The use of adhesive joints in naval applications requires a thorough understanding of their fatigue performance. This paper reports on the fatigue experiments performed on double cantilever beam specimens with thick adhesive bondline manufactured under shipyard conditions. The specimens have an initial crack at the steel–adhesive interface and are tested in unaged, salt-spray-aged and immersion-aged conditions to determine the interface mode I fatigue properties. The strain energy release rate is calculated using the Kanninen–Penado model, and the fatigue crack growth curve is determined using a power law model. The crack growth rate slope for salt-spray-aged specimens is 16.5% lower than for unaged specimens, while that for immersion-aged specimens is 66.1% lower and is shown to be significantly different. The fracture surfaces are analyzed to identify the failure mechanisms and the influence of the aging process on the interface properties. Since the specimens are manufactured under shipyard conditions, the presence of voids and discontinuities in the adhesive bondline is observed and as a result leads to scatter. Hence, Bayesian linear regression is performed in addition to the ordinary least squares regression to account for the scatter and provide a distribution of plausible values for the power law coefficients. The results highlight the impact of aging on the fatigue property, underscoring the importance of considering environmental effects in the qualification of such joints for marine applications. Full article

Copper joints are indispensable in electronics and the electrical power industry due to their predominant usage in battery pack manufacturing for electric vehicle). Traditional joining methods are often limited by oxidation-related challenges. Recent efforts have focused on addressing these limitations by employing solid-state techniques like ultrasonic welding (USW) for joining similar metals. USW presents attractive advantages such as a lower processing temperature and shorter weld time. This study investigates the ultrasonic welding of Cu-Cu joints with a thickness of 0.5 mm, focusing on both mechanical and metallurgical properties. The influence of key process parameters, such as the welding time, pressure and vibration amplitude, was examined in relation to the welding energy and lap shear strength. Additionally, the relationship between the input energy and lap shear strength was explored. A Pareto chart analysis revealed the standardized effects of these parameters on the welding energy and average lap shear strength. The welding time had a significant influence on the welding energy, while the vibration amplitude had the greatest impact on the joint strength. Longer weld times of 2.50 to 4 s yielded a higher lap shear strength, averaging up to 2.30 kN. Notably, a higher lap shear strength was achieved at lower welding energy levels. Full article

In linear elastic fracture mechanics, the stress intensity factor describes the magnitude of the stress singularity near a crack tip caused by remote stress and is related to the rate of fatigue crack growth. The literature lacks SIF solutions for cracks emanating from a three-dimensional semi-ellipsoidal pit. This study undertakes a comprehensive parametric investigation of the Mode I stress intensity factor ${(K}_I)$ concerning cracks originating from a semi-ellipsoidal pit in a plate. This work utilizes finite element analysis, controlled by Python scripts, to conduct an extensive study on the effect of various pit dimensions and crack lengths on $K_I$. Two cracks in the shape of a circular arc are introduced at the pit mouth perpendicular to the loading direction. The $K_I$ values are calculated using the displacement extrapolation method. The effect of normalized geometric parameters pit-depth-to-pit-width $(a/2c$), pit-depth-to-plate-thickness $(a/t)$, and crack-radius-to-pit-depth $(R/a)$ are investigated. The crack-radius-to-pit-depth $(R/a)$ is found to be the dominating parameter based on correlation analysis. The data obtained from 216 FEA simulations are incorporated into a predictive model using a k-dimensional (k-d) tree and k-Nearest Neighbour (k-NN) algorithm. Full article

WAAM has emerged as a promising technique for manufacturing medium- and large-scale metal parts due to its high material deposition efficiency and automation level. However, its high heat accumulation and complex thermal evolution strongly affect the resulting microstructures and mechanical properties. The heterogeneous and unpredictable nature of these properties hinder the widespread application of WAAM in the steel construction industry. In this study, an artificial neural network (ANN) hardness model is developed, based on a thermal–metallurgical model for mild steel. The objective is to establish non-linear relationships between the input process parameters and the desired output, i.e., hardness. The thermal–metallurgical model utilizes a well-distributed heat source model, a death-and-birth algorithm, and a metallurgical model to simulate the temperature field and to calculate the microstructure phase fraction. The temperature prediction errors at four thermocouple positions are mostly below 20%. Because of the limited experimental data, twenty-five simulation experiments are performed using the L25 orthogonal array based on the Taguchi method. The analysis of variance (ANOVA) reveals that the travel speed has the greatest impact on hardness. With the dataset from the thermal–metallurgical model, an ANN model to predict hardness is developed. A comparison to experimental data shows excellent performance and accuracy, with the Mean Absolute Percentage Error (MAPE) of ANN predictions within 10% of the targeted hardness. Full article

The use of additive manufacturing for metallic materials presents a wide range of possibilities for industrial applications. The technology offers several advantages, including weight optimisation and the ability to create complex geometries. However, because of the inherent characteristics of the manufacturing process, the dimensions of the produced objects are frequently constrained. In some cases, it may be necessary to join two additively manufactured parts together or to join such parts with an existing, conventionally manufactured structure. Evaluating welding processes for joining additively manufactured workpieces is a crucial step in this development. In this work, the welding of additively manufactured powder bed fusion 316L stainless steel components is discussed. The welding processes considered are manual TIG, manual and robotic MIG/MAG and laser welding. All optimised welds were of good quality and did not show any weld imperfections. All welds fulfil the requirements of standard ISO 15614-1 for the tensile and bend test results and for the hardness values. It can be concluded that the investigated processes are feasible for welding additively manufactured parts. Full article

Due to the time-consuming and costly nature of high-cycle fatigue experiments, correlations between fatigue strength and mechanical properties obtained through more simple and fast experiments can be interesting from an economic perspective. This review article aims to provide an overview of such relations established in the open literature from the 1980s to 2023 for conventionally manufactured steel grades. The majority of these models relate fatigue strength at a given fatigue life (often termed “fatigue limit” or “endurance limit”) to ultimate tensile strength, yield strength (both static and cyclic), hardness, elongation, reduction in area, and Charpy impact energy. Relations taking flaws such as nonmetallic inclusions into account are also discussed. Additionally, models predicting S–N curves are provided. The various estimations are presented in tables, together with the materials and test conditions for which they were established. Full article

Additive manufacturing (AM) processes are playing a significant role in several industrial sectors such as construction and machine building industries, involving a wide variety of metallic materials. Among these, the AM of aluminium alloys has developed significantly over the last decade, mainly through Powder Bed Fusion (PBF) and Directed Energy Deposition (DED) processes. Despite the many advantages of AM technology, some large or complex products cannot be produced entirely without the use of conventional manufacturing and joining processes, generally for financial or operational reasons. In this way, the ability to join conventionally and additively manufactured components or parts represents a crucial step towards their future use and the consolidation of conventional and additive manufacturing technologies. Despite the growing interest in AM technologies, there is still a significant lack of information on the joining of conventionally and additively manufactured components. The present work proposes a first review of the literature evaluating the weldability of AM aluminium alloys. The focus is on the use of fusion and solid-state welding processes and analysing the achieved microstructural evolution and mechanical properties. A clear relationship is observed between the AM technology used to produce the part, and the physical principles of the joining process. In addition, the gaps in the literature are highlighted to enable focused future work. Full article

Hydrogen can degrade the mechanical properties of steel components, which is commonly referred to as “hydrogen embrittlement” (HE). Quantifying the effect of HE on the structural integrity of components and structures remains challenging. The authors investigated an X70 pipeline steel through uncharged and hydrogen-charged (notched) tensile tests. This paper presents a combination of experimental results and numerical simulations using a micro-mechanics-inspired damage model. Four specimen geometries and three hydrogen concentrations (including uncharged) were targeted, which allowed for the construction of a fracture locus that depended on the stress triaxiality and hydrogen concentration. The multi-physical finite element model includes hydrogen diffusion and damage on the basis of the complete Gurson model. Hydrogen-Assisted degradation was implemented through an acceleration of the void nucleation process, as supported by experimental observations. The damage parameters were determined through inverse analysis, and the numerical results were in good agreement with the experimental data. The presented model couples micro-mechanical with macro-mechanical results and makes it possible to evaluate the damage evolution during hydrogen-charged mechanical tests. In particular, the well-known ductility loss due to hydrogen was captured well in the form of embrittlement indices for the different geometries and hydrogen concentrations. The limitations of the damage model regarding the stress state are discussed in this paper. Full article

This work addresses the lack of focus on verification and comparison of existing fatigue damage accumulation and life prediction models on the basis of large and well-documented experiment datasets. Sixty-four constant amplitude, 54 two-level block loading, and 27 three-level block loading valid experiments were performed in order to generate an open-access, high-quality dataset that can be used as a benchmark for existing models. In the future, more experiments of various specimen geometries and loading conditions will be added. The obtained dataset was used for a study comparing five (non)linear fatigue damage and life prediction models. It is shown how the performance of several (non)linear damage models is strongly dependent on the considered material dataset and loading sequence. Therefore, it is important to verify models with a broad set of independent datasets, as many existing models show significant bias to certain datasets. Full article

The components of an operational wind turbine are continuously impacted by both static and dynamic loads. Regular inspections and maintenance are required to keep these components healthy. The main bearing of a wind turbine is one such component that experiences heavy loading forces during operation. These forces depend on various parameters such as wind speed, operating regime and control actions. When a wind turbine provides frequency containment reserve (FCR) to support the grid frequency, the forces acting upon the main bearing are also expected to exhibit more dynamic variations. These forces have a direct impact on the lifetime of the main bearing. With an increasing trend of wind turbines participating in the frequency ancillary services market, an analysis of these dynamic forces becomes necessary. To this end, this paper assesses the effect of FCR-based control on the main bearing lifetime of the wind turbine. Firstly, a control algorithm is implemented such that the output power of the wind turbine is regulated as a function of grid frequency and the amount of FCR. Simulations are performed for a range of FCR to study the changing behaviour of dynamical forces acting on the main bearing with respect to the amount of FCR provided. Then, based on the outputs from these simulations and using 2 years of LiDAR wind data, the lifetime of the main bearing of the wind turbine is calculated and compared for each of the cases. Finally, based on the results obtained from this study, the impact of FCR provision on the main bearing lifetime is quantified and recommendations are made, that could be taken into account in the operation strategy of a wind farm. Full article

Acute kidney injury (AKI) is common after pediatric cardiac surgery (CS). Several urine biomarkers have been validated to detect AKI earlier. The objective of this study was to evaluate urine CHI3L1, NGAL, TIMP-2, IGFBP7, and NephroCheck^® as predictors for AKI ≥ 1 in pediatric CS after 48 h and AKI ≥ 2 after 12 h. Pediatric patients (age < 18 year; body weight ≥ 2 kg) requiring CS were prospectively included. Urine CHI3L1, NGAL, TIMP-2, IGFBP7, and NephroCheck^® were measured during surgery and intensive care unit (ICU) stay and corrected for urine dilution. One hundred and one pediatric patients were included. AKI ≥ 1 within 48 h after ICU admission occurred in 62.4% and AKI ≥ 2 within 12 h in 30.7%. All damage biomarkers predicted AKI ≥ 1 within 48 h after ICU admission, when corrected for urine dilution: CHI3L1 (AUC-ROC: 0.642 (95% CI, 0.535–0.741)), NGAL (0.765 (0.664–0.848)), TIMP-2 (0.778 (0.662–0.868)), IGFBP7 (0.796 (0.682–0.883)), NephroCheck^® (0.734 (0.614–0.832)). Similarly, AKI ≥ 2 within 12 h was predicted by all damage biomarkers when corrected for urine dilution: uCHI3L1 (AUC-ROC: 0.686 (95% CI, 0.580–0.780)), NGAL (0.714 (0.609–0.804)), TIMP-2 (0.830 (0.722–0.909)), IGFBP7 (0.834 (0.725–0.912)), NephroCheck^® (0.774 (0.658–0.865)). After pediatric cardiac surgery, the damage biomarkers urine CHI3L1, NGAL, TIMP-2, IGFBP7, and NephroCheck^® reliably predict AKI after correction for urine dilution. Full article

This study aims to demonstrate the capability of the digital image correlation (DIC) technique for evaluating full-field residual stresses in wire and arc additive manufactured (WAAM) components. Investigations were carried out on WAAM steel parts (wall deposited on a substrate) with two different wall heights: 24 mm and 48 mm. Mild steel solid wire AWS ER70S-6 was used to print WAAM walls on substrates that were rigidly clamped to H-profiles. DIC was used to monitor the bending deformation of WAAM parts during unclamping from the H-profiles, and residual stresses were calculated from the strain field captured during unclamping. Residual stresses determined from the proposed DIC-based method were verified with an analytical model and validated by the results from established residual stress measurement techniques, i.e., the contour method and X-ray diffraction. Full article

Ultrasonic welding (USW) is a solid-state welding process based on the application of high frequency vibration energy to the workpiece to produce the internal friction between the faying surface and the local heat generation required to promote the joining. The short welding time and the low heat input, the absence of fumes, sparks or flames, and the automation capacity make it particularly interesting for several fields, such as electrical/electronic, automotive, aerospace, appliance, and medical products industries. The main problems that those industries have to face are related to the poor weld quality due the improper selection of weld parameters. In the present work, 0.3 mm thick copper sheets were joined by USW varying the welding time, pressure, and vibration amplitude. The influence of the process variables on the characteristics of the joints and weld strength is investigated by using the analysis of variance. The results of the present work indicate that welding time is the main factor affecting the energy absorbed during the welding, followed by the pressure and amplitude. The shear strength, on the other hand, resulted mostly influenced by the amplitude, while the other parameters have a limited effect. Regardless the welding configuration adopted, most welds registered a failure load higher than the base material pointing out the feasibility of the USW process to join copper sheets. Full article

This work presents the development of a J-integral estimation procedure for deep and shallow cracked bend specimens based upon plastic η_pl factors for a butt weld made in an S690 QL high strength low alloyed steel. Experimental procedures include the characterization of average material properties by tensile testing and evaluation of base and weld metal resistance to stable tearing by fracture testing of square SE(B) specimens containing a weld centerline notch. J-integral has been estimated from plastic work using a single specimen approach and the normalization data reduction technique. A comprehensive parametric finite element study has been conducted to calibrate plastic factor η_pl and geometry factor λ for various fixture and weld configurations, while a corresponding plastic factor γ_pl was computed on the basis of the former two. The modified η_pl and γ_pl factors were then incorporated in the J computation procedure given by the ASTM E1820 standard, for evaluation of the plastic component of J and its corresponding correction due to crack growth, respectively. Two kinds of J-R curves were computed on the basis of modified and standard η_pl and γ_pl factors, where the latter are given by ASTM E1820. A comparison of produced J-R curves for the base material revealed that variations in specimen fixtures can lead to ≈10% overestimation of computed fracture toughness J_Ic. Furthermore, a comparison of J-R curves for overmatched single-material idealized welds revealed that the application of standard η_pl and γ_pl factors can lead to the overestimation of computed fracture toughness J_Ic by more than 10%. Similar observations are made for undermatched single material idealized welds, where fracture toughness J_Ic is overestimated by ≈5%. Full article

The demand for joining dissimilar metals has exponentially increased due to the global concerns about climate change, especially for electric vehicles in the automotive industry. Ultrasonic welding (USW) surges as a very promising technique to join dissimilar metals, providing strength and electric conductivity, in addition to avoid metallurgical defects, such as the formation of intermetallic compounds, brittle phases and porosities. However, USW is a very sensitive process, which depends on many parameters. This work evaluates the impact of the process parameters on the quality of ultrasonic spot welds between copper and aluminium plates. The weld quality is assessed based on the tensile strength of the joints and metallographic examination of the weld cross-sections. Furthermore, the welding energy is examined for the different welding conditions. This is done to evaluate the influence of each parameter on the heat input resulting from friction at the weld interface and on the weld quality. From the obtained results, it was possible to optimise parameters to achieve satisfactory weld quality in 1.0 mm thick Al–Cu plate joints in terms of mechanical and metallurgical properties. Full article
