Special Issue Information

Dear Colleagues,

Metal oxide semiconductors represent a unique class of materials that show prominent optoelectronic applications today. Typical p-type metal oxides, such as vanadium oxide (VO_x), nickel oxide (NiO_x), and cobalt oxide (CoO_x), have the advantages of high hole mobility, superior stability, and solution processibility. On the other hand, several representative n-type metal oxide materials, including zinc oxide (ZnO), titanium dioxide (TiO₂), and tin dioxide (SnO₂), show benefits in device performance due to their high electron mobility, long-term stability, solution-processing capability, and relatively high abundance on earth. In addition to thin films, metal oxides with specific nanostructures such as nanoparticles, nanowires, nanorods, nanotubes, nanosheets, nanowalls, and nanoflowers, have also been developed to increase the active surface area. These nanostructures are achievable via solution processes to reduce production cost and to expand research diversity. Nanostructured metal oxides are especially useful for carrier transport in miscellaneous devices, including organic light emitting diodes, polymer solar cells, perovskite photovoltaics, perovskite light emitting diodes, quantum-dot light emitting diodes, and organic/inorganic hybrid transistors and sensors.

This Special Issue of Nanomaterials is open to manuscripts concerning synthesis, characterization, and especially carrier transport abilities of metal oxide thin films and nanostructures in working devices. Potential topics include but are not limited to:

Hole transport metal oxides such as VO_x, NiO_x, CoO_x, etc.;
Electron transport metal oxides such as ZnO, TiO₂, SnO₂, etc.;
Preparation and characterization of metal oxide thin films and nanostructures;
Utilization of nanostructured metal oxides as carrier transport layers in miscellaneous devices.

Dr. Sheng-Hsiung Yang
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Nanomaterials is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2900 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

metal oxide semiconductors
solution processibility
nanostructures
organic optoelectronics
perovskite photovoltaics and light-emitting diodes
quantum-dot light-emitting diodes
transistors and sensors

Published Papers (6 papers)

Download All Papers

Editorial

Jump to: Research

3 pages, 176 KiB

Open AccessEditorial

Solution-Processed Metal Oxide Nanostructures for Carrier Transport

by Sheng-Hsiung Yang

Nanomaterials 2023, 13(8), 1331; https://doi.org/10.3390/nano13081331 - 11 Apr 2023

Cited by 2 | Viewed by 939

Abstract

Metal oxide semiconductors represent a unique class of materials that show prominent optoelectronic applications nowadays [...] Full article

(This article belongs to the Special Issue Solution-Processed Metal Oxide Nanostructures for Carrier Transport)

Research

Jump to: Editorial

14 pages, 2626 KiB

Open AccessArticle

Organic–Inorganic Hybrid Device with a Novel Deep-Blue Emitter of a Donor–Acceptor Type, with ZnO Nanoparticles for Solution-Processed OLEDs

by Seokwoo Kang, Raveendra Jillella, Sunwoo Park, Sangshin Park, Joo Hwan Kim, Dakyeung Oh, Joonghan Kim and Jongwook Park

Nanomaterials 2022, 12(21), 3806; https://doi.org/10.3390/nano12213806 - 28 Oct 2022

Cited by 2 | Viewed by 1726

Abstract

Two new deep-blue emitters with bipolar properties based on an organoboron acceptor and carbazole donor were newly synthesized: 2-(9H-carbazol-9-yl)-5-(2,12-di-tert-butyl-5,9-dioxa-13b-boranaphtho [3,2,1-de]anthracen-7-yl)-5H-benzo[b]carbazole (TDBA-BCZ) and 5-(2,12-di-tert-butyl-5,9-dioxa-13b-boranaphtho [3,2,1-de]anthracen-7-yl)-8-phenyl-5,8-dihydroindolo[2,3-c]carbazole (TDBA-PCZ). The two emitters showed deep-blue and real-blue photoluminescence emission in their solution and film states, respectively. The doped spin-coated films were prepared using synthesized materials and showed a root-mean-square roughness of less than 0.52 nm, indicating excellent surface morphology. The doped devices, fabricated via a solution process using TDBA-BCZ and TDBA-PCZ as the dopants, showed electroluminescence peaks at 428 and 461 nm, corresponding to the Commission Internationale de L’éclairage (CIE) coordinates of (0.161, 0.046) and (0.151, 0.155), respectively. The external quantum efficiency (EQE)/current efficiency (CE) of the solution-processed forward devices, with TDBA-BCZ and TDBA-PCZ as dopants, were 7.73%/8.67 cd/A and 10.58%/14.24 cd/A, respectively. An inverted OLED device fabricated using rod-shaped ZnO nanoparticles as an electron injection layer showed a CE of 1.09 cd/A and an EQE of 0.30%. Full article

(This article belongs to the Special Issue Solution-Processed Metal Oxide Nanostructures for Carrier Transport)
