A Feedback Optimal Control Algorithm with Optimal Measurement Time Points
Abstract
:1. Introduction
2. On the Estimation, Control, and Design Problems
2.1. Nonlinear Dynamic Systems
2.2. State and Parameter Estimation Problems
2.3. Optimal Control Problems
2.4. Optimal Experimental Design Problems
Algorithm 1 OED
Input: Fixed p and u, initial values $x({t}_{0}),G({t}_{0})$, possible measurement times $\{{t}_{1},\dots ,{t}_{N}\}\subset [{t}_{0},{t}_{\mathrm{f}}]$

3. A Feedback Optimal Control Algorithm With Optimal Measurement Times
Algorithm 2 FOCoed
Input: Initial guess $\widehat{p}$, initial values $x({t}_{0}),G({t}_{0})$, possible measurement times $\{{t}_{1},\dots ,{t}_{N}\}\subset [{t}_{0},{t}_{\mathrm{f}}]$ Initialize sampling counter $i=0$, measurement grid counter $k=0$ and “current time” ${\tau}_{0}={t}_{0}$ while stopping criterion not fulfilled do

3.1. Finite Support Designs
3.2. Robustification
4. Numerical Examples
4.1. LotkaVolterra Fishing Benchmark Problem
4.2. Software and Experimental Settings
4.3. Three Versions of Algorithm FOCoed applied to the LotkaVolterra fishing problem
 with_OED. This is Algorithm 2, i.e., using measurement time points from nonrobust OED.
 without_OED. The OED problem in Step 2 of Algorithm 2 is omitted, and an equidistant time grid is used for measurements.
 with_r_OED. The OC problem in Step 1 and the OED problem in Step 2 of Algorithm 2 are replaced with their robust counterparts as described in Section 3.2.
4.4. Analyzing Finite Support Designs of Optimal Experimental Design Problems
4.5. Discussion
5. Conclusions
Acknowledgments
Author Contributions
Conflicts of Interest
Abbreviations
FIM  Fisher Information Matrix
MPC  Model Predictive Control
NLP  Nonlinear Program
ODE  Ordinary Differential Equation
OC  Optimal Control
OED  Optimal Experimental Design
SPE  State and Parameter Estimation
References
