Search Results (17)

Optical networks today constitute the fundamental backbone infrastructure of telecom and cloud operators. A possible medium-term solution to address the enormous increase in traffic demands faced by these operators is to rely on Super C+ L transmission optical bands, which can offer a bandwidth of about 12 THz. In this paper, we propose a methodology to compute the throughput of an optical network based on this solution. The methodology involves detailed physical layer modeling, including the impact of stimulated Raman scattering, which is responsible for energy transfer between the two bands. Two approaches are implemented for throughput evaluation: one assuming idealized Gaussian-modulated signals and the other using real modulation formats. For designing such networks, it is crucial to choose the most appropriate technological solution for optical amplification. This could either be a band-dedicated scheme, which uses a separate amplifier for each of the two bands, or a single-wideband amplifier capable of amplifying both bands simultaneously. The simulation results show that the single-wideband scheme provides an average throughput improvement of about 18% compared to the dedicated scheme when using the Gaussian modulation approach. However, with the real modulation approach, the improvement increases significantly to about 32%, highlighting the benefit in developing single-wideband amplifiers for future applications in Super C+L-band networks. Full article

Multi-band optical communication presents a promising avenue for the significant enhancement of fiber-optic transmission capacity without incurring additional costs related to new cable deployment via the utilization of the bandwidth beyond the established C&L bands. However, a big challenge in its field implementation lies in the high cost and suboptimal performance of optical amplifiers, stemming from the underdeveloped state of rare-earth-doped fiber-optic amplifier technologies for these bands. Fiber-optic parametric amplifiers provide an alternative for wideband optical amplification, yet their low power efficiency limits their practical use in the field. In this paper, we study a hybrid optical amplifier that combines the excellent power efficiency of rare-earth-doped amplifiers with broadband wavelength conversion capability of parametric amplifiers. It uses wavelength converters to shift signals between the S- and L-bands, amplifying them with an L-band erbium-doped fiber amplifier, and converting them back to the S-band. We experimentally demonstrate such a hybrid S-band amplifier, characterize its performance with 16-QAM input signals, and evaluate its power efficiency and four-wave-mixing-induced crosstalk. This hybrid approach paves the way for scalable expansion of optical communication bands without waiting for advancements in rare-earth-doped amplifier technology. Full article

Polymer-based waveguide amplifiers are essential components in integrated optical systems, as their gain bandwidths directly determine the operating wavelength of optical circuits. However, development of the wideband gain media has been challenging, making it difficult to fabricate devices with broadband amplification capability. Rare earth ion-doped nanoparticles (NPs) are a key component in the gain media, and their full width at half maximum (FWHM) of the emission peak decides the final gain bandwidth of the gain media. Here, KMnF₃: Yb, Er, Ce@KMnF₃: Yb NPs with the broad full width at half maximum (FWHM) of the emission peak covering the S+C band was prepared. The NPs were synthesized using a hydrothermal method, and the FWHM of the emission peak of NPs reached 76 nm under the excitation of a 980 nm laser. The introduction of Ce³⁺ ions and a core-shell structure coating greatly enhanced the emission intensity of NPs at C band. Since KMnF₃: Yb, Er, Ce@KMnF₃: Yb NPs have exceptional broadband luminescence properties at C band, KMnF₃: Yb, Er, Ce@KMnF₃: Yb NPs can be the potential gain medium in the future polymer-based waveguide amplifiers. Full article

Low–coherence laser is regarded as the key to mitigating laser–plasma instability (LPI) in laser–driven inertial confinement fusion (ICF), where LPI can decrease the laser energy coupled to the target. With the merits of low coherence, high spectral stability, and flexible output characteristics, the Raman random fiber laser (RRFL) is considered to be a candidate light source in ICF. In this paper, the 1054 nm RRFL with high slope efficiency is achieved for the first time. In the RRFL pump source design section, we have optimized the ytterbium–doped fiber (YDF) length by simulation and amplified the power by Master Oscillator Power Amplifier (MOPA) to realize a 1011 nm YDF laser with 47.3 dB optical signal–to–noise ratio (OSNR). In terms of RRFL cavity design, a fiber loop mirror and Rayleigh scattering in the HI 1060 Flex fiber provide wideband point feedback and random distributed feedback, respectively. Based on this system, we achieve an RRFL output with 0.4 nm half–maximum full width, 182% slope efficiency, and 41.3 dB OSNR. This work will provide guidance for the application of RRFL in high–energy–density physics research. Full article

Perfect metamaterial absorber (PMA) is an attractive optical wavelength absorber with potential solar energy and photovoltaic applications. Perfect metamaterials used as solar cells can improve efficiency by amplifying incident solar waves on the PMA. This study aims to assess a wide-band octagonal PMA for a visible wavelength spectrum. The proposed PMA consists of three layers: nickel, silicon dioxide, and nickel. Based on the simulations, polarisation-insensitive absorption transverse electric (TE) and transverse magnetic (TM) modes were achieved due to symmetry. The proposed PMA structure was subjected to computational simulation using a FIT-based CST simulator. The design structure was again confirmed using FEM-based HFSS to maintain pattern integrity and absorption analysis. The absorption rates of the absorber were estimated at 99.987% and 99.997% for 549.20 THz and 653.2 THz, respectively. The results indicated that the PMA could achieve high absorption peaks in TE and TM modes despite being insensitive to polarisation and the incident angle. Electric field and magnetic field analyses were performed to understand the absorption of the PMA for solar energy harvesting. In conclusion, the PMA possesses outstanding visible frequency absorption, making it a promising option. Full article

Ultra-wideband (UWB) wavelength division multiplexing (WDM) transmission, which utilizes low-loss spectral windows of single-mode fiber for data transmission, is a highly promising method for increasing the capacity of optical communication. In this paper, we investigate the performance of a UWB WDM transmission system that covers the widely used C+L band as well as the additional O-, E-, and S-bands. We establish the transmission system for UWB and discuss the effects of the channel, including Kerr nonlinearity and inter-channel interference from inter-channel stimulated Raman scattering (ISRS) between O-, E-, S-, C-, and L-bands. Moreover, we demonstrate an optimization scheme for compensating the spectral power tilt caused by SRS in the S+C+L band system, which utilizes the Raman amplifier and the partition particle swarm optimization (PPSO) algorithm. The results show that the power tilt value of the algorithm is reduced from 18 to 2.93 dB, and the iteration speed is improved by 10% compared with the normal particle swarm algorithm. The scheme provides an efficient way to improve the generalized mutual information (GMI) performance of UWB WDM systems. Full article

An optimized design for a broadband Raman optical amplifier in standard single-mode fiber covering the C and L bands is presented, to be used in combination with wideband optical phase conjugation (OPC) nonlinearity compensation. The use of two Raman pumps and fiber Bragg grating reflectors at different wavelengths for the transmitted (C band) and conjugated (L band) WDM channels is proposed to extend bandwidth beyond the limits imposed by single-wavelength pumping, for a total 10 THz. Optimization of pump and reflector wavelength, as well as pump powers, allows us to achieve low asymmetry across the whole transmission band for optimal nonlinearity compensation. System performance is simulated to estimate OSNR, gain flatness and nonlinear Kerr distortion. Full article

A comprehensive study has been conducted on ultra-broadband optically pumped quantum dot (QD) reflective semiconductor optical amplifiers (QD-RSOAs). Furthermore, little work has been done on broadband QD-RSOAs with an optical pump. About 1 μm optical bandwidth, spanning 800 nm up to 1800 nm, is supported for the suggested device by superimposing nine groups of QDs. It has been shown that the device can be engineered to amplify a selected window or a group of desired windows. Moreover, the operation of the device has been thoroughly investigated by solving the coupled differential rate and signal propagation equations. A numerical algorithm has been suggested to solve these equations. As far as we are concerned, a broadband optically pumped QD-RSOA that can operate as a filter has been introduced. Full article

A traveling-wave tube (TWT) with a sheet electron beam and staggered double-grating slow-wave structure (SWS) is a promising high-power, wideband terahertz amplifier. In such tubes, electron-optical systems (EOSs) with a converging sheet beam are mostly used, which allow a reduction of the cathode load, increase the lifetime, and enable operation in a continuous-wave (CW) mode. This paper presents the results of a 3D particle-in-cell (PIC) simulation of the 0.22 THz TWT driven with a converged sheet beam, which is compressed to less than 100 μm thickness in the EOS with a magnetically shielded cathode. The beam with high compression has a significant transversal velocity spread and essentially non-uniform current density distribution over the cross-section. These factors significantly affect the beam–wave interaction. We compare the performance of the TWT driven by the compressed sheet beam and by an idealized initially rectilinear beam without any velocity spread. Full article

Broadband amplification in the O+E-band is very desirable nowadays as a way of coping with increasing bandwidth demands. The main issue with doped fiber amplifiers working in this band such as the bismuth-doped fiber amplifier is that they are costly and not widely available. Therefore, a wideband and flat-gain hybrid optical amplifier (HOA) covering the O+E-band based on a parallel combination of a praseodymium-doped fiber amplifier (PDFA) and a semiconductor optical amplifier (SOA) is proposed and demonstrated through numerical simulations. The praseodymium-doped fiber (PDF) core is pumped using a laser diode with a power of 500 mW that is centered at a wavelength of 1030 nm. The SOA is driven by an injection current of 60 mA. The performance of the HOA is analyzed by the optimization of various parameters such as the PDF length, Pr${}^{3+}$ concentration, pump wavelength, and injection current. A flat average gain of 24 dB with a flatness of 1 dB and an output power of 9.6 dBm is observed over a wavelength range of 1270–1450 nm. The noise figure (NF) varies from a minimum of 4 dB to a maximum of 5.9 dB for a signal power of 0 dBm. A gain reduction of around 4 dB is observed for an O-band signal at a wavelength of 1290 nm by considering the up-conversion effect. The transmission performance of the designed HOA as a pre-amplifier is evaluated based on the bit-error rate (BER) analysis for a coarse wavelength-division multiplexing (CWDM) system of eight on-off keying (OOK)-modulated channels, each having a data rate of 10 Gbps. An error-free transmission over 60 km of standard single-mode fiber (SMF) is achieved for different data rates of 5 Gbps, 7.5 Gbps, and 10 Gbps. Full article

In the optical energy gap, visible and near-IR emission of halide phosphate glasses with a composition of 40P₂O₅-30ZnO-20LiCl-10BaF₂ in mol% doped with 3.5 × 10⁴ ppm Pr₂O₃, referred to as PZLBPr, were synthesized. The UV-VIS-NIR and spectroscopic properties of these glasses were also predicted. The current glasses had broadband emission photoluminescence covering a wavelength range of 1250 to 1700 nm when excited at 455 nm. These bands for near-infrared emission luminescence relate to the transitions ¹G₄ → ³H₅, ¹D₂ → ¹G₄, and ³H₄ → ³F₃, ³F₄ in the optical telecommunication window. The significant PL emission wideband was caused by the radiative transition from Pr³⁺: ¹D₂ to ¹G₄. At 445 nm excitation, these glasses exhibited emission bands that corresponded to blue/reddish orange spectral ranges in visible ranges. The prepared glass has a high lasing quality factor (Ω₄/Ω₆ = 0.9), high optical energy (4.72 eV), and quantum efficiency = 87.3% with FWHM = 156 nm of transition emission from the ¹D₂ → ¹G₄ level. As a result, broadband near infrared optical amplifiers can be fabricated from the prepared glasses. Full article

Cladding-pumped erbium (Er³⁺)/ytterbium (Yb³⁺)-co-doped fiber amplifiers are more advantageous at high output powers. However, this amplification technique also has potential in telecom-related applications. These types of amplifiers have complex properties, especially when considering gain profile and a pump conversion efficiency. Such metrics depend on the doped fiber profile, absorption/emission spectra, and the input signal power. In this context, we design, build and characterize an inhouse prototype of cladding-pumped Er³⁺/Yb³⁺-co-doped fiber amplifier (EYDFA). Our goal is to identify the EYDFA configuration (a co-doped fiber length, pump power, input signal power) suitable for signal amplification in a multichannel fiber-optic transmission system with a dense wavelength allocation across the C-band (1530–1565 nm). Our approach involves experimentally determining the Er³⁺/Yb³⁺-co-doped fiber’s parameters to be used in a simulation setup to decide on an initial EYDFA configuration before moving to a laboratory setup. An experimental EYDFA prototype is tested under different conditions using a 48-channel dense wavelength division multiplexing (DWDM, 100 GHz) system to evaluate the absolute gain and gain uniformity. The obtained results allow the cladding pump amplifier’s suitability for wideband signal amplification to be assessed. The developed prototype provides >21 dB of gain with a 12 dB ripple within 1534–1565 nm. Furthermore, we show that the gain profile can be partially flattened out by using longer EYDF spans. This enhances signal amplification in the upper C-band in exchange for a weaker amplification in the lower C-band, which can be marginally improved with higher pump powers. Full article

Quasi-coherent optical receivers have recently emerged targeting access networks, offering improved sensitivity and reach over direct-detection schemes at the expense of a higher receiver bandwidth. Higher levels of system integration together with sufficiently wideband front-end blocks, and in particular high-speed linear transimpedance amplifiers (TIAs), are currently demanded to reduce cost and scale up receiver data rates. In this article, we report on the design and testing of a linear TIA enabling high-speed quasi-coherent receivers. A shunt-feedback loaded common-base topology is adopted, with gain control provided by a subsequent Gilbert cell stage. The circuit was fabricated in a commercial 130 nm SiGe BiCMOS technology and has a bandpass characteristic with a 3 dB bandwidth in the range of 5–50 GHz. A differential transimpedance gain of 68 dB$\mathsf{\Omega }$ was measured, with 896 $m{V}_{pp}$ of maximum differential output swing at the 1 dB compression point. System experiments in a quasi-coherent receiver demonstrate an optical receiver sensitivity of −30.5 dBm (BER = 1 × 10${}^{-3}$) at 10 Gbps, and −26 dBm (BER = 1 × 10${}^{-3}$) at 25 Gbps. The proposed TIA represents an enabling component towards highly integrated quasi-coherent receivers. Full article

We demonstrated a 1.1-µm band extended wideband wavelength-swept laser (WSL) that combined two semiconductor optical amplifiers (SOAs) based on a polygonal scanning wavelength filter. The center wavelengths of the two SOAs were 1020 nm and 1140 nm, respectively. Two SOAs were connected in parallel in the form of a Mach-Zehnder interferometer. At a scanning speed of 1.8 kHz, the 10-dB bandwidth of the spectral output and the average power were approximately 228 nm and 16.88 mW, respectively. Owing to the nonlinear effect of the SOA, a decrease was observed in the bandwidth according to the scanning speed. Moreover, the intensity of the WSL decreased because the oscillation time was smaller than the buildup time. In addition, a cholesteric liquid crystal (CLC) cell was fabricated as an application of WSL, and the dynamic change of the first-order reflection of the CLC cell in the 1-µm band was observed using the WSL. The pitch jumps of the reflection band occurred according to the electric field applied to the CLC cell, and instantaneous changes were observed. Full article

We proposed and experimentally demonstrated a secure key generation and distribution system that is compatible with optical amplifiers and standard wavelength-division multiplexing (WDM) transmission systems. The key is generated from the phase fluctuations induced by environmental instabilities. The key generation system is tested in a 240 km bidirectional fiber-pair link with multiple optical amplifiers. To demonstrate the compatibility with WDM systems, 38 WDM channels are transmitted together with the key distribution channel. The secret key is protected against eavesdropping and coherence detection attack by the wide-band property of the signal carrier and the fast-changing rate of the phase fluctuations. Full article
