Sensors 2017, 17(8), 1716; https://doi.org/10.3390/s17081716

A Disposable Amperometric Sensor Based on High-Performance PEDOT:PSS/Ionic Liquid Nanocomposite Thin Film-Modified Screen-Printed Electrode for the Analysis of Catechol in Natural Water Samples

1
West African Centre for Cell Biology of Infectious Pathogens (WACCBIP), University of Ghana, Legon, Accra, Ghana
2
Department of Biochemistry, Cell & Molecular Biology, University of Ghana, Legon, Accra, Ghana
3
Nanotechnology & Integrated Bioengineering Centre, Ulster University, Jordanstown BT37 0QB, UK
*
Author to whom correspondence should be addressed.
Received: 8 June 2017 / Revised: 12 July 2017 / Accepted: 13 July 2017 / Published: 26 July 2017
(This article belongs to the Special Issue Screen-Printed Electrodes)
Full-Text   |   PDF [2459 KB, uploaded 26 July 2017]   |

Abstract

A conducting polymer-based composite material of poly(3,4-ethylenedioxythiophene) (PEDOT): poly(4-styrenesulfonate) (PSS) doped with different percentages of a room temperature ionic liquid (IL), 1-ethyl-3-methylimidazolium tetrafluoroborate ([EMIM][BF4]), was prepared and a very small amount of the composite (2.0 µL) was drop-coated on the working area of a screen-printed carbon electrode (SPCE). The SPCE, modified with PEDOT:PSS/IL composite thin-film, was characterized by cyclic voltammetry (CV), electrochemical impedance spectroscopy (EIS), scanning electron microscopy (SEM), profilometry and sessile contact angle measurements. The prepared PEDOT:PSS/IL composite thin-film exhibited a nano-porous microstructure and was found to be highly stable and conductive with enhanced electrocatalytic properties towards catechol, a priority pollutant. The linear working range for catechol was found to be 0.1 µM–330.0 µM with a sensitivity of 18.2 mA·mM·cm−2 and a calculated limit of detection (based on 3× the baseline noise) of 23.7 µM. When the PEDOT:PSS/IL/SPCE sensor was used in conjunction with amperometry in stirred solution for the analysis of natural water samples, the precision values obtained on spiked samples (20.0 µM catechol added) (n = 3) were 0.18% and 0.32%, respectively, with recovery values that were well over 99.0%. View Full-Text
Keywords: room temperature ionic liquids; PEDOT:PSS; disposable sensors; cyclic voltammetry; electrochemical impedance spectroscopy; screen-printed electrodes; conducting polymers; nanocomposites; hexacyanoferrate; sessile contact angle measurement room temperature ionic liquids; PEDOT:PSS; disposable sensors; cyclic voltammetry; electrochemical impedance spectroscopy; screen-printed electrodes; conducting polymers; nanocomposites; hexacyanoferrate; sessile contact angle measurement
Figures

Figure 1
