This study analyzed the frequency control challenges within the West Africa Power Pool Interconnected Transmission System (WAPPITS) as it plans to incorporate variable renewable energy (VRE) resources, such as wind and solar energy. Concerns center on the ability of WAPPITS primary frequency control reserves to adapt to high VRE penetration given the synchronization and frequency control problems experienced by the three separate synchronous blocks of WAPPITS. Optimizing solutions requires a better understanding of WAPPITS’ current frequency control approach. This study used questionnaires to understand operators’ practical experience with frequency control and compared these observations to field tests at power plants and frequency response metrics during system events. Eight (8) of ten (10) Transmission System Operators (TSOs) indicated that primary frequency control service was implemented in the TSO, but nine (9) of ten TSOs indicated that the reserves provided were inadequate to meet system needs. Five (5) of ten (10) respondents answered “yes” to the provision of secondary frequency control service, while only one (1) indicated that secondary reserves were adequate. Three (3) TSOs indicated they have AGC (Automatic Generation Control) installed in the control room, but none have implemented it for secondary frequency control. The results indicate a significant deficiency in primary control reserves, resulting in a reliance on under-frequency load shedding for primary frequency control. Additionally, the absence of an AGC system for secondary frequency regulation required manual intervention to restore frequency after events. To ensure the effectiveness of battery energy storage systems (BESSs) and the reliable operation of the WAPPITS with a higher penetration of inverter-based VRE, this paper recommends (a) implementing and enforcing basic primary frequency control structures through regional regulation and (b) establishing an ancillary services market to mobilize secondary frequency control resources. Full article

The increasing power consumption reflects technological and industrial growth, but meeting this demand with conventional fossil-fuel-based plants is challenging. Microgrids address this issue by integrating renewable energy-based Distributed Energy Resources (DERs) and Energy Storage Systems (ESS). Efficient Microgrid operation requires a power management system to balance supply and demand, reduce costs, and ensure load prioritization. This paper presents a wide area measurement (WAMS)-based Centralized Power Management System (CPMS) for AC microgrids in both Islanded and Grid-Connected modes. The modified IEEE 13-bus system is utilized as a microgrid test system by integrating DERs and ESS. WAMS significantly enhances intra-microgrid communication by offering real-time, high-resolution monitoring of electrical parameters, surpassing the limitations of traditional SCADA-based monitoring systems. In grid-connected mode, the proposed CPMS effectively manages dynamic grid tariffs, generation variability in DERs, and state-of-charge (SoC) variations in the ESS while ensuring uninterrupted load supply. In islanded mode, a load prioritization scheme is employed to dynamically disconnect and restore loads to enhance the extent of load coverage across consumer categories. The inclusion of diverse load categories, such as domestic, industrial, commercial, etc., enhances the practical applicability of the CPMS in real-world power systems. The effectiveness of the proposed CPMS is validated through multiple case studies conducted in Simulink/MATLAB. Full article

To ensure the reliability and security of Colombia’s national power system, there is an ongoing necessity for upgrades in monitoring and protection mechanisms. Approximately sixteen years ago, the introduction of synchrophasor measurements enabled the swift detection of potentially network-detrimental events. Subsequent advancements have seen the deployment of Phasor Measurement Units (PMUs), currently tallying 150 across 25 substations, facilitating real-time monitoring and analysis. The growth of the PMU network is pivotal for the modernization of the National Control Center, particularly in the face of complexities introduced by renewable energy sources. There is an increasing demand for data analytics platforms to support operators in responding to threats. This paper explores the development of the Colombian Wide-Area Measurement System (WAMS) network, highlighting its milestones and advancements. Significant contributions include the technological evolution of the WAMS for real-time monitoring, an innovative high-speed data analytics strategy, and tools for the monitoring of frequency, rate of change of frequency (RoCoF), angular differences, oscillations, and voltage recovery, alongside industry-specific criteria for real-time assessment. Implemented within an operational WAMS, these tools enhance situational awareness, thereby assisting operators in decision-making and augmenting the power system’s reliability, security, and efficiency, underscoring their significance in modernization and sustainability initiatives. Full article

Smart grid reliability and efficiency are critical for uninterrupted service, especially amidst growing demand and network complexity. Wide-Area Measurement Systems (WAMS) are valuable tools for mitigating faults and reducing fault-clearing time while simultaneously prioritizing cybersecurity. This review looks at smart grid WAMS implementation and its potential for cyber-physical power system (CPPS) development and compares it to traditional Supervisory Control and Data Acquisition (SCADA) infrastructure. While traditionally used in smart grids, SCADA has become insufficient in handling modern grid dynamics. WAMS differ through utilizing phasor measurement units (PMUs) to provide real-time monitoring and enhance situational awareness. This review explores PMU deployment models and their integration into existing grid infrastructure for CPPS and smart grid development. The review discusses PMU configurations that enable precise measurements across the grid for quicker, more accurate decisions. This study highlights models of PMU and WAMS deployment for conventional grids to convert them into smart grids in terms of the Smart Grid Architecture Model (SGAM). Examples from developing nations illustrate cybersecurity benefits in cyber-physical frameworks and improvements in grid stability and efficiency. Further incorporating machine learning, multi-level optimization, and predictive analytics can enhance WAMS capabilities by enabling advanced fault prediction, automated response, and multilayer cybersecurity. Full article

This paper proposes a correction technique for bad data and high-precision analysis based on micro-phasor measurement unit (μPMU) data for a stable and reliable smart substation. First, a high-precision wide-area monitoring system (WAMS) with 35 μPMUs installed at Korea’s Yeonggwang substation, which is connected to renewable energy sources (RESs), is introduced. Time-synchronized μPMU data are collected through the phasor data concentrator (PDC). A pre-processing program is implemented and utilized to integrate the raw data of each μPMU into a single comma-separated values (CSV) snapshot file based on the Timetag. After presenting the technique for identification and correction of event, duplicate, and spike bad data of μPMU, causal relationships are confirmed through the voltage and current fluctuations for a total of five states, such as T/L fault, tap-up, tap-down, generation, and generation shutdown. Additionally, the difference in active power between the T/L and the secondary side of the M.Tr is compared, and the fault ride through (FRT) regulations, when the fault in wind power generation (WP), etc., occurred, is analyzed. Finally, a statistical analysis, such as boxplot and kernel density, based on the instantaneous voltage fluctuation rate (IVFR) is conducted. As a result of the simulation evaluation, the proposed correction technique and precise analysis can accurately identify various phenomena in substations and reliably estimate causal relationships. Full article

This paper examines the use of manifold learning in the context of electric power system transient stability analysis. Since wide-area monitoring systems (WAMSs) introduced a big data paradigm into the power system operation, manifold learning can be seen as a means of condensing these high-dimensional data into an appropriate low-dimensional representation (i.e., embedding) which preserves as much information as possible. In this paper, we consider several embedding methods (principal component analysis (PCA) and its variants, singular value decomposition, isomap and spectral embedding, locally linear embedding (LLE) and its variants, multidimensional scaling (MDS), and others) and apply them to the dataset derived from the IEEE New England 39-bus power system transient simulations. We found that PCA with a radial basis function kernel is well suited to this type of power system data (where features are instances of three-phase phasor values). We also found that the LLE (including its variants) did not produce a good embedding with this particular kind of data. Furthermore, we found that a support vector machine, trained on top of the embedding produced by several different methods was able to detect power system disturbances from WAMS data. Full article

Smart Grid 3.0 is the latest evolution of the smart grid and incorporates advanced computing and communication technologies. The synchrophasor communication system plays a critical role in wide-area measurement systems (WAMS) for real-time protection and control of power systems, supporting the objectives of Smart Grid 3.0. This system relies on synchrophasor communication technologies, where Phasor Measurement Units (PMUs) transmit synchrophasor data to Phasor Data Concentrators (PDCs) over the synchrophasor communication network. The communication infrastructure of this network is based on the TCP/IP protocol stack, which, unfortunately, is susceptible to cyberattacks, posing security threats such as data tampering and false data injection. These vulnerabilities undermine the intended benefits of synchrophasor applications in terms of situational awareness, observability, grid reliability, resiliency, and synchronized monitoring and control in the smart grid. To address these challenges, it is crucial to enhance the security, integrity, and confidentiality of synchrophasor data within the communication system. This paper proposes a blockchain-based synchrophasor communication system that preserves the security and integrity of synchrophasor data. In this paper, an architecture is proposed for a synchrophasor communication system based on blockchain technology. The proposed architecture aims to enhance the security and integrity of synchrophasor measurements. Furthermore, the architecture is developed as a peer-to-peer distributed blockchain network, leveraging the robustness of a distributed, decentralized, hierarchical PDC architecture. To evaluate the efficacy of the proposed architecture, two case studies, one using the IEEE 9 bus and the other using IEEE 14 bus systems are considered. Moreover, various challenges with potential solutions are also recommended. The proposed work is envisioned to contribute to the advancement of Smart Grid 3.0 by adopting blockchain technology for synchrophasor applications. Full article

State estimation (SE) is an essential tool of energy management systems (EMS), providing power system operators with an overall grasp of the actual power system operating conditions and aiding them in sustaining reliable and secure operation of the grid. In modern transmission sectors, two main measurement systems are deployed, namely the supervisory control and data acquisition (SCADA) and the wide area monitoring systems (WAMS). The multiple advantages of augmenting conventional SCADA-based SE algorithms with synchrophasor measurements from WAMS are already well-established; thus, an abundance of different methodologies has been reported in the field of hybrid SE (HSE). Under this premise, this paper provides a thorough literature review of novel HSE methods in transmission systems and proposes a classification based on the scope and mathematical modeling of each method. Following a brief introduction to the concept of SE based on WAMS and SCADA measurements, an insight into the main challenges emerging in HSE implementations is provided. Various HSE methods which overcome these challenges are reviewed, for both static and dynamic SE implementations. In conclusion, the research trends in the area of HSE are summarized, and the main findings of this literature review are discussed. Full article

This work is a survey of current trends in applications of PMUs. PMUs have the potential to solve major problems in the areas of power system estimation, protection, and stability. A variety of methods are being used for these purposes, including statistical techniques, mathematical transformations, probability, and AI. The results produced by the techniques reviewed in this work are promising, but there is work to be performed in the context of implementation and standardization. As the smart grid initiative continues to advance, the number of intelligent devices monitoring the power grid continues to increase. PMUs are at the center of this initiative, and as a result, each year more PMUs are deployed across the grid. Since their introduction, myriad solutions based on PMU-technology have been suggested. The high sampling rates and synchronized measurements provided by PMUs are expected to drive significant advancements across multiple fields, such as the protection, estimation, and control of the power grid. This work offers a review of contemporary research trends and applications of PMU technology. Most solutions presented in this work were published in the last five years, and techniques showing potential for significant impact are highlighted in greater detail. Being a relatively new technology, there are several issues that must be addressed before PMU-based solutions can be successfully implemented. This survey found that key areas where improvements are needed include the establishment of PMU-observability, data processing algorithms, the handling of heterogeneous sampling rates, and the minimization of the investment in infrastructure for PMU communication. Solutions based on Bayesian estimation, as well as those having a distributed architectures, show great promise. The material presented in this document is tailored to both new researchers entering this field and experienced researchers wishing to become acquainted with emerging trends. Full article

Depletion of fossil fuel deposits is the main current issue related to the world’s power generation. Renewable energy sources integrated with energy efficiency represent an effective solution. The electrification of end-use coupled with renewable power generation integration is considered as an important tool to achieve these tasks. However, the current electric power system does not currently have the suitable features to allow this change. Therefore, in the future, it has to allow two-way direction power flows, communication, and automated controls to fully manage the system and customers. The resulting system is defined as the smart grid. This article analyses the smart grid state of play within China, the US, and the EU, assessing the completion state of each smart grid technology and integrated asset. The analysis related to these countries presented here shows that the smart grid overall state of play in China, the US, and the EU are equal to 18%, 15%, and 13%, respectively, unveiling the need related to further efforts and investments in these countries for the full smart grid development. Full article

The wide area measurement system (WAMS) based on synchronous phasor measurement technology has been widely used in power transmission grids to achieve dynamic monitoring and control of the power grid. At present, to better realize real-time situational awareness and control of the distribution network, synchronous phasor measurement technology has been gradually applied to the distribution network, such as the application of micro multifunctional phasor measurement units (μMPMUs). The distribution network phasor data concentrator (DPDC), as a connection node between the μMPMUs and the main station, is also gaining more attraction. This paper first analyzes the communication network structure of DPDCs and μMPMUs and compares and analyzes the differences in the installation locations, functions, communication access methods and communication protocols of the phasor technology devices of the distribution network and the transmission network. It is pointed out that DPDCs not only need the functions of data collection, storage, and forwarding like transmission network PDCs, but also should be able to access more μMPMUs, and can aggregate the phasor data of the same time scale from μMPMUs by different communication methods. The communication protocol selected by DPDC should be expanded to support remote control, telemetry, fault diagnosis and other functions of distribution automation. The application requirements of DPDCs are clarified, and the key indicators of DPDCs are given as a method to evaluate the basic performance of DPDCs. Then, to address the problems of more μMPMU access, abnormal communication, and data collection with different delays that DPDC encountered, a DPDC that considers multiple communication methods is designed. Based on the Linux system and the libuv library, the DPDC is designed with event-driven mechanism and structured programming, runs multiple threads to implement multitasking, and invokes callbacks to perform asynchronous non-blocking operations. The DPDC test system and test methods are designed. The performance of the designed DPDC is evaluated through the test and the test results are analyzed. Lastly, its real-world application is disclosed, which further confirmed the value of our DPDC. Full article

Fast online transient stability assessment (TSA) is very important to maintain the stable operation of power systems. However, the existing transient stability assessment methods suffer the drawbacks of unsatisfactory prediction accuracy, difficult applicability, or a heavy computational burden. In light of this, an improved high accuracy power system transient stability prediction model is proposed, based on min-redundancy and max-relevance (mRMR) feature selection and winner take all (WTA) ensemble learning. Firstly, the contributions of four different series of raw sampled data from all of the three-time stages, namely the pre-fault, during-fault and post-fault, to transient stability are compared. The new feature of generator electromagnetic power is introduced and compared with three conventional types of input features, through a support vector machine (SVM) classifier. Furthermore, the two types of most contributive input features are obtained by the mRMR feature selection method. Finally, the prediction results of the electromagnetic power of generators and the voltage amplitude of buses are combined using the WTA ensemble learning method, and an improved transient stability prediction model with higher accuracy for unstable samples is obtained, whose overall prediction accuracy would not decrease either. The real-time data collected by wide area monitoring systems (WAMS) can be fed into this model for fast online transient stability prediction; the results can also provide a basis for the future emergency control decision-making of power systems. Full article

Synchrophasor technology opens a new window for power system observability. Phasor measurement units (PMUs) are able to provide synchronized and accurate data such as frequency, voltage and current phasors, vibration, and temperature for power systems. Thus, the utilization of PMUs has become quite important in the fast monitoring, protection, and even the control of new and complicated distribution systems. However, data quality and communication are the main concerns for synchrophasor applications. This study presents a comprehensive survey on wide-area monitoring systems (WAMSs), PMUs, data quality, and communication requirements for the main applications of PMUs in a modern and smart distribution system with a variety of energy resources and loads. In addition, the main challenges for PMU applications as well as opportunities for the future use of this intelligent device in distribution systems will be presented in this paper. Full article

Real-time monitoring of the power system by phasor measurement units (PMUs) leads to the development of such devices in a wide area measurement system (WAMS). However, the power system observability cannot be obtained by employing only PMUs. The communication infrastructure (CI) is a significant part of the WAMS that has to be optimally designed and implemented to collect data from PMUs and deliver them to control centers. In this paper, a novel hybrid wireless sensor network is proposed for the connection of PMUs throughout the system to enable convenient and low-cost communication media. The problem of observability in the communication system is checked along with the optimal placement of PMUs in the power system to reach full observability. A hybrid wireless sensor network including plug-in powered sensor nodes (PPSNs) and energy harvesting sensor nodes (EHSNs) is utilized for increasing the reliability of the communication system. In the proposed co-optimal PMU-sensor placement problem, the main objective is to minimize the total cost of PMU placement and the related communication system, considering full observability of the power system and CI. To achieve better results, the zero-injection bus (ZIB) effect and system observability redundancy index (SORI) are considered as a constraint in the objective function. A binary-coded genetic algorithm is used for solving the proposed mixed-objective optimization problem subject to different technical operating constraints. The proposed method is examined on IEEE 13-bus and IEEE 37-bus test feeder systems. The results show the applicability and effectiveness of the proposed method compared with the conventional methods in this subject area. Full article

Phasor measurement units (PMUs), which are the key components of a synchrophasor-based wide area monitoring system (WAMS), were historically conceived for transmission networks. The current trend to extend the benefits of the synchrophasor technology to distribution networks requires the PMU to also provide trustworthy information in the presence of signals that can occur in a typical distribution grid, including the presence of severe power quality (PQ) issues. In this framework, this paper experimentally investigates the performance of PMUs in the presence of one of the most important PQ phenomena, namely the presence of voltage fluctuations that generate the disturbance commonly known as flicker. The experimental tests are based on an ad-hoc high-accuracy measurement setup, where the devices under test are considered as “black boxes” to be characterized in the presence of the relevant signals. Two simple indices are introduced for the comparison among the different tested PMUs. The results of the investigation highlight possible critical situations in the interpretation of the measured values and provide a support for both the design of a new generation of PMUs and the possible development of an updated synchrophasor standard targeted to distribution systems. Full article
