J. Imaging, Volume 6, Issue 3 (March 2020) – 8 articles

Vitiligo vulgaris is an autoimmune disease which causes a strong reduction of the cells producing melanin, which is the main skin pigment. This results in the growth of white patches on patients’ skin, which are more or less visible, depending on the skin phototype. Precise, objective and fast detection of vitiligo patches would be crucial to produce statistically relevant data on huge populations, thus giving an insight on the disease. However, few methods are available in literature. In the present paper, a semi-automatic tool based on image processing to detect facial vitiligo patches is described. The tool requires pictures to be captured under black light illumination, which enhances patches contrast with respect to healthy skin. The user is only required to roughly define the regions of interest and set a global threshold, thus, no specific image-processing skills are required. An adaptive algorithm then automatically discerns between vitiligo and healthy skin pixels. The tools also allow for a statistical data interpretation by overlapping the detected patches of all patients on a face template through an occurrence map. Preliminary results obtained on a small population of 15 patients allowed us to assess the tool’s performance. Patch detection was checked by an experienced dermatologist, who confirmed the detection for all the studied patients, thus supporting the effectiveness of the proposed tool. Full article

A novel pulsed neutron imaging technique based on the finite element method is used to reconstruct the residual strain within a polycrystalline material from Bragg edge strain images. This technique offers the possibility of a nondestructive analysis of strain fields with a high spatial resolution. The finite element approach used to reconstruct the strain uses the least square method constrained by the conditions of equilibrium. This inclusion of equilibrium makes the problem well-posed. The procedure is developed and verified by validating for a cantilevered beam problem. It is subsequently demonstrated by reconstructing the strain from experimental data for a ring-and-plug sample, measured at the spallation neutron source RADEN at J-PARC in Japan. The reconstruction is validated by comparison with conventional constant wavelength strain measurements on the KOWARI diffractometer at ANSTO in Australia. It is also shown that the addition of a Tikhonov regularisation scheme further improves the reconstruction. Full article

With the increase in life expectancy, one of the most important topic for scientific research, especially for the elderly, is good nutrition. In particular, with an advanced age and health issues because disorders such as Alzheimer and dementia, monitoring the subjects’ dietary habits to avoid excessive or poor nutrition is a critical role. Starting from an application aiming to monitor the food intake actions of people during a meal, already shown in a previously published paper, the present work describes some improvements that are able to make the application work in real time. The considered solution exploits the Kinect v1 device that can be installed on the ceiling, in a top-down view in an effort to preserve privacy of the subjects. The food intake actions are estimated from the analysis of depth frames. The innovations introduced in this document are related to the automatic identification of the initial and final frame for the detection of food intake actions, and to the strong revision of the procedure to identify food intake actions with respect to the original work, in order to optimize the performance of the algorithm. Evaluation of the computational effort and system performance compared to the previous version of the application has demonstrated a possible real-time applicability of the solution presented in this document. Full article

Depth sensors are important in several fields to recognize real space. However, there are cases where most depth values in a depth image captured by a sensor are constrained because the depths of distal objects are not always captured. This often occurs when a low-cost depth sensor or structured-light depth sensor is used. This also occurs frequently in applications where depth sensors are used to replicate human vision, e.g., when using the sensors in head-mounted displays (HMDs). One ideal inpainting (repair or restoration) approach for depth images with large missing areas, such as partial foreground depths, is to inpaint only the foreground; however, conventional inpainting studies have attempted to inpaint entire images. Thus, under the assumption of an HMD-mounted depth sensor, we propose a method to inpaint partially and reconstruct an RGB-D depth image to preserve foreground shapes. The proposed method is comprised of a smoothing process for noise reduction, filling defects in the foreground area, and refining the filled depths. Experimental results demonstrate that the inpainted results produced using the proposed method preserve object shapes in the foreground area with accurate results of the inpainted area with respect to the real depth with the peak signal-to-noise ratio metric. Full article

This paper presents automated harmonic removal as a desirable solution to effectively identify and discard the harmonic influence over the output signal by neglecting any user-defined parameter at start-up and automatically reconstruct back to become a useful output signal prior to system identification. Stochastic subspace-based algorithms (SSI) methods are the most practical tool due to the consistency in modal parameters estimation. However, it will be problematic when applied to structures with rotating machines and the presence of harmonic excitations. Difficulties arise when automating this procedure without any human interaction and the problem is still unresolved because stochastic subspace-based algorithms (SSI) methods still require parameters (the maximum within-cluster distance) that are compulsory to be defined at start-up for each analysis of the dataset. Thus, the use of image-based feature extraction for clustering and classification of harmonic components and structural poles directly from a stabilization diagram and for modal system identification is the focus of the present paper. As a fundamental necessary condition, the algorithm has been assessed first from computed numerical responses and then applied to the experimental dataset with the presence of harmonic excitation. Results of the proposed approach for estimating modal parameters demonstrated very high accuracy and exhibited consistent results before and after removing harmonic components from the response signal. Full article

Image source forensics is widely considered as one of the most effective ways to verify in a blind way digital image authenticity and integrity. In the last few years, many researchers have applied data-driven approaches to this task, inspired by the excellent performance obtained by those techniques on computer vision problems. In this survey, we present the most important data-driven algorithms that deal with the problem of image source forensics. To make order in this vast field, we have divided the area in five sub-topics: source camera identification, recaptured image forensic, computer graphics (CG) image forensic, GAN-generated image detection, and source social network identification. Moreover, we have included the works on anti-forensics and counter anti-forensics. For each of these tasks, we have highlighted advantages and limitations of the methods currently proposed in this promising and rich research field. Full article

In recent years, the rise of car accident fatalities has grown significantly around the world. Hence, road security has become a global concern and a challenging problem that needs to be solved. The deaths caused by road accidents are still increasing and currently viewed as a significant general medical issue. The most recent developments have made in advancing knowledge and scientific capacities of vehicles, enabling them to see and examine street situations to counteract mishaps and secure travelers. Therefore, the analysis of driver’s behaviors on the road has become one of the leading research subjects in recent years, particularly drowsiness, as it grants the most elevated factor of mishaps and is the primary source of death on roads. This paper presents a way to analyze and anticipate driver drowsiness by applying a Recurrent Neural Network over a sequence frame driver’s face. We used a dataset to shape and approve our model and implemented repetitive neural network architecture multi-layer model-based 3D Convolutional Networks to detect driver drowsiness. After a training session, we obtained a promising accuracy that approaches a 92% acceptance rate, which made it possible to develop a real-time driver monitoring system to reduce road accidents. Full article

We need data sets of images and subjective scores to develop robust no reference (or blind) visual quality metrics for consumer applications. These applications have many uncontrolled variables because the camera creates the original media and the impairment simultaneously. We do not fully understand how this impacts the integrity of our subjective data. We put forward two new data sets of images from consumer cameras. The first data set, CCRIQ2, uses a strict experiment design, more suitable for camera performance evaluation. The second data set, VIME1, uses a loose experiment design that resembles the behavior of consumer photographers. We gather subjective scores through a subjective experiment with 24 participants using the Absolute Category Rating method. We make these two new data sets available royalty-free on the Consumer Digital Video Library. We also present their integrity analysis (proposing one new approach) and explore the possibility of combining CCRIQ2 with its legacy counterpart. We conclude that the loose experiment design yields unreliable data, despite adhering to international recommendations. This suggests that the classical subjective study design may not be suitable for studies using consumer content. Finally, we show that Hoßfeld–Schatz–Egger $\alpha$ failed to detect important differences between the two data sets. Full article
