The acoustical modelling of multilayered systems is crucial for researchers and engineers aiming to evaluate and control the behaviour of complex media and to determine their internal properties. In this work, we first develop a forward model describing the propagation of acoustic waves through various types of materials, including fluids, solids, and poroelastic media. The model relies on the classical theoretical frameworks of Thomson and Haskell for non-porous layers, while Biot’s theory is employed to describe wave propagation in poroelastic materials. The propagation is mathematically treated using the transfer matrix method, which links the acoustic displacement and stress at the extremities of each layer. Appropriate boundary conditions are applied at each interface to assemble all local matrices into a single global matrix representing the entire multilayer system. This forward model allows the calculation of theoretical transmission coefficients, which are then compared to experimental measurements to validate the approach proposed. Secondly, this modelling framework is used as the basis for solving inverse problems, where the goal is to retrieve unknown internal parameters, such as mechanical or acoustic properties, by minimizing the discrepancy between simulated and experimental transmission spectra. This inverse problem approach is essential in non-destructive evaluation applications, where direct measurements are often unfeasible. Full article

Elastic closed-cell porous material is widely applied as a class of light sound insulation product. However, it is difficult to accurately predict its soundproof property due to the occurrence of the closed cells. Therefore, a combined theoretical model of Biot’s theory and acoustic field equations has been developed to predict the sound transmission loss (STL) in the mass control region. Five NBR-PVC closed-cell composites with different parameters were selected to verify the prediction model. Their STL measurement values were compared with the data calculated separately by the theoretical model and the Mass Law, whether under normal incidence or under random incidence. The results show that the Mass Law overestimates the sound insulation values of closed-cell porous material. STL prediction values from the theoretical model have more acceptable agreements to the measurement data than those from the Mass Law. The average deviation rates of the theoretical model are less than 4% under the normal incidence condition and are about 2.9% under the random incidence condition. Full article

Wellbore instability during drilling in soft formations often leads to unwanted hydraulic fractures and lost circulation, resulting in non-productive time and elevated costs. The fracture initiation pressure (FIP) and fracture propagation pressure (FPP) are critical for managing these risks, particularly in narrow mud weight windows, yet industrial models overlook post-plugging stress behaviors at plug locations, where changes in stress concentration may initiate secondary fractures. This study introduces a fully coupled hydro-mechanical plane-strain (KGD) finite element model to examine fluid diffusion and deformation in fractured formations, emphasizing plastic and poroelastoplastic effects for wellbore strengthening. Fluid flow in the fracture follows lubrication theory for incompressible Newtonian fluids, while Darcy’s law governs porous media diffusion. Rock deformation adheres to Biot’s effective stress principle, extended to poroelastoplasticity via the Mohr–Coulomb criterion with associative flow. Simulations yield fracture dimensions, fluid pressures, in situ stress changes, and principal stresses during propagation and plugging, for both plastic and poroplastic cases. A new yield factor is proposed, derived from the Mohr–Coulomb criterion, that quantifies the risk of failure and reveals that fracture tips resist propagation through plastic and poroelastoplastic deformation, with the poroelastoplastic coupling amplifying back-stresses and dilation after plugging. Pore pressure evolution critically influences the fracture growth and plugging efficiency. These findings advance wellbore strengthening by optimizing lost circulation material plugs, bridging the gaps from elastic and poroelastic models, and offer practical tools for safer and more efficient plugging in soft rocks through modeling. Full article

During drilling in fractured formations, wellbore instability issues such as fluid loss and collapse frequently occur, severely compromising drilling safety. Traditional criteria such as Mohr–Coulomb often fail to adequately account for fracture effects, leading to inaccurate collapse pressure predictions. Taking the Tahe Oilfield as a case study, this research develops an enhanced model for predicting wellbore collapse pressure in fractured formations. Based on principles of elastic mechanics and Biot’s effective stress theory, a stress distribution model around deviated wellbores is established. The single weak plane strength criterion is integrated with the Mohr–Coulomb criterion to characterize failure mechanisms in both fractured zones and intact rock matrix. Newton’s iterative method, implemented in MATLAB, is employed to solve for collapse pressure, and a sensitivity analysis is conducted to evaluate the influence of factors such as in situ stresses and fracture orientation. A case study from Well THX demonstrates that neglecting fractures results in a symmetrical collapse pressure profile and an unduly narrow safe mud weight window. In contrast, accounting for fractures significantly increases the required mud weight and identifies an optimal azimuth range for enhancing wellbore stability. The Mohr–Coulomb criterion is shown to underestimate the necessary mud weight, which aligns with actual wellbore collapse incidents encountered during drilling. The single weak plane criterion offers more accurate predictions, recommending a higher minimum mud density and an optimized well trajectory to mitigate drilling risks. These findings offer theoretical and practical guidance for mitigating wellbore instability in fractured formations. Full article

This paper investigates the influence of groundwater level fluctuations on the vibration response and isolation performance of saturated soil foundations under moving loads. A coupled model consisting of an overlying elastic layer and a saturated half-space is established, with water level variation simulated by adjusting the elastic layer thickness. Using Biot’s theory and Fourier transforms, the dynamic response is solved analytically and validated numerically via COMSOL6.0 simulations with perfectly matched layers. Results indicate that the groundwater level significantly affects wave propagation: deeper water levels lead to responses resembling an elastic half-space, while rising water levels amplify surface displacement due to wave reflection at the saturation interface. As water levels approach the surface, behavior converges to that of a fully saturated foundation. P-wave resonance at certain water levels reduces isolation effectiveness. Furthermore, isolation performance is sensitive to load frequency, soil permeability, and trench dimensions. These findings offer valuable insights for designing vibration mitigation measures in environments with variable groundwater conditions. Full article

This study incorporates a nonlinear seepage relationship into Biot’s consolidation theory and simulates the consolidation of a single vertical drain under vacuum preloading using the finite element method. The model, simplified via the equal-strain assumption, is validated against theoretical predictions. Under the axisymmetric Biot’s framework, consolidation behavior is analyzed in detail. The results show that in the early stages of consolidation, excess pore water pressure in the vicinity of the prefabricated vertical drain (PVD) does not fully dissipate and may even increase, indicating the occurrence of the Mandel–Cryer effect. As the consolidation process advances, the consolidation front gradually extends outward, and the void ratio near the PVD decreases rapidly, leading to the formation of a clogging zone. In contrast, the reduction in the void ratio in the non-clogging region is relatively slow. The progressive development of the clogging zone significantly impedes the overall consolidation rate. Furthermore, this study explores the influence of key parameters—including the compression index, permeability coefficient, well diameter ratio, smear effect, and well resistance—on the formation of the clogging zone and the Mandel–Cryer effect. Full article

This paper presents a finite element implementation of a fractional rheological consolidation model in ABQUS, in which the fractional Merchant model governs the mechanical behavior of the soil skeleton, and the water flow is controlled by the fractional Darcy’s law. The implementation generally involves two main parts: subroutine-based fractional constitutive models’ development and their coupling. Considering the formal similarity between the energy equation and the mass equation, the fractional Darcy’s law was implemented using the UMATHT subroutine. The fractional Merchant model was then realized through the UMAT subroutine. Both subroutines were individually verified and then successfully coupled. The coupling was achieved by modifying the stress update scheme based on Biot’s poroelastic theory and the effective stress principle in UMAT, enabling a finite element analysis of the fractional consolidation model. Finally, the model was applied to simulate the consolidation behavior of a multi-layered foundation. The proposed approach may serve as a reference for the finite element implementation of consolidation models incorporating a fractional seepage model in ABAQUS. Full article

Monopile foundation is an important foundation form for offshore wind turbines, and the stability of the seabed around it is affected by the combined effects of wave and pile vibration. Based on the Biot consolidation theory and elastoplastic constitutive model, a multi-physical field coupling model of wave–vibration–seabed–monopile is constructed, and the dynamic characteristics of seabed pore pressure around the monopile under the joint action of wave–vibration are systematically investigated, and the influences of waves, vibrations, and seabed parameters on the distribution of pore pressure amplitude are analysed in depth. The results show that the increase in wave incident energy will increase the seabed wave pressure, and the suction and pressure generated by pile vibration will change the soil force state; the coupling of waves and vibrations results in pile displacement difference, causing the seabed pore pressure dissipation depth dissimilarity, and the peak relative amplitude of pore pressure and the peak of vibration displacement are in a linear relationship; the wave parameters and seabed characteristics have a significant effect on the change in pore pressure amplitude distribution. Full article

The dynamic interaction between shallow cylindrical tunnels with grouting reinforcement zones and saturated poroelastic medium under Rayleigh surface wave excitation is investigated. Employing the wave function expansion method within the framework of Biot theory, the analytical solution is derived in the frequency domain. A comprehensive parametric analysis evaluates the influence of critical parameters—including input frequency, the stiffness and thickness ratios between the tunnel lining and grouting zone, as well as tunnel burial depth—on the dynamic behavior of the composite structure. The spatial distributions of dynamic stress concentration factors and pore pressure concentration factors obtained in this study may offer critical insights for optimizing seismic resilience design in tunnel engineering. Full article

We draw connections between eight different theories used to describe microscopic (atomic) and macroscopic (seismological) scales. In particular, we show that all these different theories belong to a particular case of a single partial differential equation, allowing us to gain new physical insights and draw connection among them. With this general understanding, we apply the micropolar theory to the description of shear-wave dispersion in marine sediments, showing how we can reproduce observations by only using two micropolar parameters in contrast to the seventeen parameters required by modifications of Biot’s theory. We next establish direct connections between the micro (laboratory) and macro (seismological) scales, allowing us to predict (and confirm) the presence of post-perovskite in the lowermost mantle based on laboratory experiments and to predict the characteristic length $L_c$ at which shear deformation becomes significant at seismological scales in the lowermost mantle. Full article

This study investigates the seabed response induced by wave shoaling and breaking on a sloping seabed through numerical modeling. A coupled approach is employed, integrating a Reynolds-Averaged Navier–Stokes (RANS) wave model with a poro-elastic soil model based on Biot’s consolidation theory. The wave model incorporates a stress-$\omega$ turbulence model to mitigate the tendency to overestimate turbulence intensity during wave breaking. The numerical simulations capture key hydrodynamic processes such as wave transformation, breaking-induced turbulence, and the evolution of pore pressure and soil stress within the seabed. Model validation against analytical solutions and experimental data confirms the reliability of the numerical framework. The study simulates two types of breaking waves: spilling and plunging breakers. The results indicate that wave breaking significantly alters the spatial and temporal distribution of pore pressures and effective stresses in the seabed. In particular, the undertow generated by breaking waves plays an important role in modulating seabed responses by inducing asymmetric pore pressure and stress distributions. The influence of soil permeability and the degree of saturation on wave-induced responses is investigated, showing that higher permeability facilitates deeper pore pressure penetration, while under lower permeability conditions, a higher degree of saturation significantly enhances pore pressure transmission. Additionally, different breaker types exhibit distinct seabed response characteristics, with plunging breakers causing stronger nonlinear effects. These findings provide valuable insights for the design and stability assessment of marine and coastal infrastructure subjected to dynamic wave loading. Full article

This paper presents the development and principle of operation of resource-saving overcurrent protection, which is an alternative to traditional current protections. The experiments were used to study the electromagnetic field for the protection of electrical installations connected to the cells of complete switchgears, voltage 6–10 kV, without the use of conventional protections with metal-core current transformers. As is known, such current transformers (CTs) have significant weight and dimensional parameters and high price costs. The method of research is comparison of the developed protection with traditional current protections made using traditional measuring current transformers. The scientific novelty of this work consists of the developmental theory of the construction of protection for inductive coils based on the measurement of electromotive force values in different modes and points in the simulation of a three-phase short circuit inside the cell of the complete switchgear. The dependence of magnetic induction on the position of the inductive coil inside the cell has been found. It has been shown that the simplest formula of the Biot–Savart–Laplace law can be used to calculate them. This paper presents and describes the conducted experiments with their methodology. As a result of the industrial application of such protections, the act of implementation of the patent for the invention of an industrial enterprise is presented. The selection of settings of resource-saving protection is presented, as well as a feasibility study of the presented protection in comparison with conventional protection. This paper consists of the following sections: The Materials and Methods section describes the methodology used to achieve the purpose of the research. The Experiments section describes all the experiments conducted to achieve the purpose of the research. The Results section presents the results of the conducted experiments, an evaluation of the use of inductive coils in relay protection, an example of calculating the selection of the settings of parameters of resource-saving protection, a presentation of the patent for the invention, and a presentation of the feasibility study of the effectiveness of the considered resource-saving protection on inductive coils. The Conclusions section presents the result of this work, which is the creation of resource-saving protection on inductance coils. The References section presents a list of the sources used. Full article

Analyzing the mechanisms of soil instability in tunnels due to sudden water ingress is essential for construction safety. This kind of problem belongs to the category of seepage deformation, mostly due to the near tunnel range of water pipeline blowing cracks and heavy rainfall flooding rainwater into the tunnel. Distinguished from general infiltration behavior, the relevant problems have the characteristics of rapid occurrence and short action time. This study develops a 3D fluid–solid coupling model for soil deformation in tunnels with water ingress, grounded in Biot’s theory and Darcy’s law while considering water level variations within the tunnel. The governing equations are discretized in space and time, and the model’s accuracy is validated through comparison with actual measurements from a Zhengzhou subway project. The study analyzes pore pressure, stress-deformation responses, and surface settlement patterns in surrounding soil and rock mass under soil–water coupling. The findings show that (1) the tunnel cavern, as a seepage source, has minimal impact on the lateral settlement trough width, while seepage mainly affects the vertical deformation of surrounding rock; (2) pressure dissipation exhibits hysteresis in clay strata; (3) water ingress increases soil saturation and decreases effective stress, resulting in persistent surface settlement until drainage. There is a minimal discrepancy between model-calculated and measured settlements. Full article

Concrete stress is a key factor influencing the operational safety of concrete dams, and understanding the true distribution and variation of stress is a major research focus in the field of dam engineering. In the heel region of the dam, internal voids in the concrete may allow external water infiltration under high hydraulic head, leading to changes in the concrete’s elastic modulus and Biot coefficient. These changes, in turn, affect the effective stress experienced by the concrete. Consequently, the measured stress in the heel and toe regions may differ from conventional understanding and standard calculation methods for dam stresses. This is particularly evident in the following aspects: after water impoundment, compressive stress in the dam heel is higher than in the dam toe, with the heel stress exceeding the calculated value by a significant margin, and the variation in stress during the impoundment process being smaller than the calculated value. To address these issues, this paper proposes a theoretical method for measuring the Biot coefficient of concrete through experimental testing and innovatively develops the corresponding experimental equipment. This equipment can accurately simulate the conditions of the dam under different water depths (confining pressures) and measure the deformation of concrete caused by changes in water depth. Based on this equipment, tests were conducted on the elastic modulus and Biot coefficient of dry and saturated concrete specimens under different confining pressures. The Voigt–Reuss–Hill mixed average modulus formula was applied to calculate the elastic modulus of the concrete matrix, exploring the influence of pore water on the mechanical properties of the concrete. The results indicate that the pore water inside the concrete increases its equivalent elastic modulus during the testing process. In numerical simulations of the dam, this increased modulus due to pore water is often overlooked, leading to an underestimation of the results. This partially explains why the measured compressive stress in the dam heel consistently exceeds the calculated values. According to the Biot coefficient calculation theory proposed in this paper, the Biot coefficient of concrete varies with its water content. The Biot coefficient is lower in specimens with high water content compared to those with low water content. Using the Voigt–Reuss–Hill mixed average modulus formula, the elastic modulus of the concrete matrix obtained from the tests was found to be 28 $\mathrm{G}\mathrm{P}\mathrm{a}$, which is in good agreement with the results from regression analysis. These findings are of significant importance for the safe operation of concrete dam engineering. Full article

The efficacy of silencers in reducing piping noise is contingent upon the specific installation and operating environment. Among the various forms of silencers, the acoustic characteristics of dissipative silencers with sound-absorbing materials attached internally exist in an area that is difficult to explain by existing theories. This is dependent upon the specific type and placement of the attached sound-absorbing materials. This paper presents a methodology for calculating the acoustic transmission loss (TL) of a cylindrical silencer filled with a multilayer poroelastic material, employing the mode-matching method. To describe the numerical process of treating waves propagating within a poroelastic material and determine the modes in accordance with the boundary conditions necessary for analyzing the acoustic performance of the silencer, the Biot model and the Johnson–Champoux–Allard–Lafarge model were employed. The obtained modes were utilized to calculate the acoustic TL of silencers filled with single, double, and triple layers of poroelastic materials. In particular, the results obtained for the single layer were validated by comparing them with the results of a finite element analysis, and the results obtained for multiple layers with the same material were validated by comparing them with the equivalent single-layer results. Moreover, the results of the numerical calculations of the acoustic TLs of the silencer for three distinct types of poroelastic materials, including those with varying degrees of frame rigidity or softness, were compared, and the acoustic characteristics were analyzed in relation to the intrinsic properties of the materials and their arrangement. It is anticipated that the methodology presented in this paper will facilitate the design of silencers using poroelastic materials in accordance with the specific requirements of users or designers by allowing for a comprehensive consideration of the thickness of layers and the arrangement of materials. Full article
