Search Results (25)

This study aims to propose a method for constructing basic digital twin data in South Korea by adhering to international standards and by utilizing publicly available data. Specifically, the study focuses on designing and proposing a digital twin data model for buildings, as building-related digital twin data are the most applicable among the basic digital twin data. To achieve this, the first section provides essential background information, introduces concepts and requirements related to basic digital twin data, and offers a brief overview of City Geography Markup Language (CityGML). The second section explains the methodology and the data used in this study. The third section presents the main findings: the selection of public data (building data) for constructing basic digital twin data, the mapping process using CityGML, and the creation of Unified Modeling Language (UML) diagrams. The fourth section discusses these findings. Finally, the conclusion and recommendations for future research are provided. This approach enhances the accuracy of building-related digital twin data and supports the use of digital twin services in both public and private sectors by enabling various spatial analyses. Full article

In the dynamic realm of digital twin modeling, where advancements are swiftly unfolding, users now possess the unprecedented ability to capture and generate geospatial data in real time. This article delves into a critical exploration of this landscape by presenting a meticulously devised workflow tailored for the creation of Level of Detail 3 (LOD3) models. Our research methodology capitalizes on the integration of Apple LiDAR technology alongside photogrammetric point clouds acquired from Unmanned Aerial Vehicles (UAVs). The proposed process unfolds with the transformation of point cloud data into Industry Foundation Classes (IFC) models, which are subsequently refined into LOD3 Geographic Information System (GIS) models leveraging the Feature Manipulation Engine (FME) workbench 2022.1.2. This orchestrated synergy among Apple LiDAR, UAV-derived photogrammetric point clouds, and the transformative capabilities of the FME culminates in the development of precise LOD3 GIS models. Our proposed workflow revolutionizes this landscape by integrating multi-source point clouds, imbuing them with accurate semantics derived from IFC models, and culminating in the creation of valid CityGML LOD3 buildings through sophisticated 3D geometric operations. The implications of this technical innovation are profound. Firstly, it elevates the capacity to produce intricate infrastructure models, unlocking new vistas for modeling digital twins. Secondly, it extends the horizons of GIS applications by seamlessly integrating enriched Building Information Modeling (BIM) components, thereby enhancing decision-making processes and facilitating more comprehensive spatial analyses. Full article

The subject of this research was to develop an effective strategy for combining various data sources, including the feasibility of implementing BIM in CityGML into an existing system supported by the GIS program. The study analyzed the path for converting BIM files to the CityGML format and the course of transmission of this data and data from the completed queries to the GIS program. An overview of external sources, map services, tools for acquiring accurate information about the terrain, and IT tools that could potentially be used was also carried out. The collected data proved deficiencies in the geospatial information of the analyzed area, defining the type of missing data necessary for the planned analyses. The results made it possible to determine further work and the basis for developing a plugin for the QGIS program. The plugin should facilitate energy efficiency, urban, and architectural analyses. The article also discusses the future opportunities for developing research directions for developing new 3D models of cities and collecting data for analysis. The analyses took into account the directions of geometric changes in 3D models as the result of the rapid development of digital tools. Ultimately, this research demonstrated the development demand for modern digital tools in the context of spatial and urban analysis, emphasizing the dynamic evolution in the field of GIS and the prospects of accelerating work on the integration of spatial data and their analysis thanks to the possibility of using open-source programs and our own efforts for their expansion. Full article

CityGML (City Geography Markup Language) is the most investigated standard in the integration of building information modeling (BIM) and the geographic information system (GIS), and it is essential for digital twin and smart city applications. The new CityGML 3.0 has been released for a while, but it is still not clear whether its new features bring new challenges or opportunities to this research topic. Therefore, the aim of this study is to understand the state of the art of CityGML in BIM/GIS integration and to investigate the potential influence of CityGML3.0 on BIM/GIS integration. To achieve this aim, this study used a systematic literature review approach. In total, 136 papers from Web of Science (WoS) and Scopus were collected, reviewed, and analyzed. The main findings of this review are as follows: (1) There are several challenging problems in the IFC-to-CityGML conversion, including LoD (Level of Detail) mapping, solid-to-surface conversion, and semantic mapping. (2) The ‘space’ concept and the new LoD concept in CityGML 3.0 can bring new opportunities to LoD mapping and solid-to-surface conversion. (3) The Versioning module and the Dynamizer module can add dynamic semantics to the CityGML. (4) Graph techniques and scan-to-BIM offer new perspectives for facilitating the use of CityGML in BIM/GIS integration. These findings can further facilitate theoretical studies on BIM/GIS integration. Full article

Using solid building models, instead of the surface models in City Geography Markup Language (CityGML), can facilitate data integration between Building Information Modeling (BIM) and Geographic Information System (GIS). The use of solid models, however, introduces a problem of model simplification on the GIS side. The aim of this study is to solve this problem by developing a framework for generating simplified solid building models from BIM. In this framework, a set of Level of Details (LoDs) were first defined to suit solid building models—referred to as s-LoD, ranging from s-LoD1 to s-LoD4—and three unique problems in implementing s-LoDs were identified and solved by using a semantics-based approach, including identifying external objects for s-LoD2 and s-LoD3, distinguishing various slabs, and generating valid external walls for s-LoD2 and s-LoD3. The feasibility of the framework was validated by using BIM models, and the result shows that using semantics from BIM can make it easier to convert and simplify building models, which in turn makes BIM information more practical in GIS. Full article

In a post-earthquake scenario, the semantic enrichment of 3D building models with seismic damage is crucial from the perspective of disaster management. This paper aims to present the methodology and the results for the Level of Detail 3 (LOD3) building modelling (after an earthquake) with the enrichment of the semantics of the seismic damage based on the European Macroseismic Scale (EMS-98). The study area is the Vrisa traditional settlement on the island of Lesvos, Greece, which was affected by a devastating earthquake of Mw = 6.3 on 12 June 2017. The applied methodology consists of the following steps: (a) unmanned aircraft systems (UAS) nadir and oblique images are acquired and photogrammetrically processed for 3D point cloud generation, (b) 3D building models are created based on 3D point clouds and (c) 3D building models are transformed into a LOD3 City Geography Markup Language (CityGML) standard with enriched semantics of the related seismic damage of every part of the building (walls, roof, etc.). The results show that in following this methodology, CityGML LOD3 models can be generated and enriched with buildings’ seismic damage. These models can assist in the decision-making process during the recovery phase of a settlement as well as be the basis for its monitoring over time. Finally, these models can contribute to the estimation of the reconstruction cost of the buildings. Full article

The development of a smart city and digital twin requires the integration of Building Information Modeling (BIM) and Geographic Information Systems (GIS), where BIM models are to be integrated into GIS for visualization and/or analysis. However, the intrinsic differences between BIM and GIS have led to enormous problems in BIM-to-GIS data conversion, and the use of City Geography Markup Language (CityGML) has further escalated this issue. This study aims to facilitate the use of BIM models in GIS by proposing using the shapefile format, and a creative approach for converting Industry Foundation Classes (IFC) to shapefile was developed by integrating a computer graphics technique. Thirteen building models were used to validate the proposed method. The result shows that: (1) the IFC-to-shapefile conversion is easier and more flexible to realize than the IFC-to-CityGML conversion, and (2) the computer graphics technique can improve the efficiency and reliability of BIM-to-GIS data conversion. This study can facilitate the use of BIM information in GIS and benefit studies working on digital twins and smart cities where building models are to be processed and integrated in GIS, or any other studies that need to manipulate IFC geometry in depth. Full article

Nowadays, cultural and historical built heritage can be more effectively preserved, valorised and documented using advanced geospatial technologies. In such a context, there is a major issue concerning the automation of the process and the extraction of useful information from a huge amount of spatial information acquired by means of advanced survey techniques (i.e., highly detailed LiDAR point clouds). In particular, in the case of historical built heritage (HBH) there are very few effective efforts. Therefore, in this paper, the focus is on establishing the connections between semantic and geometrical information in order to generate a parametric, structured model from point clouds using ontology as an effective approach for the formal conceptualisation of application domains. Hence, in this paper, an ontological schema is proposed to structure HBH representations, starting with international standards, vocabularies, and ontologies (CityGML-Geography Markup Language, International Committee for Documentation conceptual reference model (CIDOC-CRM), Industry Foundation Classes (IFC), Getty Art and Architecture Thesaurus (AAT), as well as reasoning about morphology of historical centres by analysis of real case studies) to represent the built and architecture domain. The validation of such schema is carried out by means of its use to guide the segmentation of a LiDAR point cloud from a castle, which is later used to generate parametric geometries to be used in a historical building information model (HBIM). Full article

The complexity and variety of buildings and the defects of point cloud data are the main challenges faced by 3D urban reconstruction from point clouds, especially in metropolitan areas. In this paper, we developed a method that embeds multiple relations into a procedural modelling process for the automatic 3D reconstruction of buildings from photogrammetric point clouds. First, a hybrid tree of constructive solid geometry and boundary representation (CSG-BRep) was built to decompose the building bounding space into multiple polyhedral cells based on geometric-relation constraints. The cells that approximate the shapes of buildings were then selected based on topological-relation constraints and geometric building models were generated using a reconstructing CSG-BRep tree. Finally, different parts of buildings were retrieved from the CSG-BRep trees, and specific surface types were recognized to convert the building models into the City Geography Markup Language (CityGML) format. The point clouds of 105 buildings in a metropolitan area in Hong Kong were used to evaluate the performance of the proposed method. Compared with two existing methods, the proposed method performed the best in terms of robustness, regularity, and topological correctness. The CityGML building models enriched with semantic information were also compared with the manually digitized ground truth, and the high level of consistency between the results suggested that the produced models will be useful in smart city applications. Full article

In this study, we present a meso-scale simulation of the urban microclimate in Berlin, Germany, using the Weather Research and Forecasting (WRF) numerical weather prediction platform. The objective of the study is to derive an accurate estimate of the near-surface urban heat island (UHI) intensity. The simulation is conducted over a two-week summer period. We compare different physical schemes, different urban canopy schemes and different methods for estimating the UHI intensity. The urban fraction of each urban category is derived using the Copernicus Impervious Density data and the Corine Land Cover data. High-resolution City Geography Markup Language (CityGML) data is used to estimate the building height densities required by the multi-layer urban canopy model (UCM). Within the single-layer UCM, we implement an anthropogenic heat profile based on the large scale urban consumption of energy (LUCY) model. The optimal model configuration combines the WRF Single Moment Five-Class (WSM5) microphysics scheme, the Bougeault–Lacarrère planetary boundary layer scheme, the eta similarity (Mellor–Yamada–Janjic) surface layer scheme, the Noah Multi-Parameterization land surface model, the Dudhia and Rapid Radiative Transfer Model (RRTM) radiation schemes, and the multi-layer UCM (including the building energy model). Our simulated UHI intensity results agree well with measurements with a root mean squared error of $0.86$$\mathrm{K}$ and a mean bias error of $0.20$$\mathrm{K}$. After model validation, we proceed to compare several UHI intensity calculation methods, including the ‘ring rural reference’ (RRR) method and the ‘virtual rural reference’ (VRR) method. The VRR mthod is also known as the ‘urban increment’ method. We suggest and argument that the VRR approach is superior. Full article

Humans’ activities in urban areas put a strain on local water resources. This paper introduces a method to accurately simulate the stress urban water demand in Germany puts on local resources on a single-building level, and scalable to regional levels without loss of detail. The method integrates building geometry, building physics, census, socio-economy and meteorological information to provide a general approach to assessing water demands that also overcome obstacles on data aggregation and processing imposed by data privacy guidelines. Three German counties were used as validation cases to prove the feasibility of the presented approach: on average, per capita water demand and aggregated water demand deviates by less than 7% from real demand data. Scenarios applied to a case region Ludwigsburg in Germany, which takes the increment of water price, aging of the population and the climate change into account, show that the residential water demand has the change of −2%, +7% and −0.4% respectively. The industrial water demand increases by 46% due to the development of economy indicated by GDP per capita. The rise of precipitation and temperature raise the water demand in non-residential buildings (excluding industry) of 1%. Full article

This study aims to improve the interoperability between the application domains of Building Information Modelling (BIM) and Geographic Information Systems (GIS) by linking and harmonizing core information concepts. Many studies have investigated the integration of application schemas and data instances according to the BIM model IFC and the GIS model CityGML. This study investigates integration between core abstract concepts from IFC and ISO/TC 211 standards for GIS—independent of specific application schemas. A pattern was developed for conversion from IFC EXPRESS schemas to Unified Modelling Language (UML) models according to ISO/TC 211 standards. Core concepts from the two application domains were linked in the UML model, and conversions to implementation schemas for the Geography Markup Language (GML) and EXPRESS were tested. The results showed that the IFC model could be described as an ISO/TC 211 compliant UML model and that abstract concepts from ISO/TC 211 standards could be linked to core IFC concepts. Implementation schemas for BIM and GIS formats could be derived from the UML model, enabling implementation in applications from both domains without conversion of concepts. Future work should include refined linking and harmonization of core abstract concepts from the two application domains. Full article

This study describes the technical-systemic and conceptual-informative interoperability tests for the integration of a Historic Building Information Modeling (HBIM) model in a 3D Geographic Information System (GIS) environment aimed to provide complete and useful documentation for multiscale analyses on cultural heritage particularly exposed to risks. The case study of the San Lorenzo Church in Norcia (Italy) has been chosen given the urgent need to update the existing documentation for its protection and conservation issues, due to the extensive damage suffered after the series of earthquakes that occurred in central Italy starting from summer 2016. Different tests to evaluate two levels of conceptual interoperability (technical and semantic) when importing the HBIM model into a GIS environment were performed, whether with commercial software or with open source ones (ArcGIS Pro and QGIS, respectively). A data integration platform (Feature Manipulation Engine, FME) has been used for converting the IFC (Industry Foundation Classes) data format into the GML (Geography Markup Language) format, in order to obtain a unique and unified model and vocabulary for the 3D GIS project, structured with different levels of detail, according to CityGML standard. Finally, as HBIM-GIS integration is considered, the loss of geometric and informative data has been taken into account and evaluated. Full article

Although interest in indoor space modeling is increasing, the quantity of indoor spatial data available is currently very scarce compared to its demand. Many studies have been carried out to acquire indoor spatial information from floorplan images because they are relatively cheap and easy to access. However, existing studies do not take international standards and usability into consideration, they consider only 2D geometry. This study aims to generate basic data that can be converted to indoor spatial information using IndoorGML (Indoor Geography Markup Language) thick wall model or the CityGML (City Geography Markup Language) level of detail 2 by creating vector-formed data while preserving wall thickness. To achieve this, recent Convolutional Neural Networks are used on floorplan images to detect wall and door pixels. Additionally, centerline and corner detection algorithms were applied to convert wall and door images into vector data. In this manner, we obtained high-quality raster segmentation results and reliable vector data with node-edge structure and thickness attributes that enabled the structures of vertical and horizontal wall segments and diagonal walls to be determined with precision. Some of the vector results were converted into CityGML and IndoorGML form and visualized, demonstrating the validity of our work. Full article

Many of today’s data models for 3D applications, such as City Geography Markup Language (CityGML) or Industry Foundation Classes (IFC) encode rich semantic information in addition to the traditional geometry and materials representation. However, 3D editing techniques fall short of maintaining the semantic information across edit operations if they are not tailored to a specific data model. While semantic information is often lost during edit operations, geometry, UV mappings, and materials are usually maintained. This article presents a data model synchronization method that preserves semantic information across editing operation relying only on geometry, UV mappings, and materials. This enables easy integration of existing and future 3D editing techniques with rich data models. The method links the original data model to the edited geometry using point set registration, recovering the existing information based on spatial and UV search methods, and automatically labels the newly created geometry. An implementation of a Level of Detail 3 (LoD3) building editor for the Virtual Singapore project, based on interactive push-pull and procedural generation of façades, verified the method with 30 common editing tasks. The implementation synchronized changes in the 3D geometry with a CityGML data model and was applied to more than 100 test buildings. Full article
