Pharmaceutics 2014, 6(3), 436-446;

Mixing Acid Salts and Layered Double Hydroxides in Nanoscale under Solid Condition

Department of Functional Molecular Chemistry, Kobe Pharmaceutical University, Kobe 658-8558, Japan
Author to whom correspondence should be addressed.
Received: 6 June 2014 / Revised: 22 July 2014 / Accepted: 23 July 2014 / Published: 30 July 2014
(This article belongs to the Special Issue Layered Double Hydroxide Used in Drug Delivery)
Full-Text   |   PDF [2136 KB, uploaded 30 July 2014]   |


The immobilization of potassium sorbate, potassium aspartate and sorbic acid in layered double hydroxide under solid condition was examined. By simply mixing two solids, immobilization of sorbate and aspartate in the interlayer space of nitrate-type layered double hydroxide, so called intercalation reaction, was achieved, and the uptakes, that is, the amount of immobilized salts and the interlayer distances of intercalation compounds were almost the same as those obtained in aqueous solution. However, no intercalation was achieved for sorbic acid. Although intercalation of sorbate and aspartate into chloride-type layered double hydroxide was possible, the uptakes for these intercalation compounds were lower than those obtained using nitrate-type layered double hydroxide. The intercalation under solid condition could be achieved to the same extent as for ion-exchange reaction in aqueous solution, and the reactivity was similar to that observed in aqueous solution. This method will enable the encapsulation of acidic drug in layered double hydroxide as nano level simply by mixing both solids. View Full-Text
Keywords: intercalation; carrier; layered double hydroxide; hydrotalcite intercalation; carrier; layered double hydroxide; hydrotalcite

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License (CC BY 3.0).
