Search Results (71)

The paper presents results of experimental research on tyre–road contact stress distributions, measured indoors for a motorsport slick tyre. The triaxial contact stress distributions have been measured using the complex transducer containing a transversal array of 30 sensing pins covering the entire contact patch width. Wheel displacement in the longitudinal direction was measured using a rotary encoder. The parameters allocated for the experimental programme have included different values of tyre inflation pressure, vertical load, camber angle and toe angle. All measurements were performed at low longitudinal speed in free-rolling conditions. The influence of tyre functional parameters on the contact patch shape and size has been discussed. The stress distributions on each orthogonal direction are presented in multiple formats, such as 2D graphs in which the curves show the stresses measured by each sensing element versus contact length; surfaces with stress values plotted as vertical coordinates versus contact patch length and width; and colour maps for stress distributions and orientations of shear stress vectors. The effects of different parameter types and values on stress distributions have been emphasised and analysed. Furthermore, the magnitude and position of local extreme values for each stress distribution have been investigated with respect to the above-mentioned tyre functional parameters. Full article

Heavy rolling contact fatigue (RCF) may be caused by wheel surface defects under the influence of rail corrosion, which threatens the operational safety of rail vehicles. To investigate the role of surface defects on wheel RCF damage under the influence of rail corrosion, a salt spray tester was used to corrode the rails, an impact testing machine was employed to create surface defects, and RCF tests were completed. The role of surface defects on wheel RCF damage was studied by monitoring the wheel defect surface and cross-section. The results indicate that the tendencies of the RCF crack extension of surface defects of different sizes are similar, and they all extend in a C-shape along the tangential force direction. However, the larger the defect size, the later the crack is initiated. The leading edge material is continuously squeezed into the defect by the tangential force, and a larger plastic deformation layer is formed, which causes the RCF at the leading edge to crack more severely. Meanwhile, under the effect of combined normal force and shear stress, the leading edge crack intersects with the middle edge crack, and the leading edge material is spalled off first. Wheel RCF damage and wear are aggravated by rail corrosion, the longer the corrosion time, the more serious the RCF damage and wear, and the earlier the material spalling time, the lower the fatigue life. Full article

In the context of wheelchair racing, research primarily focuses on studying wheelchair ergonomics and determining kinematic, kinetic, and rolling resistance variables. One factor identified as influencing athletes’ performance is wheel skidding on the ground, a parameter complementary to rolling resistance. The objective of this study, therefore, is to identify, within a laboratory setting, the parameters that influence the risk of skidding in racing wheelchairs by measuring skidding torque. The ultimate goal is to enhance athletes’ performance by optimizing the interaction between the athlete and their wheelchair, and the wheelchair and the environment. In this perspective, four parameters were examined: the type of tubular, the camber angle, the tire pressure, and the load applied to the wheel using a skidometer. This tool characterizes a tire’s grip on a surface by measuring torques. The aim is to develop a system for classifying tire grip on dry athletics track at ambient temperature. The findings revealed that only the effects of load and tubular type had a significant impact on the torque values obtained. The tire that minimized the risk of skidding, among all tested combinations, is the Vittoria Pista Speed 23–28″. Furthermore, as the mass applied to the wheel increases, so do the resulting torques. This implies that a heavier athlete would require a greater force to be applied to the hand rim for the tire to skid. However, it was also demonstrated that the risk of skidding in a racing wheelchair is unlikely, as the torques obtained were over a range of 90 to 190 Nm. These values far exceed those typically exerted by para-athletes, which are a maximum of 60 Nm. The long-term goal would be to adjust the mode of torque application on the wheel using the skidometer for a more realistic field approach. Full article

The movement of a wheeled vehicle is a non-regular dynamic process characterized by a large number of states that depend on the movement conditions. This movement involves a large number of situations where elastic tires skid and slip against the base surface. This reduces the efficiency of movement as useful mechanical energy of the electromechanical drive is spent to overcome the increased skidding and slipping. Complete sliding results in the loss of control over the vehicle, which is unsafe. Processes that take place immediately before such phenomena are of special interest as their parameters can be useful in diagnostics and control. Additionally, such situations involve adverse oscillatory processes that cause additional dynamic mechanical and electrical loading in the electromechanical drive that can result in its failure. The authors provide the results of laboratory road research into the emergence of self-oscillatory phenomena during the rolling of a wheel with increased skidding on the base surface and a low traction factor. This paper reviews the methods of designing an anti-slip control system for wheels with an oscillation damping function and studies the applicability and efficiency of the suggested method using mathematical simulation of the virtual vehicle operation in the Matlab Simulink software package. Using the self-oscillation suppression algorithm in the control system helps reduce the maximum amplitude values by 5 times and average amplitudes by 2.5 times while preventing the moment operator from changing. The maximum values of current oscillation amplitude during algorithm changes were reduced by 2.5 times, while the current change rate was reduced by 3 times. The reduction in the current-change amplitude and rate proves the efficiency of the self-oscillation suppression algorithm. The high change rate of the current consumed by the drive’s inverters may have a negative impact on the remaining operating life of the rechargeable electric power storage system. This impact increases with the proximity of its location due to the low inductance of the connecting lines and the operating parameters, and the useful life of the components of the autonomous voltage inverters. Full article

Prolonged rolling contact fatigue between wheels and rails results in the formation of surface cracks on the rail and accurately analyzing the crack expansion behavior is essential to ensuring the safe operation of the train. Drawing upon the principles of fracture mechanics and finite element theory, this study establishes a finite element model of wheel–rail rolling contact that incorporates the presence of cracks. The method utilizes an interaction integral to calculate the stress intensity factors at the leading edge of the crack; then, the Paris formula is used to solve the crack spreading rate. It systematically examines the effects of the initial crack angle, the coefficient of friction of wheels to rails, and crack size on the behavior of fatigue crack propagation. The results indicate that the cracks primarily extend in the depth direction of the rail, transforming the semi-circular surface cracks into elliptical cracks with the major axis oriented along the rail’s width. Crack propagation is primarily driven by model II and III composite crack propagation, with their expansion rates influenced by operating conditions. In contrast, mode-I expansion is less sensitive to these conditions. Under single-variable loading conditions, a smaller initial crack angle results in a faster crack growth rate. Increasing crack length accelerates crack growth, while a higher friction coefficient inhibits it. Full article

This study proposes a new wheel-leg mechanism concept and formulations for the kinematics and dynamics of a stair-climbing robot utilizing the rotating leg locomotion of curved spokes and rolling tires. The system consists of four motor-driven tires and four curved-spoke legs. The curved-spoke leg is semicircle-like and is used to climb stairs. Once the spoke leg rolls on the surface, it lifts and pulls the mating wheel toward the surface, owing to the kinematic constraint between the spoke and the wheel. Single-wheel climbing is a necessary condition for the stair climbing of whole robots equipped with front and rear axles. This study proposes the design requirements of a spoke leg for the success of single-wheel climbing in terms of kinematic inequality equations according to the scenario of single-wheel climbing. For a design configuration that enables single-wheel climbing, the required minimum friction coefficient for the static analysis of the stair-climbing wheeled robots is demon-strated. Thereafter, the stair-climbing ability is validated through the dynamic equations that enable the frictional slip of the tires, as well as the curved-spoke legs. Lastly, the results revealed that the rotating locomotion of the well-designed curved-spoke legs effectively enables the stair climbing of the whole robot. Full article

The automotive industry is currently transforming, primarily due to the rise of electric and hybrid vehicle technologies and the need to reduce vehicle mass and energy losses to decrease consumption, pollution, and raw material usage. Additionally, road surface manufacturers emphasize improving pavement durability and reducing rolling noise. This necessitates precise load condition definitions and drives the need for reliable wheel testing benches. Many current benches use abrasive-coated rollers or synthetic tapes, but devices capable of testing on actual road surfaces are rare. In this work, a novel device for testing tire-pavement interaction is proposed. The system features a cart moving along a closed-track platform, ensuring test repeatability and enabling structural durability tests on uneven surfaces with installed obstacles. The cart is equipped with a cantilever arm capable of supporting either a testing wheel with customizable dimensions and kinematic parameters or a tire integrated with a complete suspension system, moving along a customizable pavement surface. The system includes actuators and sensors for applying vertical loads and adjusting the alignment of the testing wheel (slip angle, camber angle, etc.), allowing the characterization of tire behavior such as wear, fatigue, rolling noise, and rolling resistance. Multibody simulations were performed to evaluate the bench’s feasibility in terms of kinematics, power requirements, and structural loads. Results confirmed how this novel test bench represents a promising advancement in tire testing capabilities, enabling comprehensive studies on tire performance, noise reduction, and the structural dynamics of vehicle subsystems. Full article

With the rapid development of railway towards being high speed and having heavy load capacity, the wheel–rail wear and rolling contact fatigue in the curve section with a small radius of freight have become the key problems in urban railways, which need to be solved urgently. The aims of this study were to compare the wear resistance with three different lubricating conditions on wheel–rail wear based on the wheel–rail rolling contact simulation tests. The wear loss, microhardness, and microstructure of the contacted surface of the rail were detected systematically. The results showed that the wear rates of rail were reduced by 71% for grease lubrication and 55% for solid lubrication, compared to those without lubrication. At the same time, the thickness of plastic deformation layer of rail samples were about 167 μm for the dry state, 138 μm for the solid lubrication state, and 128 μm for the oil lubrication state, respectively. It indicates that the thickness of the plastic deformation layer was significantly reduced under both grease and/or solid lubricating conditions. In addition, the microstructure of the deformation layer with two kinds of lubricated states was coarser and denser than that without lubricants. The average grain size of the deformation layer was approximately 0.22 μm under dry conditions and 0.32 μm under lubricated conditions. It also indicated that the changes in lubricants did not have a significant effect on the average grain size of the deformation layer. The results of the present study could provide theoretical reference for the development and design of lubricants used as rail materials. Full article

In current railway rails, trains are propelled by the rolling contact between iron wheels and iron rails, and the high frequency of train repetition on rails results in a significant load exertion on a very small area where the wheel and rail come into contact. Furthermore, a contact stress beyond the allowable stress of the rail may lead to cracks due to plastic deformation. The railway rail, which is the primary contact surface between the wheel and the rail, is prone to rolling contact fatigue cracks. Therefore, a thorough inspection and diagnosis of the condition of the cracks is necessary to prevent fracture. The Detailed Guideline on the Performance Evaluation of Track Facilities in South Korea specifies the detailed requirements for the methods and procedures for conducting track performance evaluations. However, diagnosing rail surface damage and determining the severity solely rely on visual inspection, which depends on the qualitative evaluation and subjective judgment of the inspector. Against this backdrop, rail surface defect detection was investigated using Fast R-CNN in this study. To test the feasibility of the model, we constructed a dataset of rail surface defect images. Through field investigation, 1300 images of rail surface defects were obtained. Aged rails collected from the field were processed, and 1300 images of internal defects were generated through SEM testing; therefore, a total of 1300 pieces of learning data were constructed. The detection results indicated that the mean average precision was 94.9%. The Fast R-CNN exhibited high efficiency in detecting rail surface defects, and it demonstrated a superior recognition performance compared with other algorithms. Full article

The parameters of the discrete element simulation model for rice field soils serve as valuable data references for investigating the dynamic characteristics of the walking wheel of high-speed precision seeding machinery in paddy fields. The research specifically targets clay loam soil from a paddy field in South China. Calibration of essential soil parameters was achieved using EDEM_2022 software (and subsequent versions) discrete element simulation software, employing the Edinburgh Elasto-Plastic Adhesion (EEPA) nonlinear elastic-plastic contact model. The tillage layer and plough sub-base layer underwent calibration through slump and uniaxial compression tests, respectively. Influential contact parameters affecting slump and axial pressure were identified through a Plackett–Burman test. The optimal contact parameter combinations for the discrete element model of the tillage layer and plough sub-base layer were determined via a quadratic rotational orthogonal test. The accuracy of the discrete element simulation model’s parameters for paddy field soils was further validated through a comparative analysis of the simulation test’s cone penetration and the field soil trench test. Results indicate that the Coefficient of Restitution, surface energy, Contact Plasticity Ratio, and Tensile Exp significantly influence slump (p < 0.05). Additionally, the Coefficient of Restitution, Contact Plasticity Ratio, coefficient of rolling friction, and Tangential Stiff Multiplier significantly impact axial pressure (p < 0.05). Optimal contact parameters for the plough layer were achieved with a particle recovery coefficient of 0.49, a surface energy of 18.52 J/m², a plastic deformation ratio of 0.45, and a tensile strength of 3.74. For the plough subsoil layer, optimal contact parameters were a particle recovery coefficient of 0.47, a coefficient of interparticle kinetic friction of 0.32, a plastic deformation ratio of 0.49, and a tangential stiffness factor of 0.31. Results from the cone penetration test reveal no significant disparity in compactness between the actual experiment and the simulation test. The calibrated discrete element model’s contact parameters have been verified as accurate and reliable. The findings of this study offer valuable data references for understanding the dynamic characteristics of the walking wheel of the entire machinery in high-speed precision seeding in paddy fields. Full article

This paper is concerned with the modeling of power dissipation due to friction and its relation with wear estimation in wheel–rail contact. Wear is a complex multi-scale and multi-physical phenomenon appearing in rolling contact. Wear is generated by high contact stress and the work of friction forces. This phenomenon leads to the appearing of the worn material in the form of wear debris between contacting surfaces. In contact models, wear is usually described in terms of the wear depth function. This function modifies the gap between the contacting bodies as well as the shape of the surfaces of the wheel and rail in contact. In this paper, besides the wear depth function, the dissipated energy, rather than the contact stress, is taken into account to evaluate the wear impact on rail or wheel surfaces. The dissipated energy allows us to more precisely evaluate the wear debris amount as well as the depth of wear and its distribution along the contact interface. A two-dimensional rolling contact problem with frictional heat flow is considered. The elasto-plastic deformation of the rail is considered. This contact problem is governed by a coupled system of mechanical and thermal equations in terms of generalized stresses, displacement and temperature. The finite element method is used to discretize this problem. A discretized system of equations with nonpenetration and friction conditions is transformed and formulated as a nonlinear complementarity problem. The generalized Newton method is applied to numerically solve this mechanical subproblem. The Cholesky method is used to find the solution of the heat-conductive problem. The dissipated power is evaluated based on the resultant force and slip at a reference point. Numerical results including the distribution of slip velocity, power factor and wear rate are provided and discussed. Full article

The effects of cyclic loading on the surface microstructure evolution of different contact locations in a used pearlitic rail were studied. Microstructures were analyzed using Scanning Electron Microscopy (SEM). Meanwhile, grain boundaries and crystallographic orientations were explored via Electron Backscatter Diffraction (EBSD). At last, wheel–rail contact probabilities and forces were calculated using rail profiles. The results indicate that the side wear region located in the gauge face was 71.5% in the high-angle grain boundaries (HAGBs) fraction, 0.88 in the Kernel Average Misorientation (KAM) value, 36% in the recrystallization (REX) fraction, and had a predominant orientation in grains. The rolling contact fatigue (RCF) region situated at the gauge corner was 66.3% in the HAGBs fraction, 0.92 in the KAM value, 33% in the REX fraction, and was mis-orientated in grains. The region located at the edge of the running band was 60.7% in the low-angle grain boundaries (LAGBs) fraction, 0.97 in the KAM value, 12% in the REX fraction, and was mis-orientated in grains. Continuous dynamic recrystallization (cDRX) took place in wear and RCF regions during the cyclic rolling contact loading, creating ultra-fine grains with a transformation from LAGBs to HAGBs, lower KAM values, and more REX. Grains oriented along [111] parallel to the vertical direction in the wear region were influenced by the dominant normal force, while grains in the RCF region were non-oriented, which was attributed to large lateral and vertical forces of similar magnitudes. Full article

In railway systems, layered structures could be induced in wheel–rail contact interfaces due to several causes, such as head hardening, work hardening, plastic deformation, and mechanical or thermal excursion-induced phase transformation. This study proposes an explicit finite element (FE) method for investigating elastic layer effects in wheel–rail rolling contact. The proposed method is first validated by comparing its solution with that of Kalker’s boundary element method (BEM) when the layer is not present, with a focus on the tractive rolling contact. To investigate general layer effects, the rail is assumed to consist of two layers, i.e., the top layer and the matrix material. The top layer is assumed to have different elastic moduli from the matrix material and then the top elastic layer effects on contact characteristics such as contact stress, contact patch, and subsurface stress are investigated. Different layer thicknesses are also considered. It is observed that a harder layer tends to introduce larger contact pressure and surface shear stress, but a smaller contact patch. A harder layer also produces larger subsurface stresses. A thicker layer may intensify these effects. The results suggest that in engineering applications, the analysis of wheel–rail rolling contact consequences such as wear and rolling contact fatigue (RCF) may need to consider the layered structures using appropriate methods. Full article

With the extensive use of plastic film mulching in planting, the amount of residual plastic film in soil has been increasing, causing soil and water pollution, harming crop growth, and reducing agricultural product quality and yield. In response to this issue, this study proposes a roll-type residual film recovery mechanism using the tillage layer method. The structure and operation principles of this system are discussed, and a detailed analysis of its key components and working process is provided. The lifting cutter operates at a speed of 22.37 rad/s, the pick-up drum at 4.58 rad/s, the roll forward rotation picks up the film at 13.74 rad/s, and the roll reverse film rotation unloads the film at 17.57 rad/s, with the unloading wheel rotating at a speed of 4.5 rad/s. ADAMS (software of automatic dynamic analysis of mechanical systems) Version No.2019 is used for modeling and analysis, and the displacement and velocity change patterns of MARKER_499, MARKER_500, and MARKER_505, which are marked points of the spring-tooth tips and are found to be the same. The maximum resultant displacement of MARKER_499 and MARKER_500 is 22.146 mm when picking up plastic film and 17.047 mm when unloading plastic film. Meanwhile, the maximum resultant displacement of MARKER_500 and MARKER_505 is 231.715 mm in the film-picking area and 234.028 mm in the film-unloading area. After analyzing the velocity of MARKER_499 during picking and unloading of the film, it was determined that the absolute velocity for the picking direction was 79,809.407 mm/s, and for the unloading direction it was 10,2266.168 mm/s. Bench tests show a tillage gathering rate of 71.6% and a surface gathering rate of 83.4%, meeting the performance requirements of the roller-type residual film recovery mechanism. These findings provide a theoretical basis for the design of the structure and operational parameters for the roll-type residual film recovery mechanism using the tillage layer method. Full article

Rolling noise is a significant contributor to railway noise. Wheel and rail roughness are decisive for the emitted noise level. An optical measurement method installed on a moving train is suitable for closer monitoring of the rail surface condition. A measurement setup based on the chord method requires the sensors to be positioned in a straight line along the direction of measurement and in a stable lateral position. Measurements should always be performed within the shiny and uncorroded running surface, even when there are lateral movements of the train. In this study, concepts for the detection of the running surface and the compensation of lateral movements are investigated in a laboratory setting. The setup consists of a vertical lathe with a ring-shaped workpiece that incorporates an implemented artificial running surface. The detection of the running surface based on laser triangulation sensors and a laser profilometer is investigated. It is shown that the running surface can be detected using a laser profilometer that measures the intensity of the reflected laser light. It is possible to detect the lateral position and the width of the running surface. A linear positioning system is proposed to adjust the lateral position of the sensors based on the running surface detection of the laser profilometer. When the lateral position of the measuring sensor is disturbed by a movement with a wavelength of $18.85 \mathrm{m}$, the linear positioning system can keep the laser triangulation sensor inside the running surface for $98.44\%$ of the measured data points at a velocity of approximately $7.5 {\mathrm{km} \mathrm{h}}^{-1}$. The mean positioning error is $1.40 \mathrm{mm}$. By implementing the proposed system on the train, future studies can be conducted to examine the lateral position of the running surface as a function of the various operational parameters of the train. Full article
