To address the limited maneuverability and tracking accuracy of autonomous four-wheel steering (4WS) vehicles during parallel parking in confined spaces, an adaptive linear time-varying model predictive control (LTV-MPC) strategy for integrated path tracking and steering coordination is proposed. Different from conventional MPC-based parking controllers with fixed weighting parameters and steering allocation schemes, the proposed method introduces an adaptive weighting mechanism that adjusts the tracking-error weights online according to the yaw-angle error, thereby improving the balance between tracking accuracy and control smoothness throughout the parking process. A hyperbolic tangent (tanh)-based steering allocation strategy is further developed to realize smooth transitions between reverse-phase steering and posture adjustment, while a PID compensation module is incorporated to improve steering command execution. A kinematic single-track model considering Ackermann steering geometry is established to formulate the prediction model of the controller. MATLAB/Simulink and CarSim co-simulation, together with hardware-in-the-loop (HIL) experiments, are conducted to evaluate the proposed control strategy. The experimental results demonstrate that the proposed method achieves more accurate path tracking, smoother steering responses, and higher parking stability than conventional controllers under typical parallel parking scenarios. The proposed strategy provides an effective and practical control framework for improving the low-speed maneuverability and path-tracking performance of autonomous 4WS vehicles. Full article

Reliable execution of a planned path is essential for autonomous mobile robots and vehicle-like robot platforms. This study experimentally evaluates the path-following performance of a scaled Ackermann-steered autonomous vehicle under different localization and controller configurations. A QCar 2 platform was operated in a hardware-in-the-loop configuration using a Pure Pursuit lateral controller and a proportional-integral longitudinal speed controller. Two localization approaches were compared in the closed control loop: a kinematic localization method and an Extended Kalman Filter. A full factorial ($2^4$) experimental design included the localization method, reference-path geometry (rounded rectangle and figure-eight), commanded speed (0.4 and 0.7 m/s), and Pure Pursuit look-ahead distance (0.3 and 0.6 m), resulting in 16 test configurations. Realized vehicle trajectories were recorded independently using an OptiTrack motion-capture system and compared with the planned paths. Path-following performance was assessed using cross-track error, symmetric Hausdorff distance, and mean bidirectional nearest-neighbor distance. Within the tested runs, differences between the localization variants were small, with mean (${\mathrm{CTE}}_{\mathrm{RMS}}$) values of 0.0929 m and 0.0921 m for the Extended Kalman Filter and kinematic variants, respectively. In contrast, substantially larger differences in trajectory deviations and traveled-path length were observed across path geometries, look-ahead distances, and commanded speeds. The figure-eight path, particularly at the shorter look-ahead distance and higher speed, showed the largest deviations and path-length excess within the tested configurations. The results show that, under the tested laboratory conditions, path-execution quality was more strongly associated with controller tuning and planned-path geometry than with the investigated localization variant. The study provides experimentally validated guidance for selecting path-following parameters for Ackermann-steered autonomous mobile robots. Full article

Distributed-drive all-wheel steering (AWS) six-axle vehicles possess distinct advantages in power performance, maneuverability, and environmental adaptability. However, when navigating tight curves under sudden low-friction road conditions, their inherent long wheelbase and strong inter-axle coupling typically lead to compromised spatial maneuverability, trajectory decoupling between the vehicle nose and tail, and lateral dynamic instability. To resolve these critical issues, this paper proposes a geometry–dynamics coupled lateral control scheme with adaptive speed planning for six-axle vehicles under confined spatial and low-friction conditions by seamlessly fusing a dual-point preview mechanism with multi-mode steering mappings. First, a three-degree-of-freedom nonlinear vehicle dynamic model incorporating longitudinal, lateral, and yaw motions is constructed, alongside the formulation of extended Ackermann kinematic steering manifolds for three distinct modes: rear-axle steering, center steering, and crab steering. To rectify the kinematic under-constrained deficiency inherent in conventional single-point preview path-tracking architectures, a joint front-and-rear dual-point preview constraint mechanism is established. This framework permits the quantitative derivation of a spatial geometric reconstruction method for the instantaneous center of rotation (ICR), which algebraically maps the ideal ICR trajectory requirements onto the physical constraints of the selected steering modes. Consequently, complete geometric constraints on both the front and rear trajectories are achieved, enabling active compression of the vehicle’s turning radius. Furthermore, to handle sudden low-friction disturbances, road adhesion limits and vehicle lateral stability boundaries are explicitly incorporated to design a multi-scale adaptive preview distance dynamic scaling mechanism driven by dynamic safety margin corrections. By adaptively scaling the spatial constraint at the geometric layer, this mechanism proactively mitigates nonlinear tire sideslip force saturation via feedforward action, thereby preventing tracking divergence and catastrophic sideslip instability under physical adhesion limits. Co-simulations based on the high-fidelity TruckSim-Simulink platform demonstrate that, in standard curves, the proposed dual-point preview manifold fusion strategy reduces the minimum turning radius by 9.6–10.1% and shortens the cornering transit time by 7.5% compared with the traditional single-point preview mechanism. By actively constraining the front and rear trajectories, the trajectory decoupling between the vehicle nose and tail is effectively resolved. Under narrow-lane scenarios, the maximum lateral error is restricted within 0.78 m, representing a 37.6% reduction relative to the single-point preview, while the maximum steering angle of the front axle is compressed by approximately 18%, thereby significantly improving spatial passability and preventing intermediate body interference. Most notably, under low-friction surface disturbances, the dynamic-margin-corrected adaptive preview adjustment mechanism exhibits remarkable robustness, constraining the maximum lateral tracking error to within 0.68 m. The proposed geometry–dynamics coupled lateral control strategy successfully elevates the tight-curve maneuverability of heavy transport vehicles while concurrently reinforcing their lateral dynamic stability under limit combined spatial and adhesion constraints. Full article

To address the prevalent issues of slow convergence, low exploration efficiency, and large value estimation bias in traditional Deep Q-Networks for intelligent vehicle path planning, this paper proposes an improved Dueling Double Deep Q-Network (D3QN) path-planning method guided by the Dynamic Window Approach (DWA) heuristic. The Dueling Double DQN architecture decouples state value and action advantage representations, while the dual estimator of Double DQN mitigates Q-value overestimation. A Prioritized Experience Replay (PER) mechanism samples transitions non-uniformly based on Temporal Difference error with importance sampling correction, improving the reuse of critical samples and training stability. DWA evaluation criteria are transformed into dense heuristic reward signals, enabling the agent to receive continuous multi-dimensional guidance during exploration without executing online trajectory optimization. The environment augments the sparse navigation objective with a Chebyshev goal-progress term motivated by potential-based reward shaping theory together with auxiliary DWA-style channels. The policy-invariance property of potential-based shaping is referenced only for the goal term added to the sparse task reward rather than for the full composite training return. A continuous Ackermann steering kinematic model with a pure-pursuit path-tracking controller is adopted for deployment to ensure executable trajectories under non-holonomic constraints. The proposed method (DWA-D3QN) is systematically evaluated against sparse-reward D3QN, PBRS-guided D3QN, DQN, DDQN, Dueling DQN, APF-DQN, PPO, SAC, TD3, A*, and classical DWA in a grid map environment with static and dynamic obstacles. Results are reported with statistical significance over multiple random seeds. Under complex difficulty, DWA-D3QN achieves a success rate of 94.1 ± 3.4% with a collision rate of 5.9 ± 3.4% over 15 seeds, representing improvements of 64.1 and 8.4 percentage points over the sparse-reward and PBRS-guided D3QN baselines, respectively. Ablation experiments reveal the differentiated contributions of clearance, heading, and velocity shaping terms: clearance awareness provides the strongest single contribution, heading alignment reinforces directional guidance, and velocity regularization refines trajectory quality under the joint constraints of the former two. The full composite reward achieves the lowest variance among all evaluated DRL methods, confirming enhanced training stability. Comparisons with PPO, SAC, and TD3 confirm the statistically significant advantages of the proposed framework (PPO: $p=0.0010$, SAC: $p=0.0007$, TD3: $p=0.0024$). ROS/Gazebo validation with an Ackermann-steered vehicle achieves a success rate of 96.0% with a collision rate of 4.0% over 50 trials, further confirming the applicability of the learned policy in continuous-state environments with realistic vehicle kinematics. Full article

This study proposes an adaptive multi-mode graph search algorithm that integrates spatial previewing with terminal analytics to address node proliferation and terminal oscillation in path planning for four-wheel independent steering (4WIS) vehicles under complex, low-speed conditions. By employing line-of-sight checking and the Douglas–Peucker algorithm to extract the environmental topological skeleton, the proposed method generates Predictive Spatial Profiling (PSP) fields that precisely quantify channel safety margins. Departing from conventional soft-weight arbitration, a dynamic driving state machine leverages these rigid spatial constraints to deterministically prune redundant expansion branches—including Ackermann steering, crab steering, and in-place rotation—prior to node generation. Furthermore, a comprehensive cost function incorporating a mode-switching penalty and a gradient-heading heuristic is formulated to accelerate search convergence. To circumvent reliance on traditional empirical distance thresholds, a topology-triggered, multi-dimensional terminal analytical strategy is introduced, enabling a seamless transition from discrete search node expansion to continuous curve generation near the target. Extensive simulations demonstrate that the proposed algorithm reduces both the node expansion scale and optimization time by over 80% compared with conventional unconstrained methods, while effectively mitigating chaotic motion-mode transitions. Ultimately, integrating environmental spatial dimensionality reduction with terminal analytics yields a highly efficient and smooth global path-planning solution for 4WIS vehicles. Full article

Modern logistics and manufacturing environments simultaneously demand mobility platforms that are compact enough to navigate narrow aisles and powerful enough to transport oversized or heavy components. We previously developed a compact Steering–Drive–Suspension (SDS) module that integrates steering, in-wheel drive, and suspension within a single wheel envelope, achieving $\pm {90}^{\circ }$ wide-angle steering with a single actuator. The present paper extends that hardware-centric work by treating the two-wheel (2WD) configuration assembled from two SDS modules as the unit module of the platform, building a four-wheel (4WD) operation by coupling two such 2WD units, and developing a unified balance and impedance-based control scheme. We derive a cart–pole inverted-pendulum model for the 2WD configuration and a planar 2-DOF bicycle model for the coupled and cooperative configurations, with full controllability proof and quantitative LQR robustness margins. Three Python 3.12 based scenarios validate the framework: (i) a 2WD inverted-pendulum tracking task, (ii) a forward and lateral relocation maneuver compared across SDS Crab, Ackermann, and four-wheel-steering modes, and (iii) cooperative transport of a $100\mathrm{kg}$ steel plate by two impedance-coupled 2WD units. Across all scenarios the proposed controllers achieve sub-centimetre tracking gap, pitch deviation within $\pm 2^{\circ }$, and well-damped cooperative behavior without payload sloshing. The results substantiate the central design claim that the SDS module’s compactness enables a single hardware platform to act simultaneously as an autonomous small-payload mover, a building block of a 4WD platform, and a cooperative agent for oversized loads. Full article

This study investigates the dimensional synthesis and optimization of multi-link steering mechanisms—namely, the leading and mixed-leading double four-bar configurations—for front-wheel-drive vehicles. To overcome the accuracy limitations of conventional steering at large angles (up to 70°), a comparative metaheuristic approach is employed, utilizing two popular metaheuristic optimizations, Improved Particle Swarm Optimization (IPSO) and Differential Evolution with golden ratio (DE-gr), to optimize the geometric parameters of these complex eight-bar steering systems. Using a track-to-wheelbase ratio of 0.5, the optimization minimizes a mean-squared structural-error objective function integrated with Grashof mobility constraints. The optimized mechanisms are validated via ADAMS kinematic simulations and further analyzed in MATLAB R2021 regarding steering accuracy, transmission angles, and mechanical advantage. The results reveal a distinct performance trade-off: mixed-leading configurations achieve superior geometric precision and mass reduction due to shorter link lengths, with IPSO yielding the highest accuracy. Conversely, leading-type mechanisms provide a more linear and stable mechanical advantage, ensuring predictable force transmission. While DE-gr exhibits faster convergence across both variants, both algorithms effectively exploit the complex parameter space of multi-link systems. Ultimately, this metaheuristic optimization-based approach offers a superior and robust framework for the dimensional synthesis of high-performance multi-link steering mechanisms, surpassing the constraints of traditional gradient-based methods. Our findings recommend the mixed-leading configuration for precision-focused applications and the leading configuration for scenarios requiring consistent mechanical performance. Full article

To effectively reduce traffic accidents caused by inner wheel differences during large vehicles’ right turns at intersections, this study proposes a quantitative method to calculate the range of inner wheel difference areas. Typical intersections in Nanjing and Taiyuan were selected for field tests using rigid-body and articulated vehicles with different parameters. Dynamic data during turning were collected, revealing a significant linear correlation between the number of steering wheel rotations and the geometric parameters of the intersection as well as the structural dimensions of the vehicle. On the basis of Ackermann’s steering geometry theory, trajectory prediction models for both vehicle types were constructed. Verification with actual trajectory data extracted by Tracker software revealed that the rigid-body vehicle model had a maximum relative error of 8.12% and an average of 5.39%, whereas the articulated vehicle model had a maximum of 8.32% and an average of 5.12%, confirming high model accuracy. A Python-based visualization program for inner wheel difference areas was developed. The results provide technical support for scientifically marking warning areas at intersections and improving the refined management of traffic safety. Full article

This paper examines the impact of symmetry and asymmetry on the dynamic modeling and nonlinear control of a mobile robot with Ackermann steering geometry. A neural network-based residual model is incorporated as a novel control enhancement. This study presents a control-oriented formulation that addresses both idealized symmetric dynamics and real-world asymmetric behaviors caused by actuator imperfections, tire slip, and environmental variability. Using the Euler–Lagrange formalism, the robot’s dynamic equations are derived, and a modular simulation framework is implemented in MATLAB/Simulink R2022a, that incorporates distinct steering and propulsion subsystems. Symmetric elements, such as the structure of the inertia matrix and kinematic constraints, are contrasted with asymmetries introduced through actuator lag, unequal tire stiffness, and nonlinear friction. A residual neural network term is introduced to capture unmodeled dynamics and improve the robustness. The simulation results show that the control strategy, originally developed under symmetric assumptions, remains effective when adapted to systems exhibiting asymmetry, such as actuator delays and tire slip. Explicitly modeling these asymmetries enhances the precision of trajectory tracking and the overall system robustness, particularly in scenarios involving varied terrain and obstacle-rich environments. Full article

To improve the stability and safety of electric vehicles during medium-to-high-speed cornering, this paper investigates torque differential control for dual rear-wheel hub motor drive systems, extending beyond traditional speed control based on the Ackermann steering model. A nonlinear three-degree-of-freedom vehicle dynamics model incorporating the Dugoff tire model was established. By introducing the maximum correntropy criterion, an unscented Kalman filter was developed to estimate longitudinal velocity, sideslip angle at the center of mass, and yaw rate. Building upon the speed differential control achieved through Ackermann steering model-based rear-wheel speed calculation, improvements were made to the conventional exponential reaching law, while a novel switching function was proposed to formulate a new sliding mode controller for computing an additional yaw moment to realize torque differential control. Finally, simulations conducted on the Carsim/Simulink platform demonstrated that the maximum correntropy criterion unscented Kalman filter effectively improves estimation accuracy, achieving at least a 22.00% reduction in RMSE metrics compared to conventional unscented Kalman filter. With torque control exhibiting higher vehicle stability than speed control, the RMSE values of yaw rate and sideslip angle at the center of mass are reduced by at least 20.00% and 4.55%, respectively, enabling stable operation during medium-to-high-speed cornering conditions. Full article

Compound steering technology has been extensively adopted in military logistics and related applications, owing to its superior maneuverability and enhanced stability compared to conventional systems. To enhance the steering efficiency and dynamic response of distributed-drive unmanned platforms under low driving torque conditions, this study investigates their unique compound steering system. Specifically, a compound steering dynamics model is established, and a hierarchical stability control strategy, along with a model predictive control-based trajectory tracking algorithm, are innovatively proposed. First, a compound steering platform dynamics model is established by combining the Ackermann steering and skid yaw moment methods. Then, a trajectory tracking controller is designed using model predictive control algorithm. Finally, the additional yaw moment is calculated based on the lateral velocity error and yaw rate error, with stability control allocation performed using a fuzzy control algorithm. Comparative hardware-in-the-loop experiments are conducted for compound steering, Ackermann steering, and skid steering. The experimental results show that the compound steering technology enables unmanned platforms to achieve trajectory tracking tasks with a lower torque, faster speed, and higher efficiency. Full article

This study investigates the dimensional synthesis of steering mechanisms for front-wheel-drive, two-axle, four-wheeled vehicles using two metaheuristic optimization algorithms: Differential Evolution with golden ratio (DE-gr) and Improved Particle Swarm Optimization (IPSO). The vehicle under consideration has a track-to-wheelbase ratio of 0.5 and an inner wheel steering angle of 70 degrees. The mechanisms synthesized include the Ackermann steering mechanism and two variants (Type I and Type II) of the Watt-I six-bar steering mechanisms, also known as central-lever steering mechanisms. To ensure accurate steering and minimize tire wear during cornering, adherence to the Ackermann steering condition is enforced. The objective function combines the mean squared structural error at selected steering positions with a penalty term for violations of the Grashoff inequality constraint. Each optimization run involved 100 or 200 iterations, with numerical experiments repeated 100 times to ensure robustness. Kinematic simulations were conducted in ADAMS v2015 to visualize and validate the synthesized mechanisms. Performance was evaluated based on maximum structural error (steering accuracy) and mechanical advantage (transmission efficiency). The results indicate that the optimized Watt-I six-bar steering mechanisms outperform the Ackermann mechanism in terms of steering accuracy. Among the Watt-I variants, the Type II designs demonstrated superior performance and convergence precision compared to the Type I designs, as well as improved results compared to prior studies. Additionally, the optimal Type I-2 and Type II-2 mechanisms consist of two symmetric Grashof mechanisms, can be classified as non-Ackermann-like steering mechanisms. Both optimization methods proved easy to implement and showed reliable, efficient convergence. The DE-gr algorithm exhibited slightly superior overall performance, achieving optimal solutions in seven cases compared to four for the IPSO method. Full article

Autonomous driving solutions for agricultural machinery have advanced rapidly; however, large-wheeled harvesters present unique challenges compared to traditional vehicles. Specifically, the 5.4 m cutting width, 9.2 m minimum turning diameter, and rear-wheel–steered configuration demand specialized path tracking and steering methods. To address these challenges, this study developed an integrated system combining feedforward PID and Look-Ahead Ackermann (LAA) algorithms with sensors, actuators, and an embedded control platform. Field experiments indicated that the system maintained an average lateral deviation of approximately 5 cm on straight-line paths, with slightly larger errors observed only during turning or alignment maneuvers. Additionally, a “three-cut” steering method was implemented, which enhanced path tracking accuracy and prevented crop damage at headland turns. Successful field tests confirmed the robustness of the developed system, highlighting its practical potential for production-level autonomous harvesting. Full article

This article presents the instrumentation of an electronic–mechanical differential prototype, consisting of an arrangement of three throttles to operate two hub motors on the rear wheels of an electric vehicle. Each motor is connected to its respective throttle, while a third throttle is connected in series with the other two. This configuration allows for speed control during both rectilinear and curvilinear motion, following Ackermann differential geometry, in a simple manner and without the need for complex electronic systems that make the electronic differential more expensive. The differential throttles are strategically positioned on the mass bars connected to the steering system, ensuring that the rear wheels maintain the appropriate differential ratio. For this reason, it is referred to as an “electronic–mechanical differential”. Additionally, this method can be extended to a four-wheel differential system. Full article

The recent growth in e-commerce has significantly increased the demand for indoor delivery solutions, highlighting challenges in last-mile delivery. This study presents a time-interval-based collision detection method for Four-Wheel Independent Steering (4WIS) mobile robots operating in human-shared indoor environments, where traditional path following algorithms often create unpredictable movements. By integrating kinematic-based robot trajectory calculation with LiDAR-based human detection and Kalman filter-based prediction, our system enables more natural robot–human interactions. Experimental results demonstrate that our parallel driving mode achieves superior human detection performance compared to conventional Ackermann steering, particularly during cornering and high-speed operations. The proposed method’s effectiveness is validated through comprehensive experiments in realistic indoor scenarios, showing its potential for improving the efficiency and safety of indoor autonomous navigation systems. Full article
