Remote Sens. 2017, 9(10), 1060; https://doi.org/10.3390/rs9101060

Exploring the Potential of WorldView-2 Red-Edge Band-Based Vegetation Indices for Estimation of Mangrove Leaf Area Index with Machine Learning Algorithms

1
Center of Integrated Geographic Information Analysis, Guangdong Key Laboratory for Urbanization and Geo-Simulation, School of Geography and Planning, Sun Yat-sen University, Guangzhou 510275, China
2
Center of Geographic Information Analysis for Public Security, School of Geographic Sciences, Guangzhou University, Guangzhou 510006, China
3
Department of Geography, University of Cincinnati, Cincinnati, OH 45221-0131, USA
4
School of Geographical Sciences and Urban Planning, Arizona State University, Tempe, AZ 85287-5302, USA
5
Guangdong Key Laboratory of Geological Processes and Mineral Resources Survey, School of Earth Science and Geological Engineering, Sun Yat-sen University, Guangzhou 510275, China
*
Authors to whom correspondence should be addressed.
Received: 15 August 2017 / Revised: 26 September 2017 / Accepted: 15 October 2017 / Published: 18 October 2017
(This article belongs to the Special Issue Machine Learning Applications in Earth Science Big Data Analysis)
Full-Text   |   PDF [10261 KB, uploaded 18 October 2017]   |

Abstract

To accurately estimate leaf area index (LAI) in mangrove areas, the selection of appropriate models and predictor variables is critical. However, there is a major challenge in quantifying and mapping LAI using multi-spectral sensors due to the saturation effects of traditional vegetation indices (VIs) for mangrove forests. WorldView-2 (WV2) imagery has proven to be effective to estimate LAI of grasslands and forests, but the sensitivity of its vegetation indices (VIs) has been uncertain for mangrove forests. Furthermore, the single model may exhibit certain randomness and instability in model calibration and estimation accuracy. Therefore, this study aims to explore the sensitivity of WV2 VIs for estimating mangrove LAI by comparing artificial neural network regression (ANNR), support vector regression (SVR) and random forest regression (RFR). The results suggest that the RFR algorithm yields the best results (RMSE = 0.45, 14.55% of the average LAI), followed by ANNR (RMSE = 0.49, 16.04% of the average LAI), and then SVR (RMSE = 0.51, 16.56% of the average LAI) algorithms using 5-fold cross validation (CV) using all VIs. Quantification of the variable importance shows that the VIs derived from the red-edge band consistently remain the most important contributor to LAI estimation. When the red-edge band-derived VIs are removed from the models, estimation accuracies measured in relative RMSE (RMSEr) decrease by 3.79%, 2.70% and 4.47% for ANNR, SVR and RFR models respectively. VIs derived from red-edge band also yield better accuracy compared with other traditional bands of WV2, such as near-infrared-1 and near-infrared-2 band. Furthermore, the estimated LAI values vary significantly across different mangrove species. The study demonstrates the utility of VIs of WV2 imagery and the selected machine-learning algorithms in developing LAI models in mangrove forests. The results indicate that the red-edge band of WV2 imagery can help alleviate the saturation problem and improve the accuracy of LAI estimation in a mangrove area. View Full-Text
Keywords: WorldView-2 imagery; vegetation index; leaf area index; red-edge band; variable importance; mangrove forests; machine learning WorldView-2 imagery; vegetation index; leaf area index; red-edge band; variable importance; mangrove forests; machine learning
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
