Search Results (18)

This study examined bubbling fluidized beds as an alternative to fixed-bed dry scrubbers on ships for reducing pollutants from marine fuels. It focused on overcoming the challenges of gas maldistribution/slug formation, especially under rough sea conditions. This research departed from traditional methods by introducing mobile internal elements into the bed emulsion phase and investigating their effectiveness in various settings, such as vertical, inclined, and rolling beds. A specialized hexapod-driven bubbling fluidized bed was developed to mimic marine operating conditions and to study the behavior of shipboard fluidized beds. Techniques such as digital image analysis (DIA) and particle image velocimetry (PIV) were used to observe bubble dynamics and granular phases, measuring local void fractions and particle velocities. A key finding is the effectiveness of moving internals in preventing bubble coalescence, which is critical for avoiding wall slugs, at different inclinations. Three types of packing were used as mobile internals: Super Raschig, Pall, and square rings. Super Raschig rings, which are characterized by high porosity, were the most efficient in reducing bubble coalescence, making them a preferred choice for offshore fluidized bed applications. This research contributes to the advancement of fluidized bed technology in marine applications and provides insight for future improvements. Full article

With the ever-increasing role that nuclear power is playing to meet the aim of net zero carbon emissions, there is an intensified demand for understanding the thermal hydraulic phenomena at the heart of current and future reactor concepts. In response to this demand, the development of high-resolution flow analysis instrumentation is of increased importance. One such under-utilised and under-researched instrumentation technology, in the context of fluid flow analysis, is fibre Bragg grating (FBG)-based sensors. This technology allows for the construction of simple, minimally invasive instruments that are resistant to high temperatures, high pressures and corrosion, while being adaptable to measure a wide range of fluid properties, including temperature, pressure, refractive index, chemical concentration, flow rate and void fraction—even in opaque media. Furthermore, concertinaing FBG arrays have been developed capable of reconstructing 3D images of large phase structures, such as bubbles in slug flow, that interact with the array. Currently a significantly under-explored application, FBG-based instrumentation thus shows great potential for utilisation in experimental thermal hydraulics; expanding the available flow characterisation and imaging technologies. Therefore, this paper will present an overview of current FBG-based flow characterisation technologies, alongside a systematic review of how these techniques have been utilised in nuclear thermal hydraulics experiments. Finally, a discussion will be presented regarding how these techniques can be further developed and used in nuclear research. Full article

There are many petrochemical industries that need adequate knowledge of multiphase flow phenomena inside pipes. In such industries, measuring the void fraction is considered to be a very challenging task. Thus, various techniques have been used for void fraction measurements. For determining more accurate multiphase flow measurements, this study employed dual non-intrusive techniques, gamma-ray and electrical capacitance sensors. The techniques using such sensors are considered non-intrusive as they do not cause any perturbation of the local structure of the phases’ flow. The first aim of this paper is to analyze both techniques separately for the void fraction data obtained from practical experiments. The second aim is to use both techniques’ data in a neural network model to analyze measurements more efficiently. Accordingly, a new system is configured to combine the two techniques’ data to obtain more precise results than they can individually. The simulations and analyzing procedures were performed using MATLAB. The model shows that using gamma-ray and capacitance-based sensors gives Mean Absolute Errors (MAE) of 3.8% and 2.6%, respectively, while using both techniques gives a lower MAE that is nearly 1%. Consequently, measurements using two techniques have the ability to enhance the multiphase flows’ observation with more accurate features. Such a hybrid measurement system is proposed to be a forward step toward an adaptive observation system within related applications of multiphase flows. Full article

The deposited particulate material within a fibrous filter affects the pressure drop which develops through three different stages. The implementation of a time-adjustable matrix is intended to cause detachment of particle structures from fibers within the upstream layers at low flow velocities. The deposited particle structures are transported further within the filter and clear up void space for an extension of filter service life. As in previous studies observed fiber stretching initiate cracks and following detachment of particle structures with a simultaneously applied airflow. For complete detachment of the particle structure, five consecutive stretching cycles are performed in this study. The elongation velocity, the flow velocity and the particle loading are varied. Using an image analysis technique and a laser-light measurement technique simultaneously, the cumulative fraction of detached particle structures and the size of detached particle structures are determined. A high initial particle loading on the fiber induces early detachment of larger structures from the fiber. The size of detached structures is increased by the increase of the elongation velocity. The mean value remains almost constant whether the elongation velocity or superficial velocity are increased. For small initial structures on the fiber, a decrease in superficial velocity causes detachment of larger particle fragments. Full article

In this study, a technique that uses a capacitance sensor with an asymmetric electrode to measure the void fraction of a refrigerant was developed. It is known that the void fraction and flow pattern affect the measured capacitance. Therefore, the relationship between the void fraction and capacitance is not linear; hence, a calibration method for obtaining accurate measurements is necessary. A calibration method was designed in this study based on repeated capacitance measurements and the bimodal temporal distribution to calibrate the atypical and repetitive flow patterns of slug flow and its transition to the intermittent flow regime. The calibration method also considers the weighted-average relation for the gradual transition of the intermittent to annular flow pattern according to the change from low to high quality. The proposed method was experimentally analyzed under the conditions of R32 refrigerant, a tube inner diameter of 7.1 mm, saturation temperature of 25 °C, mass flux of 100–400 kg m⁻² s⁻¹, and vapor quality of 0.025–0.900, and it was validated using a quick-closing valve (QCV) system under identical conditions. A relative error of 2.99% was obtained for the entire system, indicating good agreement between the proposed and QCV-based methods. Full article

The paper presents a novel twofold use of the photographic technique for flow boiling heat transfer investigation in the horizontal mini-channel. The dedicated measurement system was constructed to record basic thermal and flow parameters, i.e., boiling liquid inlet and outlet temperatures and pressures, and also temperatures inside the heating block to calculate heat flux going into the liquid. A high-speed video camera equipped with synchronous movement system was applied to combine the recording of two-phase flow images with simultaneous local void fraction measurements both based on the same photographic data set. The data were collected, managed, and refined with the scripts developed in the MathWorks Matlab 2019b environment. The synchronous use of two intelligent techniques in the scripts, i.e., the background subtraction technique and the statistical analysis of individual pictures allowed obtaining reliable experimental results. The proposed method of the void fraction determination ensures high measurement accuracy. Full article

Gas–liquid two-phase flow is widely used in many engineering fields, and bubble dynamics is of vital importance in optimizing the engineering design and operating parameters of various adsorptive bubble systems. The characteristics of gas–liquid two-phase (e.g., bubble size, shape, velocity, and trajectory) remain of interest because they give insight into the dynamics of the system. Bubble plumes are a transport phenomenon caused by the buoyancy of bubbles and are capable of generating large-scale convection. The surface flow generated by bubble plumes has been proposed to collect surface-floating substances (in particular, oil layers formed during large oil spills) to protect marine systems, rivers, and lakes. Furthermore, the surface flows generated by bubble plumes are important in various types of reactors, engineering processes, and industrial processes involving a free surface. The bubble parameters play an important role in generating the surface flow and eventually improving the flow performance. This paper studies the effects of temperature on bubble parameters and bubble motion to better understand the relationship between the various bubble parameters that control bubble motion and how they impact the formation of surface flow, with the ultimate goal of improving the efficiency of the generation of surface flow (i.e., rapidly generate a strong, high, and wide surface flow over the bubble-generation system), and to control the parameters of the surface flow, such as thickness, width, and velocity. Such flow depends on the gas flow rate, bubble size (mean bubble diameter), void fraction, bubble velocity, the distance between bubble generator and free surface (i.e., water height), and water temperature. The experiments were carried out to measure bubble parameters in a water column using the image visualization technique to determine their inter-relationships and improve the characteristics of surface flow. The data were obtained by processing visualized images of bubble flow structure for the different sections of the bubble regions, and the results confirm that temperature, bubble size, and gas flow rate significantly affect the flow structure and bubble parameters. Full article

Void fraction is one of the most important parameters for the modeling and characterization of two-phase flows. This manuscript presents an overview of void fraction measurement techniques, experimental databases and correlations, in the context of microchannel two-phase flow applications. Void fraction measurement techniques were reviewed and the most suitable techniques for microscale measurements were identified along its main characteristics. An updated void fraction experimental database for small channel diameter was obtained including micro and macrochannel two-phase flow data points. These data have channel diameter ranging from 0.5 to 13.84 mm, horizontal and vertical directions, and fluids such as air-water, R410a, R404a, R134a, R290, R12 and R22 for both diabatic and adiabatic conditions. New published void fraction correlations as well high cited ones were evaluated and compared to this small-diameter void fraction database in order to quantify the prediction error of them. Moreover, a new drift flux correlation for microchannels was also developed, showing that further improvement of available correlations is still possible. The new correlation was able to predict the microchannel database with mean absolute relative error of 9.8%, for 6% of relative improvement compared to the second-best ranked correlation for small diameter channels. Full article

A multiphase flow measurement technique plays a critical role in the studies of heat and mass transfer characteristics and mechanism of the gas–liquid two-phase, the practical measurement of the gas–liquid flow and the improvement of multiphase theoretical models. The four-sensor electrical probe as an emerging measurement method has been proved to be able to get the local flow parameters of multi-dimensional two-phase flow. However, few studies have been reported using the four-sensor probe to obtain the interface information (e.g., the interface direction and velocity). This paper presents a new signal processing method by which the interface direction and velocity can be obtained, besides void fraction, interfacial area concentration (IAC) and bubble chord length. The key solution is to employ the vector-based calculating method, which possesses the merits of simplicity and efficiency, to gain the interface velocity vector through legitimately assuming a direction of the interface velocity. A miniaturized four-sensor electrical probe was made and a gas–liquid two-phase flow experiment was performed to test the proposed signal process scheme. The two-phase flow was controlled to be in cap-bubble flow regime. To validate the availability and reliability of the proposed method, the local flow parameters obtained by the probe measurement were compared with the results from visual measurement technique in the same flow conditions. The comparison indicates that the above local flow parameters from four-sensor probe measurement are in good agreement with the visual measurement results, with maximum deviations of chord length of 8.7%, thereby proving the correctness of the proposed method. Full article

Fused filament fabrication (FFF) is one of the most popular additive manufacturing (AM) techniques used to fabricate polymeric structures. However, these polymeric structures suffer from an inherent deficiency of weak inter-laminar tensile strength. Because of this weak inter-laminar strength, these parts fail prematurely and exhibit only a fraction of the mechanical properties of those fabricated using conventional means. In this paper, we study the effect of thermal annealing in the presence of an initially applied static uniaxial load on the ultimate tensile strength of parts fabricated using FFF. Tensile specimens or dogbones were fabricated from an acrylonitrile butadiene styrene (ABS) filament with a glass transition temperature (T_g) of 105 °C; these specimens were then isothermally annealed, post manufacture, in a fixture across a given range of temperatures and static loads. Tensile testing was then performed on these specimens to gauge the effect of the thermal annealing and static loading on inter-laminar tensile strength by measuring the ultimate tensile strength of the specimens. A design of experiments (DOE) approach was followed to calculate the main and interaction effects of the two factors (temperature and static loading) on the ultimate tensile strength, and an analysis of variance was conducted. Cross-sectional images of the specimens were studied to observe the changes in the mesostructure of the specimens that led to the increase in inter-laminar strength of the parts. The results show that temperature plays a dominant role in increasing the ultimate tensile strength and an 89% increase in the average ultimate tensile strength was seen corresponding to an annealing temperature of 160 °C. A change in the mesostructure of the parts is seen, which is characterized by an increase in bond length and void coalescence. These results can be helpful in studying the structural strength of 3D printed parts, and thus could eventually guide the fabrication of components with strength comparable to those of conventional manufacturing techniques. Full article

Small angle neutron scattering (SANS) with contrast variation was used to characterize the fractal behavior and embedded porosity of micro/nano-sized 1,3,5-triamino-2,4,6-trinitrobenzene (TATB) crystallites, gauging the effects of particle sizes on the microstructural features. Scattering results reveal that the external surface of micro-sized TATB crystallites are continuous and smooth interfaces and their internal pores display a surface fractal structure (surface fractal dimension 2.15 < D_S < 2.25), while the external surface of nano-sized TATB particles exhibit a surface fractal structure (surface fractal dimension 2.36 < D_S < 2.55) and their internal pores show a two-level volume fractal structure (large voids consist of small voids). The voids volume fraction of nano-sized TATB particles are found increased distinctively when compared with micro-sized TATB particles on length scale between 1 nm and 100 nm. Specific surface areas are also estimated based on Porod law method, which are coincident with Brunauer-Emmett-Teller (BET) measurements. The contrast variation technique distinguishes the information of internal voids from external surface, suggesting SANS is a powerful tool for determining the microstructural features, which can be used to establish the relationship between microstructures and properties of micro/nano-energetic materials. Full article

The carbon capture and storage (CCS) system has the potential to reduce CO₂ emissions from traditional energy industries. In order to monitor and control the CCS process, it is essential to achieve an accurate measurement of the gas void fraction in a two-phase CO₂ flow in transportation pipelines. This paper presents a novel instrumentation system based on the laser attenuation technique for the gas void fraction measurement of the two-phase CO₂ flow. The system includes an infrared laser source and a photodiode sensor array. Experiments were conducted on the horizontal and vertical test sections. Two Coriolis mass flowmeters are respectively installed on the single-phase pipelines to obtain the reference gas void fraction. The experimental results obtained show that the proposed method is effective. In the horizontal test section, the relative errors of the stratified flow are within ±8.3%, while those of the bubble flow are within ±10.6%. In the vertical test section, the proposed method performs slightly less well, with relative errors under ±12.2%. The obtained results show that the measurement system is capable of providing an accurate measurement of the gas void fraction of the two-phase CO₂ flow and a useful reference for other industrial applications. Full article

Copper-based alloy (C93200) composites reinforced with a different weight percentage of marble dust particles (1.5, 3, 4.5, and 6 wt.%) were developed by stir casting method under vacuum environment. By using this type of reinforcement, it was possible to detect a suitable material for bearing applications. The manufactured material was characterized for its mechanical properties using a micro-hardness tester. A universal INSTRON-5967 machine was used to detect the yield and tensile strength. Further the hardness features were measured using a Walter Uhl model machine, whereby the wear characteristics were simulated under the pin-on-disc tribometer under different working conditions in ambient temperature (23 °C). Next, the preference selection index (PSI) technique that considers multi-criteria decision-making was proposed to validate which material was the best candidate. For the selection of material criteria, some specific material intrinsic properties—such as, density, void fraction, hardness resistance along with tensile, compressive, and flexural strength—were proposed and the surface characteristics linked to friction coefficients along wear properties. It was found that the novel composite material containing 4.5 wt.% of marble dust provided the best combination of properties and is a suitable candidate material for bearing applications. Full article

This study introduces a measurement technique for simultaneous phase-separated velocity in two-phase bubbly flow. The non-invasive technique, based on an Ultrasonic Velocity Profiler (UVP), is used in order to obtain an instantaneous, separate velocity profile for both liquid and bubble. The aim of this paper is to measure each phase velocity at the same time and position it using only a single resonant frequency. To achieve this aim, extended signal processing of the Short-Time Fourier Transform (STFT) is proposed, combining with amplitude classification to analyze Doppler signal influenced from the bubbly flow. The use of developed algorithms allows the instantaneous separation of liquid and bubble velocity profiles. In this work, the developed technique is used to measure the velocity profile of bubbly flow in the vertical pipe, demonstrating the classification of liquid and bubble velocity. To confirm the accuracy of each velocity profile phase, the Particle Image Velocimetry (PIV) method is used for comparison. The results clarify that the proposed method is in good agreement with the PIV measurement. Finally, the effect of void fraction against velocity measurement of both phases was demonstrated. Full article

Bubbly flows are commonly used in various applications and their measurement is an important research topic. The ultrasound pulse-echo technique allows for the detection of each bubble and the measurement of the position of its surface. However, so far it has been used only to measure single bubbles. This paper investigates whether the pulse-echo technique can be applied for measuring multiple bubbles concurrently. The ultrasonic transducer wavelength and diameter were selected based on expected bubble diameters so that each bubble produced a strong reflection. The pulse-echo was implemented to obtain good accuracy without sacrificing the signal processing speed. A tracking technique was developed for the purpose of connecting detected reflections to trajectories. The technique was tested experimentally by measuring the horizontal position of rising air bubbles in a water tank. The results show that the pulse-echo technique can detect multiple bubbles concurrently. The pulse-echo technique detected almost the same number of bubbles as a high-speed video. For average void fractions up to around $1\%$ (and instantaneous void fraction reaching $5.3\%$ ), the rate of bubbles missed by the pulse-echo and the rate of noise trajectories both stayed less than 5%. The error rate increased with the void fraction, limiting the technique’s application range. Full article
