Advance hydraulic supports are widely applied in deep coal mine roadways; however, inappropriate initial support force often leads to either insufficient roof control or over-support, weakening the effectiveness of bolt–cable systems. To clarify the interaction mechanism between advance passive support and active bolt–cable reinforcement, an advance roadway support model was developed using FLAC3D based on the geological conditions of the 1432 working face in the Dongtan Coal Mine. Numerical simulations were conducted by varying the initial support force from 0 to 14 MPa, and the corresponding roof displacement, bolt stress, and cable axial force responses were systematically analyzed. The results indicate that roof subsidence decreases nonlinearly with increasing support force, exhibiting a rapid suppression stage (0–10 MPa) and a stable coordination stage (10–12 MPa). Within this optimal range, load transfer from the roof to the passive support is significantly enhanced, leading to effective stress relief and homogenization in the bolt–cable system. When the support force exceeds 12 MPa, further deformation control becomes marginal, indicating a transition from cooperative load sharing to over-support. These findings reveal the staged interaction mechanism between advance passive support and active reinforcement systems, providing a quantitative basis for selecting appropriate initial support force in deep roadway engineering. Full article

This paper explores the correlation between the macroscopic breakdown behavior and microscopic particle motion of cable joint cross-linked polyethylene–silicone rubber (XLPE-SiR) insulation interface breakdown. Firstly, based on the characteristics of Pd values exceeding 1000 Torr·cm at the insulation interface, it shows that XLPE-SiR insulation interface breakdown falls within the scope of streamer discharge. Further, the generation process of the insulation interface breakdown is described through microscopic particle motions, and the microscopic expression of the interface breakdown energy of cable joints is derived. Based on this, it is found that the ionization degree (χ) of the interface breakdown channel is the major microscopic parameter that affects the interface breakdown energy. An experiment was conducted on equivalent samples under different conditions of pyrolysis degree interface pressure (P) and breakdown gap (d). The experiment shows that the value of χ is positively related to the pyrolysis degree and P. Additionally, it is found that with the increase in d, the value of χ increases at first and then decreases gradually. The results of this paper can be taken as a basis for research on the microscopic process of XLPE-SiR insulation interface breakdown at different stages. Full article

This work presents a novel soft gripper concept featuring integrated force feedback and a compact, resource-efficient geometry. The gripper is designed to provide a low-cost, adaptable, and precise solution for manipulating delicate and irregularly shaped objects. By embedding force feedback directly into the structure, the system reliably detects contact and enables controlled, gentle gripping of fragile items. The design was developed for collaborative and assistive robotic applications, where safety and human–robot interaction are prioritized. The prototype is fabricated using consumer-grade 3D-printed components and employs a simple cable-driven actuation system. The hybrid soft–rigid architecture combines compliant fingers with a rigid, sensorized thumb, preserving the adaptive grasping characteristics of soft robotics while simplifying sensing integration and construction. A motor-based control mechanism synchronizes finger motion through cable traction, ensuring reliable and repeatable performance. Experimental evaluations demonstrate secure, damage-free handling across diverse object types, highlighting the gripper’s potential in assistive robotics, cobot environments, biomedical contexts, and other domains requiring safe and delicate manipulation. Full article

Efficient on-site connection of power cable conductors is critical for ensuring the safe operation of the power grid. Traditional thermite welding methods pose significant safety risks, including open flames and fumes. Meanwhile, induction heating, when applied to cable conductors, faces challenges of severe magnetic field dispersion, low heating efficiency, and a high risk of damaging adjacent insulation layers. This paper proposes a novel magnetic flux control system based on gradient permeability ceramics to address these issues. The core of this system is the synergistic utilization of a gradient permeability composite ceramic mold and a high-permeability shielding shell. A 2D axisymmetric multiphysics coupled model was established to compare the performance of the optimized system with a conventional case and single control components. Simulation results demonstrate that the optimized system increases the magnetic flux density at the weld seam to 3.7 times that of the conventional setup (0.263 T). Consequently, the weld seam of the 240 mm² copper conductor is rapidly heated to the melting point of copper (1083 °C) within 7.78 s. Due to the high heating rate, upon completion of the welding process, the temperatures of the inner shielding and insulation layers are only 48.8 °C and 24.3 °C, respectively, well below the materials’ safety thresholds. These findings suggest that the proposed magnetic flux control strategy achieves rapid and precise heating, offering a theoretical foundation for the development of high-performance on-site equipment for fabricating cable joints. Full article

CubeSat missions increasingly rely on microwave-band communication systems, whose antennas often exhibit directional radiation patterns. As a result, multiple antennas are commonly used to improve coverage; however, a quantitative method to evaluate their performance across all spacecraft attitudes has been lacking. This paper introduces the Coverage Ratio of CubeSat Attitude (CRCA), a metric that quantifies the proportion of orientations for which the antenna gain exceeds a required threshold. CRCA is introduced and demonstrated using the S-band command antenna system of the 6U CubeSat VERTECS. The proposed metric is then used to quantitatively compare multiple antenna placement configurations, clarifying the effect of mounting faces on attitude-dependent coverage. Electromagnetic simulations and three-dimensional radiation pattern measurements using a metal CubeSat enclosure show good agreement when splitter and cable losses are taken into account. The combined radiation pattern achieves greater than $-8.0$ dBic in 90% of attitudes in simulation, and greater than $-10.0$ dBic of attitudes in 90% in measurement. Furthermore, a CRCA-based link budget analysis demonstrates that sufficient uplink margin can be conservatively maintained under tumbling conditions. The proposed CRCA framework provides a practical and generalizable approach for evaluating antenna omnidirectionality and attitude-dependent communication performance in CubeSat missions. Full article

With the increasing deployment of grid-forming static var generators (GFM-SVG) in modern power systems, the reliability of the valve hall that houses the core power modules has become a critical concern. To overcome the limitations of conventional wired monitoring systems—complex cabling, poor scalability, and incomplete state perception—this paper proposes and implements a multi-source fusion wireless data acquisition system specifically designed for GFM-SVG valve halls. The system integrates acoustic, visual, and infrared sensing nodes into a wireless sensor network (WSN) to cooperatively capture thermoacoustic visual multi-physics information of key components. A dual-mode communication scheme, using Wireless Fidelity (Wi-Fi) as the primary link and Fourth-Generation Mobile Communication Network (4G) as a backup channel, is adopted together with data encryption, automatic reconnection, and retransmission-checking mechanisms to ensure reliable operation in strong electromagnetic interference environments. The main innovation lies in a multi-source information fusion algorithm based on an improved Dempster–Shafer (D–S) evidence theory, which is combined with the object detection capability of the You Only Look Once, Version 8 (YOLOv8) model to effectively handle the uncertainty and conflict of heterogeneous data sources. This enables accurate identification and early warning of multiple types of faults, including local overheating, abnormal acoustic signatures, and coolant leakage. Experimental results demonstrate that the proposed system achieves a fault-diagnosis accuracy of 98.5%, significantly outperforming single-sensor approaches, and thus provides an efficient and intelligent operation-and-maintenance solution for ensuring the safe and stable operation of GFM-SVG equipment. Full article

The ageing of elevator travelling cables results in the breakage of inner copper strands, leading to communication and control faults in the elevator system. In this paper, a travelling cable state evaluation method based on time-frequency transformation and a deep learning fitting method is proposed. The cable diagnosis is based on the transmission line theory and finite element simulation results, which indicate that the number of broken strands of copper wires in twisted cables is positively related to the amplitude of fluctuation in the cable’s transmission spectrum. To evaluate this fluctuation with low cost and high accuracy, we acquired the 500 Msps time-domain signal after a square wave with different periods was transmitted through the detected cable; the transmission in base frequency and harmonics is calculated and combined into the total transmission spectrum. A deep learning model with a two-layer 1-D CNN and squeeze-excitation channel attention is utilized to fit the spectrum data, and cross-entropy is applied to estimate the departure between the fitting results and the experimental data, which serves as the cable’s broken-state index. Experiments demonstrate that the proposed method is able to detect minor cable faults such as one or two copper strands broken and could distinguish different broken states with a sensitivity of 16.42 ± 1.39 per break strand. Full article

To address the difficulty of controlling surrounding rock subjected to repeated repair-induced disturbances, the characteristics of the roadway surrounding rock and its deformation–failure mechanisms were examined. An experimental scheme for surrounding-rock control was formulated, and a three-dimensional numerical model was established. Four support schemes were evaluated to identify a rational support method and corresponding parameters: (a) rock bolts and cable bolts; (b) rock bolts, cable bolts, and floor cable bolts; (c) rock bolts, cable bolts, floor cable bolts, and U-shaped closed steel sets; and (d) rock bolts, cable bolts, floor cable bolts, U-shaped closed steel sets, and grouting. Comparative analyses were conducted in terms of plastic-zone evolution, stress-field distribution, surrounding-rock displacement, and the mechanical response of the support structures. The results indicate that, in roadways experiencing multiple repair disturbances and supported only by rock bolts and cable bolts, distinct stress-concentration zones develop within the supported surrounding rock, suggesting that reliance solely on bolts and cables is unfavorable for effective rock-mass control. Grouting improves the overall integrity and self-bearing capacity of the surrounding rock. Both the U-shaped closed support and the combined U-shaped closed support with grouting effectively restrain surrounding-rock deformation, and the corresponding stress distribution shows no pronounced stress-concentration zones. Based on the analyses of surrounding-rock displacement, support-structure loading, and incremental shear strain, the effectiveness of the support schemes in mitigating roof and floor displacement ranks, in descending order, as (d), (c), (b), and (a). Engineering practice further demonstrates that the combined support system consisting of 29U-type sets, grouted bolts, and bundle-type grouted cable bolts provides effective control over the deformation and failure of the roadway surrounding rock. Full article

Optical Fiber Composite Overhead Ground Wire (OPGW) cables serve dual functions in power systems, lightning protection and critical communication infrastructure for real-time grid monitoring. Accurate OPGW identification during UAV inspections is essential to prevent miscuts and maintain power-communication functionality. However, detecting small, twisted OPGW segments among visually similar ground wires is challenging, particularly given the computational and energy constraints of edge-based UAV platforms. We propose OPGW-DETR, a lightweight detector based on the D-FINE framework, optimized for low-power operation to enable reliable detection. The model incorporates two key innovations: multi-scale convolutional global average pooling (MC-GAP), which fuses spatial features across multiple receptive fields and integrates spectrally motivated features for enhanced fine-grained representation, and a hybrid gating mechanism that dynamically balances global and spatial features while preserving original information through residual connections. By enabling real-time inference with minimal energy consumption, OPGW-DETR addresses UAV battery and bandwidth limitations while ensuring continuous detection capability. Evaluated on a custom OPGW dataset, the S-scale model achieves 3.9% improvement in average precision (AP) and 2.5% improvement in AP₅₀ over the baseline. By mitigating misidentification risks, these gains improve communication reliability. As a result, uninterrupted grid monitoring becomes feasible in low-power UAV inspection scenarios, where accurate detection is essential to ensure communication integrity and safeguard the power grid. Full article

As core infrastructure of power transmission networks, power towers require high-precision 3D models, which are critical for intelligent inspection and digital twin applications of power transmission lines. Traditional reconstruction methods, such as LiDAR scanning and oblique photogrammetry, suffer from issues including high operational risks, low modeling efficiency, and loss of fine details. To address these limitations, this paper proposes a 3D Gaussian Splatting (3DGS)-based method for power tower 3D reconstruction to enhance reconstruction efficiency and detail preservation capability. First, a multi-view data acquisition scheme combining “unmanned aerial vehicle + oblique photogrammetry” was designed to capture RGB images acquired by Unmanned Aerial Vehicle (UAV) platforms, which are used as the primary input for 3D reconstruction. Second, a sparse point cloud was generated via Structure from Motion. Finally, based on 3DGS, Gaussian model initialization, differentiable rendering, and adaptive density control were performed to produce high-precision 3D models of power towers. Taking two typical power tower types as experimental subjects, comparisons were made with the oblique photogrammetry + ContextCapture method. Experimental results demonstrate that 3DGS not only achieves high model completeness (with the reconstructed model nearly indistinguishable from the original images) but also excels in preserving fine details such as angle steels and cables. Additionally, the final modeling time is reduced by over 70% compared to traditional oblique photogrammetry. 3DGS enables efficient and high-precision reconstruction of power tower 3D models, providing a reliable technical foundation for digital twin applications in power transmission lines. By significantly improving reconstruction efficiency and reducing operational costs, the proposed method supports sustainable power infrastructure inspection, asset lifecycle management, and energy-efficient digital twin applications. Full article

As urban power grids grow increasingly complex and underground space resources become increasingly scarce, traditional two-dimensional cable design methods face significant challenges in spatial representation accuracy and design efficiency. This study proposes an automated cable path planning method based on an improved Rapidly exploring Random Tree (RRT) algorithm. This framework first introduces an enhanced RRT algorithm (referred to as ABS-RRT) that integrates adaptive stride, target-biased sampling, and Soft Actor-Critic reinforcement learning. This algorithm automates the planning of serpentine cable laying paths in confined environments such as cable tunnels and manholes. Subsequently, through trajectory simplification and smoothing optimization, it generates final paths that are safe, smooth, and compliant with engineering specifications. Simulation validation on a typical cable tunnel project in a city’s core area demonstrates that compared to the traditional RRT algorithm, this approach reduces path planning time by over 57%, decreases path length by 8.1%, and lowers the number of nodes by 52%. These results validate the algorithm’s broad application potential in complex urban power grid projects. Full article

To investigate the stability evolution pattern of deep-cutting slopes during staged excavation, on-site monitoring was conducted on the lateral displacement, anchor bolt axial force, and anchor cable anchoring force of the deep-cutting slope at Section EK1 + 640 of the Zhengxi Expressway. Additionally, FLAC3D was employed to study the impact of anchor cable anchoring force loss on slope stability. The research results indicate the following: During the staged excavation, the middle and lower parts of the slope exhibited significant lateral displacement, with a maximum displacement amplitude reaching 26.3 mm; as the monitoring period progressed, the axial force of anchor bolts located in the lower part of each slope stage gradually exceeded that of those in the upper part, and the closer an anchor bolt to the top of each slope stage, the smaller the increment in its axial force; for anchor cables installed at the top of each slope stage, the anchoring force loss rate reached 16.4%, which was significantly higher than that of cables in other positions. Meanwhile, these anchor cables were more significantly affected by environmental changes and construction disturbances, and the loss of anchor cable anchoring force exerted a notable influence on the slope’s overall stability. Full article

This paper presents the design, prototype, and experimental evaluation of the AlmatyExoElbow, a lightweight cable-driven robotic exoskeleton that is intended to support elbow joint rehabilitation. The device provides two active degrees of freedom for flexion/extension and pronation/supination. It also incorporates a sensor-based control system for accurate motion tracking. The mechanical structure is fabricated using 3D-printed PLA plastic, resulting in a compact, modular, and comfortable design suitable for prolonged use. The control architecture is based on an Arduino Nano microcontroller integrated with IMU sensors, enabling the real-time monitoring of elbow motion and the precise reproduction of physiologically relevant movement patterns. The results of experimental testing demonstrate smooth and stable operation, confirming reliable torque transmission through antagonistic cable mechanisms. Overall, the proposed design achieves a balanced combination of functionality, portability, and user comfort, highlighting its potential for upper-limb rehabilitation applications in both clinical and home-based settings. Full article

With the depletion of shallow coal resources, deep extra-thick coal seam mining has become vital for energy security, yet fully mechanized top-coal caving (FMTC) goaf-side roadways face severe challenges of excessive advanced deformation and intense strata behavior. To address this gap, this study took the 4301 tailgate of a coal mine in Shaanxi province as the engineering background, integrating field investigation, theoretical analysis, FLAC^3D numerical simulation, and industrial tests. Guided by the key stratum theory, we systematically analyzed the influence of overlying key strata fracture on strata pressure. The results show three key strata: near-field secondary key strata (KS1, KS2) with “vertical O-X” fracturing and far-field main key stratum (MKS) with “horizontal O-X” fracturing. The radial extrusion force from MKS rotational blocks is the core cause of 200 m range advanced deformation. A collaborative control scheme of near-field key strata directional fracturing roof-cutting pressure relief and high-strength bolt-cable support was proposed. Industrial verification indicates roadway deformation was significantly reduced, with roof subsidence, floor heave, and rib convergence controlled within safe engineering limits. This study fills the gap of insufficient research on far-field key strata’s impact, providing a reliable technical solution for similar extra-thick coal seam FMTC goaf-side roadway surrounding rock control. Full article

Background: Electromagnetic compatibility (EMC) challenges in 2.5D/3D semiconductor packaging arise from the complex coupling between device, interposer, board, and cable domains, which are insufficiently captured by conventional board-level analysis. Method: This study proposes HiPAC-EMC, a packaging-aware EMC workflow that integrates the device, package, PCB, cable harness, line impedance stabilization network (LISN), and receiver elements into an isomorphic co-model. The model mirrors the entire measurement chain and links simulation to real conducted and radiated tests. Validation: The workflow was verified using CISPR-25-compliant conducted measurements, magnetic near-field mapping, and key-point radiated checks at 3 m and 10 m, ensuring model–measurement consistency within ±2–3 dB (1σ ≈ 3.1 dB). Results: Two quantitative indices—the mitigation efficiency (η) and the common-mode hot-spot headroom (CMH)—enabled the traceable evaluation of suppression effectiveness, achieving up to 22–25 dB reduction across dominant 300–800 MHz bands. Significance: The HiPAC-EMC workflow establishes a traceable, reproducible, and measurement-faithful design methodology, providing a practical tool to de-risk EMC during early design and reduce full-band chamber time for advanced semiconductor packaging. Full article
