The Influence of Various Preparation Parameters on the Histological Image of Bone Tissue during Implant Bed Preparation—An In Vitro Study
Abstract
:1. Introduction
2. Materials and Methods
- 0
- —smooth drill hole surfaces, even edges, no compression, no charring, no cracks or damage to adjacent tissues—positive—OK
- 1
- —surface smoothness (jagged drill holes, uneven edges, presence of tissue residues)—not positive—NOK
- 2
- —the presence of compressed (pressed) tissues—not positive—NOK
- 3
- —presence of carbonization (char)—not positive—NOK
- 4
- —cracking and damage to neighboring tissues—not positive—NOK
Statistical Analysis
3. Results
3.1. Osstem (D1)
3.2. Straumann (D2)
3.3. S-Wide (Neobiotech S-Wide)
4. Scoring
5. Discussion
6. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Conflicts of Interest
References
- Marheineke, N.; Scherer, U.; Rücker, M.; Von See, C.; Rahlf, B.; Stoetzer, M.; Gellrich, N.-C. Evaluation of accuracy in implant site preparation performed in single- or multi-step drilling procedures. Clin. Oral Investig. 2017, 22, 2057–2067. [Google Scholar] [CrossRef]
- Stocchero, M.; Toia, M.; Jinno, Y.; Cecchinato, F.; Becktor, J.P.; Naito, Y.; Halldin, A.; Jimbo, R. Influence of different drilling preparation on cortical bone: A biomechanical, histological, and micro-CT study on sheep. Clin. Oral Implant. Res. 2018, 29, 707–715. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Favero, V.; Sakuma, S.; Alccayhuaman, K.A.A.; Benedetto, G.A.; Bengazi, F.; Botticelli, D. Healing at sites prepared using different drilling protocols. An experimental study in the tibiae of sheep. PLoS ONE 2018, 13, e0202957. [Google Scholar] [CrossRef]
- Di Fiore, A.; Sivolella, S.; Stocco, E.; Favero, V.; Stellini, E. Experimental Analysis of Temperature Differences during Implant Site Preparation: Continuous Drilling Technique Versus Intermittent Drilling Technique. J. Oral Implant. 2018, 44, 46–50. [Google Scholar] [CrossRef] [PubMed]
- Effect of Surgical Drill Guide and Irrigans Temperature on Thermal Bone Changes during Drilling Implant Sites—Thermographic Analysis on Bovine Ribs. Available online: https://pubmed.ncbi.nlm.nih.gov/29328609/ (accessed on 21 December 2020).
- Sannino, G.; Capparé, P.; Gherlone, E.F.; Barlattani, A. Influence of the Implant Drill Design and Sequence on Temperature Changes during Site Preparation. Int. J. Oral Maxillofac. Implant. 2015, 30, 351–358. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Stavropoulos, A.; Cochran, D.; Obrecht, M.; Pippenger, B.; Dard, M. Effect of Osteotomy Preparation on Osseointegration of Immediately Loaded, Tapered Dental Implants. Adv. Dent. Res. 2016, 28, 34–41. [Google Scholar] [CrossRef]
- Folkman, M.; Becker, A.; Meinster, I.; Masri, M.; Ormianer, Z. Comparison of bone-to-implant contact and bone volume around implants placed with or without site preparation: A histomorphometric study in rabbits. Sci. Rep. 2020, 10, 1–10. [Google Scholar] [CrossRef] [PubMed]
- Alghamdi, H.; Anand, P.S.; Anil, S. Undersized Implant Site Preparation to Enhance Primary Implant Stability in Poor Bone Density: A Prospective Clinical Study. J. Oral Maxillofac. Surg. 2011, 69, e506–e512. [Google Scholar] [CrossRef]
- Tabassum, A.; Meijer, G.J.; Walboomers, X.F.; Jansen, J.A. Evaluation of primary and secondary stability of titanium implants using different surgical techniques. Clin. Oral Implant. Res. 2013, 25, 487–492. [Google Scholar] [CrossRef] [PubMed]
- Rea, M.; Lang, N.P.; Ricci, S.; Mintrone, F.; González, G.G.; Botticelli, D. Healing of implants installed in over- or under-prepared sites—An experimental study in dogs. Clin. Oral Implant. Res. 2014, 26, 442–446. [Google Scholar] [CrossRef]
- O’Sullivan, D.; Sennerby, L.; Meredith, N. Influence of implant taper on the primary and secondary stability of osseointegrated titanium implants. Clin. Oral Implant. Res. 2004, 15, 474–480. [Google Scholar] [CrossRef] [PubMed]
- Becker, W.; Sennerby, L.; Bedrossian, E.; Becker, B.E.; Lucchini, J.P. Implant Stability Measurements for Implants Placed at the Time of Extraction: A Cohort, Prospective Clinical Trial. J. Periodontol. 2005, 76, 391–397. [Google Scholar] [CrossRef] [PubMed]
- Osseodensification Drilling vs. Standard Protocol of Implant Site Preparation: An In Vitro Study on Polyurethane Foam Sheets. Available online: https://www.researchgate.net/publication/341808179_Osseodensification_Drilling_vs_Standard_Protocol_of_Implant_Site_Preparation_An_In_Vitro_Study_on_Polyurethane_Foam_Sheets (accessed on 23 January 2021).
- Scarano, A.; Crocetta, E.; Quaranta, A.; Lorusso, F. Influence of the Thermal Treatment to Address a Better Osseointegration of Ti6Al4V Dental Implants: Histological and Histomorphometrical Study in a Rabbit Model. BioMed Res. Int. 2018, 2018, 1–7. [Google Scholar] [CrossRef] [Green Version]
- Kirstein, K.; Dobrzyński, M.; Kosior, P.; Chrószcz, A.; Dudek, K.; Fita, K.; Parulska, O.; Rybak, Z.; Skalec, A.; Szklarz, M.; et al. Infrared Thermographic Assessment of Cooling Effectiveness in Selected Dental Implant Systems. BioMed Res. Int. 2016, 2016, 1–8. [Google Scholar] [CrossRef]
- Möhlhenrich, S.; Modabber, A.; Steiner, T.; Mitchell, D.; Hölzle, F. Heat generation and drill wear during dental implant site preparation: Systematic review. Br. J. Oral Maxillofac. Surg. 2015, 53, 679–689. [Google Scholar] [CrossRef]
- Alam, K.; Silberschmidt, V.V. Analysis of temperature in conventional and ultrasonically-assisted drilling of cortical bone with infrared thermography. Technol. Health Care 2014, 22, 243–252. [Google Scholar] [CrossRef]
- Ihde, S.; Pałka, Ł.; Janeczek, M.; Kosior, P.; Kiryk, J.; Dobrzynski, M. Bite Reconstruction in the Aesthetic Zone Using One-Piece Bicortical Screw Implants. Case Rep. Dent. 2018, 2018, 1–4. [Google Scholar] [CrossRef] [Green Version]
- Chana, H.; Smith, G.; Bansal, H.; Zahra, D. A Retrospective Cohort Study of the Survival Rate of 88 Zygomatic Implants Placed Over an 18-year Period. Int. J. Oral Maxillofac. Implant. 2019, 34, 461–470. [Google Scholar] [CrossRef] [PubMed]
- Osseointegration of Zirconium Dental Implants Three Months after Insertion in Rabbit Femur. Histopathological Study. Available online: https://pubmed.ncbi.nlm.nih.gov/30534817/ (accessed on 21 December 2020).
- Sarendranath, A.; Khan, R.; Tovar, N.; Marin, C.; Yoo, D.; Redisch, J.; Jimbo, R.; Coelho, P. Effect of low speed drilling on osseointegration using simplified drilling procedures. Br. J. Oral Maxillofac. Surg. 2015, 53, 550–556. [Google Scholar] [CrossRef]
- Implant Materials, Designs, and Surface Topographies: Their Effect on Osseointegration. A Literature Review. Available online: https://pubmed.ncbi.nlm.nih.gov/11055135/ (accessed on 25 January 2021).
- Saini, M. Implant biomaterials: A comprehensive review. World J. Clin. Cases 2015, 3, 52–57. [Google Scholar] [CrossRef]
- Ehrenfest, D.M.D.; Coelho, P.G.; Kang, B.-S.; Sul, Y.-T.; Albrektsson, T. Classification of osseointegrated implant surfaces: Materials, chemistry and topography. Trends Biotechnol. 2010, 28, 198–206. [Google Scholar] [CrossRef]
- Rupp, F.; Scheideler, L.; Rehbein, D.; Axmann, D.; Geis-Gerstorfer, J. Roughness induced dynamic changes of wettability of acid etched titanium implant modifications. Biomaterials 2004, 25, 1429–1438. [Google Scholar] [CrossRef]
- Mendonça, G.; Mendonça, D.B.; Aragão, F.J.; Cooper, L.F. Advancing dental implant surface technology—From micron- to nanotopography. Biomaterials 2008, 29, 3822–3835. [Google Scholar] [CrossRef]
- Smeets, R.; Stadlinger, B.; Schwarz, F.; Beck-Broichsitter, B.; Jung, O.; Precht, C.; Kloss, F.; Gröbe, A.; Heiland, M.; Ebker, T. Impact of Dental Implant Surface Modifications on Osseointegration. BioMed Res. Int. 2016, 2016, 1–16. [Google Scholar] [CrossRef] [Green Version]
- Histologic Evidence of a Connective Tissue Attachment to Laser Microgrooved Abutments: A Canine Study. Available online: https://pubmed.ncbi.nlm.nih.gov/20386781/ (accessed on 25 January 2021).
- Collaert, B.; Wijnen, L.; De Bruyn, H. A 2-year prospective study on immediate loading with fluoride-modified implants in the edentulous mandible. Clin. Oral Implant. Res. 2011, 22, 1111–1116. [Google Scholar] [CrossRef] [PubMed]
- Sul, Y.-T.; Johansson, C.B.; Röser, K.; Albrektsson, T. Qualitative and quantitative observations of bone tissue reactions to anodised implants. Biomater. 2002, 23, 1809–1817. [Google Scholar] [CrossRef]
- Yeniyol, S.; Jimbo, R.; Marin, C.; Tovar, N.; Janal, M.N.; Coelho, P.G. The effect of drilling speed on early bone healing to oral implants. Oral Surg. Oral Med. Oral Pathol. Oral Radiol. 2013, 116, 550–555. [Google Scholar] [CrossRef]
- Slete, F.B.; Olin, P.; Prasad, H. Histomorphometric Comparison of 3 Osteotomy Techniques. Implant. Dent. 2018, 27, 424–428. [Google Scholar] [CrossRef] [PubMed]
- Trisi, P.; Berardini, M.; Falco, A.; Vulpiani, M.P.; Masciotra, L. Effect of 50 to 60°C Heating on Osseointegration of Dental Implants in Dense Bone. Implant. Dent. 2014, 23, 516–521. [Google Scholar] [CrossRef] [PubMed] [Green Version]
- Galli, S.; Jimbo, R.; Tovar, N.; Yoo, D.Y.; Anchieta, R.B.; Yamaguchi, S.; Coelho, P.G. The effect of osteotomy dimension on osseointegration to resorbable media-treated implants: A study in the sheep. J. Biomater. Appl. 2014, 29, 1068–1074. [Google Scholar] [CrossRef] [PubMed]
- Osseointegrated Dental Implants. Available online: https://pubmed.ncbi.nlm.nih.gov/3514290/ (accessed on 21 December 2020).
- Berglundh, T.; Abrahamsson, I.; Lang, N.P.; Lindhe, J. De novo alveolar bone formation adjacent to endosseous implants. Clin. Oral Implant. Res. 2003, 14, 251–262. [Google Scholar] [CrossRef] [Green Version]
- Zakrzewski, W.; Dobrzynski, M.; Rybak, Z.; Szymonowicz, M.; Wiglusz, R.J. Selected Nanomaterials’ Application Enhanced with the Use of Stem Cells in Acceleration of Alveolar Bone Regeneration during Augmentation Process. Nanomaterials 2020, 10, 1216. [Google Scholar] [CrossRef]
- Brunski, J.B. Biomechanical factors affecting the bone-dental implant interface. Clin. Mater. 1992, 10, 153–201. [Google Scholar] [CrossRef]
- Boustany, C.M.; Reed, H.; Cunningham, G.; Richards, M.; Kanawati, A. Effect of a Modified Stepped Osteotomy on the Primary Stability of Dental Implants in Low-Density Bone: A Cadaver Study. Int. J. Oral Maxillofac. Implant. 2015, 30, 48–55. [Google Scholar] [CrossRef] [PubMed]
- Friberg, B.; Sennerby, L.; Gröndahl, K.; Bergström, C.; Bäck, T.; Lekholm, U. On cutting torque measurements during implant placement: A 3-year clinical prospective study. Clin. Implant. Dent. Relat. Res. 1999, 1, 75–83. [Google Scholar] [CrossRef] [PubMed]
- Stocchero, M. On Influence of an Undersized Implant Site on Implant Stability and Osseointegration. Ph.D. Thesis, Malmö University, Malmo, Sweden, 2018. [Google Scholar]
X1 Systems | X2 vc (m/s) | X3 Environmental Conditions | Quality of the Drill Hole Surface (Score) | Y |
---|---|---|---|---|
1—Osstem | 0.147 | 1—without cooling | 0 | OK |
1—Osstem | 0.220 | 1—without cooling | 0 | OK |
1—Osstem | 0.275 | 1—without cooling | 1 | NOK |
1—Osstem | 0.147 | 2—with cooling at room temperature | 2 | NOK |
1—Osstem | 0.220 | 2—with cooling at room temperature | 2 | NOK |
1—Osstem | 0.275 | 2—with cooling at room temperature | 2 | NOK |
1—Osstem | 0.147 | 3—with cooling with normal saline at 4°C | 1 | NOK |
1—Osstem | 0.220 | 3—with cooling with normal saline at 4°C | 1 | NOK |
1—Osstem | 0.275 | 3—with cooling with normal saline at 4°C | 1 | NOK |
2—Strauman | 0.147 | 1—without cooling | 0 | OK |
2—Strauman | 0.220 | 1—without cooling | 0 | OK |
2—Strauman | 0.275 | 1—without cooling | 1 | NOK |
2—Strauman | 0.147 | 2—with cooling at room temperature | 0 | OK |
2—Strauman | 0.220 | 2—with cooling at room temperature | 0 | OK |
2—Strauman | 0.275 | 2—with cooling at room temperature | 1 | NOK |
2—Strauman | 0.147 | 3—with cooling with normal saline at 4°C | 1 | NOK |
2—Strauman | 0.220 | 3—with cooling with normal saline at 4°C | 1 | NOK |
2—Strauman | 0.275 | 3—with cooling with normal saline at 4°C | 1 | NOK |
3—Neobiotech S-Wide | 0.230 | 1—without cooling | 1 | NOK |
3—Neobiotech S-Wide | 0.346 | 1—without cooling | 1 | NOK |
3—Neobiotech S-Wide | 0.432 | 1—without cooling | 1 | NOK |
3—Neobiotech S-Wide | 0.230 | 2—with cooling at room temperature | 1 | NOK |
3—Neobiotech S-Wide | 0.346 | 2—with cooling at room temperature | 1 | NOK |
3—Neobiotech S-Wide | 0.432 | 2—with cooling at room temperature | 1 | NOK |
3—Neobiotech S-Wide | 0.230 | 3—with cooling with normal saline at 4°C | 1 | NOK |
3—Neobiotech S-Wide | 0.346 | 3—with cooling with normal saline at 4°C | 1 | NOK |
3—Neobiotech S-Wide | 0.432 | 3—with cooling with normal saline at 4°C | 1 | NOK |
Parameters | The Quality of the Drill Hole Surface | Fischer’s Exact Test p-Value | |||
---|---|---|---|---|---|
OK | NOK | ||||
n | % | n | % | ||
System: | 0.076 * | ||||
Osstem | 2 | 33.3% | 7 | 33.3% | |
Straumann | 4 | 66.7% | 5 | 23.8% | |
Neobiotech S-Wide | 0 | 0.0% | 9 | 42.9% | |
Environmental conditions: | 0.076 * | ||||
Without cooling | 4 | 66.7% | 5 | 23.8% | |
With cooling at room temperature | 2 | 33.3% | 7 | 33.3% | |
With cooling with normal saline at 4 °C | 0 | 0.0% | 9 | 42.9% | |
Cutting speed vc(m/s) | 0.003 ** | ||||
<0.22 | 6 | 100.0% | 6 | 28.6% | |
>0.22 | 0 | 0.0% | 15 | 71.4% |
System and Cooling | High Quality | OR [95% CI] | |
---|---|---|---|
OK | NOK | ||
For: Straumann | 4 | 5 | 6.40 [0.89–46.00] |
For: Osstem or Neobiotech S-Wide | 2 | 16 | 0.16 [0.02–1.12] |
For: without cooling | 4 | 5 | 6.40 [0.89–46.00] |
For: with cooling | 2 | 16 | 0.16 [0.02–1.12] |
