Search Results (136)

Robust and efficient contactless human–machine interaction is critical for integrated sensor systems in clinical settings, demanding low-power solutions adaptable to edge computing platforms. This paper presents a real-time hand gesture recognition system using a low-power Frequency-Modulated Continuous Wave (FMCW) radar sensor, featuring a novel Multiple Feature Fusion (MFF) framework optimized for deployment on edge devices. The proposed system integrates velocity profiles, angular variations, and spatial-temporal features through a dual-stage processing architecture: an adaptive energy thresholding detector segments gestures, followed by an attention-enhanced neural classifier. Innovations include dynamic clutter suppression and multi-path cancellation optimized for complex clinical environments. Experimental validation demonstrates high performance, achieving 98% detection recall and 93.87% classification accuracy under LOSO cross-validation. On embedded hardware, the system processes at 28 FPS, showing higher robustness against environmental noise and lower computational overhead compared with existing methods. This low-power, edge-based solution is highly suitable for applications like sterile medical control and patient monitoring, advancing contactless interaction in healthcare by addressing efficiency and robustness challenges in radar sensing for edge computing. Full article

State-of-the-art radar systems for the contactless monitoring of vital signs and respiratory diseases are typically based on single-channel continuous wave (CW) technology. This technique allows precise measurements of respiration patterns, periods of movement, and heart rate. Major practical problems arise as CW systems suffer from signal cancellation due to destructive interference, limited overall functionality, and a possibility of low signal quality over longer periods. This work introduces a sophisticated multiple-input multiple-output (MIMO) solution that captures a radar image to estimate the sleep pose and position of a person (first step) and determine key vital parameters (second step). The first step is enabled by processing radar data with a forked convolutional neural network, which is trained with reference data captured by a time-of-flight depth camera. Key vital parameters that can be measured in the second step are respiration rate, asynchronous respiratory movement of chest and abdomen and limb movements. The developed algorithms were tested through experiments. The achieved mean absolute error (MAE) for the locations of the xiphoid and navel was less than 5 cm and the categorical accuracy of pose classification and limb movement detection was better than 90% and 98.6%, respectively. The MAE of the breathing rate was measured between 0.06 and 0.8 cycles per minute. Full article

This paper proposes a miniaturized design for a terahertz tri-mirror compact antenna test range (CATR) system, composed of a square-aperture paraboloid primary mirror with a side length of 0.2 m and two shaped mirrors with circular apertures of 0.06 m and 0.07 m in diameter. The design first employs the cross-polarization cancelation method based on beam mode expansion to determine the geometric configuration of the system, thereby enabling the structure to exhibit low cross-polarization characteristics. Subsequently, the shaped mirrors, with beamforming and wave-front control capabilities, are synthesized using dynamic ray tracing based on geometric optics (GO) and the dual-paraboloid expansion method. Finally, the strong edge diffraction effects induced by the small-aperture primary mirror are suppressed by optimizing the desired quiet-zone (QZ) field width, adjusting the feed-edge taper, and incorporating rolled-edge structures on the primary mirror. Numerical simulation results indicate that within the 100–500 GHz frequency band, the system’s cross-polarization level is below −40 dB, while the amplitude and phase ripples of the co-polarization in the QZ are, respectively, less than 1.6 dB and 10°, and the QZ usage ratio exceeds 70%. The designed CATR was manufactured and tested. The results show that at 183 GHz and 275 GHz, the measured co-polarization amplitude and phase ripples in the system’s QZ are within 1.8 dB and 15°, respectively. While these values deviate slightly from simulations, they still meet the CATR evaluation criteria, which specify QZ co-polarization amplitude ripple < 2 dB and phase ripple < 20°. The overall physical structure sizes of the system are 0.61 m × 0.2 m × 0.66 m. The proposed miniaturized terahertz tri-mirror CATR design methodology not only enhances the QZ characteristics but also significantly reduces the spatial footprint of the entire system, demonstrating significant potential for practical engineering applications. Full article

A co-design of radar cross section (RCS) reducing surface and array antenna on a single-layer printed board is presented in this paper. To achieve this goal, two kinds of artificial magnetic conductors (AMCs) are designed and optimized. The first kind of AMC shares the same geometry with the array element and thus is simultaneously used as the array element. The other kind of AMC generates opposed-phased reflections for a normal incident wave, and when they are in a checkerboard configuration, the RCS is reduced via phase cancellation of opposed-phased reflections. In the range of 10 GHz to 16 GHz, the designed bi-functional surface achieves an 8 dB decline in monostatic RCS, while the array antenna obtains a gain of 15 dBi, a side-lobe less than −10 dB, and a cross-polarization less than −20 dB at 13.5 GHz. To validate the calculation results, a prototype is fabricated and measured. To feed the array antenna, a T-type power divider network is etched under the ground and the array is fed via coupling slots on the ground. The measured results agree with the simulation results. Full article

At the core of AI-driven electrocardiogram diagnosis lies the precise localization of the QRS complex. While QRS detection methods for multiple leads have been researched adequately in the last few decades, their multi-lead strategies still need to be designed manually. Therefore, a QRS detector that can fuse multiple leads automatically is still worth investigating. Methods: The proposed QRS detector comprises a leads-distillation module (LDM) and a QRS detection module. The LDM can distill multi-lead signals into single-lead ones. This procedure minimizes the weight proportions assigned to noisy leads, enabling the network to generate a novel signal that facilitates the recognition of QRS waves. The QRS detection module, utilizing U-Net, is capable of discerning QRS complexes from the novel signal. Results: Our method demonstrates outstanding performance with a parameter count of only 5216. It achieves an excellent F1 score of 99.83 on the MITBIHA database and 99.77 on the INCART database, specifically in the inter-patient pattern. In the cross-database pattern, our approach maintains a strong performance with an F1 score of 99.22 on the INCART database and an F1 score of 99.09 on the MITBIHA database. Conclusion: Our method provides a novel idea for universal multi-lead QRS detection. It possesses advantages, such as reduced computational parameters, enhanced precision, and heightened compatibility. Significance: Our method canceled the repeated deployment of the QRS detection function to different lead configurations in the electrocardiogram (ECG) diagnostic system. Moreover, the scaling operation may become a simple tool to decrease the computational load of the network. Full article

Millimeter-wave antennas have become more important recently due to the diversity of applications in 5G and upcoming 6G technologies, of which automotive systems constitute a significant part. Two crucial indices, detection range and angular resolution, are used to distinguish the performance of the automotive antenna. Strong gains and narrow beamwidths of highly directive radiation beams afford longer detection range and finer spatial selectivity. Although conventionally used, patch antennas suffer from intrinsic path losses that are much higher when compared to the waveguide antenna. Designed at 77 GHz, presented in this article is an 8-element slot array on the narrow side wall of a rectangular waveguide, thus being readily extendable to planar arrays by adding others alongside while maintaining the element spacing requirement for grating lobe avoidance. Comprising tilted Z-shaped slots for higher gain while keeping constrained within the narrow wall, adjacent ones separated by half the guided wavelength are inclined with reversed tilt angles for cross-polar cancelation. An open-ended external waveguide is placed over each slot for polarization purification. Equivalent circuit models of slotted waveguides aid the design. An approach for sidelobe suppression using the Chebyshev distribution is adopted. Four types of arrays are proposed, all of which show potential for different demands and applications in automotive radar. Prototypes based on designs by simulations were fabricated and measured. Full article

Air-coupled ground penetrating radar (GPR) systems are widely used for subsurface imaging in demining, geological surveys, and infrastructure assessment applications. However, strong surface reflections can introduce interference, leading to receiver saturation and reducing the clarity of subsurface features. This paper presents a novel surface reflection suppression algorithm for stepped-frequency continuous wave (SFCW) GPR systems. The proposed method estimates the surface reflection component and applies phase-compensated subtraction at the receiver site, effectively suppressing background reflections. A modular SFCW radar system was developed and tested in a laboratory setup simulating a low-altitude airborne deployment to validate the proposed approach. B-scan and time-domain analyses demonstrate significant suppression of surface reflections, improving the visibility of subsurface targets. Unlike previous static echo cancellation methods, the proposed method performs on-board pre-downconversion removal of surface clutter that compensates for varying ground distance, which is a unique contribution of this work. Full article

The adjustment of delay time in open-pit bench blasting is a research hotspot in vibration control. Its core lies in utilizing the periodic characteristics of vibration waves to achieve the superposition and cancellation of wave peaks and troughs. However, due to the spatiotemporal variability in the propagation of blast-induced vibration waves, the optimal delay time determined for vibration control requirements at a specific protected area (monitoring point) makes it difficult to achieve the misalignment superposition effect simultaneously at multiple monitoring points. To address the challenge of multi-area vibration control in open-pit bench blasting, this paper proposes an adjustment method based on local delay adjustment. First, a spatiotemporal relationship model between blast holes with monitoring points is established to calculate vibration wave arrival times. This enables rapid hole identification during dense wave arrivals at monitoring points, with waveform separation achieved through initiation delay adjustments. Following the Anderson principle, reconstructed single-hole vibrations are superimposed according to the wave arrival sequence to validate control efficacy. Statistical analysis of concurrent wave arrivals across all-direction monitoring points identifies high-probability vibration hazard locations. Targeted delay adjustments for blast holes within clustering arrival periods at these locations enable comprehensive vibration reduction. Field data confirm that single-point control reduces peak vibration by >10.55% through simultaneously reducing the amount of waves in clustering arrival periods. Multi-point control resolves seven hazard locations across two directions, attaining 88.57% hazard elimination efficiency and 14.05% peak velocity attenuation. This method achieves vibration control through local delay adjustments while maintaining the fragmentation effect of the original scheme, providing a new approach to solving the challenge of vibration control in large-scale blasting areas. Full article

Continuous-wave (CW) radar sensors can remotely measure respiration and heartbeat by detecting the periodic movements of internal organs. However, external disturbances, such as random body motion (RBM) or environmental interference, significantly degrade the signal-to-noise ratio (SNR) and reduce the accuracy of vital sign detection. The various motion cancellation techniques that have been proposed to enhance robustness against RBMs include improvements in radar architecture, advanced signal processing algorithms, and studies on electromagnetic propagation characteristics. This paper provides a comprehensive review of recent advancements in motion cancellation techniques for CW radar-based vital sign detectors and discusses future research directions to improve detection performance in dynamic environments. Full article

In modern radar operations, detection and jamming systems play a critical role. Integrated detection and jamming systems simultaneously fulfill both functions, thereby optimizing resource utilization. In this paper, we introduce a novel random noise frequency modulation nimble modulation integrated signal (RNFM-NMIS) that is designed based on reconnaissance analysis of adversary linear frequency modulated (LFM) radar signal parameters. This waveform facilitates flexible adjustment of parameters, enabling adaptive detection and jamming functions. Furthermore, to address the challenge of direct-wave interference from adversary transmissions, we propose a signal processing method based on time-domain pre-cancellation (TDPC). Simulation and experimental results show that the proposed integrated waveform exhibits excellent and adjustable detection and jamming capabilities. Under the proposed processing method, interference suppression and target detection performance are significantly enhanced, achieving substantial improvements over traditional methods. Full article

Medical ultrasound imaging using coherent plane-wave compounding (CPWC) for higher frame-rate applications has generated considerable interest in the research community. The adaptive Eigenspace Beamformer technique combined with a Generalized Sidelobe Canceler (GSC) provides noise and interference reduction in images, improving resolution and contrast compared to basic methods: Delay and Sum (DAS) and Minimum Variance (MV). Different filtering approaches are applied in ultrasound image processing to reduce speckle signals. This work introduces the combination of beamformer Eigenspace Based on Minimum Variance (ESBMV) associated with GSC (EGSC) and the Kuan (EGSCK), Lee (EGSCL), and Wiener (EGSCW) filters and their enhanced versions to obtain better quality of plane-wave ultrasound images. The EGSCK technique did not present significant improvements compared to other methods. However, the EGSC with enhanced Kuan (EGSCKe) showed a remarkable reduction in geometric distortion, i.e., 0.13 mm (35%) and 0.49 mm (67%) compared to the EGSC and DAS techniques, respectively. The EGSC with Enhanced Wiener (EGSCWe) showed the best improvements in contrast radio (CR) aspects, i.e., 74% compared to the DAS technique and 60% to the EGSC technique. Furthermore, our proposed method reduces geometric distortion, making it a good option for plane-wave ultrasound imaging. Full article

In this article, resonance phenomena of high-speed interconnects and power delivery networks in glass packages are measured and analyzed. The resonances are generated in the interconnection by the physical dimension, cancelation of reactance components, and modes. When the resonances are generated in the operation frequency band, the signal/power integrity of the interconnect can be affected. As such, resonances generated in high-speed interconnects increase insertion loss, which degrades signal integrity. Also, resonances of the power delivery network (PDN) associated with boundary conditions increase PDN impedance, which degrades power integrity by generating power/ground noise and return current discontinuity of through vias. Recently, glass packaging has been gaining more attention due to its advantages associated with low substrate loss and large dimensions compared to silicon wafers. However, the low loss of the substrate and process variation may affect the resonance properties of interconnects. The resonance impacts on signal/power integrity must be analyzed, and mitigation plans should be proposed to maximize the advantages of the glass packaging technology. To analyze the resonance impacts on signal/power integrity, various glass package test vehicles are designed and fabricated. The fabricated test vehicles include transmission lines, PDNs, and patterns to measure an interaction between the through via and PDN. First, transmission line patterns that have 50-ohm characteristic impedance are measured. Due to the process variations, quarter-wave resonances are monitored, and at those frequencies, a sharp increase in insertion loss is observed, which deteriorates the signal integrity of the interconnect. Various PDN patterns are measured in the frequency domain, and regardless of the PDN shape, PDN impedance peaks are observed at the mode resonance frequencies. Due to a low-loss characteristic of the glass substrate, sharp PDN impedance peaks are generated at these frequencies. Also, at these frequencies, both signal and power integrity degradations are measured and analyzed. To fully benefit from the advantages of glass packaging technology, a thorough electrical performance analysis should be conducted to avoid resonances in the target frequency range. Full article

The radiation mode of the interaction between electromagnetic waves and materials has always been a research hotspot in nanophotonics, and bound states in the continuum (BICs) belong to one of the nonradiative modes. Owing to their high-quality factor characteristics, BICs are extensively employed in nonlinear harmonic generators and sensors. Here, the influence of structural parameters on radiation modes has been systematically analyzed using band theory; the mechanisms of quasi-BIC mode and BIC mode were also analyzed through multipole decomposition of scattered power and near-field distribution. Notably, this study presents the discovery that the toroidal dipole-BIC (TD-BIC) arises from the interference and cancellation of electric and toroidal dipoles. The research results indicate that the structure, which supports symmetry-protected BICs, is sensitive to variations in the concentration of NaCl solution in its surroundings, making it applicable for liquid detection in miniaturized metal sensors. The proposed scheme broadens the applicability of BIC-based sensors and provides a prospective platform for biological and chemical sensing. Full article

As design options for floating wind farms continue to be explored, shared (or multiline) anchors that secure mooring lines from multiple turbines remain a promising technology that can potentially reduce the number of anchors and overall mooring costs. This study evaluates two methods for analyzing the loads on shared anchors: one in which floating offshore wind turbines are simulated individually (using the software OpenFAST), and one in which an entire floating wind farm is simulated collectively (using the software FAST.Farm). A three-line shared anchor is evaluated for multiple loading scenarios in deep water, using the International Energy Agency 15 MW turbine on the VolturnUS-S semisubmersible platform. While the two methods produce broadly comparable results, the coupled wave loading on platforms within the farm results in wave force cancellations and amplifications that decrease multiline force directional ranges and increase multiline force extreme values (up to 7%) and standard deviations (up to 11%) for wave-driven load cases. The inclusion of wakes in FAST.Farm also reduces the net load on the shared anchor due to the velocity deficit, leading to larger differences between OpenFAST and FAST.Farm (up to 3% difference in mean loads) for load cases with operational turbines. Full article

Underwater acoustic (UWA) communication encounters significant challenges, including impulsive noise from breaking waves and marine organisms, as well as long-delay taps caused by ocean properties and high transmission rates. To address these issues, we enhance the channel estimation process by introducing iteratively reweighted least squares (IRLS) methods and propose an impulsive noise suppression algorithm. Furthermore, we analyze the inter-frequency interference (IFI) resulting from channel variability and implement IFI cancellation (IFIC) during iterative processing. Furthermore, an IFIC-based dual decision–feedback equalization (DDFE) algorithm is proposed for fast time-varying channels, enabling a considerable reduction in channel length and subsequent equalizer complexity. The proposed IFIC-based DDFE algorithm with impulsive noise suppression has been validated through sea trial data, demonstrating robustness against impulsive noise. Experimental results indicate that the proposed algorithm reduces click signal energy and significantly improves receiver performance compared to traditional DDFE algorithms. This research highlights the effectiveness of adapted UWA communication strategies in environments characterized by impulsive noise and long delay taps, facilitating more reliable UWA communication. Full article
