Search Results (18)

This paper presents a low-voltage, low-power current differencing transconductance amplifier (CDTA) utilizing the bulk-driven MOS transistor technique in the subthreshold region for reduced voltage and power consumption. The proposed CDTA includes a z-copy terminal, which enhances its functionality in current-mode circuit applications. Designed in the Cadence Virtuoso environment using 0.18 µm CMOS technology from Taiwan Semiconductor Manufacturing Company (TSMC), the amplifier operates with a supply voltage of 0.45 V and consumes 328 nW of power, with a bias current set to 10 nA. The current bandwidth and offset of the CDTA are 35 kHz and 0.3 nA, respectively. To demonstrate its performance, the CDTA is applied in a current-mode universal filter, which can realize low-pass, band-pass, high-pass, band-stop, and all-pass responses within a single topology. This design eliminates issues related to inverting input signals, input signal matching, or the need for multiple input signals. Additionally, the natural frequency of these filtering functions can be electronically controlled. The low-pass filter achieves a dynamic range of 61 dB, with a total harmonic distortion of 0.8%. Full article

In this study, we developed a cost-effective and rapid method for fabricating force-sensing resistor (FSR) sensors as an alternative to commercial force sensors. Our aim was to achieve performance characteristics comparable to existing commercial products while significantly reducing costs and fabrication time. We analyzed the material composition of two widely used commercial force sensors: Interlink FSR-402 and Flexiforce A201-1. Based on this analysis, we selected 4B and 9B pencils, which contain high concentrations of graphite, and silicone sealant to replicate these material properties. The fabrication process involved creating piezoresistive sheets by shading A4 copy paper with 4B and 9B pencils to form a uniform layer of graphite. Additionally, we prepared a mixture of 9B pencil lead powder and silicone sealant, ensuring a consistent application on the paper substrate. Measurement results indicated that the force sensor fabricated using a mixture of 9B pencil powder and silicone sealant exhibited electrical and mechanical characteristics closely resembling those of commercial sensors. Load tests revealed that the hand-made sensors provided a proportional voltage output in response to increasing and decreasing loads, similar to commercial FSR sensors. These results suggest that our fabrication method can produce reliable and accurate FSR sensors suitable for various applications, including wearable technology, robotics, and force-sensing interfaces. Overall, this study demonstrates the potential for creating cost-effective and high-performance FSR sensors using readily available materials and simple fabrication techniques. Full article

In this work, an interface circuit applied to resistive gas or chemical sensors is proposed. The interface circuit includes a detection front-end, a single-end to differential circuit, a successive approximation analog-to-digital converter (SAR ADC), and some reference auxiliary circuits. In detection front-end circuits, mirrored currents in a current mirror usually differ by several orders of magnitude. In order to ensure that the current mirror can be copied accurately, this work uses a negative feedback structure consisting of an operational amplifier and an NMOS tube to ensure that the ${\mathrm{V}}_{\mathrm{DS}}$ of the current mirroring tube remains consistent. Simulation results show that the replication error of the current mirror is 0.015%. The proposed interface circuit has a detection range of 10 $\Omega$ to 1 G$\Omega$ with a relative error of 0.55%. The current multiplication or divided technique allows the interface circuit to have a high sampling frequency of up to 10 kHz. The proposed circuit is based on a 180 nm CMOS process with a chip area of 0.308 ${\mathrm{mm}}^2$ (723 $\mathsf{\mu }$m ∗ 426 $\mathsf{\mu }$m). The power consumption of the whole interface circuit is 3.66 mW when the power supply voltage is 1.8 V. Full article

Mitochondria hold redox homeostasis and energy metabolism as a crucial factor during oocyte maturation, while the exposure of estrogenic mycotoxin zearalenone causes developmental incapacity in porcine oocyte. This study aimed to reveal a potential resistance of phytoalexin resveratrol against zearalenone during porcine oocyte maturation and whether its mechanism was related with PTEN-induced kinase 1 (PINK1)/Parkin-mediated mitophagy. Porcine oocytes were exposed to 20 μM zearalenone with or without 2 μM resveratrol during in vitro maturation. As for the results, zearalenone impaired ultrastructure of mitochondria, causing mitochondrial depolarization, oxidative stress, apoptosis and embryonic developmental incapacity, in which mitophagy was induced in response to mitochondrial dysfunction. Phytoalexin resveratrol enhanced mitophagy through PINK1/Parkin in zearalenone-exposed oocytes, manifesting as enhanced mitophagy flux, upregulated PINK1, Parkin, microtubule-associated protein light-chain 3 beta-II (LC3B-II) and downregulated substrates mitofusin 2 (MFN2), voltage-dependent anion channels 1 (VDAC1) and p62 expressions. Resveratrol redressed zearalenone-induced mitochondrial depolarization, oxidative stress and apoptosis, and accelerated mitochondrial DNA copy during maturation, which improved embryonic development. This study offered an antitoxin solution during porcine oocyte maturation and revealed the involvement of PINK1/Parkin-mediated mitophagy, in which resveratrol mitigated zearalenone-induced embryonic developmental incapacity. Full article

The genetic dissection of autism spectrum disorders (ASD) has uncovered the contribution of de novo mutations in many single genes as well as de novo copy number variants. More recent work also suggests a strong contribution from recessively inherited variants, particularly in populations in which consanguineous marriages are common. What is also becoming more apparent is the degree of pleiotropy, whereby mutations in the same gene may have quite different phenotypic and clinical consequences. We performed whole exome sequencing in a group of 115 trios from countries with a high level of consanguineous marriages. In this paper we report genetic and clinical findings on a proband with ASD, who inherited a biallelic truncating pathogenic/likely pathogenic variant in the gene encoding voltage-gated sodium channel X alpha subunit, SCN10A (NM_006514.2:c.937G>T:(p.Gly313*)). The biallelic pathogenic/likely pathogenic variant in this study have different clinical features than heterozygous mutations in the same gene. The study of consanguineous families for autism spectrum disorder is highly valuable. Full article

Electrical Vehicles (EVs) have gained popularity in recent years in the automotive field. They are seen as a way to reduce the CO₂ footprint of vehicles. Although EVs have witnessed significant advancement in recent years, they still have two major setbacks: limited autonomy and long recharging time. Dynamic Inductive Power Transfer (DIPT) systems permit charging EVs while driving, provide unlimited autonomy, and eliminate stationary charging time and lower battery dependency. Multiple transmitters are required to achieve DIPT; thus, dealing with transient phases is essential because every time a receiver crosses over from one transmitter to another, it experiences a new transient phase. This article presents a novel control strategy for multi-transmitter DIPT systems that ensures a continuous and stable power transfer to a moving EV. The proposed control strategy eliminates drop and inrush currents during transient phases. The control integrates a soft start feature and a degraded operating mode at a predefined maximum current value. The studied structure is a symmetrical series–series compensation network. Each transmitter coil is driven by a variable frequency inverter (around 85 kHz) to ensure Zero Phase Angle mode. The control strategy was numerically validated using MATLAB Simulink and then tested experimentally. Results show a relatively low power disruption after applying the proposed control during transmitter sequencing. Full article

Nav1.5 is the pore forming α-subunit of the cardiac voltage-gated sodium channel that initiates cardiac action potential and regulates the human heartbeat. A normal level of Nav1.5 is crucial to cardiac function and health. Over- or under-expression of Nav1.5 can cause various cardiac diseases ranging from short PR intervals to Brugada syndromes. An assay that can directly quantify the protein amount in biological samples would be a priori to accurately diagnose and treat Nav1.5-associated cardiac diseases. Due to its large size (>200 KD), multipass transmembrane domains (24 transmembrane passes), and heavy modifications, Nav1.5 poses special quantitation challenges. To date, only the relative quantities of this protein have been measured in biological samples. Here, we describe the first targeted and mass spectrometry (MS)-based quantitative assay that can provide the copy numbers of Nav1.5 in cells with a well-defined lower limit of quantification (LLOQ) and precision. Applying the developed assay, we successfully quantified transiently expressed Nav1.5 in as few as 1.5 million Chinese hamster ovary (CHO) cells. The obtained quantity was 3 ± 2 fmol on the column and 3 ± 2 × 10⁴ copies/cell. To our knowledge, this is the first absolute quantity of Nav1.5 measured in a biological sample. Full article

This paper presents a high-frequency pulse-density-modulated (PDM) soft-switching series load resonant inverter for use in induction heating (IH) fixed roller applications, which is used in copy and printing machines. The proposed simple high-frequency resonant inverter uses an asymmetrical pulse pattern PDM control scheme to achieve complete zero-current soft-switching commutations over a wide output range of input power regulation. Additionally, when the printer toner requires operation in very light load conditions, this causes difficulty in achieving zero-voltage or zero-current soft-switching operations in the IH high-frequency resonant inverters with pulse frequency modulation or pulse width modulation control schemes. The proposed resonant inverter demonstrates the capability to accomplish highly efficient power conversions. In this work, a fixed roller for printing machines is developed for doing experiments to verify the efficiency of the proposed circuit topology and its PDM control schemes. The inverter’s steady-state and transient operating principles are analyzed based on the proposed control strategy at a high-frequency PDM. Operating conditions such as power loss analysis, power conversion efficiency and temperature rise characteristics of the proposed inverter are presented and analyzed through experimental results. Finally, from a practical viewpoint, a comparative study of a conventional halogen lamp heater and the proposed IH fixed roller is deliberated. Full article

Copy number variation (CNV) can affect gene function and even individual phenotypic traits by changing the transcription and translation level of related genes, and it also plays an important role in species evolution. Chloride voltage-gated channel 2 (CLCN2) encodes a voltage-gated chloride channel (CLC-2), which has a wide organ distribution and is ubiquitously expressed. Based on previous studies, we hypothesize that CLCN2 could be a candidate gene involved in cell volume regulation, transepithelial transport and cell proliferation. This study aimed to explore CNVs in the CLCN2 gene and investigate its association with growth traits in four Chinese cattle breeds (Yunling cattle, Xianan cattle, Qinchuan cattle and Pinan cattle). We identified there are two copy number variation regions (CNV1: 3600 bp, including exon 2–11; CNV2: 4800 bp, including exon 21–22) of the CLCN2 gene. The statistical analysis showed that the CNV1 mutation in the YL cattle population was significantly associated with cannon circumference (p < 0.01). The CNV2 mutation in the XN cattle population had a significant effect on body slanting length, chest girth and body weight (p < 0.05). In the YL cattle, the association analysis of CLCN2 gene CNV1 and CNV2 combination with cannon circumference was significant (p < 0.01). Our results provide evidence that CNV1 and CNV2 in CLCN2 are associated with growth traits in two different cattle populations and could be used as candidate markers for cattle molecular breeding. Full article

Optogenetic switches allow light-controlled gene expression with reversible and spatiotemporal resolution. In Saccharomyces cerevisiae, optogenetic tools hold great potential for a variety of metabolic engineering and biotechnology applications. In this work, we report on the modular optimization of the fungal light–oxygen–voltage (FUN-LOV) system, an optogenetic switch based on photoreceptors from the fungus Neurospora crassa. We also describe new switch variants obtained by replacing the Gal4 DNA-binding domain (DBD) of FUN-LOV with nine different DBDs from yeast transcription factors of the zinc cluster family. Among the tested modules, the variant carrying the Hap1p DBD, which we call “HAP-LOV”, displayed higher levels of luciferase expression upon induction compared to FUN-LOV. Further, the combination of the Hap1p DBD with either p65 or VP16 activation domains also resulted in higher levels of reporter expression compared to the original switch. Finally, we assessed the effects of the plasmid copy number and promoter strength controlling the expression of the FUN-LOV and HAP-LOV components, and observed that when low-copy plasmids and strong promoters were used, a stronger response was achieved in both systems. Altogether, we describe a new set of blue-light optogenetic switches carrying different protein modules, which expands the available suite of optogenetic tools in yeast and can additionally be applied to other systems. Full article

In most high power industrial applications, the low switching frequency modulations (LSFM) are usually implemented to reduce power loss and heat dissipation pressure. However, there are some unexpected influences caused by the low order harmonic sinusoidal pulse width modulation (SPWM), such as the imbalanced submodule power in cascaded half-bridge inverter (CHB) and limited output power capability in H-bridge neutral-point-clamped (HNPC) converter. This paper starts by generalizing the basic characteristic of two-level SPWM, then deeply investigates the influences of low-frequency modulation on the operation of the circuits. They are classified into three mechanisms and generally named as harmonic overlap effect (HOE). The corresponding solutions to copy with the mechanisms are proposed and verified in some topologies through high-power simulations in simulations. In addition, a comprehensive summary of the influences and solutions of these effects on typical high power converters is drawn. The design rules of the modulation schemes for multilevel voltage source converters (VSCs) at low switching frequency are also proposed. Full article

Autism spectrum disorders (ASDs) are a group of neurodevelopmental disorders with high heritability, although their underlying genetic factors are still largely unknown. Here we present a comprehensive genetic characterization of two ASD siblings from Sardinia by genome-wide copy number variation analysis and whole exome sequencing (WES), to identify novel genetic alterations associated with this disorder. Single nucleotide polymorphism (SNP) array data revealed a rare microdeletion involving CAPG, ELMOD3, and SH2D6 genes, in both siblings. CAPG encodes for a postsynaptic density (PSD) protein known to regulate spine morphogenesis and synaptic formation. The reduced CAPG mRNA and protein expression levels in ASD patients, in the presence of hemizygosity or a particular genetic and/or epigenetic background, highlighted the functional relevance of CAPG as a candidate gene for ASD. WES analysis led to the identification in both affected siblings of a rare frameshift mutation in VDAC3, a gene intolerant to loss of function mutation, encoding for a voltage-dependent anion channel localized on PSD. Moreover, four missense damaging variants were identified in genes intolerant to loss of function variation encoding for PSD proteins: PLXNA2, KCTD16, ARHGAP21, and SLC4A1. This study identifies CAPG and VDAC3 as candidate genes and provides additional support for genes encoding PSD proteins in ASD susceptibility. Full article

This paper presents an improvement of the capacitive emulation (CE) method to reduce the line current distortion caused by grid-tied LCL-filtered converters. In these cases, the grid voltage is applied to the LCL’s capacitor, which generates a distorted capacitor current that pollutes the line. The CE method consists in controlling the converter currents instead of the grid currents, while the converter generates a copy of the distorted capacitor current, so that both the copy and the distorted currents cancel each other in the grid. Therefore, we can say that the converter emulates a negative capacitance connected to the grid, while at the same time delivers its active and reactive powers at the fundamental frequency. The CE method is achieved by adding an estimation of the distorted capacitor current to the converter current reference. However, an effective capacitive emulation requires a current control capable of accurately tracking all harmonics added to the current reference. In this sense, this paper proposes the use of a new integral predictive current control (IPCC), a dead-beat type of control that ensures a constant closed-loop group delay in a wide bandwidth. Unlike a PI control where the closed-loop delay varies with the frequency of the tracked harmonic, the constant control delay of the IPCC can be effectively compensated with a buffer-based advanced current reference. The effectiveness of the proposed CE method with IPCC control to reduce the total harmonic distortion (THD) of the line currents has been proved experimentally on a 10 kVA transformerless grid-connected three-phase inverter. Full article

Photoanodes fabricated by the electrophoretic deposition of a thermally prepared zinc tantalum oxynitride (ZnTaO₂N) catalyst onto indium tin oxide (ITO) substrates show photoactivation for the oxygen evolution reaction (OER) in alkaline solutions. The photoactivity of the OER is further boosted by the photodeposition of cobalt phosphate (CoPi) layers onto the surface of the ZnTaO₂N photoanodes. Structural, morphological, and photoelectrochemical (PEC) properties of the modified ZnTaO₂N photoanodes are studied using X-ray diffraction (XRD), scanning electron microscopy (SEM), ultraviolet visible (UV−Vis) diffuse reflectance spectroscopy, and electrochemical techniques. The presence of the CoPi layer significantly improved the PEC performance of water oxidation in an alkaline sulphate solution. The photocurrent-voltage behavior of the CoPi-modified ZnTaO₂N anodes was improved, with the influence being more prominent at lower oxidation potentials. A stable photocurrent density of about 2.3 mA·cm⁻² at 1.23 V vs. RHE was attained upon visible light illumination. Relative to the ZnTaO₂N photoanodes, an almost three-fold photocurrent increase was achieved at the CoPi/ZnTaO₂N photoelectrode. Perovskite-based oxynitrides are modified using an oxygen-evolution co-catalyst of CoPi, and provide a new dimension for enhancing the photoactivity of oxygen evolution in solar-assisted water-splitting reactions. Full article

The magnitude of the information content associated with a particular implementation of a Physical Unclonable Function (PUF) is critically important for security and trust in emerging Internet of Things (IoT) applications. Authentication, in particular, requires the PUF to produce a very large number of challenge-response-pairs (CRPs) and, of even greater importance, requires the PUF to be resistant to adversarial attacks that attempt to model and clone the PUF (model-building attacks). Entropy is critically important to the model-building resistance of the PUF. A variety of metrics have been proposed for reporting Entropy, each measuring the randomness of information embedded within PUF-generated bitstrings. In this paper, we report the Entropy, MinEntropy, conditional MinEntropy, Interchip hamming distance and National Institute of Standards and Technology (NIST) statistical test results using bitstrings generated by a Hardware-Embedded Delay PUF called HELP. The bitstrings are generated from data collected in hardware experiments on 500 copies of HELP implemented on a set of Xilinx Zynq 7020 SoC Field Programmable Gate Arrays (FPGAs) subjected to industrial-level temperature and voltage conditions. Special test cases are constructed which purposely create worst case correlations for bitstring generation. Our results show that the processes proposed within HELP to generate bitstrings add significantly to their Entropy, and show that classical re-use of PUF components, e.g., path delays, does not result in large Entropy losses commonly reported for other PUF architectures. Full article
