Gas–water two-phase flow in horizontal and inclined wells is significantly influenced by gravitational forces and spatial asymmetry around the wellbore, resulting in complex and variable flow patterns. Accurate measurement of water holdup is essential for analyzing phase distribution and understanding multiphase flow behavior. Water holdup imaging provides a valuable means for visualizing the spatial distribution and proportion of gas and water phases within the wellbore. In this study, air and tap water were used to simulate downhole gas and formation water, respectively. An array capacitance arraay tool (CAT) was employed to measure water holdup under varying total flow rates and water cuts in a horizontal well experimental setup. A total of 228 datasets were collected, and the measurements were processed in MATLAB (2020 version) using three interpolation algorithms: simple linear interpolation, inverse distance interpolation, and Lagrangian nonlinear interpolation. Water holdup across the wellbore cross-section was also calculated using arithmetic averaging and integration methods. The results obtained from the three imaging algorithms were compared with these reference values to evaluate accuracy and visualize imaging performance. The CAT demonstrated reliable measurement capabilities under low- to medium-flow conditions, accurately capturing fluid distribution. For stratified flow regimes, the linear interpolation algorithm provided the clearest depiction of the gas–water interface. Under low- to medium-flow rates with high water content, both inverse distance and Lagrangian methods produced more refined images of phase distribution. In dispersed flow conditions, the Lagrangian nonlinear interpolation algorithm delivered the highest accuracy, effectively capturing subtle variations within the complex flow field. Full article

During natural gas development, the gas–water two-phase flows in upward and horizontal wellbores are complex and variable. The accurate calculation of the water holdup in each production layer using appropriate methods based on the logging data collected by fluid identification instruments can enable the precise identification of primary oil-producing and water-producing layers and facilitate subsequent water shutoff operations. In this study, we first investigated the measurement techniques and calculation methods for gas–water two-phase holdups both in China and internationally. Second, we conducted gas–water two-phase simulation experiments in upward and horizontal large-diameter wellbores using a Triangular Arm Array Imager (TAAI) equipped with six fiber-optic probes in a multiphase flow simulation laboratory. We then categorized the flow patterns observed in the physical simulation experiments based on typical theoretical classifications of gas–water two-phase flow patterns. Subsequently, we calculated the spatial positions of the fiber-optic probes and the local water holdup in the wellbore cross-section from the data collected by TAAI and compared the results obtained by Gaussian radial basis function (GRBF) or inverse distance weighted (IDW) interpolation algorithms. We processed the experimental data and found significant discrepancies between the holdup calculated by the two algorithms and the actual wellbore holdup. Therefore, we applied the Levenberg–Marquardt (L-M) algorithm to optimize these interpolation algorithms and discovered that the holdup obtained from the optimized algorithms aligned more closely with the actual wellbore holdup with reduced errors. Finally, we applied the optimized algorithms to the processing of measured data from a gas–water two-phase horizontal well. The results indicate that the L-M algorithm can improve the accuracy of 4–5% of holdup calculations. In the actual production process, the output situation of each production layer can be more accurately judged to provide important opinions for the subsequent actual production by this study. Full article

This study aimed to evaluate the effect of different concentrations of Tween 20 on various physical properties of agar gel as a model material. The effects of other sources of agar-agar powder on the gel properties were also evaluated. The pure gels were prepared with agar powders obtained from two suppliers. Also, agar gels with Tween 20 in the 0.10 to 0.70% range were produced. The measurement of density, water activity, maximal force at fracture and gelling temperature, and the agar gels’ rheological properties, showed that the gels prepared with different agar powders had similar properties. The syneresis and stability indexes, gas hold-up, mechanical and acoustic attributes, and structure of foamed gels with Tween 20 were measured. The addition of Tween 20 in amounts ranging from 0.10 to 0.35% contributed to a gradual decrease in the stability and mechanical parameters of the gels. Using a concentration of 0.7%, Tween was able to obtain foamed gels with a uniform structure and small pore size, but low hardness and gumminess. Application of a lower concentration of Tween of 0.1% produced more rigid gels with limited gel syneresis. Adding Tween 20 at the appropriate level can be a factor in obtaining gels with a tailored structure and texture. Full article

Unconventional oil and gas reservoirs are frequently developed using inclined and horizontal wells, leading to intricate multiphase flow patterns due to spatial asymmetry surrounding the wellbore and gravitational differentiation effects. Through the examination of water holdup imaging, the spatial arrangement of oil and water phases within the wellbore may be clearly depicted, yielding critical information for precisely assessing the ratios of oil and gas. This study employed No. 10 industrial white oil and tap water as fluid media, with measurements obtained using a resistive ring array tool (RAT) to evaluate its response properties over the wellbore cross-section. The data gathered throughout the trials were analyzed by two-dimensional interpolation imaging utilizing 2020 version MATLAB software. To enhance the analysis of water holdup distribution in the wellbore, three interpolation algorithms were utilized: Simple Linear Interpolation (SLI), Inverse Distance Weighting Interpolation (IDWI), and Ordinary Kriging Interpolation (OKI). The results indicated that RAT operates effectively in medium and low flow circumstances, correctly representing the real distribution of oil and water phases while yielding more dependable water holdup data. The SLI algorithm effectively delineates the oil-water interface during stratified flow of oil and water phases, rendering it the optimal algorithm for determining water holdup in standard flow patterns. Under DW/O&W and DO/W&W flow patterns, SLI continues to perform well; however, the accuracy of IDWI and OKI markedly enhances, with IDWI more effectively delineating the attributes of intricate mixed flow and more precisely representing the dynamic fluid distribution. Under DW/O and DO/W flow patterns, the OKI algorithm exhibits optimal performance in these intricate dispersed flow patterns. OKI more precisely represents the dynamic distribution of dispersed oil and water due to its capacity to simulate the spatial correlation of both phases, surpassing both SLI and IDWI. Full article

This study investigates bubble size measurements, bubble characteristics, and the relationship between key operating variables and gas dispersion properties in column flotation. As the frother concentration increased to 120 ppm, the bubble size distribution (BSD) transformed from bimodal to unimodal and achieved a minimum bubble size of 0.62 mm. The critical coalescence concentration (CCC) was identified as 120 ppm. Gas velocity and wash water velocity significantly influenced bubble size, with gas holdup peaking at 27% at 1.08 cm/s a gas velocity. The bubble-rising velocity increased as the bubble size increased, indicating that the bubble size and bubble-rising velocity were proportional. The bubble surface area flux decreased linearly with increasing bubble size and was significantly affected by the gas velocity. A strong correlation (R² = 0.86) between measured and calculated bubble sizes was achieved, with an average size of 0.64 mm and an estimation error of ±13%. The study demonstrated that bubble size and distribution could be effectively controlled under specific operational conditions (J_g = 0.65–1.3 cm/s, J_W = 0.13–0.52 cm/s, frother = 30–120 ppm). These findings highlight the importance of optimizing key variables to enhance column stability, regime maintenance, and flotation performance. Full article

The flow dynamics of low-yield horizontal wells demonstrate considerable complexity and unpredictability, chiefly attributable to the structural attributes of the wellbore and the interplay of gas–water two-phase flow. In horizontal wellbores, precisely predicting flow patterns using conventional approaches is often problematic. Consequently, accurate monitoring and analysis of water holdup in gas–water two-phase flows are essential. This study performs a gas–water two-phase flow simulation experiment under diverse total flow and water cut conditions, utilizing air and tap water to represent downhole gas and formation water, respectively. The experiment relies on the measurement principles of an array fiber holdup meter (GAT) and the response characteristics of the sensors. In the experiment, GAT was utilized for real-time water holdup measurement, and the acquired sensor data were analyzed using three interpolation algorithms: simple linear interpolation, inverse distance weighted interpolation, and Gaussian radial basis function interpolation. The results were subsequently post-processed and visualized with 2020 version MATLAB software, generating two-dimensional representations of water holdup in the wellbore. The study findings demonstrate that, at total flow of 300 m³/d and 500 m³/d, the simple linear interpolation approach yields superior accuracy in water holdup calculations, with imaging outcomes closely aligning with the actual gas–water flow patterns and the authentic gas–water distribution. As total flow and water cut increase, the gas–water two-phase flow progressively shifts from stratified smooth flow to stratified wavy flow. In this paper, the Gaussian radial basis function and inverse distance weighted interpolation algorithms exhibit superior accuracy in water holdup calculations, effectively representing the fluctuating features of the gas–water interface and yielding imaging outcomes that align more closely with experimentally observed gas–water flow patterns. Full article

Accurately measuring water holdup in horizontal wells is crucial for effectively using heavy oil reservoirs. The capacitance method is among the most widely used and accurate techniques. However, the absence of suitable insulating materials at high temperatures and pressures limits the effectiveness of capacitive water holdup measurement in heavy oil thermal recovery. This study introduces a new composite material based on an aviation-grade, special glass glaze as the insulating medium doped with inorganic components (CaSO₄, MgSO₄, Ca(OH)₂, and SiO₂). This new composite material demonstrates outstanding insulating performance under high-temperature and high-pressure conditions in water. A water environment with a high temperature of 350 °C and a pressure of 12 MPa considerably enhances the composite material’s insulation. After 72 h of continuous use, the insulation performance remains 0.3 MΩ. The layers exhibit improved insulation and stability, maintaining integrity through five consecutive temperature shocks in 500 °C air and 20 °C water. XRD, IR, SEM, and TEM analyses reveal that the new composite material is amorphous after firing and that the addition of inorganic components improves the bonding between the glass glaze components and contributes to a denser structure. Simultaneously, SEM and TEM analyses indicate that adding inorganic components results in a smoother, crack-free, and more compact surface of the special glass glaze. This enhancement is crucial for the material’s long-term stability in high-temperature and high-pressure water environments. Full article

Counter-current spontaneous imbibition of water is a critical oil recovery mechanism. In the laboratory, the Amott test is a commonly used method to assess the efficacy of brine imbibition into oil-saturated core plugs. The classic Amott-cell experiment estimates ultimate oil recovery, but not the recovery dynamics that hold fundamental information about the imbibition mechanisms. Retention of oil droplets at the outer core surface and initial production delay are the two key artifacts of the classic Amott experiment. This retention, referred to here as the “external-surface oil holdup effect” or simply “oil holdup effect”, often results in stepwise recovery curves that obscure the true dynamics of spontaneous imbibition. To address these holdup drawbacks of the classic Amott method, we modified the Amott cell and experimental procedure. For the first time, using water-wet Indiana limestone cores saturated with brine and mineral oil, we showed that our improvements of the Amott method enabled accurate and reproducible measurements of oil recovery dynamics. Also for the first time, we used the generalized extreme value (GEV) statistics to describe oil production histories from water-wet heterogeneous limestone cores with finite initial water saturations. We demonstrated that our four-parameter GEV model accurately described the recovery dynamics, and that optimal GEV parameter values systematically reflected the key characteristics of the oil–rock system, such as oil viscosity and rock permeability. These findings gave us a more fundamental understanding of spontaneous, counter-current imbibition mechanisms and insights into what constitutes a predictive model of counter-current water imbibition into oil-saturated rocks with finite initial water saturation. Full article

In industrial production and water resource management involving fluid flows, two-phase flow measurement in complex environments has always been a research hotspot. In this study, a broadband detection device (40–110 MHz) suitable for two-phase flow in pipes was designed in a laboratory environment, the impedance response of two-phase flow was investigated under different salinity conditions and flow patterns, and a new impedance dispersion model suitable for two-phase flow in pipes was built. The experimental results show that the new model can better describe the rules of impedance dispersion in two-phase flow and is universally applicable, and that the equivalent solution resistance and interfacial polarization frequency have a stable functional relationship with water holdup. Based on the static experimental results, water holdup evaluation models for four flow patterns were established, and the dynamic detection results were predicted. The prediction results show that the new method proposed herein is not affected by changes in salinity and flow pattern when the flow pattern is known, and that its accuracy can meet the production requirements. This study expands the application range of traditional single-frequency conductivity detection techniques and provides a new idea for the development and improvement of systems for online detection of water holdup in two-phase flow. Full article

This study explores the dynamics of liquid holdup in a lab-scale co-current two-phase upflow moving packed bed reactor, specifically examining how superficial gas velocity influences the line average external liquid holdup at a fixed superficial liquid velocity. Utilizing gamma-ray densitometry (GRD) for precise measurements, this research extends to determining line average internal porosity within catalyst particles. Conducted with an air–water system within a bed packed with 3 mm porous particles, the study presents a novel methodology using Beer–Lambert’s law to calculate liquid, gas, and solid holdups and catalyst porosity that is equivalent to the internal liquid holdup that fills the catalyst pores. Findings reveal a decrease in liquid holdup corresponding with increased superficial gas velocity across axial and radial locations, with a notable transition from bubbly to pulse flow regime at a critical velocity of 3.8 cm/sec. Additionally, the lower sections of the packed bed exhibited higher external liquid holdup compared to the middle sections at varied gas velocities. The liquid holdup distribution appeared uniform at lower flow rates, whereas higher flow rates favored the middle sections. Full article

For technical application with continuous operation of sorption-enhanced (SE) reactions, e.g., Fischer–Tropsch, a special reactor concept is required. SE processes are promising due to the negative effects of water on conversion and catalyst. The reactor concept of two interconnected slurry bubble columns combines the reaction with in situ water removal in the first, and sorbent regeneration in the second column with continuous exchange of slurry between the two. The liquid circulation rate (LCR) between the columns is studied in a cold flow model, measured by an ultrasonic sensor. The effects of different operating and geometric parameters, e.g., superficial gas velocity, liquid level and tube diameter on gas holdup and LCR are discussed and modelled via artificial intelligence methods, i.e., extremely randomized trees and neural networks. It was found that the LCR strongly depends on the gas holdup. The maximum of 4.28 L min⁻¹ was reached with the highest exit, widest tube and highest superficial gas velocity of 0.15 m s⁻¹. The influence of liquid level above the exit was marginal but water quality has to be considered. Both models offer predictions of the LCR with errors < 6%. With an extension of the models, particle circulation can be studied in the future. Full article

Experimental data for frictional pressure drop using both air–water and air–oil mixtures are reported, compared and used to evaluate predictive methods. The data were gathered using the 2-inch (54.8 mm) flow loop of the multiphase flow facility at the National University of Singapore. Experiments were carried out over a wide range of flow conditions of superficial liquid and gas velocities that were varied from 0.05 to 1.5 m/s and 2 to 23 m/s, respectively. Pressure drops were measured using pressure transducers and a differential pressure (DP) cell. A hitherto unreported finding was achieved, as the pressure drop in air–oil flow can be lower than that in air–water flow for the higher range of flow conditions. Using flow visualization to explain this phenomenon, it was found that it is related to the higher liquid holdup that occurs in the case of air–oil around the annular flow transition and the resulting interfacial friction. This additional key finding can have applications in flow assurance to improve the efficiency of oil and gas transportation in pipelines. Models and correlations from the open literature were tested against the present data. Full article

Production logging (PL) instruments play a pivotal role in the comprehensive management and monitoring of oil and gas reservoirs. These devices facilitate the resolution of complex flow diagnosis challenges throughout the life cycle of hydrocarbon field exploitation. However, the advent of highly deviated well drilling technology has exposed certain limitations inherent in conventional centralized logging sensing techniques. When fluid flow within horizontal wells becomes segregated or even laminar, these traditional methods struggle to accurately decipher the zonal productions of oil, gas, and water. To address this challenge, multi-array production logging tools were developed in the late 1990s. Historically, these tools were characterized by considerable lengths, reaching up to 30 feet for an entire suite incorporating flow speed and holdup sensors that were not always collocated. Despite the integration of multiple sensors, uncertainties in determining flow profiles persisted. In this paper, we propose a novel integrated multi-parameter evaluation method based on measurements from a recently developed ultracompact flow array sensing tool, aimed at enhancing the accuracy of reservoir evaluation. The validity of the multi-parameter method is substantiated through a comparison of the new tool with an industry benchmark array PL tool on the same well. By combining the monitoring results, an optimization strategy for oil and gas extraction is presented, which is expected to improve the oil and gas recovery rate, thereby providing guidance for subsequent extraction endeavors. Moreover, we demonstrate how this innovative integrated workflow significantly enhances energy savings and efficiency, further underlining its value in modern oil and gas field management. Full article

Bubble columns (BCs) are widely used in the chemical industry. In many industrial applications, these important gas-liquid contactors operate in a churn-turbulent flow regime. In principle, it is essential to determine the operating conditions in every BC reactor, in which local isotropic turbulence is established. In this work, it was demonstrated that several different parameters (Kolmogorov entropy, correlation dimension and novel hybrid index) follow a monotonic decreasing trend. This finding could be explained by the constantly increasing coalesced bubble size, which brings more order into the gas-liquid system and thus any entropic or chaotic parameter should decrease with the increase in the superficial gas velocity U_g. The profiles of the new parameters in various gas-liquid systems were studied. They were extracted from different pressure signals (gauge or absolute). In this research, BCs of different diameter and equipped with different gas distributors were used. It was demonstrated that the studied parameters could be successfully correlated with the length scale of the micro eddies and thus the U_g range of applicability of the local isotropic turbulence theory under various operating conditions was indirectly determined. The overall gas holdup profiles were analyzed and, based on the exponent of the U_g value, it was found that in the aqueous solutions of alcohols studied, the conditions in the bubble bed (BB) are homogeneous, whereas in the air-tap water system aerated in different BCs, the conditions in the BB are heterogeneous. This result implies that the local isotropic turbulence conditions predominate mainly around the corresponding measurement positions. Full article

Liquid-phase dispersion in a continuous flow bubble column was studied using computational fluid dynamics (CFD) and different combinations of turbulence and biphasic models. The results were compared with the experimental data obtained by the stimulus-response method in an air-water pilot-scale bubble column (2 m tall, 0.234 m internal diameter). Two flow combinations were examined: high flow rates of 3.2 m³ h⁻¹ and 4.5 m³ h⁻¹ and low flow rates of 1.98 m³ h⁻¹ and 0.954 m³ h⁻¹ for water and air, respectively. The objective was to evaluate commercial CFD 16.1 software to predict flow behavior beyond macroscale parameters such as hold-up or mixing time. The turbulence models that best replicated the experimental tracer dispersion were large eddy simulation-type models: scale-adaptive simulation (SAS) and shear stress transport-SAS. The simulations qualitatively predicted the tracer concentration with time but were unable to reveal the small-scale perturbations in the biphasic system. The predicted tracer residence time was double or triple the measured times for low and high flow, respectively. Full article
