Article

A Laboratory Goniometer System for Measuring Reflectance and Emittance Anisotropy

1
Laboratory of Geo-Information Science and Remote Sensing, Wageningen University, P.O. Box 47, 6700 AA Wageningen, The Netherlands
2
Remote Sensing Laboratories, Department of Geography, University of Zurich, Winterthurerstrasse 190, CH-8057 Zurich, Switzerland
3
Institute of Evolutionary Biology and Environmental Studies, University of Zurich, Winterthurerstrasse 190, CH-8057 Zurich, Switzerland
4
Wageningen UR Greenhouse Horticulture, P.O. Box 644, 6700 AP Wageningen, The Netherlands
5
Alterra, Wageningen University & Research Centre, P.O. Box 47, 6700 AA Wageningen, The Netherlands
*
Author to whom correspondence should be addressed.
Sensors 2012, 12(12), 17358-17371; https://doi.org/10.3390/s121217358
Received: 19 September 2012 / Revised: 7 December 2012 / Accepted: 11 December 2012 / Published: 13 December 2012
(This article belongs to the Special Issue Workshop Sensing A Changing World 2012)
In this paper, a laboratory goniometer system for performing multi-angular measurements under controlled illumination conditions is described. A commercially available robotic arm enables the acquisition of a large number of measurements over the full hemisphere within a short time span making it much faster than other goniometers. In addition, the presented set-up enables assessment of anisotropic reflectance and emittance behaviour of soils, leaves and small canopies. Mounting a spectrometer enables acquisition of either hemispherical measurements or measurements in the horizontal plane. Mounting a thermal camera allows directional observations of the thermal emittance. This paper also presents three showcases of these different measurement set-ups in order to illustrate its possibilities. Finally, suggestions for applying this instrument and for future research directions are given, including linking the measured reflectance anisotropy with physically-based anisotropy models on the one hand and combining them with field goniometry measurements for joint analysis with remote sensing data on the other hand. The speed and flexibility of the system offer a large added value to the existing pool of laboratory goniometers. View Full-Text
Keywords: reflectance anisotropy; BRDF; emittance anisotropy; laboratory goniometer; biophysical parameter retrieval reflectance anisotropy; BRDF; emittance anisotropy; laboratory goniometer; biophysical parameter retrieval
Show Figures

Graphical abstract

MDPI and ACS Style

Roosjen, P.P.J.; Clevers, J.G.P.W.; Bartholomeus, H.M.; Schaepman, M.E.; Schaepman-Strub, G.; Jalink, H.; Van der Schoor, R.; De Jong, A. A Laboratory Goniometer System for Measuring Reflectance and Emittance Anisotropy. Sensors 2012, 12, 17358-17371. https://doi.org/10.3390/s121217358

AMA Style

Roosjen PPJ, Clevers JGPW, Bartholomeus HM, Schaepman ME, Schaepman-Strub G, Jalink H, Van der Schoor R, De Jong A. A Laboratory Goniometer System for Measuring Reflectance and Emittance Anisotropy. Sensors. 2012; 12(12):17358-17371. https://doi.org/10.3390/s121217358

Chicago/Turabian Style

Roosjen, Peter P.J., Jan G.P.W. Clevers, Harm M. Bartholomeus, Michael E. Schaepman, Gabriela Schaepman-Strub, Henk Jalink, Rob Van der Schoor, and Arjan De Jong. 2012. "A Laboratory Goniometer System for Measuring Reflectance and Emittance Anisotropy" Sensors 12, no. 12: 17358-17371. https://doi.org/10.3390/s121217358
