Anchoring Mechanism for Capsule Endoscope: Mechanical Design, Fabrication and Experimental Evaluation
Abstract
:1. Introduction
- The design and development of a low footprint anchoring mechanism that fit within a capsule endoscope and can anchor at the target site in the gut;
- The design and selection of the custom-built SMA spring actuator to operate the anchoring mechanism;
- The development of a miniaturised actuation system based on an SMA spring actuator by tackling the high-drain current requirements using a custom-built battery and a miniaturised wireless transceiver.
2. Materials and Methods
2.1. Mechanical Design of Anchoring Mechanism
2.1.1. Capsule Size
2.1.2. Parameters of Small Intestine
2.1.3. Development of Anchoring Mechanism
2.1.4. Capsule Fabrication
2.1.5. Biocompatibility and Strength of Capsule Material
2.2. Actuation System for Anchoring Mechanism
2.2.1. Force Analysis of Fabricated Anchoring Mechanism
2.2.2. Design Requirements for Actuator Selection
2.2.3. Design of SMA Spring Actuator
2.2.4. Development of Actuation System
2.2.5. Simulator for Anchoring Trials
2.2.6. Living Intestinal Trials
3. Results and Discussion
3.1. Anchoring Trials on a Simulator
3.2. Anchoring Trials on Ex-Vivo Intestine
3.3. Anchoring Trials on Living Intestine
4. Discussion
5. Conclusions
Supplementary Materials
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
Abbreviations
GI tract | Gastrointestinal tract |
UHMWPE | Ultra-high-molecular-weight Polyethylene |
SMA | Shape memory alloy |
References
