Search Results (52)

Breast cancer detection through non-invasive and accurate techniques remains a critical challenge in medical diagnostics. This study introduces a deep learning-based framework that leverages a microwave radar system equipped with an arc-shaped array of six antennas to estimate key tumor parameters, including position, size, and depth. This research begins with the evolutionary design of an ultra-wideband octagram ring patch antenna optimized for enhanced tumor detection sensitivity in directional near-field coupling scenarios. The antenna is fabricated and experimentally evaluated, with its performance validated through S-parameter measurements, far-field radiation characterization, and efficiency analysis to ensure effective signal propagation and interaction with breast tissue. Specific Absorption Rate (SAR) distributions within breast tissues are comprehensively assessed, and power adjustment strategies are implemented to comply with electromagnetic exposure safety limits. The dataset for the deep learning model comprises simulated self and mutual S-parameters capturing tumor-induced variations over a broad frequency spectrum. A core innovation of this work is the development of the Attention-Based Feature Separation (ABFS) model, which dynamically identifies optimal frequency sub-bands and disentangles discriminative features tailored to each tumor parameter. A multi-branch neural network processes these features to achieve precise tumor localization and size estimation. Compared to conventional attention mechanisms, the proposed ABFS architecture demonstrates superior prediction accuracy and interpretability. The proposed approach achieves high estimation accuracy and computational efficiency in simulation studies, underscoring the promise of integrating deep learning with conformal microwave imaging for safe, effective, and non-invasive breast cancer detection. Full article

The identification of vital signs is becoming increasingly important in various applications, including healthcare monitoring, security, smart homes, and locating entrapped persons after disastrous events, most of which are achieved using continuous-wave radars and ultra-wideband systems. Operating frequency and transmission power are important factors to consider when conducting earthquake search and rescue (SAR) operations in urban regions. Poor communication infrastructure can also impede SAR operations. This study proposes a method for vital sign detection using an integrated sensing and communication (ISAC) system where a unified orthogonal frequency division multiplexing (OFDM) signal was adopted, and it is capable of sensing life signs and carrying out communication simultaneously. An ISAC demonstration system based on software-defined radios (SDRs) was initiated to detect respiratory and heartbeat rates while maintaining communication capability in a typical office environment. The specially designed OFDM signals were transmitted, reflected from a human subject, received, and processed to estimate the micro-Doppler effect induced by the breathing and heartbeat of the human in the environment. According to the results, vital signs, including respiration and heartbeat rates, have been accurately detected by post-processing the reflected OFDM signals with a 1 MHz bandwidth, confirmed with conventional contact-based detection approaches. The potential of dual-function capability of OFDM signals for sensing purposes has been verified. The principle and method developed can be applied in wider ISAC systems for search and rescue purposes while maintaining communication links. Full article

In this study, a composite substrate with adjustable dielectric properties was prepared, and its promising application in wearable medical device antennas was demonstrated. 3-Methacryloxypropyltrimethoxysilane (KH570) was used to modify titanium dioxide (TiO₂) nano-powder, and the modified powder was blended with a mixture of polydimethylsiloxane (PDMS) and polytetrafluoroethylene (PTFE) under the action of anhydrous ethanol. The resulting polymer material had the advantages of hydrophobicity, softness, low loss, and a high dielectric constant. Meanwhile, the effects of the KH570 mass fraction on the microstructure and dielectric properties of TiO₂-PTFE-PDMS composites were investigated, and the results showed that when the mass fraction was 5%, the composites exhibited better dielectric properties in the range of 2–12 GHz. Finally, an ultra-wideband antenna with an operating frequency band in the range of 2.37–11.66 GHz was prepared based on this composite substrate. The antenna demonstrated significant potential for future applications in detecting environmental thermal changes due to its special temperature-sensitive linear frequency shift characteristics, and its effect on the human body under bending conditions was studied. In addition, specific absorption rate (SAR) measurements were performed to assess the effects of antenna radiation on the human body in practical applications. Full article

The design of wideband multi-port multiple-input multiple-output (MIMO) antennas and their optimization are very important for next-generation smartphones with the increase in massive connectivity. This paper offers the design, simulation, measurement, and specific absorption rate (SAR) analysis of a Pi-shaped ten-element MIMO antenna system for use in the upper mid-band, covering LTE 46 (5.15–5.925 GHz), LTE 47 (5.855–5.925 GHz), and n102 (5.925–6.425 GHz), thus meeting a good fractional bandwidth of 32.7% with a maximum peak gain of 2.89 dBi. Hence, it is well suited for high-isolation (<−10 dB), compactness, and wideband (4.7–6.5 GHz) applications suitable for the current communication system needs. The overall size of the proposed system is 125 mm × 70 mm, with a planar dielectric material Rogers RT/5880. Designing the proposed antenna with multiple units entails the preservation of the spatial features of the antenna alongside the reduction of the mutual coupling for adjacent elements by using a decoupling structure. Due to the high accuracy of the positioning elements and precise geometric transformations, the antenna system provides high-performance analysis based on reflection coefficients, radiation patterns, and each antenna’s averaged efficiency values (76.12–91.57%). Full article

Synthetic aperture radar (SAR) systems, as wideband radar systems, are inherently susceptible to interference signals within their operational frequency band, which significantly affects SAR signal processing and image interpretation. Recent studies have demonstrated that semiparametric methods (e.g., the RPCA method) exhibit excellent performance in suppressing these interference signals. However, these methods predominantly focus on processing SAR’s raw echo data, which does not satisfy the sparsity requirements and entails extremely high computational complexity, complicating integration with imaging algorithms. This paper introduces an effective method for suppressing interference signals by leveraging the sparsity of the SAR image domain. It utilizes the sparsity of the interference signal in the two-dimensional frequency domain, following focusing processing, rather than relying on low-rank properties. This approach significantly reduces the computational complexity. Ultimately, the effectiveness and efficiency of the proposed algorithm are validated through experiments conducted with simulated and real SAR data. Full article

This paper presents an innovative, compact, dual-element, implantable, ultra-wideband, circularly polarized multiple-input multiple-output (MIMO) antenna designed to operate within the 2.45 GHz industrial, scientific, and medical band, and both of its radiating units are circularly polarized antennas with polarization diversity. Specifically, antenna-1 exhibits left-handed circular polarization properties, while antenna-2 demonstrates right-handed circular polarization properties. The slots in the radiating patch and ground plane help the antenna achieve 690 MHz (2.14–2.83 GHz) ultra-wide bandwidth characteristics and circularly polarized characteristics. Additionally, a slit connecting two U-slots on the ground plane allows the antenna to achieve a wide effective circularly polarized axial ratio bandwidth of 400 MHz (2.23–2.63 GHz). The antenna is compact, with dimensions of 0.065 × 0.057 × 0.0042 λ₀³ (λ₀ represents the free-space wavelength corresponding to the lowest operating frequency). The proposed antenna system’s performance was evaluated with a seven-layer homogeneous human head model, a real human head model, and minced pork. This evaluation revealed that the antenna attained a peak gain of −24.1 dBi and an isolation level of 27.5 dB. Furthermore, the assessment included the antenna’s link margin (LM), key MIMO channel characteristics, and Specific Absorption Rate (SAR) metrics. The results indicate that the antenna performs exceptionally well. Full article

Detecting sub-surface objects poses significant challenges, partly due to attenuation of the ground medium and cluttered environments. The acquisition polarisation and antenna orientation can also yield significant variation of detection performance. These challenges can be mitigated by developing more versatile systems and algorithms to enhance detection and identification. In this study, a novel application of a 3D SAR inverse algorithm and polarisation synthesis was applied to ultra-wideband polarimetric data of buried objects. The principle of polarisation synthesis facilitates an adaptable technique which can be used to match the target’s polarisation characteristics, and the application of this revealed hidden structures, enhanced detection, and increased received power when compared to single polarisation results. This study emphasises the significance of polarimetry in ground-penetrating radar (GPR), particularly for target discrimination in high-lift-off applications. The findings offer valuable insights that could drive future research and enhance the performance of these sensing systems. Full article

This paper investigates the airborne synthetic aperture radar via outfield experiments based on carrier-free ultra-wideband signals with fifth-order Gaussian pulses with imaging using the backward projection algorithm. Typical blanket jamming is selected in the study, and NAM, NFM, and SFM are used as jamming signals to investigate the backward projection BP imaging effect of airborne synthetic aperture radar when subjected to blanket jamming in a real-world environment. Subsequently, a variational modal decomposition algorithm is proposed, aiming at the anti-jamming processing of airborne synthetic aperture radar. Further, the variational modal decomposition algorithms are compared with the empirical modal decomposition for the anti-jamming effect, which verified the effectiveness and high efficiency of the method. This study provides a new solution for the imaging problem of airborne synthetic aperture radar when subjected to blanket jamming, and a helpful reference is provided for the selection of anti-jamming processing methods. Full article

A novel dual-wideband textile antenna designed for wearable applications is introduced in this study. Embedding antennas into wearable devices requires a detailed analysis of the specific absorption rate (SAR) to ensure safety. To achieve this, SAR values were meticulously simulated and evaluated within a human voxel model, considering various body regions such as the left/right head and the abdominal region. The proposed antenna is a monopole design utilizing denim textile as the substrate material. The characterization of the denim textile substrate is carried out using two different methods. The first analysis included a DAC (Dielectric Assessment Kit), while a ring resonator technique was employed for the second examination. Operating within the frequency bands of (58.06%) 2.2–4 GHz and (61.43) 5.3–10 GHz, the antenna demonstrated flexibility in its dual-wideband capabilities. Extensive simulations and tests were conducted to assess the performance of the antenna in both flat and bent configurations. The SAR results obtained from these tests indicate that the antenna complies with safety standard limits when integrated with the human voxel model. This validation underscores the potential of the proposed antenna for seamless integration into wearable applications, offering a promising solution for future developments in this domain. Full article

In this study, at ultra-wideband (UWB) frequency band (3.1–10.6 GHz), we propose the use of compact 2:1 and 3:1 nonuniform transmission line Wilkinson power dividers (NTL WPDs) as feeding networks for simple 2 × 1 linear UWB Vivaldi tapered and nonuniform slot antenna (VTSA and VNSA) arrays. The 2:1 and 3:1 tapered transmission line (TTL) WPDs are designed and tested in this work as benchmarks for NTL WPDs. The VTSA array provides measured S₁₁ < −10.28 dB at 2.42–11.52 GHz, with a maximum gain of 8.61 dBi, which is 24.39% higher than the single element. Using the VNSA array, we achieve 52% compactness and 6.76% bandwidth enhancement, with good measured results of S₁₁ < −10.2 dB at 3.24–13 GHz and 15.11% improved gain (8.14 dBi) compared to the VNSA single element. The findings show that the NTL and Vivaldi nonuniform slot profile antenna (VNSPA) theories are successful at reducing the size of the UWB WPD and VTSA without sacrificing performance. They also emphasize the Vivaldi antenna’s compatibility with other circuits. These compact arrays are ideal for high-resolution medical applications like breast cancer detection (BCD) because of their high gain, wide bandwidth, directive stable radiation patterns, and low specific absorption rate (SAR). A simple BCD simulation scenario is addressed in this work. Detailed parametric studies are performed on the two arrays for impedance-matching enhancement. The computer simulation technology (CST) software is used for the simulation. Hardware measurement results prove the validity of the proposed arrays. Full article

Geosynchronous spaceborne–airborne (GEO-SA) ultra-high-frequency ultra-wideband bistatic synthetic aperture radar (UHF UWB BiSAR) provides high-precision images for marine and polar environments, which are pivotal in glacier monitoring and sea ice thickness measurement for polar ocean mapping and navigation. Contrasting with traditional high-frequency BiSAR, it faces unique challenges, such as the considerable spatial variability, significant range–azimuth coupling, and vast volumes of echo data, which impede high-resolution image reconstruction. This paper presents an improved bistatic nonlinear chirp scaling (NLCS) algorithm for imaging oceanic scenes with GEO-SA UHF UWB BiSAR. This methodology extends the two-dimensional (2-D) spectrum up to the sixth order via the method of series reversion (MSR) to meet accuracy demands and then employs an elliptical model to elucidate the alterations in the azimuth frequency modulation (FM) rate mismatch. Initially, the imaging geometry and signal model are introduced, and then a separation of bistatic slant ranges based on the configuration is proposed. In addition, during range processing, after eliminating linear range cell migration (RCM), the derivation process for the sixth-order 2-D spectrum is detailed and an improved filter is applied to correct the high-order RCM. Finally, during azimuth processing, the causes of the FM rate mismatch are analyzed, a cubic perturbation function derived from the elliptical model is used for FM rate equalization, and a unified sixth-order filter is applied to complete the azimuth compression. Experimental results with point targets and natural oceanic scenes validate the outstanding efficacy of the proposed NLCS algorithm, particularly in imaging quality enhancements for GEO-SA UHF UWB BiSAR. Full article

Wideband interference (WBI) can significantly reduce the image quality and interpretation accuracy of synthetic aperture radar (SAR). To eliminate the negative effects of WBI on SAR, we propose a novel end-to-end data-driven approach to mitigate WBI. Specifically, the WBI is mitigated by an explicit function called WBI mitigation–generative adversarial network (WBIM-GAN), mapping from an input WBI-corrupted echo to its properly WBI-free echo. WBIM-GAN comprises a WBI mitigation network and a target echo discriminative network. The WBI mitigation network incorporates a deep residual network to enhance the performance of WBI mitigation while addressing the issue of gradient saturation in the deeper layers. Simultaneously, the class activation mapping technique fully demonstrates that the WBI mitigation network can localize the WBI region rather than the target echo. By utilizing the PatchGAN architecture, the target echo discriminative network can capture the local texture and statistical features of target echoes, thus improving the effectiveness of WBI mitigation. Before applying the WBIM-GAN, the short-time Fourier transform (STFT) converts SAR echoes into a time–frequency domain (TFD) to better characterize WBI features. Finally, by comparing different WBI mitigation methods applied to several real measured SAR data collected by the Sentinel-1 system, the efficiency and superiority of WBIM-GAN are proved sufficiently. Full article

This article presents an in-depth investigation of wearable microwave antenna sensors (MASs) used for vital sign detection (VSD) and lung water level (LWL) monitoring. The study looked at two different types of MASs, narrowband (NB) and ultra-wideband (UWB), to decide which one was better. Unlike recent wearable respiratory sensors, these antennas are simple in design, low-profile, and affordable. The narrowband sensor employs an offset-feed microstrip transmission line, which has a bandwidth of 240 MHz at −10 dB reflection coefficient for the textile substrate. The UWB microwave sensor uses a CPW-fed line to excite an unbalanced U-shaped radiator, offering an extended simulated operating bandwidth from 1.5 to 10 GHz with impedance matching ≤−10 dB. Both types of microwave sensors are designed on a flexible RO 3003 substrate and textile conductive fabric attached to a cotton substrate. The specific absorption rate (SAR) of the sensors is measured at different resonant frequencies on 1 g and 10 g of tissue, according to the IEEE C95.3 standard, and both sensors meet the standard limit of 1.6 W/kg and 2 W/kg, respectively. A simple peak-detection algorithm is used to demonstrate high accuracy in the detection of respiration, heartbeat, and lung water content. Based on the experimental results on a child and an adult volunteer, it can be concluded that UWB MASs offer superior performance when compared to NB sensors. Full article

This paper investigates a real-time process generator of wideband signals, which calculates waveforms in a field-programmable gate array (FPGA) using the high-level synthesis (HLS) method. To obtain high-resolution and wide-swath images, the generator must produce multiple modes of large time-bandwidth product (TBP) linear frequency modulation (LFM) signals. However, the conventional storage method is unrealistic as it requires huge storage resources to save pre-computed waveforms. Therefore, this paper proposes a novel processing approach that calculates waveforms in real-time based simply on parameters such as the sampling frequency, bandwidth, and time width. Additionally, this paper implements predistortion through the polynomial curve to approximate phase errors of the system. The parallelizing process in the FPGA is necessary to satisfy the high-speed requirement of a digital-to-analog converter (DAC); however, repeatedly multiplexing real-time calculation consumes extensive logic and DSP resources, potentially exceeding FPGA limitations. To address this, this paper proposes a piecewise linear algorithm to conserve resources, which processes the polynomial only once, acquires the difference in two adjacent values through the register and pipeline, and then adds this increment to facilitate parallel computations. The performance of this proposed generator is validated through simulation and implemented in experiments with an X-band airborne SAR system. Full article

As the electromagnetic environment becomes increasingly complex, a synthetic aperture radar (SAR) system with wideband active transmission and reception is vulnerable to interference from devices at the same frequency. SAR interference detection using the transform domain has become a research hotspot in recent years. However, existing transform domain interference detection methods exhibit unsatisfactory performance in complex interference environments. Moreover, most of them rely on label information, while existing publicly available interference datasets are limited. To solve these problems, this paper proposes an SAR unsupervised interference detection model that combines Canny edge detection with vision transformer (CEVIT). Using a time–frequency spectrogram as input, CEVIT realizes interference detection in complex interference environments with multi-interference and multiple types of interference by means of a feature extraction module and a detection head module. To validate the performance of the proposed model, experiments are conducted on airborne SAR interference simulation data and Sentinel-1 real interference data. The experimental results show that, compared with the other object detection models, CEVIT has the best interference detection performance in a complex interference environment, and the key evaluation indexes (e.g., Recall and F1-score) are improved by nearly 20%. The detection results on the real interfered echo data have a Recall that reaches 0.8722 and an F1-score that reaches 0.9115, which are much better than those of the compared methods, and the results also indicate that the proposed model achieves good detection performance with a fast detection speed in complex interference environments, which has certain practical application value in the interference detection problem of the SAR system. Full article
