal’s coupling to the diode. Using these optimized components, the AM−AM and AM−PM nonlinearities arising from the nonlinear resistance and capacitance in the diode can be effectively used to significantly flatten the AM−AM and AM−PM characteristics of the PAIC. The proposed predistorter was applied to the 2.6 GHz two-stage InGaP/GaAs HBT PAIC. The IC was tested using a 5 × 5 mm² module package based on a four-layer laminate. The load network was implemented off-chip on the laminate. By employing a continuous-wave (CW) signal, the AM−AM and AM−PM characteristics at 2.55–2.65 GHz were improved by approximately 0.05 dB and 3°, respectively. When utilizing the new radio (NR) signal, based on OFDM cyclic prefix (CP) with a signal bandwidth of 100 MHz and a peak-to-average power ratio (PAPR) of 9.7 dB, the power-added efficiency (PAE) reached at least 11.8%, and the average output power was no less than 24 dBm, achieving an adjacent channel leakage power ratio (ACLR) of −40.0 dBc. Full article

With the increasing penetration of renewable energy, the scale of AC/DC hybrid transmission systems continues to grow, intensifying risks such as line overloads under N-1 contingencies, short-circuit current violations, and operational stability challenges arising from multi-DC coupling. This paper explores the complex coupling characteristics between AC/DC and multi-DC systems in hybrid configurations, proposing innovative evaluation indicators for coupling properties and a comprehensive assessment scheme for multi-DC coupling degrees. To enhance system stability, coordinated planning strategies are proposed for AC/DC hybrid transmission systems with multi-infeed High-voltage direct-current (HVDC) based on the AC/DC strong–weak balance principle. Specifically, planning schemes are developed for determining the locations, capacities, and converter configurations of newly added DC lines. Furthermore, to mitigate multi-DC simultaneous commutation failure risks, we propose an AC-to-DC conversion planning scheme and a strategy for adjusting the DC system technology route based on a through comprehensive multi-DC coupling strength assessment, yielding coordinated planning strategies applicable to the AC/DC hybrid transmission systems with multi-infeed HVDC. Finally, simulation studies on the IEEE two-area four-machine system validate the feasibility of the proposed hybrid transmission grid planning strategies. The results demonstrate its effectiveness in coordinating multi-DC coupling interactions, providing critical technical support for future hybrid grid development under scenarios with high renewable energy penetration. Full article

Building Integrated Photovoltaic (BIPV) systems have emerged as an option to design Net Zero Energy Buildings (NZEB), thus helping to meet sustainable development goals. Based on an exhaustive review of papers, this work identifies characteristics and solutions to address power management issues in BIPV systems through three key approaches: (1) configurations of photovoltaic arrays, (2) MPPT methods, and (3) granularity level of the MPPT action. The analysis also highlights the advantages of deploying DC buses alongside conventional AC infrastructure to reduce conversion losses. This work also provides information concerning the trends in design and performance of BIPV systems, which is useful as a background for researchers and designers. In addition, the cross-coupling phenomena occurring in distributed MPPT solutions for BIPV systems is explained and evaluated in order to propose a mitigation strategy. These findings offer practical guidelines for developing more efficient BIPV systems that effectively support the transition to sustainable buildings and cities. Full article

Maritime relay communication has emerged as a critical application scenario for non-terrestrial networks (NTNs), providing beyond-line-of-sight (BLOS) connectivity for offshore terminals. Unlike terrestrial environments, the complex marine propagation conditions lead to signal instability. To enhance the robustness of maritime two-way relay networks (TWRNs), we propose a novel physical-layer network coding (PNC) scheme based on block Markov superposition transmission (BMST). The proposed scheme introduces a novel co-design framework that achieves dual breakthroughs: (1) robust error correction via BMST’s spatially coupled coding architecture and (2) spectral efficiency maximization through PNC’s spatial-domain signal superposition. Moreover, we develop a decoding–computing (DC) algorithm that sequentially performs iterative decoding followed by computing. Compared to the computing–decoding (CD) algorithm, the proposed DC algorithm mitigates useful information loss at relay nodes, achieving a 2.9 dB coding gain at a bit error rate (BER) of ${10}^{-5}$. Owing to the DC algorithm’s dual-layer decoding architecture, we can further improve the overall system performance through targeted optimization of either the code rate or memory size for communication sides with poor channel conditions, yielding an extra 0.2 dB gain at a BER of ${10}^{-5}$ compared to non-optimized configurations. The simulation results demonstrate that the proposed scheme significantly enhances maritime relay communication performance under harsh oceanic channel conditions while providing actionable insights for optimizing next-generation maritime communication system designs. Full article

This paper presents a comprehensive study on the formulation and solution of the power flow problem in bipolar direct current (DC) distribution networks with unbalanced constant power loads. Using the nodal voltage method, a unified nonlinear model is proposed which accurately captures both monopolar and bipolar load configurations as well as the voltage coupling between conductors. The model assumes a solid grounding of the neutral conductor and known system parameters, ensuring reproducibility and physical consistency. Seven iterative algorithms are developed and compared, including three Newton–Raphson-based formulations and four quasi-Newton methods with constant Jacobian approximations. The proposed techniques are validated on two benchmark networks comprising 21 and 85 buses. Numerical results demonstrate that Newton-based methods exhibit quadratic convergence and high accuracy, while quasi-Newton approaches significantly reduce computational time, making them more suitable for large-scale systems. The findings highlight the trade-offs between convergence speed and computational efficiency, and they provide valuable insights for the planning and operation of modern bipolar DC grids. Full article

We present in this paper a low-noise, low-power CMOS operational transconductance amplifier designed for the preconditioning stage of implantable neural recording microsystems. The proposed single-stage amplifier utilizes a combination of recently published techniques, including cross-coupled devices in a recycling folded-cascode topology with positive feedback, to achieve high DC voltage gain and unity-gain bandwidth while minimizing power consumption. A mixed N-type and P-type MOSFET input stage enhances input common-mode performance. Designed and implemented in a 0.18-µm CMOS process with a 1.8 V supply, post-layout simulations demonstrate an open-loop voltage gain of 97.23 dB, a 2.91 MHz unity-gain bandwidth (with a 1 pF load), and an input-referred noise of 4.75 μV_rms. The total power dissipation, including bias circuitry, is 5.43 μW, and the amplifier occupies a chip area of 0.0055 mm². Integrated into a conventional neural recording amplifier configuration, the proposed amplifier achieves a simulated input-referred noise of 5.73 µV_rms over a 1 Hz to 10 kHz bandwidth with a power consumption of 5.6 µW. This performance makes it suitable for amplifying both action potential and local field potential signals. The amplifier provides an output voltage swing of 0.976 V_pp with a total harmonic distortion of −62.68 dB at 1 kHz. Full article

Recent years have seen increasing attention paid to autonomous decentralized microgrids that are disaster-resistant and suitable for local consumption of locally generated renewable energy power. Although various methods have been discussed for achieving microgrids through autonomous decentralized cooperative control, there are few reports that have reached the stage of field testing. In this study, I propose a novel method for configuring the baseline of DC microgrids, where storage batteries are distributed and directly connected to the DC bus. I have built a testbed to demonstrate the operation of the DC microgrid through autonomous decentralized cooperative control. My method simply employs the droop characteristics inherent in batteries, and I introduce the new concept of a ‘weakly coupled grid’. This approach allows the realization of microgrids with autonomous decentralized cooperative control without the need for advanced and complex grid control technologies using DC/DC converters, and with a simple configuration. Additionally, by directly connecting batteries to the baseline, I introduce a grid stabilization method achieved by imparting electrical inertia to the baseline. This paper describes the construction method, the operation principle, and safe and stable operational methods for autonomous decentralized microgrids using this approach, aiming to serve as a guide for those who wish to build autonomous decentralized controlled microgrids in practice. Full article

Electric vehicles (EVs) are a sustainable means of transportation, with their onboard batteries being crucial for both performance and energy management. A modular and reconfigurable power converter topology to connect removable batteries to the main DC bus of an EV is proposed in this paper. By employing Dual Active Bridge (DAB) converters in an Input Parallel Output Series (IPOS) configuration, the proposed topology is compatible with 400 V and 800 V standards without the need for external switches. The research explored the possibility to apply a very simple control strategy based on independent linear regulators. A theoretical analysis of the IPOS DAB converter is presented and the design of independent control regulators which minimize the coupling effect between the control variables is addressed. The stability of the IPOS DAB converter could be ensured using the proposed simplistic approach, enabling us to drastically simplify the regulator design step. The dynamic performance of the system was confirmed by means of a simulation and experimentally. Full article

To avoid additional component losses while significantly improving the energy conversion efficiency of battery energy storage systems, the application of series-connected partial power converter (S-PPC) technology in battery energy storage systems is investigated in this study. In the S-PPC battery energy storage system configuration, coupling effects exist between the dc-link side and the battery-series side. The impedance modeling of a battery energy storage system is performed while taking these coupling effects into consideration. To address the instability observed during battery discharge conditions, an impedance reshaping control strategy that is suitable for the S-PPC battery energy storage system is proposed. The proposed method focuses on adjusting the input impedance of the load converter within a limited frequency band centered on the system’s oscillation frequency. This targeted approach significantly improves the stability of the system while ensuring ease of implementation and maintaining high reliability. Finally, the experimental results validate the theoretical analysis. Full article

This study introduces a novel method for optimising the size and control strategy of grid-connected, utility-scale photovoltaic (PV) systems with battery storage aimed at energy arbitrage and frequency containment reserve (FCR) services. By applying genetic algorithms (GA), the optimal configurations of PV generators, inverters/chargers, and batteries were determined, focusing on maximising the net present value (NPV). Both DC- and AC-coupled systems were explored. The performance of each configuration was simulated over a 25-year lifespan, considering varying pricing, solar resources, battery ageing, and PV degradation. Constraints included investment costs, capacity factors, and land use. A case study conducted in Wiesenthal, Germany, was followed by sensitivity analyses, revealing that a 75% reduction in battery costs is needed to make AC-coupled PV-plus-battery systems as profitable as PV-only systems. Further analysis shows that changes in electricity and FCR pricing as well as limits on FCR charging can significantly impact NPV. The study confirms that integrating arbitrage and FCR services can optimize system profitability. Full article

In a multi-fed DC environment, the UHV DC recipient grid faces significant challenges related to DC phase shift failure and voltage instability due to the high AC/DC coupling strength and low system inertia level. While the new large-capacity synchronous condensers (SCs) can provide effective transient reactive power support, the associated investment and operation costs are high. Therefore, it is valuable to investigate the optimization of SC configuration at key nodes in the recipient grid in a scientific and rational manner. This study begins by qualitatively and quantitatively analyzing the dynamic characteristics of DC reactive power and induction motors under AC faults. The sub-transient and transient reactive power output model is established to describe the SC output characteristics, elucidating the coupling relationship between the SC’s reactive power output and the DC reactive power demand at different time scales. Subsequently, a critical stabilized voltage index for dynamic loads is defined, and the SC’s reactive power compensation target is quantitatively calculated across different time scales, revealing the impact of transient changes in DC reactive power on the transient voltage stability of the multi-fed DC environment with dynamic load integration. Finally, an optimal configuration model for the large-capacity SC is proposed under the critical stability constraint of dynamic loads to maximize the SC’s reactive power support capability at the lowest economic cost. The proposed model is validated in a multi-fed DC area, demonstrating that the optimal configuration scheme effectively addresses issues related to DC phase shift failures and voltage instability resulting from AC bus voltage drops. Full article

Existing magnetic tracer detection systems primarily rely on fundamental wave signal acquisition using non-differential sensor configurations. These sensors are highly susceptible to external interference and lack tomographic localization capabilities, hindering their clinical application. To address these limitations, this paper presents a novel method for achieving the deep spatial localization of tracers. The method exploits second harmonic signal detection at non-zero field points. By considering the combined nonlinear characteristics of the coil’s axial spatial magnetic field distribution and the Langevin function, a correlation model linking the signal peak and bias field is established. This model enables the determination of the tracer’s precise spatial location. Building on this framework, a handheld device for localizing magnetic nanoparticle tracers was developed. The device harnesses the second harmonic response generated by coupling an AC excitation field with a DC bias field. Our findings demonstrate that under conditions of reduced coil turns and weak excitation fields, the DC bias field exhibits exclusive dependence on the axial distance of the detection point, independent of particle concentration. This implies that the saturated DC bias field corresponding to the second harmonic signal can be used to determine the magnetic nanoparticle sample detection depth. The experimental results validated the method’s high accuracy, with axial detection distance and concentration reduction errors of only 4.8% and 4.1%, respectively. This research paves the way for handheld probes capable of tomographic tracer detection, offering a novel approach for advancing magnetically sensitive biomedical detection technologies. Full article
