Effect of the Incoherent Encapsulation Layer and Oblique Sunlight Incidence on the Optical and Current-Voltage Characteristics of Surface-Textured Cu(In,Ga)Se2 Solar Cells Based on the Angle-Dependent Equispaced Thickness Averaging Method
Abstract
:1. Introduction
2. Theory of ADETAM
3. Optical Modeling Results
3.1. Planar CIGS Solar Cells
3.2. Surface-Textured CIGS Solar Cells
4. Electrical Modeling Results
4.1. Electrical Modeling Procedure
4.2. Comparison of the J–V Characteristics without and with the Inclusion of the Incoherent Front Encapsulation Layers
5. Conclusions
